BASIC INSPECTION [FS5A-EL]
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Perform the mechanical system test. (See MECHANICAL SYSTEM TEST [FS5A-EL] .) Is the mechanical system normal? | Yes | Go to the next step. |
| No | Repair or replace any malfunctioning parts according to the inspection result. | ||
| 2 | Turn the ignition switch to the ON position. When the selector lever is moved, does the gear position indicator light indication correspond to the selector lever position? Also, when other ranges are selected from N or P during idling, does the vehicle move within 1-2 s? | Yes | Go to the next step. |
| No | Inspect the selector lever and TR switch. Repair or replace malfunctioning parts. (See SELECTOR LEVER INSPECTION .) (See TRANSAXLE RANGE (TR) SWITCH INSPECTION [FS5A-EL] .) If the selector lever and TR switch are normal, go to the next step. | ||
| 3 | Inspect the ATF color and condition. (See AUTOMATIC TRANSAXLE FLUID (ATF) INSPECTION [FS5A-EL] .) Are the ATF color and odor normal? | Yes | Go to the next step. |
| No | Repair or replace any malfunctioning parts according to the inspection result. Flush the ATX and cooler line if necessary. | ||
| 4 | Perform the line pressure test. (See MECHANICAL SYSTEM TEST [FS5A-EL] .) Is the line pressure normal? | Yes | Go to the next step. |
| No | Repair or replace any malfunctioning parts according to the inspection result. | ||
| 5 | Perform the stall test. (See MECHANICAL SYSTEM TEST [FS5A-EL] .) Is the stall speed normal? | Yes | Go to the next step. |
| No | Repair or replace any malfunctioning parts according to the inspection result. | ||
| 6 | Inspect the value at the following PCM and TCM PIDs using the M-MDS. (See PCM INSPECTION [L3] .) See PID/DATA MONITOR INSPECTION [FS5A-EL] .) PCM PIDs: APP TP REL ECT RPM VPWR TCM PIDs: TFT TFTV TR TR_SENS MNL SW DWN SW UP SW THOP TSS OSS VPWR TCM Are the PID values normal? | Yes | Perform the symptom troubleshooting and follow the procedures. |
| No | Repair or replace any malfunctioning parts according to the inspection result. | ||
DIAGNOSTIC PROCEDURE CHART
SYMPTOM TROUBLESHOOTING ITEM TABLE [FS5A-EL]
- Use the chart below to verify the symptoms of the trouble in order to diagnose the appropriate area.
| No. | TROUBLESHOOTING ITEM | DESCRIPTION | PAGE |
|---|---|---|---|
| 1 | Vehicle does not move in D, M ranges, or in R position | Vehicle does not move when accelerator pedal is depressed. | (See NO.1 VEHICLE DOES NOT MOVE IN D, M RANGES, OR IN R POSITION [FS5A-EL] .) |
| 2 | Vehicle moves in N position | Vehicle creeps in N position. Vehicle creeps if brake pedal is not depressed in N position. | (See NO.2 VEHICLE MOVES IN N POSITION [FS5A-EL] .) |
| 3 | Vehicle moves in P position, or parking gear does not disengage when P position is disengaged | Vehicle rolls when on a downward slope and tires do not lock in P position. Tires locked when P position is disengaged, vehicle does not move in D, M ranges, and R position when accelerator pedal is depressed, and engine remains in stalled condition. | (See NO.3 VEHICLE MOVES IN P POSITION, OR PARKING GEAR DOES NOT DISENGAGE WHEN P IS DISENGAGED [FS5A-EL] .) |
| 4 | Excessive creep | Vehicle accelerates in D, M ranges and R position when accelerator pedal is not depressed. | (See NO.4 EXCESSIVE CREEP [FS5A-EL] .) |
| 5 | No creep at all | Vehicle does not move in D, M ranges, or R position when idling on flat paved road. | (See NO.5 NO CREEP AT ALL [FS5A-EL] .) |
| 6 | Low maximum speed and poor acceleration | Vehicle acceleration is poor at start. Delayed acceleration when accelerator pedal is depressed while driving. | (See NO.6 LOW MAXIMUM SPEED AND POOR ACCELERATION [FS5A-EL] .) |
| 7 | No shifting | Single shift range only. Sometimes shifts correctly. | (See NO.7 NO SHIFTING [FS5A-EL] .) |
| 8 | Does not shift to 5GR | Vehicle does not upshift from 4GR to 5GR even though vehicle speed is increased. Vehicle does not shift to 5GR even though accelerator pedal is released in D range at 60 km/h {37 mph}. | (See NO.8 DOES NOT SHIFT TO 5GR [FS5A-EL] .) |
| 9 | Abnormal shifting | Shifts incorrectly (incorrect shift pattern). | (See NO.9 ABNORMAL SHIFTING [FS5A-EL] .) |
| 10 | Frequent shifting | Downshifting occurs suddenly even when accelerator pedal is depressed slightly in D range. | (See NO.10 FREQUENT SHIFTING [FS5A-EL] .) |
| 11 | Shift point Is high or low | Shift point considerably different from automatic shift diagram. Shift delays when accelerating. Shift occurs suddenly when accelerating and engine speed does not increase. | (See NO.11 SHIFT POINT IS HIGH OR LOW [FS5A-EL] .) |
