FUSE SERVICE CAUTIONS
| CAUTION | Determine and correct the cause of the burnt fuse before replacing it with the specified type. If the fuse is replaced before doing this, it may burn again. |
Scheme 2
- Disconnect the negative battery cable.
- Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-345251-S35932273802009102000000) .)
- Remove in the order indicated in the table.
- Install in the reverse order of removal.
Scheme 3
- Rotate the lever in the direction of the arrow and remove the connector.
Scheme 4
- After connecting the connector, rotate the lever in the direction of the arrow to install the connector.
Scheme 5
Scheme 6
- Verify that the continuity between the ignition switch terminals is as indicated in the table. If not as indicated in the table, replace the ignition switch.
Scheme 7
Relay type
| Terminal type | Part name | |
|---|---|---|
| 4 terminals | Type A | A/C relay AT main relay Injector driver relay Drive-by-wire relay Horn relay Rear window defroster relay Front fog light relay Headlight cleaner relay (except L3 with TC) DRL relay (except L3 with TC) Fuel pump relay Fuel pump relay No.2 |
| Type B | Main relay Starter relay Blower relay Rear washer relay DRL relay (L3 with TC) Headlight cleaner relay (L3 with TC) | |
RELAY TYPE
Scheme 8
Scheme 9
- Verify the continuity between the relay terminals. If not as indicated in the table, replace the relay.
Scheme 10
Scheme 11
- Verify the continuity between the relay terminals. If not as indicated in the table, replace the relay.
