Interior Trim System: Removal & Installation Mazda 3 BL рестайлинг

GLOVE COMPARTMENT REMOVAL/INSTALLATION

Scheme 89

1. Pull the stay damper in the direction (1) shown in the figure, and detach the hook A between the glove compartment and the stay damper.
2. Pull up the hook B in the direction of arrow (2) and remove it in the direction of arrow (3) shown in the figure.
3. Lower the glove compartment.
4. Detach the hook C from the dashboard and remove the glove compartment. (Scheme 89): Pulling Stay Damper
5. Install in the reverse order of removal.

Scheme 90

1. Through the wiring harness into the position shown in the figure, remove the side ventilator grille in the direction of arrow. (Scheme 90): Removing Side Ventilator Grille
2. When installing the side ventilator grille, push it for the dashboard.

Scheme 91

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
2. Remove the center panel. (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-520454-S30556586742013010300000) )
3. Push the edge of center panel in the direction of arrow (1) and detach the hooks.
4. Remove the center ventilator grille in the direction of arrow (2) shown in the figure. (Scheme 91): Removing Center Ventilator Grille
5. Install in the reverse order of removal.

Scheme 92

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
2. Remove the following parts: Driver-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Driver-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-520454-S10636860092013010300000).) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-520433-S28071592822013010300000).) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-520454-S17814587652013010300000).) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-520487-S22617144462013010300000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-520488-S03861652532013010300000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-520490-S28221261652013010300000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-520489-S37301789532013010300000).) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-520491-S31259650412013010300000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-520454-S17124509942013010300000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-520454-S11769586082013010300000).) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-520454-S28438507612013010300000).) Driver-side lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-520454-S41081192382013010300000).)
3. Remove the bolts. (Scheme 92): Identifying Knee Bolster And Bolts With Torque Specification
4. Remove the knee bolster.
5. Install in the reverse order of removal.

Scheme 93

Scheme 94

1. Pull out the side wall in the direction shown in the direction of the arrow shown in the figure, then remove the clips. (Scheme 93): Pulling Out Side Wall
2. Remove the side wall in the direction of the arrow shown in the figure. (Scheme 94): Removing Side Wall And Guide CAUTION: When remove the side wall, be careful not to damage the guide.
3. Install in the reverse order of removal.

Scheme 95

Scheme 96

1. Detach the hooks in the direction of arrow (1) shown in the figure.
2. Pull the dashboard under cover in the direction of arrow (2). (Scheme 95): Pulling Dashboard Under Cover
3. Remove the dashboard under cover, then remove the guide. (Scheme 96): Removing Dashboard Under Cover And Guide
4. Install in the reverse order of removal.

Scheme 97

Scheme 98

1. Pull the upper panel in the direction of the arrow shown in the figure, then remove it while detaching the hook A and hooks B. (Scheme 97): Pulling Upper Panel CAUTION: When removing hook A, press the connecting part of the console with a hand to prevent damage to hook A.
2. Pull the upper panel in the direction of the arrow shown in the figure, then remove it while detaching the hook C and hooks D. (Scheme 98): Pulling Upper Panel
3. Remove the upper panel.
4. Install in the reverse order of removal.

Scheme 99

Scheme 100

1. Remove the upper panel. (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-520454-S17814587652013010300000).)
2. Remove the selector lever knob. (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-520491-S31259650412013010300000) )
3. Pull the shift panel in the direction of the arrow shown in the figure and remove it while detaching the clips A, hook B and guides C. (Scheme 99): Pulling Shift Panel
4. Pull the shift panel in the direction of the arrow (1), (2), (3) while remove the hooks D, E and guide F. (Scheme 100): Pulling Shift Panel With Hooks And Guide
5. Remove the shift panel.
6. Install in the reverse order of removal.

