REAR WASHER NOZZLE CLEANING
- Clean the rear washer nozzle. (See «WINDSHIELD WASHER NOZZLE CLEANING»(ref-345242-S12699610372009102000000) ).
Scheme 41
Scheme 42
- Disconnect the negative battery cable.
- Slightly bend back the mudguard (RH).
- Disconnect the rear washer hose A from the washer tank.
- Remove rear washer hose A from clips A.
- Remove A-pillar trim (RH). (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345251-S39724553262009102000000) .)
- Remove the glove compartment. (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-345251-S25078258972009102000000) )
- Remove the dashboard garnish. (See «DASHBOARD GARNISH REMOVAL/INSTALLATION»(ref-345251-S34296068682009102000000) )
- Disconnect joint pipe, then remove the rear washer hose A.
- Remove rear washer hose B from the clips B.
- Remove the following parts: Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-345252-S37398683842009102000000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-345251-S03552764762009102000000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-345251-S34770097052009102000000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-345251-S05968899652009102000000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-345251-S07634143762009102000000) .) Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-345253-S19841861632009102000000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-345251-S27657366472009102000000) .) Trunk side upper trim (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-345251-S21725102922009102000000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345251-S18929710872009102000000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-345247-S18086223702009102000000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-345251-S06443361722009102000000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-345251-S14925466612009102000000) .)
- Disconnect the joint pipe B.
- Remove the headliner. (See «HEADLINER REMOVAL/INSTALLATION»(ref-345251-S16496888782009102000000) )
- Remove rear washer hose B and the tapes.
- Remove clips C from the body.
- Disconnect the joint pipe C, then remove rear washer hose C.
- Remove rear washer hose D from the rear washer nozzle.
- Install in the reverse order of removal.
RAIN SENSOR INITIALIZATION SETTING
| CAUTION | Rain sensor initialization is performed when it is newly replaced and when its previously programmed setting is modified due to the reflection rate change caused by the replacement of the windshield. |
- The reflection rate at the moment the ignition switch is first turned on after replacing the rain sensor with a new one is stored as the condition indicating zero precipitation on the windshield. Therefore, before turning on the ignition switch, remove water and dirt from the windshield.
Rain Sensor Reinitialization Setting
- Remove water and dirt from the windshield surface.
- Turn the ignition switch off.
- Turn the windshield wiper switch to the AUTO position.
- Perform the windshield wiper switch operation (AUTO-->OFF-->AUTO) five times within 10 s after turning the ignition switch to the ON position. CAUTION: If the operation is too fast, the windshield wiper switch position cannot be detected and the reinitialization may not be preformed. Operate the windshield wiper switch one cycle every 1 s.
- Verify that the windshield wipers operate at low speed. If the windshield wipers do not operate at low speed, perform the rain sensor reinitialization again.
Note. When the reinitialization is performed correctly, the windshield wipers operate once at low speed.
