General Information: Other Mazda 3 BL

Range of Topics

1. This manual contains procedures for performing all required service operations. The procedures are divided into the following five basic operations: Removal/Installation Disassembly/Assembly Replacement Inspection Adjustment
2. Simple operations which can be performed easily just by looking at the vehicle (i.e., removal/installation of parts, jacking, vehicle lifting, cleaning of parts, and visual inspection) have been omitted.

Scheme 22

1. Inspection and adjustment procedures are divided into steps. Important points regarding the location and contents of the procedures are explained in detail and shown in the illustrations.

Scheme 23

1. Most repair operations begin with an overview illustration. It identifies the components, shows how the parts fit together, and describes visual part inspection. However, only removal/installation procedures that need to be performed methodically have written instructions.
2. Expendable parts, tightening torques, and symbols for oil, grease, and sealant are shown in the overview illustration. In addition, symbols indicating parts requiring the use of special service tools or equivalent are also shown.
3. Procedure steps are numbered and the part that is the main point of that procedure is shown in the illustration with the corresponding number. Occasionally, there are important points or additional information concerning a procedure. Refer to this information when servicing the related part.

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

1. There are eight symbols indicating oil, grease, fluids, sealant, and the use of SST or equivalent. These symbols show application points or use of these materials during service. SYMBOLS CHART Symbol Meaning Kind Apply oil New appropriate engine oil or gear Apply brake fluid New appropriate brake fluid Apply automatic transaxle/transmission fluid New appropriate automatic transaxle/transmission fluid Apply grease Appropriate grease Apply sealant Appropriate sealant Apply petroleum jelly Appropriate petroleum jelly Replace part O-ring, gasket, etc. Use SST or equivalent Appropriate tools

Advisory Messages

1. You will find several Warnings, Cautions, Notes, Specifications and Upper and Lower Limits in this manual.

Warning

1. A Warning indicates a situation in which serious injury or death could result if the warning is ignored.

Caution

1. A Caution indicates a situation in which damage to the vehicle or parts could result if the caution is ignored.

Note

1. A Note provides added information that will help you to complete a particular procedure.

Upper and lower limits

1. The values indicate the upper and lower limits that must not be exceeded when performing inspections or adjustments.

Scheme 29

UNITS

UNITS CHART

Conversion to SI Units (System International d'Unit<-- [eacute] -->As)

1. All numerical values in this manual are based on SI units. Numbers shown in conventional units are converted from these values.

Rounding Off

1. Converted values are rounded off to the same number of places as the SI unit value. For example, if the SI unit value is 17.2 and the value after conversion is 37.84, the converted value will be rounded off to 37.8.

1. When the data indicates upper and lower limits, the converted values are rounded down if the SI unit value is an upper limit and rounded up if the SI unit value is a lower limit. Therefore, converted values for the same SI unit value may differ after conversion. For example, consider 2.7 kgf/cm 2 in the following specifications: 210-260 kPa {2.1-2.7 kgf/cm 2 , 30-38 psi} 270-310 kPa {2.7-3.2 kgf/cm 2 , 39-45 psi}
2. The actual converted values for 2.7 kgf/cm 2 are 264 kPa and 38.4 psi. In the first specification, 2.7 is used as an upper limit, so the converted values are rounded down to 260 and 38. In the second specification, 2.7 is used as a lower limit, so the converted values are rounded up to 270 and 39.

Injury/damage Prevention Precautions

1. Depending on the vehicle, the cooling fan may operate suddenly even when the ignition switch is turned off. Therefore, keep hands and tools away from the cooling fan even if the cooling fan is not operating to prevent injury to personnel or damage to the cooling fan. Always disconnect the negative battery cable when servicing the cooling fan or parts near the cooling fan.

Scheme 30

1. Always be sure to cover fenders, seats and floor areas before starting work.

Scheme 31

1. Be sure that all necessary tools and measuring equipment are available before starting any work.

Scheme 32

1. Use special service tools or equivalent when they are required.

Disconnection of the Negative Battery Cable

1. When working with the negative battery cable disconnected, wait for 1 min or more to allow the back up power supply of the SAS control module to deplete its stored power after the cable is disconnected.
2. Disconnecting the battery cable will delete the memories of the clock, audio, and DTCs, etc. Therefore, it is necessary to note down the information stored in those memories before disconnecting the cable.
3. When the ignition switch is turned to the ON position with the negative battery cable connected, the car navigation unit starts program reading. To prevent a car navigation unit malfunction, do not start the engine while "Program reading. Do not turn the power off" is displayed on the screen ( approx. 10 sec. ).

