Air Bag System: Removal & Installation Mazda 3 BL рестайлинг

Airbag 31 illustrations ~3678 words

DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]

WARNINGHandling the air bag module improperly can accidentally deploy the air bag module, which may seriously injure you. Read the air bag system service warnings and cautions before handling the air bag module. (See AIR BAG SYSTEM SERVICE WARNINGS .)(See AIR BAG SYSTEM SERVICE CAUTIONS .)

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14
  1. Switch the ignition to off.
  2. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Remove the covers. (Scheme 13): Identifying Driver-Side Air Bag Module Covers And Bolts With Torque Specifications
  4. Remove the bolts.
  5. Using a flathead screwdriver, lift the locking device carefully, however do not remove it. (Scheme 14): Lifting Locking Device Using Flathead Screwdriver
  6. Disconnect the air bag module connector.
  7. Disconnect the horn switch connector.
  8. Remove the driver-side air bag module.
  9. Install in the reverse order of removal.
  10. Switch the ignition to ON.
  11. Verify that the air bag system warning light illuminates for approx. 6 s and goes out. If the air bag system warning light does not operate normally, refer to the on-board diagnostic system (air bag system) and perform inspection of the system. (See «FLOWCHART [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520480-S33114248592013010300000).)

DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]

WARNINGHandling the air bag module improperly can accidentally deploy the air bag module, which may seriously injure you. Read the air bag system service warnings and cautions before handling the air bag module. (See AIR BAG SYSTEM SERVICE WARNINGS .)(See AIR BAG SYSTEM SERVICE CAUTIONS .) Due to the adoption of 2-step deployment control in the driver-side air bag module, depending on the impact force, it is possible that inflator No.2 might not deploy. In such cases, before disposing of the air bag module, make sure to follow the inflator deployment procedures and verify complete deployment of inflators No.1 and 2.

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16
  1. Switch the ignition to off.
  2. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Remove the covers. (Scheme 15): Identifying Driver-Side Air Bag Module Covers And Bolts With Torque Specifications
  4. Remove the bolts.
  5. Using a flathead screwdriver, lift the locking device carefully, however do not remove it. (Scheme 16): Lifting Locking Device Using Flathead Screwdriver
  6. Disconnect the air bag module connector.
  7. Disconnect the horn switch connector.
  8. Remove the driver-side air bag module.
  9. Install in the reverse order of removal.
  10. Switch the ignition to ON.
  11. Verify that the air bag system warning light illuminates for approx. 6 s and goes out. If the air bag system warning light does not operate normally, refer to the on-board diagnostic system (air bag system) and perform inspection of the system. (See «FLOWCHART [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520481-S15536989102013010300000).)

PASSENGER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]

WARNINGHandling the air bag module improperly can accidentally deploy the air bag module, which may seriously injure you. Read the air bag system service warnings and cautions before handling the air bag module. (See AIR BAG SYSTEM SERVICE WARNINGS .) (See AIR BAG SYSTEM SERVICE CAUTIONS .)

Note. When replacing the passenger-side air bag module after the deployment, replace it together with the mid-wiring harness. When installing the mid-wiring harness, install it along the vehicle wiring harness using bands or tape.

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18
  1. Switch the ignition to off.
  2. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Remove the following parts: Passenger-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Passenger-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-520454-S10636860092013010300000).) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-520454-S21271611252013010300000).) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-520454-S00904275812013010300000).) Passenger-side lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-520454-S41081192382013010300000).) SIRIUS satellite radio unit (with SIRIUS satellite radio system) (See «SIRIUS SATELLITE RADIO UNIT REMOVAL/INSTALLATION»(ref-520392-S00355049552013010300000).)
  4. Disconnect the connector. (Scheme 17): Identifying Passenger-Side Air Bag Module Connector, Screws And Bolts With Torque Specifications
  5. Remove the screws.
  6. Remove the bolts.
  7. Pull the passenger-side air bag module in the direction of arrow (1) and detach the hook A from the instrument panel. (Scheme 18): Identifying Passenger-Side Air Bag Module Pulling Direction
  8. Pull the passenger-side air bag module in the direction of arrow (2) and detach the hook B from the instrument panel and remove it.
  9. Install in the reverse order of removal.
  10. Switch the ignition to ON.
  11. Verify that the air bag system warning light illuminates for approx. 6 s and goes out. If the air bag system warning light does not operate, refer to the on-board diagnostic system (air bag system) and perform inspection of the system. (See «FLOWCHART [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520480-S33114248592013010300000).)

