Ignition Switch/steering Lock 49 illustrations ~2493 words

FUSE SERVICE CAUTIONS

CAUTIONIf a fuse is burnt out, inspect the cause and repair the malfunctioning part, then replace the fuse with the specified value. If the fuse is replaced before doing this, it could burn again.

Scheme 3

Scheme 3: MAIN FUSE REMOVAL/INSTALLATION
Scheme 3: MAIN FUSE REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).)(See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).)(See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove nuts A and B shown in the figure. (Scheme 3): Identifying Main Fuse And Nuts With Torque Specifications A And B
  3. Remove the main fuse.
  4. Install in the reverse order of removal.

Scheme 4

Scheme 4: IGNITION SWITCH REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]
Scheme 4: IGNITION SWITCH REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).)(See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).)(See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-520454-S20642177192013010300000).)
  3. Detach the tab. (Scheme 4): Identifying Ignition Switch And Tab
  4. Pull the pin in the direction of the arrow shown in the figure and release the lock. (Scheme 5): Pulling Pin
  5. Disconnect the ignition switch connector and key interlock solenoid connector. (Scheme 6): Identifying Ignition Switch Connector And Key Interlock Solenoid Connector
  6. Remove the tabs. (Scheme 7): Identifying Ignition Switch Tabs
  7. Remove the ignition switch from the steering shaft.
  8. Install in the reverse order of removal.

Scheme 8

Scheme 8: IGNITION SWITCH INSPECTION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]
Scheme 8: IGNITION SWITCH INSPECTION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]

Scheme 9

Scheme 9
Scheme 9
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).)(See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).)(See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-520454-S20642177192013010300000).)
  3. Remove the ignition switch. (See «IGNITION SWITCH REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-520393-S34985936202013010300000).)
  4. Verify that the continuity between the ignition switch terminals is as indicated in the table. (Scheme 8): Identifying Ignition Switch Connector Terminals If not as indicated in the table, replace the ignition switch. (Scheme 9): Ignition Switch Connector Terminals Continuity Chart

Scheme 10

Scheme 10: KEY REMINDER SWITCH REMOVAL/INSTALLATION
Scheme 10: KEY REMINDER SWITCH REMOVAL/INSTALLATION

Scheme 11

Scheme 11
Scheme 11
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).)(See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).)(See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-520454-S20642177192013010300000).)
  3. Disconnect the key reminder switch connector. (Scheme 10): Identifying Key Reminder Switch Connector
  4. Detach the key reminder switch tabs. (Scheme 11): Detaching Key Reminder Switch Tabs
  5. Remove the key reminder switch.
  6. Install in the reverse order of removal.

Scheme 12

Scheme 12: KEY REMINDER SWITCH INSPECTION
Scheme 12: KEY REMINDER SWITCH INSPECTION

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).)(See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).)(See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-520454-S20642177192013010300000).)
  3. Disconnect the key reminder switch connector. (Scheme 12): Identifying Key Reminder Switch Connector
  4. Verify that the continuity between the key reminder switch terminals is as indicated in the table. (Scheme 13): Identifying Key Reminder Switch Connector Terminals If not as indicated in the table, replace the key reminder switch. (Scheme 14): Key Reminder Switch Connector Terminals Continuity Chart

Scheme 15

Scheme 15: PUSH BUTTON START REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]
Scheme 15: PUSH BUTTON START REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).)(See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).)(See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the following parts: Front scuff plate (Driver side)(See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Front side trim (Driver side)(See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-520454-S10636860092013010300000).) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-520454-S17814587652013010300000).) Shift knob (MTX)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-520488-S03861652532013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-520490-S28221261652013010300000).) Selector lever knob (ATX)(See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-520491-S31259650412013010300000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-520454-S17124509942013010300000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-520454-S11769586082013010300000).) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-520454-S28438507612013010300000).)
  3. Set the hood release lever out of the way. (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-520433-S28071592822013010300000).)
  4. Partially peel back the seaming welt.
  5. Remove the lower panel. (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-520454-S41081192382013010300000).)
  6. Release the tabs and remove the push button start from the lower panel. (Scheme 15): Pushing Button Start From Lower Panel And Tabs
  7. Install in the reverse order of removal.