Scheme 101

1. Remove the upper panel. (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-520454-S17814587652013010300000).)
2. Remove the shift knob. (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-520487-S22617144462013010300000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-520488-S03861652532013010300000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-520490-S28221261652013010300000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-520489-S37301789532013010300000).)
3. Pull the shift panel in the direction of the arrow shown in the figure and remove it while detaching the clips, hook and guides. (Scheme 101): Pulling Shift Panel
4. Remove the shift panel.
5. Install in the reverse order of removal.

Scheme 102

Scheme 103

Scheme 104

Scheme 105

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-520454-S17814587652013010300000).) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-520487-S22617144462013010300000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-520488-S03861652532013010300000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-520490-S28221261652013010300000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-520489-S37301789532013010300000).) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-520491-S31259650412013010300000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-520454-S17124509942013010300000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-520454-S11769586082013010300000).)
3. Remove the bolts. (Scheme 102): Identifying Console And Bolts
4. Remove the screws. (Scheme 103): Identifying Console And Screws
5. Pull the console in the direction of the arrow shown in the figure, then detaching clips A, C hooks B and guides D. (Scheme 104): Pulling Console
6. Pull up the console in the direction of the arrow (1) shown in the figure, move the rear console in the direction of the arrow (2), and remove it avoiding the parking brake lever. (Scheme 105): Pulling Up Console
7. Install in the reverse order of removal.

Scheme 106

1. Remove the following parts: Passenger-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Passenger-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-520454-S10636860092013010300000).) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-520454-S00904275812013010300000).) Passenger-side lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-520454-S41081192382013010300000).)
2. Remove the screw.
3. Pull the decoration panel in the direction of the arrow (1), (2) shown in the figure, while remove the hook A and hooks B. (Scheme 106): Pulling Decoration Panel
4. Remove the decoration panel.
5. Install in the reverse order of removal.

Scheme 107

Scheme 108

Scheme 109

1. Partially peel back the seaming welt.
2. Pull the upper end of the A-pillar trim in the direction of the arrow shown in the figure and remove clip A and B. (Scheme 107): Pulling Upper End Of A-Pillar Trim
3. Cut the lead wire connecting clip B and grommet using a nipper and pull out the A-pillar trim in the direction of the arrow shown in the figure. (Scheme 108): Pulling Out A-Pillar Trim CAUTION: When pulling out the A-pillar trim, be careful not to damage the tabs C.
4. Move the hook in the direction of arrows (1) and (2) shown in the figure using a flathead screwdriver and detach it from the A-pillar inner panel. (Scheme 109): Moving Hook
5. Remove the grommet in the direction of the arrow (3) shown in the figure.
6. When installing the A-pillar, install the new clip B and grommet to the A-pillar trim in advance.
7. Install in the reverse order of removal.

Scheme 110

1. Remove the front scuff plate. (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).)
2. Partially peel back the seaming welt.
3. Remove the fastener.
4. Pull the front side trim in the direction of the arrow and detach the clip. (Scheme 110): Pulling Front Side Trim
5. Install in the reverse order of removal.

Scheme 111

Scheme 112

1. Remove the rear seat cushion. (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).)
2. Remove the rear scuff plate. (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).)
3. Partially peel back the seaming welt.
4. Remove the fastener.
5. Pull the tire house trim in the direction of arrow shown in the figure while remove the clip A, pin B and C. (Scheme 111): Pulling Tire House Trim (4SD)
6. Pull the tire house trim in the direction of arrow shown in the figure while remove the hook D. (Scheme 112): Pulling Tire House Trim (4SD)
7. Remove the tire house trim.
8. Install in the reverse order of removal.

Scheme 113

1. Remove the rear seat cushion. (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).)
2. Remove the rear scuff plate. (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).)
3. Partially peel back the seaming welt.
4. Remove the fasteners.
5. Pull the tire house trim in the direction of arrow (1), while remove the hook A and B. (Scheme 113): Pulling Tire House Trim (5HB)
6. Pull the tire house trim in the direction of arrow (2), while remove the hook C, clip D, pin E and F.
7. Remove the tire house trim.
8. Install in the reverse order of removal.