| 12 | Torque converter clutch (TCC) non-operation | TCC does not operate when vehicle reaches TCC operation range. | (See NO.12 TORQUE CONVERTER CLUTCH (TCC) NON-OPERATION [FS5A-EL] .) |
| 13 | No kickdown | Does not downshift when accelerator pedal is fully depressed within kickdown range. | (See NO.13 NO KICKDOWN [FS5A-EL] .) |
| 14 | Engine flares up or slips when upshifting or downshifting | When accelerator pedal is depressed, engine speed increases normally but vehicle speed increases slowly. When accelerator pedal is depressed while driving, engine speed increases but vehicle speed does not. | (See NO.14 ENGINE FLARES UP OR SLIPS WHEN UPSHIFTING OR DOWNSHIFTING [FS5A-EL] .) |
| 15 | Engine flares up or slips when accelerating vehicle | Engine flares up when accelerator pedal is depressed for upshifting. Engine flares up suddenly when accelerator pedal is depressed for downshifting. | (See NO.15 ENGINE FLARES UP OR SLIPS WHEN ACCELERATING VEHICLE [FS5A-EL] .) |
| 16 | Judder upon torque converter clutch (TCC) operation | Vehicle jolts when TCC is engaged. | (See NO.16 JUDDER UPON TORQUE CONVERTER CLUTCH (TCC) OPERATION [FS5A-EL] .) |
| 17 | Excessive shift shock from N to D or N to R position/range | Strong shock is felt when shifting from N to D or N to R position/range at idle. | (See NO.17 EXCESSIVE SHIFT SHOCK FROM N TO D OR N TO R POSITION/RANGE [FS5A-EL] .) |
| 18 | Excessive shift shock is felt when upshifting and downshifting | Excessive shift shock is felt when depressing accelerator pedal to accelerate at upshifting. During cruising, excessive shift shock is felt when depressing accelerator pedal at downshifting. | (See NO.18 EXCESSIVE SHIFT SHOCK IS FELT WHEN UPSHIFTING AND DOWNSHIFTING [FS5A-EL] .) |
| 19 | Excessive shift shock on torque converter clutch (TCC) | Strong shock is felt when TCC is engaged. | (See NO.19 EXCESSIVE SHIFT SHOCK ON TORQUE CONVERTER CLUTCH (TCC) [FS5A-EL] .) |
| 20 | Noise occurs at idle when vehicle is stopped in all positions/ranges | Transaxle is noisy in all positions and ranges when vehicle idling. | (See NO.20 NOISE OCCURS AT IDLE WHEN VEHICLE IS STOPPED IN ALL POSITIONS/RANGES [FS5A-EL] .) |
| 21 | Noise occurs at idle when vehicle is stopped in D, M ranges, or in R position | Transaxle is noisy in driving ranges when vehicle is idling. | (See NO.21 NOISE OCCURS AT IDLE WHEN VEHICLE IS STOPPED IN D, M RANGES, OR IN R POSITION [FS5A-EL] .) |
| 22 | No engine braking in 1GR position of M range | Engine speed drops to idle but vehicle coasts when accelerator pedal is released when in M range (1GR) at low vehicle speed. | (See NO.22 NO ENGINE BRAKING IN 1GR POSITION OF M RANGE [FS5A-EL] .) |
| 23 | Transaxle overheats | Burnt smell emitted from the transaxle. Smoke is emitted from the transaxle. | (See NO.23 TRANSAXLE OVERHEATS [FS5A-EL] .) |
| 24 | Engine stalls when shifted to D, M ranges, or in R position | Engine stalls when shifting from N or P position to D, M ranges or R position at idle. | (See NO.24 ENGINE STALLS WHEN SHIFTED TO D, M RANGES, OR IN R POSITION [FS5A-EL] .) |
| 25 | Engine stalls when driving at slow speeds or stopping | Engine stalls when brake pedal is depressed while driving at low speed or stopping. | (See NO.25 ENGINE STALLS WHEN DRIVING AT SLOW SPEEDS OR STOPPING [FS5A-EL] .) |
| 26 | Starter does not work | Starter does not work even when in P or N position. | (See NO.26 STARTER DOES NOT WORK [FS5A-EL] .) |
| 27 | Gear position indicator light does not illuminate in M range | Gear position indicator light in instrument cluster does not illuminate in M range with ignition switch at ON. | (See NO.27 GEAR POSITION INDICATOR LIGHT DOES NOT ILLUMINATE IN M RANGE [FS5A-EL] .) |
| 28 | Gear position indicator light illuminates in P, R and N position | Gear position indicator light in instrument cluster illuminates in P, R and N position with ignition switch at ON. | (See NO.28 GEAR POSITION INDICATOR LIGHT ILLUMINATE IN P, R, N POSITION AND D RANGE [FS5A-EL] .) |
| 29 | Does not upshift in M range | Gear position indicator light in instrument cluster illuminates but vehicle does not upshift when selector lever is pushed to "+" side. | (See NO.29 DOES NOT UPSHIFT IN M RANGE [FS5A-EL] .) |
| 30 | Does not downshift in M range | Gear position indicator light in instrument cluster illuminates but vehicle does not downshift when selector lever is pushed to "-" side. | (See NO.30 DOES NOT DOWNSHIFT IN M RANGE [FS5A-EL] .) |