Using UV light (black light)

1. Remove any oil on the engine or transaxle/transmission. NOTE: Referring to the fluorescent dye instruction manual, mix the specified amount of dye into the engine oil or ATF (or transaxle/transmission oil).
2. Pour the fluorescent dye into the engine oil or ATF (or transaxle/transmission oil).
3. Allow the engine to run for 30 min.
4. Inspect for dye leakage by irradiating with UV light (black light), and identify the type of oil that is leaking.
5. If no dye leakage is found, allow the engine to run for another 30 min. or drive the vehicle then reinspect.
6. Find where the oil is leaking from, then make necessary repairs. NOTE: To determine whether it is necessary to replace the oil after adding the fluorescent dye, refer to the fluorescent dye instruction manual.

Scheme 33

1. Gather some of the leaking oil using an absorbent white tissue.
2. Take samples of engine oil and ATF (or transaxle/transmission oil), both from the dipstick, and place them next to the leaked oil already gathered on the tissue.
3. Compare the appearance and smell, and identify the type of oil that is leaking.
4. Remove any oil on the engine or transaxle/transmission.
5. Allow the engine to run for 30 min.
6. Check the area where the oil is leaking, then make necessary repairs.

Scheme 34

1. While correcting a problem, also try to determine its cause. Begin work only after first learning which parts and subassemblies must be removed and disassembled for replacement or repair. After removing the part, plug all holes and ports to prevent foreign material from entering.

Scheme 35

1. If the disassembly procedure is complex, requiring many parts to be disassembled, all parts should be marked in a place that will not affect their performance or external appearance and identified so that reassembly can be performed easily and efficiently.

Scheme 36

1. When removed, each part should be carefully inspected for malfunction, deformation, damage and other problems.

Scheme 37

1. All disassembled parts should be carefully arranged for reassembly.
2. Be sure to separate or otherwise identify the parts to be replaced from those that will be reused.

Scheme 38

1. All parts to be reused should be carefully and thoroughly cleaned in the appropriate method. WARNING: Using compressed air can cause dirt and other particles to fly out causing injury to the eyes. Wear protective eye wear whenever using compressed air.

Scheme 39

Scheme 40

1. Standard values, such as torques and certain adjustments, must be strictly observed in the reassembly of all parts.
2. If removed, the following parts should be replaced with new ones: Oil seals Gaskets O-rings Lock washers Cotter pins Nylon nuts
3. Depending on location: Sealant and gaskets, or both, should be applied to specified locations. When sealant is applied, parts should be installed before sealant hardens to prevent leakage. Oil should be applied to the moving components of parts. Specified oil or grease should be applied at the prescribed locations (such as oil seals) before reassembly.

Scheme 41

1. Use suitable gauges and testers when making adjustments.

Scheme 42

1. Prevent gasoline or oil from getting on rubber parts or tubing.

Scheme 43

1. When reinstalling, position the hose clamp in the original location on the hose and squeeze the clamp lightly with large pliers to ensure a good fit.

Scheme 44

1. When using a torque wrench- SST or equivalent combination, the written torque must be recalculated due to the extra length that the SST or equivalent adds to the torque wrench. Recalculate the torque by using the following formulas. Choose the formula that applies to you. TORQUE FORMULAS Torque Unit Formula N.m N.m x [L/(L+A)] kgf.m kgf.m x [L/(L+A)] kgf.cm kgf.cm x [L/(L+A)] ft.lbf ft.lbf x [L/(L+A)] in.lbf in.lbf x [L/(L+A)] A: The length of the SST past the torque wrench drive. L: The length of the torque wrench.

