Engine - Intake-Air System [Skyactiv-G 2.0]: Removal & Installation Mazda 3 BM

INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [SKYACTIV-G 2.0]

1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000) .)
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Intake-Air System With Torque Specifications. Scheme 463

Air Cleaner Cover Removal Note

1. Remove the MAF sensor/IAT sensor No.1. (See «MASS AIR FLOW (MAF) SENSOR/INTAKE AIR TEMPERATURE (IAT) SENSOR NO.1 REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579396-S06141004522013100700000) .)
2. Remove the air cleaner cover and air hose as a single unit.
3. Remove the air cleaner cover.

Air Cleaner Case Removal Note

1. Remove the air cleaner case and fresh-air duct No.3 as a single unit.
2. Remove the air cleaner case.

Resonance Chamber Removal Note

1. Remove the splash shield (LH). (See «SPLASH SHIELD REMOVAL/INSTALLATION»(ref-579341-S13061542712013100700000) .)
2. Set the front mudguard (LH) out of the way. (See «FRONT MUDGUARD REMOVAL/INSTALLATION»(ref-579341-S42819834192013100700000) .)
3. Remove the resonance chamber.

Vacuum Hose Removal Note

1. Remove the plug hole plate. (See «PLUG HOLE PLATE REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579373-S30519630082013100700000) .)
2. Remove the vacuum hose.

Scheme 464

1. Remove the MAP sensor/IAT sensor No.2. (See «MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR/INTAKE AIR TEMPERATURE (IAT) SENSOR NO.2 REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579396-S25110126592013100700000).)
2. Disconnect the harness clip from the intake manifold as shown in the figure. (Scheme 464): Identifying Harness Clip Installation Position

Scheme 465

1. Install the evaporative hose as shown in the figure. (Scheme 465): Identifying Evaporative Hose Installation

Scheme 466

1. Install the vacuum hose as shown in the figure. (Scheme 466): Identifying Vacuum Hose Installation

Scheme 467

1. Install the fresh-air duct No.3 as shown in the figure. (Scheme 467): Identifying Fresh-Air Duct No.3 Installation

Scheme 468

1. Install the air cleaner case as shown in the figure. (Scheme 468): Identifying Air Cleaner Case Installation

Scheme 469

Scheme 470

1. Install the air hose as shown in the figure. (Scheme 469): Identifying Air Hose Installation (1 Of 2) (Scheme 470): Identifying Air Hose Installation (2 Of 2)

Scheme 471

Scheme 472

1. Install the ventilation hose as shown in the figure. (Scheme 471): Identifying Ventilation Hose Installation (1 Of 2) (Scheme 472): Identifying Ventilation Hose Installation (2 Of 2)

Scheme 473

1. Install the water hose as shown in the figure. (Scheme 473): Identifying Water Hose Installation

Scheme 474

Scheme 475

1. Disconnect the harness clip as shown in the figure. (Scheme 474): Identifying Harness Clip And Air Cleaner Element
2. Remove the air cleaner element as shown in the figure. (Scheme 475): Removing Air Cleaner Element
3. Install in the reverse order of removal.