| 31 | M range position indicator light dose not illuminate in M range/M range position indicator light illuminate in D range | M range position indicator light in instrument cluster dose not illuminate in M range or M range position indicator light illuminates in D range with the ignition switch at ON position. | (See NO.31 M RANGE POSITION INDICATOR LIGHT DOSE NOT ILLUMINATE IN M RANGE/M RANGE POSITION INDICATOR LIGHT ILLUMINATE IN D RANGE [FS5A-EL] .) |
SYMPTOM TROUBLESHOOTING CHART
Scheme 465
![Scheme 465: QUICK DIAGNOSIS CHART [FS5A-EL]](https://i.diagnostdata.com/repair/00/002581e4f0f529f968b84b79e3e1fd1c943cc13ac47ef5552de32edcef0cf922.webp)
Scheme 466
Scheme 467
Diagnostic procedure
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | When the vehicle is stopped on a flat, level road and the engine is off, does the vehicle move when pushed? (in D range or N, R positions with the brake pedal released) | Yes | Go to the next step. |
| No | Inspect for parking mechanism. (See .) | ||
| 2 | Disconnect the TCM connector. Is the resistance between the GND terminal at the TCM connector and the body GND less than 5.0 ohms? | Yes | Go to the next step. |
| No | Repair open GND circuit. | ||
| 3 | Inspect the value at the following TCM PID using the M-MDS. (See PID/DATA MONITOR INSPECTION [FS5A-EL] .) LPS Is the PID value normal? | Yes | Overhaul the control valve body and repair or replace any malfunctioning parts. (See .) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. (See .) |
| No | Repair or replace any malfunctioning parts. | ||
| 4 | Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service Bulletins and/or On-line Repair Information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM. | ||
DIAGNOSTIC PROCEDURE CHART
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Does the vehicle creep when the selector lever is moved slightly in N position? | Yes | Go to the next step. |
| No | Adjust the selector cable. (See SELECTOR CABLE ADJUSTMENT .) | ||
| 2 | Disconnect the TCM connector. Is the resistance between the GND terminal at the TCM connector and the body GND less than 5.0 ohms? | Yes | Go to the next step. |
| No | Repair open GND circuit. Reconnect the TCM connector. | ||
| 3 | Inspect the value at the following TCM PID using the M-MDS. (See PID/DATA MONITOR INSPECTION [FS5A-EL] .) LPS Is the PID value normal? | Yes | Overhaul the control valve body and repair or replace any malfunctioning parts. (See .) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. (See .) |
| No | Repair or replace any malfunctioning parts. | ||
| 4 | Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service Bulletins and/or On-line Repair Information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM. | ||
DIAGNOSTIC PROCEDURE CHART
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Does the vehicle creep in any range/position? | Yes | Go to the next step. |
| No | Inspect or adjust the selector cable. (See SELECTOR LEVER INSPECTION .) (See SELECTOR CABLE ADJUSTMENT .) | ||
| 2 | Inspect the value at the following TCM PID using the M-MDS. (See PID/DATA MONITOR INSPECTION [FS5A-EL] .) THOP Is the PID value normal? | Yes | Go to the next step. |
| No | Repair or replace any malfunctioning parts. | ||
| 3 | Disconnect the TCM connector. Is the resistance between the GND terminal at the TCM connector and the body GND less than 5.0 ohms? | Yes | Go to the next step. |
| No | Repair open GND circuit. | ||
| 4 | Inspect the value at the following TCM PID using the M-MDS. (See PID/DATA MONITOR INSPECTION [FS5A-EL] .) LPS Is the PID value normal? | Yes | Overhaul the control valve body and repair or replace any malfunctioning parts. (See .) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. (See .) |
| No | Repair or replace any malfunctioning parts. | ||
| 5 | Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service Bulletins and/or On-line Repair Information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM. | ||
DIAGNOSTIC PROCEDURE CHART
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | With the ignition switch at the ON position, does the gear position indicator light indication correspond to the selector lever position? | Yes | Go to the next step. |
| No | Go to No.27 "GEAR POSITION INDICATOR LIGHT DOES NOT ILLUMINATE IN M RANGE" or No.28 "GEAR POSITION INDICATOR LIGHT ILLUMINATES IN D RANGE OR P, N, R POSITIONS" | ||
| 2 | Go to No.12 "LACK/LOSS OF POWER" . (See NO.12 LACK/LOSS OF POWER-ACCELERATION/CRUISE [L3] .) Is the CIS system normal? | Yes | Go to the next step. |
| No | Repair or replace any malfunctioning parts. | ||
| 3 | Disconnect the solenoid connector. Does the vehicle operate as follows? D range: 3GR (fixed) R position: Reverse | Yes | Go to the next step. |