PASSENGER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]

WARNINGHandling the air bag module improperly can accidentally deploy the air bag module, which may seriously injure you. Read the air bag system service warnings and cautions before handling the air bag module. (See AIR BAG SYSTEM SERVICE WARNINGS .) (See AIR BAG SYSTEM SERVICE CAUTIONS .) Due to the adoption of 2-step deployment control in the passenger-side air bag module, depending on the impact force, it is possible that inflator No.2 might not deploy. In such cases, before disposing of the air bag module, make sure to follow the inflator deployment procedures and verify complete deployment of inflators No.1 and 2.

Note. When replacing the passenger-side air bag module after the deployment, replace it together with the mid-wiring harness. When installing the mid-wiring harness, install it along the vehicle wiring harness using bands or tape.

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20
  1. Switch the ignition to off.
  2. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Remove the following parts: Passenger-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Passenger-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-520454-S10636860092013010300000).) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-520454-S21271611252013010300000).) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-520454-S00904275812013010300000).) Passenger-side lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-520454-S41081192382013010300000).) SIRIUS satellite radio unit (with SIRIUS satellite radio system) (See «SIRIUS SATELLITE RADIO UNIT REMOVAL/INSTALLATION»(ref-520392-S00355049552013010300000).)
  4. Disconnect the connector. (Scheme 19): Identifying Passenger-Side Air Bag Module Connector, Screws And Bolts With Torque Specifications
  5. Remove the screws.
  6. Remove the bolts.
  7. Pull the passenger-side air bag module in the direction of arrow (1) and detach the hook A from the instrument panel. (Scheme 20): Identifying Passenger-Side Air Bag Module Pulling Direction
  8. Pull the passenger-side air bag module in the direction of arrow (2) and detach the hook B from the instrument panel and remove it.
  9. Install in the reverse order of removal.
  10. Switch the ignition to ON.
  11. Verify that the air bag system warning light illuminates for approx. 6 s and goes out. If the air bag system warning light does not operate, refer to the on-board diagnostic system (air bag system) and perform inspection of the system. (See «FLOWCHART [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520481-S15536989102013010300000).)

SIDE AIR BAG MODULE REMOVAL/INSTALLATION

WARNINGHandling the air bag module improperly can accidentally operate (deploy) the air bag module, which may seriously injure you. Read the air bag system service warnings and cautions before handling the air bag module. (See AIR BAG SYSTEM SERVICE WARNINGS .) (See AIR BAG SYSTEM SERVICE CAUTIONS .) If the side air bag module is installed with debris in the seat back, the foreign material may be scattered when the side air bag module operates (deploys), causing injury. Verify that there is no foreign material in the seat back before installing the side air bag module.

Scheme 21

Scheme 21
Scheme 21
  1. Switch the ignition to off.
  2. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Remove the front seat. (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-520455-S27188652042013010300000).)
  4. Remove the front seat back trim and front seat back pad. (See «FRONT SEAT BACK TRIM REMOVAL/INSTALLATION»(ref-520455-S15960907792013010300000).)
  5. Remove the bands. (Scheme 21): Identifying Bands, Nuts And Side Air Bag Module With Torque Specifications
  6. Remove the nuts.
  7. Remove the side air bag module.
  8. Install in the reverse order of removal.
  9. Switch the ignition to ON.
  10. Verify that the air bag system warning light illuminates for approx. 6 s and goes out. If the air bag system warning light does not operate normally, refer to the on-board diagnostic system (air bag system) and perform inspection of the system. (See «FLOWCHART [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520480-S33114248592013010300000).) (See «FLOWCHART [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520481-S15536989102013010300000).)