Scheme 45

1. When using a vise, put protective plates in the jaws of the vise to prevent damage to parts.

Dynamometer

1. When inspecting and servicing the power train on the dynamometer or speed meter tester, pay attention to the following: Place a fan, preferably a vehicle-speed proportional type, in front of the vehicle. Make sure the vehicle is in a facility with an exhaust gas ventilation system. Since the rear bumper might deform from the heat, cool the rear with a fan. (Surface of the bumper must be below 70°C {158°F} degrees ). Keep the area around the vehicle uncluttered so that heat does not build up. Watch the water temperature gauge and don't overheat the engine. Avoid added load to the engine and maintain normal driving conditions as much as possible. NOTE: When only the front or rear wheels are rotated on a chassis dynamometer or equivalent, the ABS CM determines that there is a malfunction in the ABS and illuminates the following lights: Vehicles with ABS ABS warning light Brake system warning light Vehicles with DSC ABS warning light Brake system warning light DSC indicator light If the above lights are illuminated, dismount the vehicle from the chassis dynamometer and turn the ignition switch to the LOCK position. Then, turn the ignition switch back to the ON position, run the vehicle at 10 km/h or more and verify that the warning lights go out. In this case, a DTC will be stored in the memory. Clear the DTC from the memory by following the memory clearing procedure [ABS]/[DSC] in the on-board diagnostic system. (See «ON-BOARD DIAGNOSIS [ABS]»(ref-345282-S30452037932009102000000) .) (See «ON-BOARD DIAGNOSIS [DYNAMIC STABILITY CONTROL (DSC)]»(ref-345277-S06207214382009102000000) .)

SST

1. Some global SST or equivalent are used as SSTs necessary for engine repair. Note that these SSTs are marked with global SST numbers.
2. Note that a global SST number is written together with a corresponding Mazda SST number as shown below.

Scheme 46

Scheme 47

Direction of View for Connector

1. The viewing direction of connectors is indicated with a symbol.
2. The figures showing the viewing direction are the same as those used in Wiring Diagrams.
3. The viewing directions are shown in the following three ways

Part-side connector

The viewing direction of part-side connectors is from the terminal side.

*: Part names are shown only when there are multiple connector drawings.

Scheme 48

Other

When it is necessary to show the terminal side of vehicle harness-side connectors, such as the following connectors, the viewing direction is from the terminal side.

Scheme 49

1. Main fuse block and the main fuse block relays
2. Data link connector
3. Check connector
4. Relay box

Jumper wire

Scheme 50

1. A jumper wire is used to create a temporary circuit. Connect the jumper wire between the terminals of a circuit to bypass a switch.

Scheme 51

1. The DC voltmeter is used to measure circuit voltage. A voltmeter with a range of 15 V or more is used by connecting the positive (+) probe (red lead wire) to the point where voltage will be measured and the negative (-) probe (black lead wire) to a body ground.

Ohmmeter

Scheme 52

1. The ohmmeter is used to measure the resistance between two points in a circuit and to inspect for continuity and short circuits.

Precautions Before Welding

A vehicle has various electrical parts. To protect the parts from excessive current generated when welding, be sure to perform the following procedure.

Scheme 53

Scheme 54

1. Turn the ignition switch to the LOCK position.
2. Disconnect the battery cables.
3. Securely connect the welding machine ground near the welding area.
4. Cover the peripheral parts of the welding area to protect them from weld spatter.

Jacking Positions

1. Use safety stands to support the vehicle after it has been lifted.

Front

Note. To prevent obstruction between the jack body and front bumper when the jack body is inserted, use a low-floor type jack.

Scheme 55

1. Near the center of the front crossmember.

Rear

Scheme 56

1. At the center of the rear crossmember.

Front and rear

1. Both sides of the vehicle, on side sills.

Scheme 57

1. Both sides of the vehicle, on side sills.

Scheme 58

Scheme 59

Scheme 60

1. Proper lifting and towing are necessary to prevent damage to the vehicle. State and local laws must be followed.
2. A towed vehicle usually should have its front wheels off the ground. If excessive damage or other conditions prevent this, use wheel dollies.
3. When towing with the rear wheels on the ground, release the parking brake. CAUTION: Do not tow the vehicle pointed backward with driving wheel on the ground. This may cause internal damage to the transaxle. CAUTION: Do not tow with sling-type equipment. This could damage your vehicle. Use wheel-lift or flatbed equipment.

Tiedown Hooks

Note. When tiedown with chain or cable, wrap the chain or cable with a soft cloth near the bumper to prevent damage to the bumper.