Scheme 16

Scheme 16: PUSH BUTTON START INSPECTION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]
Scheme 16: PUSH BUTTON START INSPECTION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).)(See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).)(See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the following parts: Front scuff plate (Driver side)(See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Front side trim (Driver side)(See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-520454-S10636860092013010300000).) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-520454-S17814587652013010300000).) Shift knob (MTX)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-520488-S03861652532013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-520490-S28221261652013010300000).) Selector lever knob (ATX)(See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-520491-S31259650412013010300000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-520454-S17124509942013010300000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-520454-S11769586082013010300000).) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-520454-S28438507612013010300000).)
  3. Set the hood release lever out of the way. (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-520433-S28071592822013010300000).)
  4. Partially peel back the seaming welt.
  5. Remove the lower panel. (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-520454-S41081192382013010300000).)
  6. Remove the push button start. (See «PUSH BUTTON START REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-520393-S29068286012013010300000).)
  7. Verify that the continuity is as indicated in the table. (Scheme 16): Identifying Push Button Start Connector Terminals If not as indicated in the table, replace the push button start. (Scheme 17): Push Button Start Connector Terminals Continuity Chart
  8. Apply battery positive voltage and connect the ground to the push button start terminals and verify that the LED illuminates. If the LEDs does not illuminate, replace the push button start. Terminal Illumination positions B+ Ground C E ACC indicator light C G ON indicator light C H Indicator (Green) C F Indicator (Red) D J START/STOP/ENGINE (Scheme 18): Identifying Push Button Start Connector Terminals

Scheme 19

Scheme 19: RELAY BLOCK REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]
Scheme 19: RELAY BLOCK REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).)(See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).)(See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the following parts: Driver-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Driver-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-520454-S10636860092013010300000).) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-520433-S28071592822013010300000).) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-520454-S17814587652013010300000).) Shift knob (MTX)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-520488-S03861652532013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-520490-S28221261652013010300000).) Selector lever knob (ATX)(See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-520491-S31259650412013010300000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-520454-S17124509942013010300000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-520454-S11769586082013010300000).) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-520454-S28438507612013010300000).) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-520454-S41081192382013010300000).) Knee bolster (See «KNEE BOLSTER REMOVAL/INSTALLATION»(ref-520454-S27123388922013010300000).)
  3. Remove the nut and clip. (Scheme 19): Identifying Relay Block Nut And Clip
  4. Disconnect the connectors. (Scheme 20): Identifying Relay Block Connectors
  5. Remove the nut and clip. (Scheme 21): Identifying Relay Block Nut And Clip
  6. Remove the relay block from the bracket.
  7. Install in the reverse order of removal.

Scheme 22

Scheme 22: RELAY BLOCK INSPECTION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]
Scheme 22: RELAY BLOCK INSPECTION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]

Scheme 23

Scheme 23
Scheme 23
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).)(See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).)(See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the following parts: Driver-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Driver-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-520454-S10636860092013010300000).) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-520433-S28071592822013010300000).) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-520454-S17814587652013010300000).) Shift knob (MTX)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-520488-S03861652532013010300000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-520490-S28221261652013010300000).) Selector lever knob (ATX)(See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-520491-S31259650412013010300000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-520454-S17124509942013010300000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-520454-S11769586082013010300000).) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-520454-S28438507612013010300000).) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-520454-S41081192382013010300000).) Knee bolster (See «KNEE BOLSTER REMOVAL/INSTALLATION»(ref-520454-S27123388922013010300000).)
  3. Remove the relay block. (See «RELAY BLOCK REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-520393-S04005501032013010300000).)
  4. Verify that the continuity is as indicated in the table. (Scheme 22): Identifying Relay Block Connector Terminals If not as indicated in the table, replace the relay block. (Scheme 23): Relay Block Connector Terminals Continuity Chart

Note. Use the IDS (laptop PC) because the PDS (Pocket PC) does not support the POWER SYSTEMS PERSONALIZATION FEATURES SETTING PROCEDURE.