CURTAIN AIR BAG MODULE REMOVAL/INSTALLATION

WARNINGHandling the air bag module improperly can accidentally deploy the air bag module, which may seriously injure you. Read the air bag system service warnings and cautions before handling the air bag module. (See AIR BAG SYSTEM SERVICE WARNINGS .)(See AIR BAG SYSTEM SERVICE CAUTIONS .)

Scheme 22

Scheme 22: 4SD
Scheme 22: 4SD

Scheme 23

Scheme 23
Scheme 23
  1. Switch the ignition to off.
  2. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Partially peel back the seaming welt.
  4. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-520457-S25870967302013010300000) )
  5. Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
  6. Remove the following parts: Sunroof seaming welt (vehicles with sunroof system) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S23919795892013010300000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-520454-S26286324672013010300000).) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S38556519212013010300000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S00144206272013010300000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S04870739352013010300000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S26302889922013010300000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-520371-S41700704732013010300000).) Interior light (See «INTERIOR LIGHT REMOVAL/INSTALLATION»(ref-520371-S28645724232013010300000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-520454-S00315961612013010300000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-520454-S22445118832013010300000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-520454-S33729404272013010300000).)
  7. Disconnect the connector (harness side). (Scheme 22): Identifying Hook, Clips, Curtain Air Bag Module And Connector (Harness Side) With Torque Specifications (Scheme 23): Identifying Locking Device, Connector (Inflator Side), Hook And Clips With Torque Specifications
  8. Disconnect the connector (inflator side).
  9. Remove the clip A. (See «CLIP REMOVAL NOTE»(ref-520390-S15709621342013010300000).)
  10. Remove the bolt A.
  11. Pull hook A in the direction shown in the figure and remove it from the body.
  12. Remove the clip B. (See «CLIP REMOVAL NOTE»(ref-520390-S15709621342013010300000).)
  13. Remove the bolt B.
  14. Pull hook B in the direction shown in the figure and remove it from the body.
  15. Remove the clip C. (See «CLIP REMOVAL NOTE»(ref-520390-S15709621342013010300000).)
  16. Remove the bolt C.
  17. Pull hook C in the direction shown in the figure and remove it from the body.
  18. Remove the curtain air bag module.
  19. Install in the reverse order of removal.
  20. When the switch the ignition to ON verify that the air bag system warning light illuminates for approx. 6 s and goes out. If the air bag system warning light does not operate normally, refer to the on-board diagnostic system (air bag system) and perform inspection of the system. (See «FLOWCHART [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520480-S33114248592013010300000).) (See «FLOWCHART [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520481-S15536989102013010300000).)