Scheme 114

Scheme 115

1. Remove the following parts: Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S26302889922013010300000).)
2. Fold the rear seat back.
3. Remove the fasteners. (Scheme 114): Identifying Rear Package Trim And Fasteners
4. Pull up the rear package trim in the direction of the arrow (1) shown in the figure while remove the clips and pin, pull the rear package trim in the direction of the arrow (2), and remove it while pulling out the guides. (Scheme 115): Pulling Rear Package Trim
5. Install in the reverse order of removal.

Scheme 116

Scheme 117

1. Remove the front scuff plate. (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000) )
2. Remove the rear scuff plate. (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000) )
3. Partially peel back the seaming welt.
4. Pull the B-pillar lower trim in the direction of the arrow (1), (2) shown in the figure, detach tab A, pin B, pin C, clip D. (Scheme 116): Pulling B-Pillar Lower Trim
5. Remove the B-pillar lower trim in the direction of the arrow (3) shown in the figure. (Scheme 117): Removing B-Pillar Lower Trim
6. Install in the reverse order of removal.

Scheme 118

Scheme 119

1. Remove the following parts: Adjuster anchor cover (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S38556519212013010300000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S00144206272013010300000).) Upper anchor installation bolts on the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S38556519212013010300000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S00144206272013010300000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).)
2. Partially peel back the seaming welt.
3. Remove the B-pillar lower trim. (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-520454-S26286324672013010300000) )
4. Grasp the lower end of the B-pillar upper trim, pull it in the direction of the arrow shown in the figure, and remove clips A, pin B, and pin C. (Scheme 118): Removing Clips A Of B-Pillar Lower Trim
5. Remove the B-pillar upper trim in the direction of the arrow shown in the figure. (Scheme 119): Removing B-Pillar Upper Trim CAUTION: When removing the B-pillar upper trim, be careful not to damage the tab D.
6. Install in the reverse order of removal.

Scheme 120

Scheme 121

Scheme 122

1. Remove the following parts: Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).)
2. Partially peel back the seaming welt.
3. Pull the C-pillar trim in the direction of the arrow (1), (2) shown in the figure, then detaching clip A and B. (Scheme 120): Pulling C-Pillar Trim
4. Cut the lead wire connecting clip A and grommet using a nipper and pull out the C-pillar trim in the direction of the arrow shown in the figure, while remove the tab C. (Scheme 121): Pulling Out C-Pillar Trim CAUTION: When removing the C-pillar trim, be careful not to damage the tab C.
5. Move the hook in the direction of arrows (1) and (2) shown in the figure using a flathead screwdriver and detach it from the rear pillar inner panel. (Scheme 122): Moving Hook
6. Remove the grommet in the direction of the arrow (3) shown in the figure.
7. When installing the C-pillar, install the new clip A and grommet to the C-pillar trim in advance.
8. Install in the reverse order of removal.

Scheme 123

1. Remove the following parts: Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).) Trunk side upper trim (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S29808716532013010300000).) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-520454-S41103934472013010300000).)
2. Partially peel back the seaming welt.
3. Remove the fastener.
4. Pull the C-pillar trim in the direction of the arrow (1), (2) shown in the figure, then remove the clips A, pin B and C.
5. Pull the C-pillar trim in the direction of the arrow (3) shown in the figure, then remove the clips D and tab E. (Scheme 123): Pulling C-Pillar Trim
6. Remove the C-pillar trim.
7. Install in the reverse order of removal.

Scheme 124

1. Detach tab A while pulling the front scuff plate in the direction of the arrow (1) shown in the figure, then detach hook B, clips C, and pins D while pulling in the direction of the arrow (2).
2. Detach tab E while pulling the front scuff plate in the direction of the arrow (3) shown in the figure, pull the front scuff plate in the direction of the arrow (4), and remove it while detaching hook F. (Scheme 124): Pulling Front Scuff Plate
3. Remove the front scuff plate.
4. Install in the reverse order of removal.

