Lighting Systems: Other Mazda 3 BL

DISCHARGE HEADLIGHT CONTROL MODULE REUSE

1. If the discharge headlight control module is dented or damaged in any way, replace the module with a new one to prevent electrical shock and improper operation.
2. Although the control module may temporarily operate normally even though it has received an impact, it is possible that the interior may have been damaged. When reusing the control module, inspect the following items regarding discharge headlight illumination to verify that there are no malfunctions. Verify that the discharge headlights illuminate normally by testing them several times under cold illumination (headlights off for approx. 10 min or more and then turned on) and hot illumination (headlights on for approx. 15 min or more, turned off for approx. 1 min, and then turned on again) conditions. Inspect the headlight illumination in the period from directly after cold illumination until they are uniformly illuminated (approx. 5 min) and verify that there is no flickering or inconsistent brightness. Turn on the headlights for approx. 30 min with normal condition bulbs and verify that there is no brightness difference between the right and left, and that illumination is consistent.

Discharge type

Scheme 77

1. Disconnect the negative battery cable.
2. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-345250-S24816571422009102000000) .)
3. Remove the front combination light. (See «FRONT COMBINATION LIGHT REMOVAL/INSTALLATION»(ref-345247-S24862070912009102000000) ).
4. Remove the cover. CAUTION: The bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When replacing the bulb, hold the metal flange, not the glass.
5. Remove the connector, then remove the discharge headlight bulb.
6. Install in the reverse order of removal.

Scheme 78

1. Disconnect the negative battery cable.
2. Disconnect the connector. CAUTION: A halogen bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When replacing the bulb, hold the metal flange, not the glass.
3. Remove the socket, then remove the headlight bulb.
4. Install in the reverse order of removal.

Discharge Headlight Inoperative

Scheme 79
