Symptom Troubleshooting [Restraints]: Overview

Symptom Troubleshooting [Restraints]: Overview Mazda 3 BM

Airbag 4 illustrations

Scheme 239: Air Bag System Wiring Diagram [Standard Deployment Control System] - Vehicles With DSC

Scheme 240: Air Bag System Wiring Diagram [Standard Deployment Control System] - Vehicles Without DSC

Scheme 241: Air Bag System Wiring Diagram [Two-Step Deployment Control System] - Vehicles With DSC

Scheme 242: Air Bag System Wiring Diagram [Two-Step Deployment Control System] - Vehicles Without DSC

Identification

In this manual, "Two-step deployment control system" or "Standard deployment control system" is used if the service contents differ depending on the control.
Control is identified by the following components.

x :Equipped-:Not equipped

Item	Two-step deployment control system	Standard deployment control system
Sophisticated air bag sensor (SAS) control module	X	X
Crash zone sensor	X	X
Pressure sensor	X
Side air bag sensor (No.1)	X	X
Side air bag sensor No.2	X
Driver-side air bag module	X (Two-step deployment type)	X (Standard deployment type)
Passenger-side air bag module	X (Two-step deployment type)	X (Standard deployment type)
Side air bag module	X	X
Curtain air bag module	X	X
Lap pre-tensioner seat belt	X
Pre-tensioner seat belt	X	X
Clock spring	X (Two-step deployment type)	X (Standard deployment type)
Seat track position sensor	X
Seat weight sensor/control module	X
Driver-side buckle switch	X	X
Passenger-side buckle switch	X
Air bag system warning light	X	X
PAD indicator	X
