Engine Mechanical - Overhaul - 2.0L & 2.3L: Other Mazda 3 BL

DISMOUNTING

1. Dismount in the reverse order of mounting.

Scheme 124

1. Disassemble in the order indicated in the figure.

Scheme 125

1. Hold the crankshaft using the SST .
2. Remove the crankshaft pulley lock bolt.

Scheme 126

1. Remove the oil seal using a screwdriver.

Scheme 127

1. Unlock the chain tensioner ratchet using a suitable screw driver or equivalent tool.
2. Slowly press the tensioner piston.
3. Hold the chain tensioner piston with a 1.5 mm {0.06 in} wire or paper clip.

Scheme 128

1. Hold the oil pump sprocket using the SST .

Scheme 129

1. Disassemble in the order indicated in the figure.

Scheme 130

Scheme 131

1. Hold the camshaft by using a wrench on the cast hexagon as shown, and loosen the camshaft sprocket installation bolt or variable valve timing actuator installation bolt (L3). LF L3

Scheme 132

1. Before removing the camshaft caps, inspect the following: Camshaft end play and camshaft journal oil clearance (See «CAMSHAFT INSPECTION»(ref-345199-S04386703032009102000000) .)
2. Loosen the camshaft caps bolts in 2-3 passes in the order shown in the figure.

ENGINE SST

Engine SST identification example

1. Mazda SST number
2. Global SST number

Scheme 133

Scheme 134