Scheme 61

Scheme 62

Scheme 63

Scheme 64

1. Remove the tiedown eyelet from trunk.
2. Wrap a screwdriver or similar tool with a soft cloth to prevent damage to the painted bumper and open the cap located on the front bumper. CAUTION: The cap cannot be completely removed. Do not use excessive force as it may damage the cap or scratch the painted bumper surface.
3. Securely install the tiedown eyelet using the wheel brace.
4. Hook the tying rope to the tiedown eyelet. CAUTION: If the tiedown eyelet is not securely tightened, it may loosen or disengage from the bumper when tying down the vehicle. Make sure that the tiedown eyelet is securely tightened to the bumper. CAUTION: Do not use the hooks under the rear bumper for towing and tying down, as they cannot hold the load and it will damage the bumper.

Scheme 65

Scheme 66

Scheme 67

Scheme 68

SAE STANDARDS

1. In accordance with new regulations, SAE (Society of Automotive Engineers) standard names and abbreviations are now used in this manual. The table below lists the names and abbreviations that have been used in Mazda manuals up to now and their SAE equivalents. SAE STANDARDS SAE Standard Remark SAE Standard Remark Abbreviation Name Abbreviation Name AP Accelerator Pedal MAP Manifold Absolute Pressure APP Accelerator Pedal Position MAF sensor Mass Air Flow Sensor ACL Air Cleaner MFL Multiport Fuel Injection A/C Air Conditioning OBD On-board Diagnostic System BARO Barometric Pressure OL Open Loop B+ Battery Positive Voltage OC Oxidation Catalytic Converter CMP sensor Camshaft Position Sensor O2S Oxygen sensor CAC Charge Air Cooler PNP Park/Neutral Position CLS Closed Loop System PSP Power Steering Pressure CTP Closed Throttle Position PCM Powertrain Control Module (3) CPP Clutch Pedal Position PAIR Pulsed Secondary Air Injection Pulsed injection CIS Continuous Fuel Injection System CKP sensor Crankshaft Position Sensor AIR Secondary Air Injection Injection with air pump DLC Data Link Connector DTM Diagnostic Test Mode (1) DTC Diagnostic Test Code(s) SAPV Secondary Air Pulse Valve DI Distributor Ignition SFI Sequential Multiport Fuel Injection DLI Distributorless Ignition EI Electronic Ignition (2) 3GR Third Gear ECT Engine Coolant Temperature TWC Three Way Catalytic Converter EM Engine Modification TB Throttle Body EVAP Evaporative Emission TP sensor Throttle Position Sensor EGR Exhaust Gas Recirculation TCC Torque Converter Clutch FC Fan Control TCM Transmission (Transaxle) Control Module FF Flexible Fuel 4GR Fourth Gear TR Transmission (Transaxle) Range GEN Generator TC Turbocharger GND Ground VSS Vehicle Speed Sensor HO2S Heated Oxygen Sensor With heater VR Voltage Regulator VAF sensor Volume Air Flow Sensor IAC Idle Air Control WU-TWC Warm Up Three Way Catalytic Converter (4) IAT Intake Air Temperature KS Knock Sensor WOP Wide Open Throttle MIL Malfunction Indicator Lamp (1) Diagnostic trouble codes depend on the diagnostic test mode. (2) Controlled by the PCM (3) Device that controls engine and powertrain (4) Directly connected to exhaust manifold

Exterior

INSPECT and ADJUST , if necessary, the following items to specification

1. Glass, exterior bright metal and paint for damage
2. Wheel lug nuts
3. All weatherstrips for damage or detachment
4. Tire pressures
5. Headlight cleaner and fluid level (if equipped)
6. Operation of hood release and lock
7. Operation of trunk lid and fuel-filler lid opener
8. Door operation and alignment including side door and back door
9. Headlight aiming

INSTALL the following parts

1. Flap (if equipped)

Under hood-engine off

INSPECT and ADJUST , if necessary, the following items to specification

1. Fuel, engine coolant, and hydraulic lines, fittings, connections, and components for leaks
2. Engine oil level
3. Brake and clutch fluid level
4. Windshield washer reservoir fluid level
5. Coolant level and specific gravity
6. Tightness of water hose clamps
7. Tightness of battery terminals, electrolyte level and specific gravity
8. Tension of drive belt

