Symptom Troubleshooting (Power Window System): Diagnosis Mazda 3 BL

Windows 3 illustrations

SYMPTOM TROUBLESHOOTING CHART [POWER WINDOW SYSTEM]

No.Malfunction Symptom
1NO.1 THE AUTO OPEN FUNCTION ON THE DRIVER'S SIDE POWER WINDOW IS INOPERATIVE [POWER WINDOW SYSTEM]
2NO.2 THE DRIVER'S SIDE POWER WINDOW IS INOPERATIVE [POWER WINDOW SYSTEM]
3NO.3 ALL POWER WINDOWS OTHER THAN DRIVER'S SIDE DO NOT OPERATE USING THE POWER WINDOW SUBSWITCH [POWER WINDOW SYSTEM]
4NO.4 ALL POWER WINDOWS OTHER THAN DRIVER'S SIDE DO NOT OPERATE USING THE POWER WINDOW MAIN SWITCH [POWER WINDOW SYSTEM]
5NO.5 ALL POWER WINDOWS ARE INOPERATIVE [POWER WINDOW SYSTEM]
6NO.6 DOOR GLASS REVERSES EVEN THOUGH THE GLASS DOES NOT ENCOUNTER A FOREIGN OBJECT WHILE IT IS MOVING UP IN AUTOMATIC MODE [POWER WINDOW SYSTEM]
7NO.7 ABNORMAL NOISE WHILE THE DOOR GLASS IS OPENING OR CLOSING [POWER WINDOW SYSTEM]

SYMPTOM TROUBLESHOOTING CHART

Scheme 3

Scheme 3: POWER WINDOW SYSTEM WIRING DIAGRAM [POWER WINDOW SYSTEM]

Manual Open/close Function Inspection

STEPINSPECTIONACTION
1Turn the ignition switch to the ON position. Operate the power window using the manual open/close function on the power window main switch. Does the power window operate properly?YesGo to the next step.
NoInspect the power window main switch and the wiring harness. Repair or replace malfunctioning parts.
2Set the power cut switch to the UNLOCK position. Operate the power window using the power window subswitch. Does the power window operate properly?YesGo to the next step.
NoInspect the power window subswitch and the wiring harness. Repair or replace malfunctioning parts.
3Set the power cut switch to the LOCK position. Operate all power windows other than the driver side. Does the power window operate properly?YesInspect the power cut switch and the wiring harness. Replace the power window main switch.
NoManual open/close function is normal. Perform the auto open/close function inspection.

MANUAL OPEN/CLOSE FUNCTION - DIAGNOSTIC PROCEDURE CHART

Auto Open Function (Driver's Side) Inspection

STEPINSPECTIONACTION
1Turn the ignition switch to the ON position. Operate the power window using the auto open function on the power window main switch. Does the power window operate properly?YesGo to the next step.
NoGo to NO.1 THE AUTO OPEN FUNCTION ON THE DRIVER'S SIDE POWER WINDOW IS INOPERATIVE [POWER WINDOW SYSTEM] .
2Operate the power window main switch to the close position while the power window is opening. Does the power window operation stop?YesAuto open function is normal.
NoReplace the power window main switch (power window control unit is malfunctioning.)

AUTO OPEN FUNCTION - DIAGNOSTIC PROCEDURE CHART

Diagnostic procedure

STEPINSPECTIONACTION
1Perform the Auto Open Function (Driver's side) Inspection in the POWER WINDOW SYSTEM PRELIMINARY INSPECTION. (See POWER WINDOW SYSTEM PRELIMINARY INSPECTION [POWER WINDOW SYSTEM] ). Is the malfunctioning part detected?YesRepair or replace malfunctioning part according to inspection results.
NoGo to NO.2 THE DRIVER'S SIDE POWER WINDOW IS INOPERATIVE .

