Seat Belt System: Other Mazda 3 BL

Restraints Control Systems 8 illustrations ~309 words

ALR

  1. Pull the belt out fully to change the lock mode from ELR to ALR.
  2. Verify that retractor makes a clicking sound as the belt slowly retracts. If no sound is heard, the lock mode has not changed to ALR. If necessary, repeat Step 1 . If there is any malfunction, replace the seat belt.
  3. Verify that the retractor locks when pulled. If there is any malfunction, replace the seat belt.
  4. Verify that the lock mode changes to ELR when the belt is fully pulled out. If there is any malfunction, replace the seat belt.

Load Limiter Retractor

WARNINGWhen the load limiter operates, the belt and anchor rub against each other strongly leaving wear tracks. If the seat belt is used in this state, the seat belt will not function at its full capability and there is the possibility of serious injury to passengers. Be sure to replace the seat belt once the load limiter operates.

Scheme 10

Scheme 10
  1. If the vehicle has been subjected to a shock in an accident, pull the belt from the retractor and confirm that there are no wear tracks (the load limiter has not operated) by visually inspecting and feeling the belt. If there is any malfunction, replace the seat belt.

Scheme 11

Scheme 11: FRONT BUCKLE REMOVAL/INSTALLATION

Scheme 12

Scheme 12
  1. Turn the ignition switch to the LOCK position.
  2. Disconnect the negative battery cable.
  3. Remove the front seat. (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-345253-S02590681772009102000000) .)
  4. Detach the tab as shown in the figure and remove the connector from the front seat connector.
  5. 5 Remove in the order indicated in the table.
  6. Install in the reverse order of removal.

Scheme 13

Scheme 13: REAR BUCKLE REMOVAL/INSTALLATION
  1. Remove the rear seat cushion. (See «REAR SEAT REMOVAL/INSTALLATION»(ref-345253-S19841861632009102000000) .)
  2. Remove in the order indicated in the table.
  3. Install in the reverse order of removal.

Scheme 14

Scheme 14: FRONT BUCKLE INSPECTION

Scheme 15

Scheme 15
  1. Inspect for continuity between the buckle switch terminals using a tester. If not as indicated in the table, replace the front buckle.

Scheme 16

Scheme 16: 4 door
  1. Remove in the order indicated in the table.
  2. Install in the reverse order of removal.

Scheme 17

Scheme 17: 5 door
  1. Remove the trunk end trim. (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-345251-S18838859652009102000000) .)
  2. Remove in the order indicated in the table.
  3. Install in the reverse order of removal.