Interior

INSTALL the following items

1. Fuse for accessories

INSPECT the operations of the following items

1. Seat controls (slide and recline) and headrests
2. Folding rear seat
3. Door locks, including childproof door locks
4. Seat belts and warning system
5. Ignition switch and steering lock
6. Transaxle range switch
7. Warning buzzers
8. Ignition key reminder alarm
9. Air bag system using warning light
10. Cruise control system (if equipped)
11. Power door lock
12. Shift-lock system (if equipped)
13. Starter interlock
14. All lights including warning, and indicator lights
15. Horn, wipers, and washers
16. Wiper blades performance

Clean wiper blades and windshield, if necessary

1. Audio system
2. Cigarette lighter and clock
3. Power windows (if equipped)
4. Heater, defroster, and air conditioner at various mode selections (if equipped)

INSPECT the following items

1. Presence of spare fuse
2. Upholstery and interior finish

INSPECT and ADJUST , if necessary, the following items

1. Operation and fit of windows
2. Pedal height and free play of clutch and brake pedal
3. Parking brake

Under hood-engine running at operating temperature

INSPECT the following items

1. Automatic transaxle fluid level
2. Operation of idle-up system for electrical load, air conditioner or power steering (if equipped)
3. Ignition timing
4. Idle speed
5. Operation of throttle position sensor

On hoist

INSPECT the following items

1. Manual transaxle oil level
2. Underside fuel, coolant and hydraulic lines, fittings, connections, and components for leaks
3. Tires for cuts or bruises
4. Steering linkage, suspension, exhaust system, and all underside hardware for looseness or damage

Schedule 1: Normal driving conditions (U.S.A. only)

1. The vehicle is mainly operated where none of the "unique driving conditions" apply. MAINTENANCE SCHEDULED CHART Maintenance Interval Number of months or kilometers (miles), whichever comes first Months 6 12 18 24 30 36 42 48 x1000 km 12 24 36 48 60 72 84 96 x1000 miles 7.5 15 22.5 30 37.5 45 52.5 60 ENGINE Engine valve clearance Audible inspect every 120,000 km (75,000 miles), if noisy, adjust Drive belts (tension) I Engine oil R R R R R R R R Engine oil filter R R R R R R R R COOLING SYSTEM Cooling system I I Engine coolant FL22 type (1) Replace at first 192,000 km (120,000 miles) or 10 years; after that, every 96,000 km (60,000 miles) or 5 years Others Replace at first 96,000 km (60,000 miles) or 4 years; after that, every 2 years FUEL SYSTEM Air cleaner element R Fuel lines and hoses (2) I I Hoses and tubes for emission (2) I IGNITION SYSTEM Spark plugs Replace every 120,000 km (75,000 miles) CHASSIS and BODY Brake lines, hoses and connections I I Disc brakes I I I I Tire (Rotation) Rotate every 12,000 km (7,500 miles) Steering operation and linkages I I Front and rear suspension, ball joints and wheel bearing axial play I I Driveshaft dust boots I I Exhaust system and heat shields Inspect every 72,000 km (45,000 miles) or 5 years All locks and hinges L L L L L L L L Bolts and nuts on chassis and body T T AIR CONDITIONER SYSTEM (if installed) Cabin air filter Replace every 40,000 km (25,000 miles) or 2 years Chart symbols I : Inspect and repair, clean, adjust, or replace if necessary. R : Replace L : Lubricate T : Tighten Remarks After the prescribed period, continue to follow the described maintenance at the recommended intervals. Refer below for a description of items marked* in the maintenance chart. (1) Use FL22 type coolant in vehicles with the inscription "FL22" on the radiator cap itself or the surrounding area. Use FL22 when replacing the coolant. (2) According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.

Schedule 2: Unique driving conditions (For U.S.A. unique conditions and CANADA/Puerto Rico all conditions)