Scheme 24

Scheme 24: POWER SYSTEMS PERSONALIZATION FEATURES SETTING PROCEDURE
Scheme 24: POWER SYSTEMS PERSONALIZATION FEATURES SETTING PROCEDURE
  1. Connect the M-MDS to the DLC-2. (Scheme 24): Identifying DLC-2
  2. After the vehicle is identified, select the following items from the initial screen of the M-MDS. Select the "Module Programming".
  3. Then, select items from the screen menu in the following order. Select "Programmable Parameters". Select "RKE".
  4. Select an item name, and then select option. M-MDS display Function Initial setting Setting content Control unit ACC auto off The function to automatically switch off the ignition after one hour has elapsed since the ignition was switched to ACC can be set to operable or inoperable. Enabled Disabled/Enabled Keyless control module Power off mode The transition pattern in which the ignition position is switched by pressing the push button start can be selected. Direct Direct/Stepwise Keyless control module

FORCED IGNITION ON [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]

Note. In order to perform a forced ignition ON, the M-MDS (IDS) is necessary. If the servicing is being done outside of an Authorized Mazda dealership, contact an Authorized Mazda dealership for instructions. The forced ignition ON procedure forces a power supply to each part when no power is available even after the ignition switch has been operated. However, the engine cannot be started and the steering cannot be unlocked. When performing a forced ignition ON procedure, remove all advanced keys from the vehicle. If an advanced key is left in the vehicle, the forced ignition ON procedure cannot be done.

Scheme 25

Scheme 25: FORCED IGNITION ON [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]
Scheme 25: FORCED IGNITION ON [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]

Scheme 26

Scheme 26
Scheme 26
  1. Verify that there are no advanced keys in the vehicle.
  2. Get PCM part number from As-built site.
  3. Connect the M-MDS (IDS) to the DLC-2. (Scheme 25): Identifying DLC-2
  4. Manual vehicle identification. Select "Manual Vehicle Entry".
  5. Select the "All other" from Vehicle list.
  6. Input the PCM part number on the following screen. (Scheme 26): Screen Display - Input PCM Part Number
  7. After the vehicle is identified, select the following items from the initialization screen of the IDS. Select "Body". Select "Special Ignition ON".
  8. Perform the procedure according to the directions on the screen.
  9. Delete session with keeping ignition ON.
  10. Normal vehicle identification.

Scheme 27

Scheme 27: FRONT FOG LIGHT RELAY REMOVAL/INSTALLATION
Scheme 27: FRONT FOG LIGHT RELAY REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).)(See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).)(See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the front mudguard.(RH) (See «FRONT MUDGUARD REMOVAL/INSTALLATION»(ref-520448-S04135051462013010300000).)
  3. Remove the front fog light relay case. (Scheme 27): Removing Front Fog Light Relay Case
  4. Remove the cover.
  5. Remove the front fog light relay.
  6. Install in the reverse order of removal. (See «FRONT FOG LIGHT RELAY INSTALLATION NOTE»(ref-520393-S35731599272013010300000).)

Scheme 28

Scheme 28: Front Fog Light Relay Installation Note
Scheme 28: Front Fog Light Relay Installation Note
  1. Install the front fog light relay case to the shroud panel with the front fog light relay cover facing upward. CAUTION: If the front fog light relay case is installed to the shroud panel with the cover downward, water may penetrate the cover and the front fog light relay may not operate normally. Install the front fog light relay case with the cover facing upward. (Scheme 28): Identifying Front Fog Light Relay Case With Cover Facing Upward

Scheme 29

Scheme 29: Advanced Keyless Entry And Push Button Start System Only
Scheme 29: Advanced Keyless Entry And Push Button Start System Only

Scheme 30

Scheme 30
Scheme 30
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).)(See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).)(See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the following parts: Front scuff plate (LH) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Front side trim (LH) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-520454-S10636860092013010300000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-520454-S11769586082013010300000).) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-520454-S28438507612013010300000).)
  3. Set the hood release lever out of the way. (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-520433-S28071592822013010300000).)
  4. Remove the lower panel. (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-520454-S41081192382013010300000).)
  5. Disconnect the connector. (Scheme 29): Identifying Starter Cut Relay And Connector
  6. Remove the nut. (Scheme 30): Identifying Starter Cut Relay And Nut With Torque Specification
  7. Remove the starter cut relay.
  8. Install in the reverse order of removal.