Scheme 125

1. Detach tab A while pulling the rear scuff plate in the direction of the arrow (1) shown in the figure, then detach hook B, clips C, pins D while pulling in the direction of the arrow (2).
2. Detach tab E while pulling the rear scuff plate in the direction of the arrow (3) shown in the figure, pull the rear scuff plate in the direction of the arrow (4) shown in the figure. (Scheme 125): Pulling Rear Scuff Plate
3. Remove the rear scuff plate.
4. Install in the reverse order of removal.

Scheme 126

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
2. Pull the inner garnish in the direction of the arrow shown in the figure and remove it while detaching clips and tab. (Scheme 126): Pulling Inner Garnish CAUTION: When pulling out the inner garnish, be careful not to damage the tab.
3. Disconnect the front tweeter connector. (Vehicles with tweeter)
4. Install in the reverse order of removal.

Scheme 127

Scheme 128

1. Remove the screw. (Scheme 127): Identifying Fuel-Filler Lid Opener Bezel And Screw
2. Pull the fuel-filler lid opener bezel in the direction of the arrow (1) then remove the tab.
3. Move the fuel-filler lid opener bezel in the direction of the arrow (2) shown in the figure. (Scheme 128): Moving Fuel-Filler Lid Opener Bezel
4. Remove the fuel-filler lid opener bezel.
5. Install in the reverse order of removal.

Scheme 129

1. Disassemble in the order shown in the figure. (Scheme 129): Identifying Rear Door Trim Components
2. Assemble in the reverse order of disassembly.

Scheme 130

1. Remove the trunk mat. (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-520454-S36237012032013010300000) )
2. Remove the trunk board. (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-520454-S36237012032013010300000) )
3. Remove the fasteners.
4. Pull the trunk end trim indicated in the arrow shown in the figure, then detach clips A, pins B, pin C, D and tabs E. (Scheme 130): Pulling Trunk End Trim
5. Remove the trunk end trim.
6. Install in the reverse order of removal.

Scheme 131

1. Remove the trunk mat. (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-520454-S36237012032013010300000) )
2. Remove the trunk board. (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-520454-S36237012032013010300000) )
3. Remove the fasteners.
4. Pull the trunk end trim indicated in the arrow shown in the figure, then detach clips A, pins B, pin C, guides D and pins E. (Scheme 131): Pulling Trunk End Trim
5. Remove the trunk end trim.
6. Install in the reverse order of removal.

Scheme 132

1. Remove the following parts: Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).) Trunk mat (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-520454-S36237012032013010300000).) Trunk board (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-520454-S36237012032013010300000).) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-520454-S13459736022013010300000).) Service hole cover
2. Remove the fasteners. (Scheme 132): Removing Trunk Side Trim Fasteners (Left-Side)
3. Install in the reverse order of removal.

Scheme 133

1. Remove the following parts: Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).) Trunk mat (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-520454-S36237012032013010300000).) Trunk board (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-520454-S36237012032013010300000).) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-520454-S13459736022013010300000).)
2. Remove the fasteners and tab. (Scheme 133): Removing Trunk Side Trim Fasteners (Right-Side)
3. Install in the reverse order of removal.

Scheme 134

Scheme 135

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
2. Remove the following parts: Rear seat (See «REAR SEAT BACK REMOVAL/INSTALLATION»(ref-520455-S28972805732013010300000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-520454-S13459736022013010300000).) Trunk side upper trim (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S29808716532013010300000).)
3. Remove the bolts, then remove the cargo net hooks. (Scheme 134): Identifying Cargo Net Hooks And Bolts With Torque Specification
4. Remove the fasteners.
5. Pull the trunk side trim in the direction of arrow, while remove the clip. (Scheme 135): Pulling Trunk Side Trim
6. Remove the trunk side trim.
7. Disconnect the cargo compartment light connector. (Right-side only)
8. Install in the reverse order of removal.

