Sunroof: Overview Mazda 3 BL

Scheme 1

Scheme 2

Scheme 3

1. Fully close the glass panel.
2. Fully open the sunshade.
3. Remove the screws, then remove the glass panel.
4. Remove the weatherstrip from the glass panel.
5. Install in the reverse order of removal.
6. Adjust the glass panel. (See «GLASS PANEL ADJUSTMENT»(ref-345322-S02306890272009102000000) ).

Scheme 4

Scheme 5

1. Fully close the glass panel.
2. Measure the gap and height difference between the glass panel and the body.
3. Loosen the glass panel installation screws and move the glass panel to adjust. Standard clearance a: 0.2-2.2 mm {0.008-0.08 in} b: 0 mm {0 in}
4. Tighten the screws.
5. Insert any available thin plastic card between the weatherstrip and the body, and verify that they are sealed. (There is resistance when the plastic card is moved.) If they are not sealed, perform Steps 3 - 4 and adjust again.

Scheme 6

1. Disconnect the negative battery cable.
2. Remove the following parts: Console (4 door) (See «CONSOLE REMOVAL/INSTALLATION»(ref-345251-S09223885732009102000000) .) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345251-S39724553262009102000000) .) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-345252-S37398683842009102000000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-345251-S03552764762009102000000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-345251-S34770097052009102000000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-345251-S05968899652009102000000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-345251-S07634143762009102000000) .) Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-345253-S19841861632009102000000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-345251-S27657366472009102000000) .) Trunk side upper trim (5 door) (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-345251-S21725102922009102000000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345251-S18929710872009102000000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-345247-S18086223702009102000000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-345251-S06443361722009102000000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-345251-S14925466612009102000000) .) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-345251-S16496888782009102000000) .) Head impact pad (See «HEAD IMPACT PAD REMOVAL/INSTALLATION»(ref-345251-S14579443612009102000000) .) Glass panel (See «GLASS PANEL REMOVAL/INSTALLATION»(ref-345322-S37585938512009102000000) ).
3. Disconnect the front and rear drain hoses from the sunroof frame.
4. Remove the bolts and nuts, then remove the sunroof unit.
5. Install in the reverse order of removal.
6. Adjust the glass panel. (See «GLASS PANEL ADJUSTMENT»(ref-345322-S02306890272009102000000) ).

Scheme 7

1. Disassemble in the order indicated in the table.
2. Assemble in the reverse order of disassembly.