Advanced Keyless Entry And Push Button Start System Only

  1. Disconnect the negative battery cable.
  2. Remove the following parts: Front scuff plate (LH) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000) .) Front side trim (LH) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-520454-S10636860092013010300000) .) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-520454-S11769586082013010300000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-520454-S28438507612013010300000) .)
  3. Set the bonnet release lever out of the way. (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-520433-S28071592822013010300000) .)
  4. Remove the lower panel. (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-520454-S41081192382013010300000) .)
  5. Remove the starter cut relay with the connector connected. (See «STARTER CUT RELAY REMOVAL/INSTALLATION [MTX]»(ref-520393-S18377887102013010300000) .)
  6. Connect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000) .)(See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000) .)(See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000) .)
  7. Measure the voltage at each terminal is as indicated in the terminal voltage tables. If the voltage or continuity is not as specified in the terminal voltage table, inspect the parts under "Inspection item (s)". If the system does not work properly even though the parts or related wiring harnesses do not have any malfunction, replace the starter cut relay.

Identifying Starter Cut Relay Connector Terminals. Scheme 31

Scheme 31: Identifying Starter Cut Relay Connector Terminals
Scheme 31: Identifying Starter Cut Relay Connector Terminals
TerminalSignal nameConnected toMeasurement conditionVoltage (V)Inspection item (s)
APower supplyStarter relaySwitch the ignitions to offClutch pedal is not depressedWave pattern 1 (See PATTERN 1 .)Starter relay Related wiring harnesses
Clutch pedal is depressedWave pattern 2 (See PATTERN 2 .)
Switch the ignitions to ONClutch pedal is not depressedB+
Clutch pedal is depressed1.0 or lessPCM Related wiring harnesses
DStarter cut relay output signalPCM Keyless control moduleSwitch the ignitions to offClutch pedal is not depressedWave pattern 2 (See PATTERN 2 .)Starter cut relay Related wiring harnesses
Clutch pedal is depressed1.0 or less
HStarter interlock switchStarter interlock switchSwitch the ignitions to ONClutch pedal is not depressedB+Starter interlock switch Related wiring harnesses
Clutch pedal is depressed1.0 or less
IIG 1Stop 15 A fuseSwitch the ignition to ONB+Stop 15 A fuse Related wiring harnesses
Switch the ignition to off1.0 or less

Starter Cut Relay Pattern 1 (Generated Pulse). Scheme 32

Scheme 32: Starter Cut Relay Pattern 1 (Generated Pulse)
Scheme 32: Starter Cut Relay Pattern 1 (Generated Pulse)
  1. Terminal: A (+) <--> body ground (-)
  2. Oscilloscope setting: 2 V/DIV (Y), 100 ms/DIV (X), DC range

Starter Cut Relay Pattern 2 (Generated Pulse). Scheme 33

Scheme 33: Starter Cut Relay Pattern 2 (Generated Pulse)
Scheme 33: Starter Cut Relay Pattern 2 (Generated Pulse)
  1. Terminal: a (+) <--> body ground (-) D (+) <--> body ground (-)
  2. Oscilloscope setting: 2 V/DIV (Y), 100 ms/DIV (X), DC range

Relay Locations (SKYACTIV-G 2.0). Scheme 34

Scheme 34: Relay Locations (SKYACTIV-G 2.0)
Scheme 34: Relay Locations (SKYACTIV-G 2.0)

Relay Locations (MZR 2.0, MZR 2.5, MZR 2.3 DISI Turbo). Scheme 35

Scheme 35: Relay Locations (MZR 2.0, MZR 2.5, MZR 2.3 DISI Turbo)
Scheme 35: Relay Locations (MZR 2.0, MZR 2.5, MZR 2.3 DISI Turbo)

Relay Type

Connector typePart name
Type AFront fog light relay Headlight relay (HI) Headlight relay (LO) Horn relay TNS relay A/C relay Starter relay Rear window defroster relay Back-up light relay Fuel pump relay Fuel injector relay Main relay
Type BDRL relay
Type CElectric variable valve timing relay
Type DBlower relay