| No | Overhaul the control valve body and repair or replace any malfunctioning parts. (See .) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. (See .) | ||
| 4 | Drive the vehicle in D range. Does the vehicle start from stop in first gear? | Yes | Go to the next step. |
| No | Inspect the values at the following PCM and TCM PID using using the M-MDS. (See PCM INSPECTION [L3] .) (See PID/DATA MONITOR INSPECTION [FS5A-L] .) PCM PIDs: APP TP REL TCM PIDs: THOP OSS TSS Repair or replace any malfunctioning parts. | ||
| 5 | Inspect the values at the following TCM PID using the M-MDS. (See PID/DATA MONITOR INSPECTION [FS5A-EL] .) SSA/SS1 SSB/SS2 SSC/SS3 SSF_SS6 Are the PID values normal? | Yes | Go to the next step. |
| No | Inspect the values at the following PCM and TCM PID using the M-MDS. (See PCM INSPECTION [L3] .) (See PID/DATA MONITOR INSPECTION [FS5A-L] .) PCM PIDs: APP TP REL TCM PIDs: THOP OSS TSS Repair or replace any malfunctioning parts. | ||
| 6 | Perform the stall test. (See MECHANICAL SYSTEM TEST [FS5A-EL] .) Is stall speed normal? | Yes | Reverify symptoms of malfunction. |
| No | Overhaul the transaxle and repair or replace any malfunctioning parts. (See .) | ||
| 7 | Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service Bulletins and/or On-line Repair Information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM. | ||
DIAGNOSTIC PROCEDURE CHART
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | With the ignition switch at the ON position, does the gear position indicator light indication correspond to the selector lever position? | Yes | Go to the next step. |
| No | Go to No.27 "GEAR POSITION INDICATOR LIGHT DOES NOT ILLUMINATE IN M RANGE" or No. 28 "GEAR POSITION INDICATOR LIGHT ILLUMINATES IN D RANGE OR P, N, R POSITIONS" | ||
| 2 | Inspect the values at the following TCM PID using the M-MDS. (See PID/DATA MONITOR INSPECTION [FS5A-EL] .) TFT TFTV Are the PID values normal? | Yes | Go to the next step. |
| No | Repair or replace any malfunctioning parts. | ||
| 3 | Inspect the value at the following TCM PIDs using the M-MDS. (See PID/DATA MONITOR INSPECTION [FS5A-EL] .) SSA/SS1 SSB/SS2 SSD/SS4 SSF_SS6 Are the PID values normal? | Yes | Overhaul the control valve body and repair or replace any malfunctioning parts. (See .) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. (See .) |
| No | Go to the next step. | ||
| 4 | Disconnect the TCM connector. Is the resistance between the GND terminal at the TCM connector and the body GND less than 5.0 ohms? | Yes | Inspect the value at the following TCM PIDs using the M-MDS. (See PID/DATA MONITOR INSPECTION [FS5A-EL] .) TR TSS OSS Repair or replace any malfunctioning parts. |
| No | Repair open GND circuit. Reconnect the TCM connector. | ||
| 5 | Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service Bulletins and/or On-line Repair Information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM. | ||
DIAGNOSTIC PROCEDURE CHART
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Disconnect the TCM connector. Is the resistance between the GND terminal at the TCM connector and the body GND less than 5.0 ohms? | Yes | Go to the next step. |
| No | Repair open GND circuit. Reconnect the TCM connector. | ||
| 2 | Inspect the value at the following PCM and TCM PIDs using the M-MDS. (See PCM INSPECTION [L3] .) (See PID/DATA MONITOR INSPECTION [FS5A-EL] .) PCM PIDs: APP TPREL TCM PIDs: THOP TSS OSS VSS Are the PID values normal? | Yes | Overhaul the control valve body and repair or replace any malfunctioning parts. (See .) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. (See .) |
| No | Repair or replace any malfunctioning parts. | ||
| 3 | Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service Bulletins and/or On-line Repair Information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM. | ||
DIAGNOSTIC PROCEDURE CHART
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | With the ignition switch at the ON position, does the gear position indicator light indication correspond to the selector lever position? | Yes | Go to the next step. |
| No | Go to No.27 "GEAR POSITION INDICATOR LIGHT DOES NOT ILLUMINATE IN M RANGE" or No.28 "GEAR POSITION INDICATOR LIGHT ILLUMINATES IN D RANGE OR P, N, R POSITIONS" | ||
| 2 | Inspect the value at the following PCM and TCM PIDs using the M-MDS. (See PCM INSPECTION [L3] .) (See PID/DATA MONITOR INSPECTION [FS5A-EL] .) PCM PIDs: APP TP REL TCM PIDs: THOP OSS TSS Are the PID values normal? | Yes | Go to the next step. |
| No | Repair or replace any malfunctioning parts. | ||