Scheme 24

Scheme 24: 5HB
Scheme 24: 5HB

Scheme 25

Scheme 25
Scheme 25
  1. Switch the ignition to off.
  2. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Partially peel back the seaming welt.
  4. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-520457-S25870967302013010300000) )
  5. Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
  6. Remove the following parts: Sunroof seaming welt (vehicles with sunroof system) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S23919795892013010300000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-520454-S26286324672013010300000).) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S38556519212013010300000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S00144206272013010300000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S04870739352013010300000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).) Trunk side upper trim (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S29808716532013010300000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S26302889922013010300000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-520371-S41700704732013010300000).) Interior light (See «INTERIOR LIGHT REMOVAL/INSTALLATION»(ref-520371-S28645724232013010300000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-520454-S00315961612013010300000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-520454-S22445118832013010300000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-520454-S33729404272013010300000).)
  7. Remove the fastener. (Scheme 24): Identifying Curtain Air Bag Module And Connector (Harness Side)
  8. Disconnect the connector (harness side). (Scheme 25): Identifying Locking Device, Connector (Inflator Side), Hook And Clips With Torque Specifications
  9. Disconnect the connector (inflator side).
  10. Remove the clip A. (See «CLIP REMOVAL NOTE»(ref-520390-S15709621342013010300000).)
  11. Remove the bolt A.
  12. Pull hook A in the direction shown in the figure and remove it from the body.
  13. Remove the clip B. (See «CLIP REMOVAL NOTE»(ref-520390-S15709621342013010300000).)
  14. Remove the bolt B.
  15. Pull hook B in the direction shown in the figure and remove it from the body.
  16. Remove the clip C. (See «CLIP REMOVAL NOTE»(ref-520390-S15709621342013010300000).)
  17. Remove the bolt C.
  18. Pull hook C in the direction shown in the figure and remove it from the body.
  19. Remove the curtain air bag module.
  20. Install in the reverse order of removal.
  21. When the switch the ignition to ON verify that the air bag system warning light illuminates for approx 6 s and goes out. If the air bag system warning light does not operate normally, refer to the on-board diagnostic system (air bag system) and perform inspection of the system. (See «FLOWCHART [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520480-S33114248592013010300000).) (See «FLOWCHART [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520481-S15536989102013010300000).)

Scheme 26

Scheme 26: Clip Removal Note
Scheme 26: Clip Removal Note

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28
  1. Pull out the pin with flathead screwdriver as shown in the figure. (Scheme 26): Pulling Out Pin With Flathead Screwdriver
  2. Insert a flathead screwdriver into shown in the figure. (Scheme 27): Inserting Flathead Screwdriver
  3. While pulling the curtain air bag in the direction of the arrow shown in the figure (1), detach tabs by prying with a flathead screwdriver in the direction of the arrow (2) (3). (Scheme 28): Detaching Tabs By Prying With Flathead Screwdriver
  4. Remove the clip from the body.

CRASH ZONE SENSOR REMOVAL/INSTALLATION

WARNINGHandling the crash zone sensor improperly can accidentally deploy the air bags and pre-tensioner seat belts, which may seriously injure you. Read the air bag system service warnings and cautions before handling the crash zone sensor. (See AIR BAG SYSTEM SERVICE WARNINGS .) (See AIR BAG SYSTEM SERVICE CAUTIONS .)

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30
  1. Switch the ignition to off.
  2. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Remove the aerodynamic under cover No.2. (See «AERODYNAMIC UNDER COVER NO.2 REMOVAL/INSTALLATION»(ref-520448-S37186396192013010300000).)
  4. Remove the aerodynamic under cover No.1. (See «AERODYNAMIC UNDER COVER NO.1 REMOVAL/INSTALLATION»(ref-520448-S27288731052013010300000).)
  5. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-520458-S33419321672013010300000).)
  6. Remove the bolt (Scheme 29): Identifying Crash Zone Sensor, Bolt, Nut And Cover With Torque Specifications
  7. Remove the cover.
  8. Disconnect the connector from the crash zone sensor by pressing the connector tab in the direction of the arrow. (Scheme 30): Disconnecting Connector From Crash Zone Sensor By Pressing Connector Tab In Direction
  9. Remove the nut.
  10. Remove the crash zone sensor.
  11. Install in the reverse order of removal.
  12. Switch the ignition to ON.
  13. Verify that the air bag system warning light illuminates for approx. 6 s and goes out. If the air bag system warning light does not operate normally, refer to the on-board diagnostic system (air bag system) and perform inspection of the system. (See «FLOWCHART [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520480-S33114248592013010300000).) (See «FLOWCHART [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520481-S15536989102013010300000).)