DIAGNOSTIC PROCEDURE CHART

STEPINSPECTIONACTION
1Turn the ignition switch to the ON position. Does the LED on the power window main switch illuminate?YesGo to Step 4.
NoGo to the next step.
2Operate all power windows other than the driver's side window using the power window main switch. Does the power window operate properly?YesGo to the next step.
NoInspect for an open or short circuit in the following wiring harnesses. Inspect the connector connections (damage/pulled-out pins, corrosion): P/WIND L 30A fuse (at PJB)-PJB terminal AO-Power window main switch terminal E Power window main switch terminal L-ground. Repair or replace if necessary.
3Is the P/WIND L 30 A fuse (at PJB) normal?YesReplace the power window main switch. (See POWER WINDOW MAIN SWITCH REMOVAL/INSTALLATION .)
NoInspect the following: Short circuit in B+ power supply wiring harness Short circuit in power window motor Repair or replace if necessary. Replace with the appropriate standard fuse.
4Measure the voltage at the power window main switch, (power window motor output terminal) while operating the power window using the power window main switch. Is the voltage B+? (Open: terminal E/close: terminal N)YesGo to the next step.
NoReplace the power window main switch. (See POWER WINDOW MAIN SWITCH REMOVAL/INSTALLATION .)
5Measure the voltage at the power window motor, (battery power supply terminal) while operating the power window using the power window motor. Is the voltage B+? (Open: terminal E/close: terminal F)YesGo to the next step.
NoInspect for an open or short circuit in the wiring harness between the power window main switch and the power window motor. Inspect the power window main switch and power window motor connector connections, (damage/pulled-out pins, corrosion) Repair or replace if necessary.
6Operate the driver's side power window using the power window main switch. Does the power window motor operate (rotate)? CAUTION: If the power window motor temperature is high, the motor may not rotate due to the motor internal bimetal function. Leave it untouched for about 3 min to cool it down, then reinspect.YesGo to the next step.
NoReplace the power window motor. (See POWER WINDOW MOTOR REMOVAL/INSTALLATION .)
7Remove the door glass from the carrier plate. Make sure that the door glass moves smoothly using your hand. Does the door glass move smoothly?YesReplace the power window regulator. (See FRONT POWER WINDOW REGULATOR REMOVAL/INSTALLATION .)
NoInspect for a bent regulator guide or other possible malfunction. If normal, replace the door glass run-channel.
CAUTION
If the power window motor temperature is high, the motor may not rotate due to the motor internal bimetal function. Leave it untouched for about 3 min to cool it down, then reinspect.

DIAGNOSTIC PROCEDURE CHART

STEPINSPECTIONACTION
1Turn the ignition switch to the ON position. Set the power cut-switch to the UNLOCK position. Measure the voltage at power window subswitch terminal A. Is the voltage B+?YesReplace the power window subswitch. (See POWER WINDOW SUBSWITCH REMOVAL/INSTALLATION .)
NoInspect for an open or short circuit in the wiring harness between PJM terminal AO (left rear), terminal AN (right front, right rear) and the power window subswitch. Inspect the power window subswitch connector connection, (damage/pulled-out pins, corrosion) Repair or replace if necessary.

DIAGNOSTIC PROCEDURE CHART

STEPINSPECTIONACTION
1Turn the ignition switch to the ON position. Set the power cut-switch to the UNLOCK position. Operate all power windows other than the driver's side using the power window main switch. Do any power windows operate?YesReplace the power window main switch. (See POWER WINDOW MAIN SWITCH REMOVAL/INSTALLATION .)
NoInspect for an open or short circuit in the power window main switch wiring harness (battery power supply). Inspect the power window main switch connector connection, (damage/pulled-out pins, corrosion) Repair or replace if necessary.

