FRONT SEAT DISASSEMBLY/ASSEMBLY

WARNINGHandling the front seat (side air bag, seat weight sensor) improperly can accidentally deploy the side air bag, which may seriously injure you. Read the service warnings and cautions before handling the air bag module. (See AIR BAG SYSTEM SERVICE WARNINGS .) (See AIR BAG SYSTEM SERVICE CAUTIONS .)
CAUTIONFor vehicles with the two-step deployment air bag system, if any of the following work is performed, perform the seat weight sensor calibration using the M-MDS. (See SEAT WEIGHT SENSOR CALIBRATION .) Replacement with a new seat weight sensor Replacement with a new seat weight sensor control module Replacement with new passenger-side seat parts Disassembly of the passenger-side seat For vehicles with the two-step deployment air bag system, if any of the following work is performed, perform the seat weight sensor inspection using the M-MDS. (See SEAT WEIGHT SENSOR INSPECTION .) Removal of the passenger-side seat Loosening and retightening of passenger's seat fixing bolts
  1. Disassemble in the order indicated in the table.
  2. Assemble in the reverse order of disassembly.

Scheme 11

Scheme 11: Driver's Seat

Scheme 12

Scheme 12: Passenger's Seat

Scheme 13

Scheme 13: SECOND-ROW SEAT REMOVAL/INSTALLATION
  1. Remove the covers.
  2. Remove the bolts, then remove the second-row seat.
  3. Install in the reverse order of removal.

Scheme 14

Scheme 14: Driver's Side
  1. Disassemble in the order indicated in the table.
  2. Assemble in the reverse order of disassembly.

Scheme 15

Scheme 15: Passenger's Side
  1. Disassemble in the order indicated in the table.
  2. Assemble in the reverse order of disassembly.

Scheme 16

Scheme 16: Recliner Lever Removal Note

Scheme 17

Scheme 17

Scheme 18

Scheme 18

Scheme 19

Scheme 19

Scheme 20

Scheme 20

Scheme 21

Scheme 21

Scheme 22

Scheme 22
  1. Raise the seat cushion.
  2. Lay the seat on its side with the recliner lever facing upward.
  3. While pushing the recliner lever in the direction of the arrow, remove the screw.
  4. Remove the side cover clips from the seat cushion frame using the fastener remover.
  5. Put the seat in the Step 1 condition.
  6. Remove the recliner lever clip using the following procedure. CAUTION: Perform the following procedures while keeping the side cover lifted. The side cover may be damaged when it is lifted up. Insert a hand into the position indicated in the figure and lift the side cover in the direction of the arrow. Insert a tape-wrapped flathead screwdriver. Remove the clip which is attached to the recliner lever by pressing it in the direction of the arrow.
  7. Remove the recliner lever.

Scheme 23

Scheme 23: Recliner Lever Clip Installation Note
  1. Install the clip to the recliner lever as shown in the figure.

Scheme 24

Scheme 24: THIRD-ROW SEAT REMOVAL/INSTALLATION
  1. Remove the rear package tray lid. (See «REAR PACKAGE TRAY LID REMOVAL/INSTALLATION»(ref-292888-S11741306112008080600000) .)
  2. Remove the floor covering installation fasteners. (See «FLOOR COVERING REMOVAL/INSTALLATION»(ref-292888-S12180065472008080600000) .)
  3. Remove the covers.
  4. Remove the bolts, then remove the third-row seat.
  5. Install in the reverse order of removal.

Scheme 25

Scheme 25: THIRD-ROW SEAT DISASSEMBLY/ASSEMBLY
  1. Disassemble in the order indicated in the table.
  2. Assemble in the reverse order of disassembly.

Scheme 26

Scheme 26: SEAT WARMER SWITCH REMOVAL/INSTALLATION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-292887-S30644836642008080600000) .)
  2. Disconnect the negative battery cable.
  3. Remove the front cup holder. (See «CENTER CONSOLE DISASSEMBLY/ASSEMBLY»(ref-292888-S40926604032008080600000) .)
  4. Remove in the order indicated in the table.
  5. Install in the reverse order of removal.
