Assembly Procedure
- Install the snap ring.
- Install the one-way clutch No.1 to the front internal gear in the direction of the arrow (on the one-way clutch) as shown in the figure.
- Install the side race.
- Install the one-way clutch retainer.
Scheme 72
Scheme 73
- Disassemble in the order indicated in the table.
- Assemble in the reverse order of disassembly.
Scheme 74
Scheme 75
Scheme 76
- Measure the spring free length. Servo return spring (Standard) SERVO RETURN SPRING SPECIFICATIONS Outer diameter mm {in} Free length mm {in} No. of coils Wire diameter mm {in} 34.0 {1.340} 36.4 {1.430} 2.5 4.0 {0.160} If not as specified, replace the spring.
- Install the servo return spring to the transaxle case.
- Install the servo piston to the transaxle case.
- Apply ATF to new O-ring and install it to the transaxle case. O-ring inner diameter 70.2 mm {2.76 in}
- Install the servo retainer by tightening the bolts evenly and gradually. Tightening torque 11-14 N.m {113-142 kgf.cm, 97.4-123 in.lbf}
Scheme 77
- Perform the preinspection before disassembly. (See «LOW AND REVERSE BRAKE PREINSPECTION»(ref-345239-S18116009942009102000000) .)
- Disassemble in the order indicated in the table.
- Assemble in the reverse order of disassembly.
Scheme 78
- Install the SSTs as shown. CAUTION: Depress the one-way clutch inner race only enough to remove the snap ring. Overpressing will damage the one-way clutch inner race assembly edges.
- Compress the one-way clutch inner race.
- Remove the snap ring.
- Remove the SSTs and remove one-way clutch inner race and the piston return spring.