Scheme 136

1. Remove the rear seat cushion. (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000) )
2. Remove the rear scuff plate. (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000) )
3. Remove the tire house trim. (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000) )
4. Open the cap.
5. Remove the screw.
6. Remove the fasteners.
7. Pull the trunk side upper trim in the direction of arrow, then detach the hooks and clips. (Scheme 136): Pulling Trunk Side Upper Trim
8. Install in the reverse order of removal.

Scheme 137

Scheme 138

Scheme 139

Scheme 140

Scheme 141

Scheme 142

Scheme 143

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-520454-S32815572972013010300000) )
3. Move the hook in the direction of arrow shown in the figure using a tape-lapped flathead screwdriver and detach it from the front door trim. (Scheme 137): Moving Hook Using Tape-Lapped Flathead Screwdriver CAUTION: Affix protective tape to the front door trim and assist handle cover to prevent damage.
4. Pull the inner handle cover in the direction of arrow and remove it while detaching tabs. (Scheme 138): Pulling Inner Handle Cover
5. Remove the screws. (Scheme 139): Identifying Screws
6. Pull in the direction of the arrow (1), (2), (3) shown in the figure and remove clips from the door inner panel using a fastener remover. (Scheme 140): Removing Clips From Door Inner Panel Using Fastener Remover
7. Remove the front door trim in the direction of the arrow shown in the figure. (Scheme 141): Removing Front Door Trim
8. Remove the inner handle and move the front door trim shown in the figure. (Scheme 142): Identifying Inner Handle And Tabs
9. Turn the inner handle 90° in the direction of the arrow and remove it from the front door trim. (Scheme 143): Turning Inner Handle
10. Disconnect the driver-side power outer mirror switch connector and driver-side power window main switch connector.
11. Install in the reverse order of removal.

Scheme 144

1. Disassemble in the order shown in the figure. (Scheme 144): Identifying Front Door Trim Components (Driver-Side)
2. Assemble in the reverse order of disassembly.

Scheme 145

1. Disassemble in the order shown in the figure. (Scheme 145): Identifying Front Door Trim Components (Passenger-Side)
2. Assemble in the reverse order of disassembly.

Scheme 146

Scheme 147

Scheme 148

Scheme 149

Scheme 150

Scheme 151

Scheme 152

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
2. Move the hook in the direction of arrow shown in the figure using a tape-lapped flathead screwdriver and detach it from the rear door trim. (Scheme 146): Moving Hook Using Tape-Lapped Flathead Screwdriver CAUTION: Affix protective tape to the rear door trim and assist handle cover to prevent damage.
3. Pull the cover of inner handle and remove it while detaching tabs. (Scheme 147): Pulling Cover Of Inner Handle
4. Remove the screws. (Scheme 148): Identifying Screws
5. Pull in the direction of the arrow (1), (2), (3) shown in the figure and remove clips from the door inner panel using a fastener remover. (Scheme 149): Removing Clips From Door Inner Panel Using Fastener Remover
6. Remove the rear door trim in the direction of the arrow shown in the figure. (Scheme 150): Removing Rear Door Trim
7. Remove the inner handle and move the rear door trim in the direction of the arrow shown in the figure. (Scheme 151): Identifying Inner Handle And Tabs
8. Turn the inner handle 90° in the direction of the arrow and remove it from the rear door trim. (Scheme 152): Turning Inner Handle
9. Disconnect the power window subswitch connector.
10. Install in the reverse order of removal.

Scheme 153

Scheme 154

1. Remove the trunk mat in the direction of arrow shown in the figure. (Scheme 153): Removing Trunk Mat
2. Remove the trunk board in the direction of arrow shown in the figure. (Scheme 154): Removing Trunk Board
3. Install in the reverse order of removal.