SAS CONTROL MODULE REMOVAL/INSTALLATION

WARNINGHandling the SAS control module or air bag module improperly can accidentally deploy the air bag modules and pre-tensioner seat belt, which may seriously injure you. Read the air bag system service warnings and cautions before handling the air bag module. (See AIR BAG SYSTEM SERVICE WARNINGS .) (See AIR BAG SYSTEM SERVICE CAUTIONS .) If the connector is connected and the switch the ignition to ON with the SAS control module not secured completely using the installation nuts, the SAS control module may detect a degree of impact even when something contacts it lightly, deploying the air bag module and pre-tensioner seat belt accidentally. If the DSC sensor initialization procedure is not completed, it could result in an unexpected accident due to the DSC being inoperative. Therefore, after the SAS control module is replaced, always perform the DSC sensor initialization procedure to ensure proper DSC operation.
CAUTIONWhen replacing the SAS control module, always perform the configuration procedure before removing the SAS control module. If the configuration is not performed and the SAS control module is removed, DTC B2477 will be displayed.

Scheme 31

Scheme 31
Scheme 31
  1. Perform SAS control module configuration when replacing it. (See «SAS CONTROL MODULE CONFIGURATION»(ref-520390-S25314182892013010300000).)
  2. Switch the ignition to off.
  3. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  4. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-520454-S17814587652013010300000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-520487-S22617144462013010300000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-520488-S03861652532013010300000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-520490-S28221261652013010300000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-520489-S37301789532013010300000).) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-520491-S31259650412013010300000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-520454-S17124509942013010300000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-520454-S11769586082013010300000).) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-520454-S28438507612013010300000).)
  5. Partially peel back the floor covering. (Scheme 31): Identifying SAS Control Module, Connectors And Bolts With Torque Specifications
  6. Disconnect the connectors.
  7. Remove the bolts.
  8. Remove the SAS control module.
  9. Install in the reverse order of removal. (See «SAS CONTROL MODULE INSTALLATION NOTE»(ref-520390-S20542056082013010300000).)
  10. Switch the ignition to ON.
  11. Verify that the air bag system warning light illuminates for approx. 6 s and goes out. If the air bag system warning light does not operate normally, refer to the on-board diagnostic system (air bag system) and perform inspection of the system. (See «FLOWCHART [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520480-S33114248592013010300000).) (See «FLOWCHART [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520481-S15536989102013010300000).)
  12. After installation, perform the DSC sensor initialization procedure. (See «DSC SENSOR INITIALIZATION PROCEDURE»(ref-520479-S26624882962013010300000).) (Vehicles with DSC)

Scheme 32

Scheme 32: SAS Control Module Installation Note
Scheme 32: SAS Control Module Installation Note
  1. Install the SAS control module and temporarily tighten bolts in the order of A, B and C. (Scheme 32): Identifying SAS Control Module Bolts Tightening Order
  2. Tighten the bolts completely with the specified torque in the order of A, B and C. Tightening torque 9-12 N.m {92-122 kgf.cm, 80-106 in.lbf}

SEAT WEIGHT SENSOR CONTROL MODULE REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]

CAUTIONWhen the seat weight sensor control module is replaced with a new one, perform the seat weight sensor calibration using the M-MDS. (See SEAT WEIGHT SENSOR CALIBRATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM] .)

Scheme 33

Scheme 33
Scheme 33
  1. Switch the ignition to off.
  2. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Disconnect the connectors. (Scheme 33): Identifying Seat Weight Sensor Control Module, Connectors, Bracket And Tab
  4. Remove the seat weight sensor control module from the bracket by lifting the tab in the direction of the arrow.
  5. Install in the reverse order of removal.
  6. Switch the ignition to ON.
  7. Verify that the air bag system warning light illuminates for approx. 6 s and goes out. If the air bag system warning light does not operate normally, refer to the on-board diagnostic system (air bag system) and perform inspection of the system. (See «FLOWCHART [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520481-S15536989102013010300000).)

