Radio — Radio circuit, w/o bose Mazda 3 BL facelift
All systems — 37 systems
- Air conditioning 3
- Anti-lock brakes 4
- Anti-theft 5
- Body control modules
- Computer data lines
- Cooling fan
- Cruise control 2.0l
- Cruise control 2.0l skyactiv
- Cruise control 2.3l turbo
- Cruise control 2.5l
- Defoggers
- Electronic power steering
- Engine performance 2.0l
- Engine performance 2.0l skyactiv
- Engine performance 2.3l turbo
- Engine performance 2.5l
- Exterior lights 2
- Ground distribution
- Headlights 2
- Horn
- Instrument cluster 5
- Interior lights 2
- Navigation 5
- Power distribution 4
- Power door locks 4
- Power mirrors 2
- Power seats 2
- Power top/sunroof
- Power windows
- Radio 4
- Shift interlock
- Starting/charging 3
- Supplemental restraints
- Transmission 2
- Trunk, tailgate, fuel door
- Warning systems 5
- Wiper/washer 5
Radio
# Radio circuit, w/o bose
# Radio circuit, w/o bose (1 of 2)
Components on the diagram
# Radio circuit, w/o bose (2 of 2)
Components on the diagram
Components on these wiring diagrams 20
Click a component to highlight it on every diagram it appears on.