DIAGNOSTIC PROCEDURE

STEPINSPECTIONACTION
1Turn the ignition switch to the ON position. Set the power cut-off switch to the UNLOCK position. Inspect the power window system operation again. Does the system operate properly?YesSystem is now normal (power cut-off switch is not set properly.)
NoGo to the next step.
2Operate all power windows other than driver's side window using the power window main switch. Does any power window operate?YesGo to Step 5.
NoGo to the next step.
3Operate the driver's side power window using the power window main switch. Does the power window operate?YesGo to the next step.
NoInspect for an open circuit in the wiring harness between the power window main switch and the body ground. Inspect the power window main switch connector connection, (damage/pulled-out pins, corrosion) Repair or replace if necessary
4Are P/WIND L 30A fuse and P/WIND R 30A fuse (at PJB) normal?YesReplace the power window main switch. (See POWER WINDOW MAIN SWITCH REMOVAL/INSTALLATION .)
NoReplace with the appropriate standard fuse. If the fuse is melted, inspect the wiring harness for a short to ground. Repair or replace the wiring harness, then replace the fuse.
5Identify the inoperative power window. Measure the voltage at the suspect power window motor (battery power supply) while operating the power window motor using the suspect power window subswitch Is the voltage B+? (Open: terminal E/close: terminal F)YesGo to the next step.
NoGo to Step 8.
6Operate the power window using the power window subswitch Does the power window motor operate (rotate)? CAUTION: If the power window motor temperature is high, the motor may not rotate due to the motor internal bimetal function. Leave it untouched for about 3 min to cool it down, then reinspect.YesGo to the next step.
NoReplace the power window motor. (See POWER WINDOW MOTOR REMOVAL/INSTALLATION .)
7Remove the door glass from the carrier plate. Make sure that the door glass moves smoothly using your hand. Does the door glass move smoothly?YesReplace the power window regulator guide.
NoInspect for a bent regulator guide or other possible malfunction. If normal, replace the glass run channel
8Measure the voltage at the power window subswitch (power window motor output) while operating the power window subswitch. Is the voltage B+? (Open: terminal F/close: terminal C)YesInspect for an open or short circuit in the wiring harness between the power window subswitch and power window motor Inspect the power window subswitch and power window motor connector connections, (damage/pulled-out pins, corrosion) Repair or replace if necessary.
NoGo to the next step.
9NOTE: Do not operate the power window subswitch during the following inspection. Inspect the continuity between power window subswitch terminal D (vehicle harness-side) and ground. Is there continuity?YesGo to the next step.
NoInspect for an open or short circuit in the power window subswitch wiring harness. Inspect the power window subswitch connector connection, (damage/pulled-out pins, corrosion) Repair or replace if necessary. Then go to Step 12.
10NOTE: Do not operate the power window subswitch during the following inspection. Inspect the continuity between power window subswitch terminal E and ground. Is there continuity?YesReplace the power window subswitch. (See POWER WINDOW SUBSWITCH REMOVAL/INSTALLATION .)
NoInspect for an open or short circuit in the power window subswitch wiring harness. Inspect the power window subswitch connector connection, (damage/pulled-out pins, corrosion) Repair or replace if necessary. Then go to the next step.
11NOTE: Do not operate the power window main switch during the following inspection. Inspect the continuity between the power window main switch terminal (up-side A, D, K) and ground. Is there continuity?YesGo to the next step.
NoReplace the power window main switch. (See POWER WINDOW MAIN SWITCH REMOVAL/INSTALLATION .)
12NOTE: Do not operate the power window main switch during the following inspection. Inspect the continuity between the power window main switch terminal (down-side B, C, M) and ground. Is there continuity?YesInspect for an open or short circuit in the wiring harness between the power window main switch and power window subswitch. Inspect the power window main switch and subswitch connector connections, (damage/pulled-out pins, corrosion) Repair or replace if necessary.
NoReplace the power window main switch. (See POWER WINDOW MAIN SWITCH REMOVAL/INSTALLATION .)
CAUTION
If the power window motor temperature is high, the motor may not rotate due to the motor internal bimetal function. Leave it untouched for about 3 min to cool it down, then reinspect.
NOTE
Do not operate the power window subswitch during the following inspection.
NOTE
Do not operate the power window subswitch during the following inspection.
NOTE
Do not operate the power window main switch during the following inspection.
NOTE
Do not operate the power window main switch during the following inspection.