Scheme 155

Scheme 156

1. Detach tab while pulling the liftgate upper trim in the direction of the arrow (1) shown in the figure, then detach clips and pin while pulling in the direction of the arrow (2). (Scheme 155): Pulling Liftgate Upper Trim
2. Detach tab while pulling the liftgate upper trim in the direction of the arrow (3) shown in the figure, then detach clip while pulling in the direction of the arrow (4). (Scheme 156): Pulling Liftgate Upper Trim
3. Remove the liftgate upper trim.
4. Install in the reverse order of removal.

Scheme 157

Scheme 158

Scheme 159

1. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S18879345672013010300000).)
2. Pull the point A of the strap hanger as shown in the figure. (Scheme 157): Pulling Point A Of Strap Hanger
3. Remove the strap hanger.
4. Remove the fastener.
5. Pull the liftgate side trim in the direction of arrow then remove clip A. (Scheme 158): Pulling Liftgate Side Trim
6. Detach tab B and C while pulling the liftgate side trim in the direction of the arrow (1) shown in the figure, then detach hook D while pulling in the direction of the arrow (2). (Scheme 159): Pulling Liftgate Side Trim Of Tab B And C
7. Install in the reverse order of removal.

Scheme 160

Scheme 161

1. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S18879345672013010300000).)
2. Remove the liftgate side trim. (See «LIFTGATE SIDE TRIM REMOVAL/INSTALLATION»(ref-520454-S30167869222013010300000).)
3. Remove the screw and fasteners. (Scheme 160): Identifying Liftgate Lower Trim, Screw And Fasteners
4. Pull the liftgate lower trim in the direction of arrow (1), (2), (3), then detach clips A, B, pin C and D from the liftgate. (Scheme 161): Pulling Liftgate Lower Trim
5. Remove the liftgate lower trim.
6. Install in the reverse order of removal.

Scheme 162

1. Remove the fasteners, then remove the trunk lid trim. (Scheme 162): Removing Trunk Lid Trim And Fasteners
2. Install in the reverse order of removal.

Scheme 163

Scheme 164

1. Insert a flathead screwdriver into the service hole and remove the assist handle covers. (Scheme 163): Inserting Flathead Screwdriver Into Service Hole And Assist Handle Covers
2. Remove the assist handle in the direction of the arrow (1) and (2), while detach the clip. (Scheme 164): Removing Assist Handle NOTE: Remove the assist handle by shaking it up and down.

Scheme 165

Scheme 166

1. Push the assist handle in the direction of the arrow shown in the figure. (Scheme 165): Pushing Assist Handle
2. Push the assist handle cover assembled to install the assist handle. (Scheme 166): Pushing Assist Handle Cover

Scheme 167

Scheme 168

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
2. Remove the screw.
3. Rotate the sunvisor in the direction of the arrow.
4. Unhook and remove the sunvisor. (Scheme 167): Rotating Sunvisor
5. Disconnect the vanity mirror illumination connector. (Vehicles with vanity mirror illumination)
6. Press the center adaptor tabs as shown in the figure using two tape-wrapped flathead screwdrivers, and remove the center adaptor. (Scheme 168): Pressing Center Adaptor Tabs
7. Install in the reverse order of removal.