| 3 | Disconnect the TCM connector. Is the resistance between the GND terminal at the TCM connector and the body GND less than 5.0 ohms? | Yes | Go to the next step. |
| No | Repair the open GND circuit. | ||
| 4 | Inspect the resistance between shift solenoid A and E control circuit at the TCM connector and control valve body connector. Inspect resistance between shift solenoid A and E circuit at the TCM connector and control valve body connector. Are the resistances less than 5.0 ohms? | Yes | Go to the next step. |
| No | Repair the shift solenoid A or E control circuit. Reconnect the TCM connector. | ||
| 5 | Inspect the shift solenoid A and E. (See SOLENOID VALVE INSPECTION (PRIMARY CONTROL VALVE BODY) [FS5A-EL] .) Are the shift solenoids operating properly? | Yes | Replace the TCM. |
| No | Overhaul the control valve body and repair or replace any malfunctioning parts. (See .) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. (See .) | ||
| 6 | Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service Bulletins and/or On-line Repair Information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM. | ||
DIAGNOSTIC PROCEDURE CHART
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Is shift point normal? | Yes | Go to the next step. |
| No | Go to No.9 "ABNORMAL SHIFTING" . (See NO.9 ABNORMAL SHIFTING [FS5A-EL] .) | ||
| 2 | Inspect the value at the following TCM PID using the M-MDS. (See PID/DATA MONITOR INSPECTION [FS5A-EL] .) THOP Is the PID value normal? | Yes | Go to the next step. |
| No | Repair or replace any malfunctioning parts. | ||
| 3 | Disconnect the TCM connector. Is the resistance between the GND terminal at the TCM connector and the body GND less than 5.0 ohms? | Yes | Go to the next step. |
| No | Repair the open GND circuit. Reconnect the TCM connector. | ||
| 4 | Inspect the value at the following TCM PID using the M-MDS. (See PID/DATA MONITOR INSPECTION [FS5A-EL] .) LPS Is the PID value normal? | Yes | Overhaul the control valve body and repair or replace any malfunctioning parts. (See .) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. (See .) |
| No | Repair or replace any malfunctioning parts. | ||
| 5 | Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service Bulletins and/or On-line Repair Information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM. | ||
DIAGNOSTIC PROCEDURE CHART
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Inspect the value at the following TCM PID using the M-MDS. (See PID/DATA MONITOR INSPECTION [FS5A-EL] .) TSS Is the PID value normal? | Yes | Go to the next step. |
| No | Repair or replace any malfunctioning parts. | ||
| 2 | Disconnect the TCM connector. Is the resistance between the GND terminal at the TCM connector and the body GND less than 5.0 ohms? | Yes | Go to the next step. |
| No | Repair the open GND circuit. | ||
| 3 | Inspect the resistance between shift solenoid A and E control circuit at the TCM connector and control valve body connector. Inspect the resistance between shift solenoid A/E circuit at the TCM connector and control valve body connector. Are the resistances less than 5.0 ohms? | Yes | Go to the next step. |
| No | Repair the shift solenoid A and/or E circuit. | ||
| 4 | Inspect the shift solenoid. (See SOLENOID VALVE INSPECTION (PRIMARY CONTROL VALVE BODY) [FS5A-EL] .) Is the solenoid valve operating properly? | Yes | Go to the next step. |
| No | Overhaul the control valve body and repair or replace any malfunctioning parts. (See .) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. (See .) | ||
| 5 | Inspect the value at the following TCM PID using the M-MDS. (See PID/DATA MONITOR INSPECTION [FS5A-EL] .) LPS Is the PID value normal? | Yes | Overhaul the control valve body and repair or replace any malfunctioning parts. (See .) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. (See .) |
| No | Replace the TCM. (See TCM REMOVAL/INSTALLATION [FS5A-EL] .) | ||
| 6 | Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service Bulletins and/or On-line Repair Information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM. | ||
DIAGNOSTIC PROCEDURE CHART
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Does the shift shock occur only when the engine is cold? | Yes | Go to the next step. |
| No | Go to Step 3. | ||
| 2 | Disconnect the TCM connector. Is the resistance between the GND terminal at the TCM connector and the body GND less than 5.0 ohms? | Yes | Inspect the value at the following PCM and TCM PIDs using the M-MDS. (See PCM INSPECTION [L3] .) (See PID/DATA MONITOR INSPECTION [FS5A-EL] .) PCM PIDs: APP TP REL TCM PIDs: THOP TFT TFTV Repair or replace any malfunctioning parts. |