1. Repeated, short-distance driving
2. Driving in dusty conditions
3. Driving with extended use of brakes
4. Driving in areas where salt or other corrosive materials are used
5. Driving on rough or muddy roads
6. Extended periods of idling or low-speed operation
7. Driving for long periods in cold temperatures or extremely humid climates MAINTENANCE SCHEDULED CHART Maintenance Interval Number of months or kilometers (miles), whichever comes first Months 4 8 12 16 20 24 28 32 36 40 44 48 x1000 km 8 16 24 32 40 48 56 64 72 80 88 96 x1000 miles 5 10 15 20 25 30 35 40 45 50 55 60 ENGINE Engine valve clearance Audible inspect every 120,000 km (75,000 miles), if noisy, adjust Drive belts (tension) I Engine oil Puerto Rico Replace every 5,000 km (3,000 miles) or 3 months Others R R R R R R R R R R R R Engine oil filter R R R R R R R R R R R R COOLING SYSTEM Cooling system I I Engine coolant FL22 type (1) Replace at first 192,000 km (120,000 miles) or 10 years; after that, every 96,000 km (60,000 miles) or 5 years Others Replace at first 96,000 km (60,000 miles) or 4 years; after that, every 2 years Engine coolant level I I I I I I I I I I I I FUEL SYSTEM Air cleaner element Puerto Rico R R Others R Fuel lines and hoses (2) I I Hoses and tubes for emission (2) I IGNITION SYSTEM Spark plugs (for LF/L3 engine) Replace every 120,000 km (75,000 miles) Spark plugs (for L3 WITH TC engine) USA Replace every 96,000 km (60,000 miles) Others (3) Replace every 120,000 km (75,000 miles) ELECTRICAL SYSTEM Function of all lights I I I I I I I I I I I I CHASSIS and BODY Brake lines, hoses and connections I I Brake and clutch fluid level I I I I I I I I I I I I Disc brakes I I I I Tire (Rotation) Rotate every 8,000 km (5,000 miles) Tire inflation pressure and tire wear I I I I I I I I I I I I Steering operation and linkages I I Power steering fluid level I I I I I I I I I I I I Front and rear suspension, ball joints and wheel bearing axial play I I Driveshaft dust boots I I Exhaust system and heat shields Inspect every 72,000 km (45,000 miles) or 5 years All locks and hinges L L L L L L L L L L L L Washer fluid level I I I I I I I I I I I I Bolts and nuts on chassis and body T T AIR CONDITIONER SYSTEM (if installed) Cabin air filter Replace every 40,000 km (25,000 miles) or 2 years Chart symbols I : Inspect and repair, clean, adjust, or replace if necessary. R : Replace L : Lubricate T : Tighten Remarks After the prescribed period, continue to follow the described maintenance at the recommended intervals. Refer below for a description of items marked* in the maintenance chart. (1) Use FL22 type coolant in vehicles with the inscription "FL22" on the radiator cap itself or the surrounding area. Use FL22 when replacing the coolant. (2) According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or mileage/kilometer period to ensure long-term reliability. (3) If the vehicle is operated under any of the following conditions, replace the spark plugs every 96,000 km (60,000 miles) or shorter. Repeated short-distance driving Extended periods of idling or low-speed operation Driving for long periods in cold temperatures or extremely humid climates

Schedule 1: Normal driving conditions

1. The vehicle is mainly operated where none of the "unique driving conditions" apply. MAINTENANCE SCHEDULED CHART Maintenance Interval Number of months or kilometers, whichever comes first Months 6 12 18 24 30 36 42 48 54 60 66 72 x1000 km 10 20 30 40 50 60 70 80 90 100 110 120 ENGINE Engine valve clearance Audible inspect every 120,000 km, if noisy, adjust Drive belts (tension) I I I Engine oil R R R R R R R R R R R R Engine oil filter R R R R R R R R R R R R COOLING SYSTEM Cooling system I I I Engine coolant FL22 type (1) Replace at first 190,000 km or 10 years; after that, every 60,000 km or 3 years Others Replace every 40,000 km or 2 years FUEL SYSTEM Air cleaner element R R R R R R Fuel lines and hoses I (2) I (2) I Hoses and tubes for emission I (2) I (2) I Fuel filter R R R IGNITION SYSTEM Spark plugs Replace every 60,000 km CHASSIS and BODY Brake lines, hoses and connections I I I I I I Brake and clutch fluid level I I I I I I I I I Brake fluid R R R Disc brakes I I I I I I I I I I I I Tire (Rotation) Rotate every 10,000 km Tire inflation pressure and tire wear I I I I I I I I I I I I Steering operation and linkages I I I I I I I I I I I I Power steering fluid level I I I I I I I I I I I I Front and rear suspension, ball joints and wheel bearing axial play I I I I I I Driveshaft dust boots I I I I I I Exhaust system and heat shields I I I I I I All locks and hinges L L L L L L L L L L L L Washer fluid level I I I I I I I I I I I I Bolts and nuts on chassis and body T T T T T T AIR CONDITIONER SYSTEM (if installed) Cabin air filter R R R Chart symbols: I : Inspect and repair, clean, adjust, or replace if necessary. R : Replace L : Lubricate C : Clean T : Tighten Remarks After the prescribed period, continue to follow the described maintenance at the recommended intervals. Refer below for a description of items marked* in the maintenance chart. (1) Use FL22 type coolant in vehicles with the inscription "FL22" on the radiator cap itself or the surrounding area. Use FL22 when replacing the coolant. (2) According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or kilometer period to ensure long-term reliability.