Scheme 169

Scheme 170

Scheme 171

Scheme 172

1. Shift to the D (ATX) or 4th gear (MTX) position. (4SD)
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
3. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-520457-S25870967302013010300000) )
4. Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
5. Partially peel back the seaming welts.
6. Remove the following parts: Sunroof seaming welt (vehicles with sunroof) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S23919795892013010300000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-520454-S26286324672013010300000).) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S38556519212013010300000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S00144206272013010300000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S04870739352013010300000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).) Trunk side upper trim (5HB) (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S29808716532013010300000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S26302889922013010300000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-520371-S41700704732013010300000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-520454-S00315961612013010300000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-520454-S22445118832013010300000).)
7. Disconnect the microphone connecter. (Vehicles with headliner installation type)
8. Disconnect the roof wiring harness connector and remove the roof wiring harness connector clip from the body.
9. Disconnect the rear washer hose. (5HB)
10. Remove the fasteners. (Scheme 169): Identifying Headliner And Fasteners (4SD) (Scheme 170): Identifying Headliner And Fasteners (5HB)
11. Take the headliner out from the opened front passenger-side door. (4SD) (Scheme 171): Opening Headliner Out From Front Passenger-Side Door (4SD)
12. Take the headliner out from the opened liftgate. (5HB) (Scheme 172): Opening Headliner Out From Liftgate (5HB)
13. Install in the reverse order of removal.

FIRE EXTINGUISHER INSTALLATION [Arab Gulf Cooperation Council]

Scheme 173

Scheme 174

Scheme 175

Scheme 176

Scheme 177

1. Switch the ignition to off.
2. Disconnect the negative battery cable and wait 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
3. Remove the following parts: Front seat (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-520455-S27188652042013010300000).) Audio amplifier (Vehicles with Bose ® ) (See «AUDIO AMPLIFIER REMOVAL/INSTALLATION»(ref-520392-S15767337652013010300000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-520454-S10636860092013010300000).)
4. Partially peel back the floor covering. (See «FLOOR COVERING REMOVAL/INSTALLATION»(ref-520454-S14981383852013010300000).)
5. Cut the passenger-side rear heater duct cover shown in the figure. CAUTION: When cutting out the portion of the passenger-side rear heat duct, do not cut it outside of the indicated area shown in the figure. Otherwise, the airflow passage could be damaged and cause the air from the heater to leak. (Scheme 173): Cutting Out Portion Of Passenger-Side Rear Heat Duct
6. Drill a 7 mm {0.3 in} diameter hole at the point shown in the figure. (Scheme 174): Drilling Diameter Hole At Point
7. Return the floor covering to its original position and open the slit at the position shown in the figure. (Scheme 175): Identifying Slit Location
8. Install in the order shown in the figure. (Scheme 176): Identifying Bracket Assembly Components
9. Apply silicone sealant to the shaded area on the under body as shown in the figure. (Scheme 177): Applying Silicone Sealant To Shaded Area On Under Body
10. Install the following parts: Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-520454-S10636860092013010300000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Audio amplifier (Vehicles with Bose ® ) (See «AUDIO AMPLIFIER REMOVAL/INSTALLATION»(ref-520392-S15767337652013010300000).) Front seat (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-520455-S27188652042013010300000).)

Scheme 178

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
2. Remove the following parts: Front seat (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-520455-S27188652042013010300000).) Audio amplifier (Vehicles with Bose ® ) (See «AUDIO AMPLIFIER REMOVAL/INSTALLATION»(ref-520392-S15767337652013010300000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Joint cover (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-520445-S38694288302013010300000).) (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-520445-S21804587892013010300000).) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-520454-S10636860092013010300000).) Fuel-filler lid opener lever bezel (See «FUEL-FILLER LID OPENER BEZEL REMOVAL/INSTALLATION»(ref-520454-S10366609462013010300000).) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-520491-S31259650412013010300000).)) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-520487-S22617144462013010300000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-520488-S03861652532013010300000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-520490-S28221261652013010300000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-520489-S37301789532013010300000).) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-520454-S17814587652013010300000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-520454-S17124509942013010300000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-520454-S11769586082013010300000).) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-520454-S28438507612013010300000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) Lower anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S38556519212013010300000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S00144206272013010300000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-520454-S26286324672013010300000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).)
3. Remove fasteners A and B. (Scheme 178): Identifying Floor Covering With Fasteners
4. Take the floor covering out from the opened door.
5. Install in the reverse order of removal.