| No | Repair the open GND circuit. Reconnect the TCM connector. | ||
| 3 | Perform the stall test. (See MECHANICAL SYSTEM TEST [FS5A-EL] .) Is the stall speed normal? | Yes | Go to the next step. |
| No | Go to Step 5. | ||
| 4 | Inspect the value at the following TCM PID using the M-MDS. (See PID/DATA MONITOR INSPECTION [FS5A-EL] .) TR Is the PID value normal? | Yes | Overhaul the control valve body and repair or replace any malfunctioning parts. (See .) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. (See .) |
| No | Repair or replace any malfunctioning parts. | ||
| 5 | Inspect the value at the following TCM PID using the M-MDS. (See PID/DATA MONITOR INSPECTION [FS5A-EL] .) THOP Is the PID value normal? | Yes | Go to the next step. |
| No | Repair or replace any malfunctioning parts. | ||
| 6 | Disconnect the TCM connector. Is the resistance between the GND terminal at the TCM connector and the body GND less than 5.0 ohms? | Yes | Go to the next step. |
| No | Repair the open GND circuit. Reconnect the TCM connector. | ||
| 7 | Inspect the value at the following TCM PID using the M-MDS. (See PID/DATA MONITOR INSPECTION [FS5A-EL] .) LPS Is the PID value normal? | Yes | Overhaul the control valve body and repair or replace any malfunctioning parts. (See .) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. (See .) |
| No | Repair or replace any malfunctioning parts. | ||
| 8 | Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service Bulletins and/or On-line Repair Information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM. | ||
DIAGNOSTIC PROCEDURE CHART
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Inspect the engine mounts for loose tightening bolts or worn parts. Are all engine mounts normal? | Yes | Go to the next step. |
| No | Readjust, retighten or replace engine mounts. | ||
| 2 | Perform the stall test. (See MECHANICAL SYSTEM TEST [FS5A-EL] .) Is the stall speed normal? | Yes | Go to the next step. |
| No | Repair or replace any malfunctioning parts. | ||
| 3 | Inspect the value at the following PCM PID using the M-MDS. (See PCM INSPECTION [L3] .) APP TPREL Is the PID value normal? | Yes | Go to the next step. |
| No | Repair or replace any malfunctioning parts. | ||
| 4 | Disconnect the TCM connector. Is the resistance between the GND terminal at the TCM connector and the body GND less than 5.0 ohms? | Yes | Go to the next step. |
| No | Repair the open GND circuit. Reconnect the TCM connector. | ||
| 5 | Inspect the value at the following TCM PID using the M-MDS. (See PID/DATA MONITOR INSPECTION [FS5A-EL] .) LPS Is the PID value normal? | Yes | Overhaul the control valve body and repair or replace any malfunctioning parts. (See .) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. (See .) |
| No | Repair or replace any malfunctioning parts. | ||
| 6 | Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service Bulletins and/or On-line Repair Information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM. | ||
DIAGNOSTIC PROCEDURE CHART
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Inspect engine condition. Is there any engine concern (i.e. rough idle)? | Yes | Go to appropriate symptom troubleshooting. (See SYMPTOM DIAGNOSTIC INDEX [L3] .) |
| No | Go to the next step. | ||
| 2 | Does the noise stop when the solenoid connector is disconnected? | Yes | Go to the next step. |
| No | Overhaul the control valve body and repair or replace any malfunctioning parts. (See .) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. (See .) | ||
| 3 | Inspect the value at the following PCM and TCM PIDs using the M-MDS. (See PCM INSPECTION [L3] .) (See PID/DATA MONITOR INSPECTION [FS5A-EL] .) PCM PIDs: APP TP REL TCM PIDs: THOP OSS TSS Are the PID values normal? | Yes | Go to the next step. |
| No | Repair or replace any malfunctioning parts. | ||
| 4 | Disconnect the TCM connector. Is the resistance between the GND terminal at the TCM connector and the body GND less than 5.0 ohms? | Yes | Go to the next step. |
| No | Repair the open GND circuit. Reconnect the TCM connector. | ||
| 5 | Inspect the value at the following TCM PID using the M-MDS. (See PID/DATA MONITOR INSPECTION [FS5A-EL] .) LPS Is the PID value normal? | Yes | Overhaul the control valve body and repair or replace any malfunctioning parts. (See .) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. (See .) |
| No | Repair or replace any malfunctioning parts. | ||
