STARTER REMOVAL/INSTALLATION [SKYACTIV-G 2.0]
| WARNING | Remove and install all parts when the engine is cold, otherwise they can cause severe burns or serious injury. When the battery cables are connected, touching the vehicle body with starter terminal B will generate sparks. This can cause personal injury, fire, and damage to the electrical components. Always disconnect the negative battery cable before performing the following operation. |
Scheme 42
- Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
- Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
- Remove the aerodynamic under cover No.2. (See «AERODYNAMIC UNDER COVER NO.2 REMOVAL/INSTALLATION»(ref-579341-S33007366072013100700000).)
- Remove in the order indicated in the table.
- Install in the reverse order of removal. (Scheme 42): Identifying Starter With Torque Specifications
Starter Installation Note (ATX)
| CAUTION | Do not overlap the starter with the end plate (area A shown in the figure) when installing. If the starter is not correctly installed, the nut installed to the drive plate may contact the end plate causing abnormal noise. |
Scheme 43