SEAT WEIGHT SENSOR REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]

CAUTIONWhen the seat weight sensor is replaced with a new one, perform the seat weight sensor calibration using the M-MDS. (See SEAT WEIGHT SENSOR CALIBRATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM] .)
  1. When replacing the seat weight sensor, replace it together with the passenger-side seat slide adjuster (because seat weight sensor is integrated with passenger-side seat slide adjuster). (See «FRONT SEAT SLIDE ADJUSTER REMOVAL/INSTALLATION»(ref-520455-S05114472112013010300000) .)

SIDE AIR BAG SENSOR REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]

WARNINGHandling the side air bag sensor improperly can accidentally operate (deploy) the air bag module, which may seriously injure you. Read the air bag system service warnings and cautions before handling the side air bag sensor. (See AIR BAG SYSTEM SERVICE WARNINGS .) (See AIR BAG SYSTEM SERVICE CAUTIONS .)

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35
  1. Switch the ignition to off.
  2. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Remove the front scuff plate. (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).)
  4. Remove the rear scuff plate. (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).)
  5. Remove the B-pillar lower trim. (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-520454-S26286324672013010300000).)
  6. Remove the nut. (Scheme 34): Identifying Side Air Bag Sensor, Connector And Nut With Torque Specifications
  7. Remove the side air bag sensor.
  8. Disconnect the connector from the side air bag sensor by pressing the connector tab in the direction of the arrow. (Scheme 35): Disconnecting Connector From Side Air Bag Sensor By Pressing Connector Tab
  9. Install in the reverse order of removal.
  10. Switch the ignition to ON.
  11. Verify that the air bag system warning light illuminates for approx. 6 s and goes out. If the air bag system warning light does not operate normally, refer to the on-board diagnostic system (air bag system) and perform inspection of the system. (See «FLOWCHART [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520480-S33114248592013010300000).)

SIDE AIR BAG SENSOR NO. 1 REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]

WARNINGHandling the side air bag sensor improperly can accidentally operate (deploy) the air bag module, which may seriously injure you. Read the air bag system service warnings and cautions before handling the side air bag sensor. (See AIR BAG SYSTEM SERVICE WARNINGS .) (See AIR BAG SYSTEM SERVICE CAUTIONS .)

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37
  1. Switch the ignition to off.
  2. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Remove the front scuff plate. (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).)
  4. Remove the rear scuff plate. (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).)
  5. Remove the B-pillar lower trim. (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-520454-S26286324672013010300000).)
  6. Remove the nut. (Scheme 36): Identifying Side Air Bag Sensor No.1, Connector And Nut With Torque Specifications
  7. Remove the side air bag sensor No.1.
  8. Disconnect the connector from the side air bag sensor No.1 by pressing the connector tab in the direction of the arrow. (Scheme 37): Disconnecting Connector From Side Air Bag Sensor No.1 By Pressing Connector Tab
  9. Install in the reverse order of removal.
  10. Switch the ignition to ON.
  11. Verify that the air bag system warning light illuminates for approx. 6 s and goes out. If the air bag system warning light does not operate normally, refer to the on-board diagnostic system (air bag system) and perform inspection of the system. (See «FLOWCHART [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520481-S15536989102013010300000).)

SIDE AIR BAG SENSOR NO. 2 REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]

WARNINGHandling the side air bag sensor improperly can accidentally operate (deploy) the air bag module, which may seriously injure you. Read the air bag system service warnings and cautions before handling the side air bag sensor. (See AIR BAG SYSTEM SERVICE WARNINGS .) (See AIR BAG SYSTEM SERVICE CAUTIONS .)