| 6 | Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service Bulletins and/or On-line Repair Information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM. | ||
DIAGNOSTIC PROCEDURE CHART
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Do the following symptoms occur concurrently? Engine flares up or slips during acceleration. Engine flares up or slips when shifting. | Yes | Go to symptom troubleshooting NO.14 "ENGINE FLARES UP OR SLIPS WHEN UPSHIFTING OR DOWNSHIFTING" or No. 15 "ENGINE FLARES UP OR SLIPS WHEN ACCELERATING VEHICLE". |
| No | Repeat basic inspection and repair or replace any malfunctioning parts according to the inspection result. (See BASIC INSPECTION [FS5A-EL] .) | ||
| 2 | Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service Bulletins and/or On-line Repair Information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM. | ||
DIAGNOSTIC PROCEDURE CHART
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Inspect for bending, damage, corrosion or kinks of the oil cooler pipes. Are oil cooler pipes normal? | Yes | Go to the next step. |
| No | Replace any malfunctioning parts. | ||
| 2 | Perform the stall test. (See MECHANICAL SYSTEM TEST [FS5A-EL] .) Is the stall speed normal? | Yes | Go to the next step. |
| No | Repair or replace any malfunctioning parts. | ||
| 3 | Inspect the value at the following PCM PID using the M-MDS. (See PCM INSPECTION [L3] .) APP TP REL Are the PID values normal? | Yes | Go to the next step. |
| No | Repair or replace any malfunctioning parts. | ||
| 4 | Disconnect the TCM connector. Is the resistance between the GND terminal at the TCM connector and the body GND less than 5.0 ohms? | Yes | Go to the next step. |
| No | Repair the open GND circuit. Reconnect the TCM connector. | ||
| 5 | Inspect the value at the following TCM PID using the M-MDS. (See PID/DATA MONITOR INSPECTION [FS5A-EL] .) LPS Is the PID value normal? | Yes | Overhaul the control valve body and repair or replace any malfunctioning parts. (See .) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. (See .) |
| No | Repair or replace any malfunctioning parts. | ||
| 6 | Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service Bulletins and/or On-line Repair Information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM. | ||
DIAGNOSTIC PROCEDURE CHART
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Go to symptom troubleshooting No.10 "LOW IDLE/STALLS DURING DECELERATION". (See NO.10 LOW IDLE/STALLS DURING DECELERATION [L3] .) Is the engine control system normal? | Yes | Repeat the basic inspection and repair or replace any malfunctioning parts according to the inspection result. (See BASIC INSPECTION [FS5A-EL] .) |
| No | Repair or replace any malfunctioning parts according to the inspection results. | ||
| 2 | Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service Bulletins and/or On-line Repair Information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM. | ||
DIAGNOSTIC PROCEDURE CHART
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Go to symptom troubleshooting No.10 "LOW IDLE/STALLS DURING DECELERATION". (See NO.10 LOW IDLE/STALLS DURING DECELERATION [L3] .) (See PCM INSPECTION [L3] .) Is the engine control system normal? | Yes | Go to the next step. |
| No | Repair or replace any malfunctioning parts according to the inspection results. | ||
| 2 | Go to symptom troubleshooting No.5 "ENGINE STALLS-AFTER START/AT IDLE" (See NO.5 ENGINE STALLS-AFTER START/AT IDLE [L3] .) (See PCM INSPECTION [L3] .) Is the engine control system normal? | Yes | Repeat the basic inspection and repair or replace any malfunctioning parts according to the inspection result. (See BASIC INSPECTION [FS5A-EL] .) |
| No | Repair or replace any malfunctioning parts according to the inspection results. | ||
| 3 | Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service Bulletins and/or On-line Repair Information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM. | ||
DIAGNOSTIC PROCEDURE CHART
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | With the ignition switch at ON, When selector lever is moved, does selector illumination indicate synchronized position to lever location? | Yes | Go to the next step. |
| No | Check value at the following. TCM terminal voltage: U (TR switch) Repair or replace any defective parts. | ||
| 2 | Inspect the voltage at TCM terminal K (M range switch). (See TCM INSPECTION [FS5A-EL] .) Is voltage normal? | Yes | Go to the next step. |
| No | Repair or replace any defective part. | ||
| 3 | Inspect the instrument duster. (See INSTRUMENT CLUSTER INSPECTION .) Is instrument cluster normal? | Yes | Go to the next step. |
