FUSE SERVICE CAUTIONS
| CAUTION | Determine and correct the cause of the burnt fuse before replacing it with the specified type. If the fuse is replaced before doing this, it may burn again. |
Scheme 2
- Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
- Disconnect the negative battery cable.
- Remove the meter hood. (See «METER HOOD REMOVAL/INSTALLATION»(ref-244361-S34979483872006092100000) ).
- Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-244361-S33738517862006092100000) ).
- Remove in the order indicated in the table.
- Install in the reverse order of removal.
Scheme 3
- Rotate the lever in the direction of the arrow and remove the connector.
Scheme 4
- After connecting the connector, rotate the lever in the direction of the arrow to install the connector.
Scheme 5
Scheme 6
- Verify that the continuity between the ignition switch terminals is as indicated in the table. If not as indicated in the table, replace the ignition switch.
Scheme 7
Relay Type
| Terminal type | Part name | |
|---|---|---|
| 4 terminals | Type A | Horn relay Front fog light relay Starter relay Drive-by-wire relay A/C relay Fuel pump relay Rear window defroster relay Blower relay TNS relay Headlight high relay Headlight low relay Main relay |
| Type B | Cooling fan relay | |
RELAY PART NAME CHART
Scheme 8
Scheme 9
- Verify the continuity between the relay terminals. If not as indicated in the table, replace the relay.
Scheme 10
Scheme 11
- Verify the continuity between the relay terminals. If not as indicated in the table, replace the relay.
