Sunroof: Overview Mazda 5 I рестайлинг

Scheme 1

Scheme 2

1. Fully open the glass panel.
2. Unhook and remove the deflector.
3. Install in the reverse order of removal.

Scheme 3

Scheme 4

1. Fully close the glass panel.
2. Fully open the sunshade.
3. Remove the screws, and then remove the glass panel.
4. Peel the weatherstrip off the glass panel.
5. Install in the reverse order of removal.
6. Adjust the glass panel. (See «GLASS PANEL ADJUSTMENT».)

Scheme 5

Scheme 6

1. Fully close the glass panel.
2. Measure the gap and height difference between the glass panel and the body.
3. Loosen the glass panel installation screws and move the glass panel to adjust. Standard clearance a: -2.7-0 mm {-0.11-0 in} b: 0 mm {0 in}
4. Tighten the screws.
5. Insert any available thin plastic card between the weatherstrip and the body, and verify that they are sealed. (There is resistance when the plastic card is moved.) If they are not sealed, perform Steps 3-4 and adjust again.

Scheme 7

1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]» )
2. Disconnect the negative battery cable.
3. Remove the following parts: A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION».) Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION».) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION».) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION».) Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION».) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION».) Rear package tray lid (See «REAR PACKAGE TRAY LID REMOVAL/INSTALLATION».) Sub-trunk Third-row seat (See «THIRD-ROW SEAT REMOVAL/INSTALLATION».) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION».) Rear header trim (See «REAR HEADER TRIM REMOVAL/INSTALLATION».) Third-row seat belt lower anchor installation bolt (See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION».) Cargo compartment light (See «CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION».) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION».) Second-row seat belt upper anchor installation bolt (See «SECOND-ROW SEAT BELT REMOVAL/INSTALLATION».) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION».) Map light (See «MAP LIGHT REMOVAL/INSTALLATION».) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION».) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION».) Seaming welt Headliner (See «HEADLINER REMOVAL/INSTALLATION».) Shock absorbing pad (See «SHOCK ABSORBING PAD REMOVAL/INSTALLATION».) Glass panel (See «GLASS PANEL REMOVAL/INSTALLATION».)
4. Disconnect the front and rear drain hoses from the sunroof frame.
5. Disconnect the sunroof motor connector.
6. Disconnect the intruder sensor connector. (Vehicles with the theft-deterrent system)
7. Remove the screw and nuts, then remove the sunroof unit.
8. Install in the reverse order of removal.
9. Adjust the glass panel. (See «GLASS PANEL ADJUSTMENT».)

Scheme 8

1. Disassemble in the order indicated in the table.
2. Assemble in the reverse order of disassembly.

Note. If the guide is removed, the sunroof motor initial position setting has to be performed. After installing the sunroof unit, perform the initial position setting using the following procedure.

1. Press the close switch to fully close the glass panel.
2. Release the close switch with the glass panel in the fully closed position, and press the close switch again until the motor performs the position learning operation. The position learning operation can be confirmed by visual check of the glass panel or motor operation sound (clickety-clack). NOTE: The position learning operation is regarded as the operation the motor operates to move the glass panel forward and backward several millimeters then stops. The motor may operate after approx. 13 s from where the switch has been pressed and held. If the switch is released during the position learning operation, resume from the beginning of Step 2.
3. Press and hold the close switch again within 5 s after the position learning operation was performed. NOTE: If the switch is not pressed within 5 s after the position learning operation, resume from the beginning of Step 2.
4. The glass panel fully opens and returns to the fully closed position and stops, then release the close switch. NOTE: If the switch is released while the glass panel is operating, resume from the beginning of Step 1.

Scheme 9

1. Insert a hand to the back side of the sunroof frame, raise the decoration link lock and remove it.
2. Slide the guide to the rear of the sunroof frame, and remove the guide and decoration link as a single unit.

Scheme 10

Scheme 11

1. Move the pin to the position shown in the figure.
2. Set the guide pin to the decoration link.

Scheme 12

1. Remove the following parts: Front door (See «FRONT DOOR REMOVAL/INSTALLATION».) Sail garnish (See «SAIL GARNISH REMOVAL/INSTALLATION»(/mazda/5/i-2007-2010/remont/exteriorinterior-trim/#exterior-trim).) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION».) Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION».) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION».) B-pillar lower trim (See «&PILLAR LOWER TRIM REMOVAL/INSTALLATION».) Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION».) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION».) Rear package tray lid (See «REAR PACKAGE TRAY LID REMOVAL/INSTALLATION».) Sub-trunk Third-row seat (See «THIRD-ROW SEAT REMOVAL/INSTALLATION».) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION».) Rear header trim (See «REAR HEADER TRIM REMOVAL/INSTALLATION».) Third-row seat belt lower anchor installation bolt (See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION».) Cargo compartment light (See «CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION».) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION».) Second-row seat belt upper anchor installation bolt (See «SECOND-ROW SEAT BELT REMOVAL/INSTALLATION».) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION».) Map light (See «MAP LIGHT REMOVAL/INSTALLATION».) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION».) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION».) Headliner (See «HEADLINER REMOVAL/INSTALLATION».) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION».) Side panel (passenger's side) (See «SIDE PANEL REMOVAL/INSTALLATION».) Side wall (See «SIDE WALL REMOVAL/INSTALLATION».) Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION».) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION».) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION».) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION».) Center panel unit (See «CENTER PANEL REMOVAL/INSTALLATION».) Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]».) (See «CLIMATE CONTROL UNIT REMOVAL [MANUAL AIR CONDITIONER]».) (See «CLIMATE CONTROL UNIT INSTALLATION [MANUAL AIR CONDITIONER]».) Car-navigation unit (vehicles with car-navigation system) (See «CAR-NAVIGATION UNIT REMOVAL/INSTALLATION».) Selector lever component (See «SELECTOR LEVER COMPONENT REMOVAL/INSTALLATION»(/mazda/5/i-2007-2010/remont/automatic-trans/#automatic-transaxle-shift-mechanism).) Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION».) Meter hood (See «METER HOOD REMOVAL/INSTALLATION».) Lower column cover (See «COLUMN COVER REMOVAL/INSTALLATION».) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION».) Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION».) Rear heat duct (1) (See «REAR HEAT DUCT REMOVAL/INSTALLATION».) Windshield wiper arm and blade (See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION».) Cowl grille (See «COWL GRILLE REMOVAL/INSTALLATION»(/mazda/5/i-2007-2010/remont/exteriorinterior-trim/#exterior-trim).) Dashboard (See «DASHBOARD REMOVAL/INSTALLATION».)
2. Disconnect the front drain hose from the sunroof frame.
3. Remove the front drain hose from the clips.
4. Pull the front drain hose into the vehicle interior and remove the front drain hose.