| No | Repair or replace any defective part. | ||
| 4 | Disconnect the TCM and instrument cluster connector. Turn the ignition switch off. Check continuity between the following circuits: TCM terminal B and body GND TCM terminal E and body GND Instrument cluster terminal 1M and body GND Instrument cluster terminal 1O and body GND Is there continuity? | Yes | Repair or replace harness for short to GND, then go to the next step. |
| No | Go to the next step. | ||
| 5 | Disconnect the TCM and instrument cluster connector. Turn the ignition switch off. Check continuity between the following circuits: TCM terminal B and instrument cluster terminal 1M TCM terminal E and instrument cluster terminal 1O Is there continuity? | Yes | Go to the next step. |
| No | Repair or replace harness for open circuit, then go to the next step. | ||
| 6 | Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service Bulletins and/or On-line Repair Information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM. | ||
DIAGNOSTIC PROCEDURE CHART
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | With the ignition switch at ON, When selector lever is moved, does selector illumination indicate synchronized position to lever location? | Yes | Go to the next step. |
| No | Check value at the following. TCM terminal voltage: U (TR switch) Repair or replace any defective parts. | ||
| 2 | Inspect the voltage at TCM terminal K (M range switch). (See TCM INSPECTION [FS5A-EL] .) Is voltage normal? | Yes | Go to the next step. |
| No | Repair or replace any defective part. | ||
| 3 | Inspect the instrument cluster. (See INSTRUMENT CLUSTER INSPECTION .) Is instrument cluster normal? | Yes | Go to the next step. |
| No | Repair or replace any defective part. | ||
| 4 | Disconnect the TCM and instrument cluster connector. Turn the ignition switch off. Check continuity between the following circuits: TCM terminal B and body GND TCM terminal E and body GND Instrument cluster terminal 1M and body GND Instrument cluster terminal 1O and body GND Is there continuity? | Yes | Repair or replace harness for short to GND, then go to the next step. |
| No | Go to the next step. | ||
| 5 | Disconnect the TCM and instrument cluster connector. Turn the ignition switch off. Check continuity between the following. circuits: TCM terminal B and instrument cluster terminal 1M TCM terminal E and instrument cluster terminal 1O Is there continuity? | Yes | Go to the next step. |
| No | Repair or replace harness for open circuit, then go to the next step. | ||
| 6 | Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service Bulletins and/or On-line Repair Information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM. | ||
DIAGNOSTIC PROCEDURE CHART
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Inspect the UP SW PID value using the M-MDS. (See PID/DATA MONITOR INSPECTION [FS5A-EL] .) Is the PID value normal? | Yes | Inspect the instrument cluster. |
| No | Inspect the up switch. If the up switch is normal, inspect for continuity between the up switch and TCM terminal G. | ||
| 2 | Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service Bulletins and/or On-line Repair Information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM. | ||
DIAGNOSTIC PROCEDURE CHART
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Inspect the DWN SW PID value using the M-MDS. (See PID/DATA MONITOR INSPECTION [FS5A-EL] .) Is the PID value normal? | Yes | Inspect the instrument cluster. |
| No | Inspect the down switch. If the down switch is normal, inspect for continuity between the down switch and TCM terminal F. | ||
| 2 | Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service Bulletins and/or On-line Repair Information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM. | ||
DIAGNOSTIC PROCEDURE CHART
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Access the TCM PID MNL SW using the M-MDS. (See PID/DATA MONITOR INSPECTION [FS5A-EL] .) Monitor the MNL SW PID with move the selector lever to all position and range. Does the PID indicate properly? | Yes | Inspect the instrument cluster using the input/output test mode. (See INSTRUMENT CLUSTER INSPECTION .). |
| No | Inspect the M range switch. (See SELECTOR LEVER COMPONENT INSPECTION .) If the M range switch is normal, inspect and repair wiring harness between manual switch terminal A and TCM terminal K. | ||
| 2 | Verify test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service Bulletins and/or On-line Repair Information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM. | ||
DIAGNOSTIC PROCEDURE CHART