DIAGNOSTIC PROCEDURE CHART

STEPINSPECTIONACTION
1INSPECT MALFUNCTION SYMPTOM Does the malfunction symptom occur only under the following special conditions?: Driving over railroad tracks Driving on bumpy roads. Opening/closing the door.YesThe system is normal (Explain to the customer that this does not indicate a malfunction because the system is designed to reverse the door glass while it is closing if it receives vibration when the vehicle is crossing railroad tracks, driving on a bumpy road, or when the door is opened/closed.)
NoGo to the next step.
2INSPECT ACRYLIC DOOR VISOR INSTALLATION CONDITION Is the acrylic door visor normal?YesGo to the next step.
NoInstall the side visor properly, then go to the next step.
3INSPECT DOOR GLASS CLOSING SPEED Affix tape to the rear edge of the door glass as shown in the figure for placing marks (to facilitate seeing the door glass movement) Start the engine and idle it (to ensure a stabilized operational voltage). Does the door glass hesitate only once while its closing?YesMark the point where the door glass closing speed changed, then go to Step 5.
NoGo to the next step.
4REINSPECT DOOR GLASS CLOSING SPEED Does the door glass hesitate periodically (5-6 times) while it is closing?YesReplace the power window motor, then go to Step 8 (See POWER WINDOW MOTOR REMOVAL/INSTALLATION .)
NoGo to Step 8.
5INSPECT GLASS RUN CHANNEL AND DOOR GLASS SLIDING SURFACE Is there an object caught between the glass run channel and the door glass, or is there roughness on the sliding surface (rubber surface)?YesObject is caught between glass run channel and door glass: Remove the object. Roughness on the sliding surface (rubber surface): Replace the glass run channel. After performing one of the above actions, reinspect. If the malfunction is not corrected, go to Step 3.
NoGo to the next step.
6INSPECT TIGHTENING OF DOOR GLASS TO CARRIER PLATE Is it normal?YesGo to the next step.
NoAfter tightening correctly, reinspect. If the malfunction is not corrected, go to Step 3.
7INSPECT CONDITION OF GLASS RUN CHANNEL AND DOOR GLASS Is it normal?YesGo to the next step.
NoAssemble the glass run channel and door glass securely, and reinspect. If the malfunction is not corrected, go to Step 3.
8INSPECT DOOR GLASS CLOSING SPEED Does the door glass hesitate at any location?YesRepeat the inspection from Step 3.
NoTroubleshooting completed.

DIAGNOSTIC PROCEDURE CHART

Scheme 4

Scheme 4
Noise typeTime of occurrencePossible causeLocation of noiseAction
Clanking noiseDoor glass begins to moveInsufficiently tightened installation screw between the door glass and carrier plate.Between door glass lower edge and carrier plate.Securely tighten the installation screw.
Groaning noise (Sound increases due to use)While door glass is operatingVibration caused by wear on the resin part from cable twisting due to use of the power window regulator. NOTE: Noise does not occur if a roller is equipped to power window regulator resin part.Power window regulatorReplace the power window regulator (See FRONT POWER WINDOW REGULATOR REMOVAL/INSTALLATION .) (See REAR POWER WINDOW REGULATOR REMOVAL/INSTALLATION .)
Whining noiseGear inside power window motor is deformed due to use.Gear in power window motorReplace the power window motor (See POWER WINDOW MOTOR REMOVAL/INSTALLATION .)
Clicking noise (Periodic noise)
NOTE
Noise does not occur if a roller is equipped to power window regulator resin part.

DIAGNOSTIC PROCEDURE CHART

Scheme 5

Scheme 5