Scheme 36

Scheme 36: Type A
Scheme 36: Type A

Scheme 37

Scheme 37
Scheme 37
  1. Verify that the continuity is as indicated in the table. (Scheme 36): Identifying Relay Connector Terminals - Type A (SKYACTIV-G 2.0) If not as indicated in the table, replace the relay. (Scheme 37): Relay Connector Terminals Continuity Chart - Type A (SKYACTIV-G 2.0)

Scheme 38

Scheme 38: Type B
Scheme 38: Type B

Scheme 39

Scheme 39
Scheme 39
  1. Verify that the continuity is as indicated in the table. (Scheme 38): Identifying Relay Connector Terminals - Type B (SKYACTIV-G 2.0) If not as indicated in the table, replace the relay. (Scheme 39): Relay Connector Terminals Continuity Chart - Type B (SKYACTIV-G 2.0)

Scheme 40

Scheme 40: Type C
Scheme 40: Type C

Scheme 41

Scheme 41
Scheme 41
  1. Verify that the continuity is as indicated in the table. (Scheme 40): Identifying Relay Connector Terminals - Type C (SKYACTIV-G 2.0) If not as indicated in the table, replace the relay. (Scheme 41): Relay Connector Terminals Continuity Chart - Type C (SKYACTIV-G 2.0)

Scheme 42

Scheme 42: Type D
Scheme 42: Type D

Scheme 43

Scheme 43
Scheme 43
  1. Verify that the continuity is as indicated in the table. (Scheme 42): Identifying Relay Connector Terminals - Type D (SKYACTIV-G 2.0) If not as indicated in the table, replace the relay. (Scheme 43): Relay Connector Terminals Continuity Chart - Type D (SKYACTIV-G 2.0)
Connector typePart name
Type AFront fog light relay Headlight relay (HI) Headlight relay (LO) Horn relay TNS relay A/C relay AT main relay (MZR 2.0, MZR 2.5) Fuel pump relay (MZR 2.3 DISI Turbo) Fuel injector relay (MZR 2.3 DISI Turbo) Fuel pump speed control relay (MZR 2.3 DISI Turbo) Starter relay Rear window defroster relay
Type BDRL relay
Type CMain relay
Type DBlower relay

Scheme 44

Scheme 44: Type A
Scheme 44: Type A

Scheme 45

Scheme 45
Scheme 45
  1. Verify that the continuity is as indicated in the table. (Scheme 44): Identifying Relay Connector Terminals - Type A (MZR 2.0, MZR 2.5, MZR 2.3 DISI Turbo) If not as indicated in the table, replace the relay. (Scheme 45): Relay Connector Terminals Continuity Chart - Type A (MZR 2.0, MZR 2.5, MZR 2.3 DISI Turbo)

Scheme 46

Scheme 46: Type B
Scheme 46: Type B

Scheme 47

Scheme 47
Scheme 47
  1. Verify that the continuity is as indicated in the table. (Scheme 46): Identifying Relay Connector Terminals - Type B (MZR 2.0, MZR 2.5, MZR 2.3 DISI Turbo) If not as indicated in the table, replace the relay. (Scheme 47): Relay Connector Terminals Continuity Chart - Type B (MZR 2.0, MZR 2.5, MZR 2.3 DISI Turbo)

Scheme 48

Scheme 48: Type C
Scheme 48: Type C

Scheme 49

Scheme 49
Scheme 49
  1. Verify that the continuity is as indicated in the table. (Scheme 48): Identifying Relay Connector Terminals - Type C (MZR 2.0, MZR 2.5, MZR 2.3 DISI Turbo) If not as indicated in the table, replace the relay. (Scheme 49): Relay Connector Terminals Continuity Chart - Type C (MZR 2.0, MZR 2.5, MZR 2.3 DISI Turbo)

Scheme 50

Scheme 50: Type D
Scheme 50: Type D

Scheme 51

Scheme 51
Scheme 51
  1. Verify that the continuity is as indicated in the table. (Scheme 50): Identifying Relay Connector Terminals - Type D (MZR 2.0, MZR 2.5, MZR 2.3 DISI Turbo) If not as indicated in the table, replace the relay. (Scheme 51): Relay Connector Terminals Continuity Chart - Type D (MZR 2.0, MZR 2.5, MZR 2.3 DISI Turbo)

More articles — Power Systems
