Interior lights — Courtesy lamps circuit Mazda 3 BM facelift
All systems — 32 systems
- Air conditioning 3
- Anti-lock brakes
- Anti-theft
- Body control modules 2
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers
- Electronic power steering
- Engine performance 2.0l skyactiv
- Engine performance 2.5l skyactiv
- Exterior lights 2
- Ground distribution
- Headlights 3
- Horn
- Instrument cluster
- Interior lights 2
- Navigation 4
- Power distribution
- Power door locks
- Power mirrors 2
- Power seats 3
- Power top/sunroof
- Power windows
- Radio 3
- Shift interlock
- Starting/charging 3
- Supplemental restraints
- Transmission
- Trunk, tailgate, fuel door
- Warning systems
- Wiper/washer 2
Components on these wiring diagrams 13
Click a component to highlight it on every diagram it appears on.