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39
  1. Switch the ignition to off.
  2. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Remove the following parts: Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).) Rear seat back (See «REAR SEAT BACK REMOVAL/INSTALLATION»(ref-520455-S28972805732013010300000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).)
  4. Remove the nut. (Scheme 38): Identifying Side Air Bag Sensor No.2, Connector And Nut With Torque Specifications
  5. Remove the side air bag sensor No.2.
  6. Disconnect the connector from the side air bag sensor No.2 by pressing the connector tab in the direction of the arrow. (Scheme 39): Disconnecting Connector From Side Air Bag Sensor No.2 By Pressing Connector Tab
  7. Install in the reverse order of removal.
  8. Switch the ignition to ON.
  9. Verify that the air bag system warning light illuminates for approx. 6 s and goes out. If the air bag system warning light does not operate normally, refer to the on-board diagnostic system (air bag system) and perform inspection of the system. (See «FLOWCHART [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520481-S15536989102013010300000).)

Scheme 40

Scheme 40: PRESSURE SENSOR REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]
Scheme 40: PRESSURE SENSOR REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]

Scheme 41

Scheme 41
Scheme 41
  1. Switch the ignition to off.
  2. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-520454-S32815572972013010300000).)
  4. Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-520454-S34560758062013010300000).)
  5. Remove the bolts. (Scheme 40): Identifying Pressure Sensor, Connector And Bolts With Torque Specifications
  6. Remove the pressure sensor.
  7. Disconnect the connector from the pressure sensor by pressing the connector tab and pulling out the lock lever in the direction of the arrow. (Scheme 41): Disconnecting Connector From Pressure Sensor By Pressing Connector Tab When connecting the pressure sensor connector, insert the lock lever (connector disconnection prevention lever) completely.
  8. Install in the reverse order of removal.
  9. Switch the ignition to ON.
  10. Verify that the air bag system warning light illuminates for approx. 6 s and goes out. If the air bag system warning light does not operate normally, refer to the on-board diagnostic system (air bag system) and perform inspection of the system. (See «FLOWCHART [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520481-S15536989102013010300000).)

Scheme 42

Scheme 42: CLOCK SPRING REMOVAL/INSTALLATION
Scheme 42: CLOCK SPRING REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the driver-side air bag module. (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520390-S30398979032013010300000).) (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520390-S38458334842013010300000).)
  3. Remove the steering wheel. (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-520445-S38694288302013010300000).)(See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-520445-S21804587892013010300000).)
  4. Remove the column cover.
  5. Remove the connectors. (Scheme 42): Identifying Steering Angle Sensor, Clock Spring, Screws And Tab Removal Direction
  6. Remove the tab direction of the arrow shown in the figure.
  7. Remove the screws.
  8. Remove the clock spring.
  9. Remove the steering angle sensor (See «STEERING ANGLE SENSOR REMOVAL NOTE»(ref-520390-S19553739262013010300000).)
  10. Install in the reverse order of removal.
  11. Verify that the air bag system warning light illuminates for approx. 6 s and goes out. If the air bag system warning light does not operate in the manner described above, there are malfunctions in the system. Inspect the system using the on-board diagnostic.

Clock Spring Installation Note

CAUTIONIf the clock spring is not adjusted, the spring wire in the clock spring will break due to overtension when the steering wheel is turned. Always adjust the clock spring after installing it.
  1. Adjust the clock spring after installing it. (See «CLOCK SPRING ADJUSTMENT»(ref-520390-S25690891452013010300000) .)

Scheme 43

Scheme 43: Steering Angle Sensor Removal Note
Scheme 43: Steering Angle Sensor Removal Note
  1. Remove the tab shown in the figure and remove the steering angle sensor. (Scheme 43): Locating Tab And Steering Angle Sensor

PASSENGER AIR BAG DEACTIVATION (PAD) INDICATOR LIGHT BULB REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]

Note. The PAD indicator light (LED) is built into the multi information display/information display.

  1. Remove the information display. (With information display) (See «INFORMATION DISPLAY REMOVAL/INSTALLATION»(ref-520387-S03721336672013010300000) .)
  2. Remove the multi information display. (With multi information display) (See «MULTI INFORMATION DISPLAY REMOVAL/INSTALLATION»(ref-520387-S06200430132013010300000) .)

More articles — Air Bag System