Schedule 2: Unique Driving Conditions

1. Repeated short-distance driving
2. Driving in dusty conditions
3. Driving with extended use of brakes
4. Driving in areas where salt or other corrosive materials are used
5. Driving on rough or muddy roads
6. Extended periods of idling or low-speed operation
7. Driving for long periods in cold temperatures or extremely humid climates
8. Driving in extremely hot conditions
9. Driving in mountainous conditions continually MAINTENANCE SCHEDULED CHART Maintenance Interval Number of months or kilometers, whichever comes first Months 3 6 9 12 15 18 21 24 27 30 33 36 x1000 km 5 10 15 20 25 30 35 40 45 50 55 60 ENGINE Engine valve clearance Audible inspect every 120,000 km, if noisy, adjust Drive belts (tension) I Engine oil R R R R R R R R R R R R Engine oil filter R R R R R R R R R R R R COOLING SYSTEM Cooling system I Engine coolant FL22 type (1) Replace at first 190,000 km or 10 years; after that, every 60,000 km or 3 years Others Replace every 40,000 km or 2 years Engine coolant level I I I I I I I I I I I I FUEL SYSTEM Air cleaner element C R C R C R Fuel lines and hoses I (2) Hoses and tubes for emission I (2) Fuel filter R IGNITION SYSTEM Spark plugs Replace every 60,000 km ELECTRICAL SYSTEM Function of all lights I I I I I I I I I I I I CHASSIS and BODY Brake lines, hoses and connections I I I Brake and clutch fluid level I I I I I Brake fluid R Disc brakes I I I I I I Tire (Rotation) Rotate every 10,000 km Tire inflation pressure and tire wear I I I I I I Steering operation and linkages I I I I I I Power steering fluid level I I I I I I Front and rear suspension, ball joints and wheel bearing axial play I I I Driveshaft dust boots I I I Exhaust system and heat shields I I I All locks and hinges L L L L L L Washer fluid level I I I I I I Bolts and nuts on chassis and body T T T AIR CONDITIONER SYSTEM (if installed) Cabin air filter R R R ENGINE Engine valve clearance Audible inspect every 120,000 km, if noisy, adjust Drive belts (tension) I I Engine oil R R R R R R R R R R R R Engine oil filter R R R R R R R R R R R R COOLING SYSTEM Cooling system I I Engine coolant FL22 type (1) Replace at first 190,000 km or 10 years; after that, every 60,000 km or 3 years Others Replace every 40,000 km or 2 years Engine coolant level I I I I I I I I I I I I FUEL SYSTEM Air cleaner element C R C R C R Fuel lines and hoses I (2) I Hoses and tubes for emission I (2) I Fuel filter R R IGNITION SYSTEM Spark plugs Replace every 60,000 km ELECTRICAL SYSTEM Function of all lights I I I I I I I I I I I I CHASSIS and BODY Brake lines, hoses and connections I I I Brake and clutch fluid level I I I I Brake fluid R R Disc brakes I I I I I I Tire (Rotation) Rotate every 10,000 km Tire inflation pressure and tire wear I I I I I I Steering operation and linkages I I I I I I Power steering fluid level I I I I I I Front and rear suspension, ball joints and wheel bearing axial play I I I Driveshaft dust boots I I I Exhaust system and heat shields I I I All locks and hinges L L L L L L Washer fluid level I I I I I I Bolts and nuts on chassis and body T T T AIR CONDITIONER SYSTEM (if installed) Cabin air filter R R R Chart symbols: I : Inspect and repair, clean, adjust, or replace if necessary. R : Replace L : Lubricate C : Clean T : Tighten Remarks After the prescribed period, continue to follow the described maintenance at the recommended intervals. Refer below for a description of items marked* in the maintenance chart. (1) Use FL22 type coolant in vehicles with the inscription "FL22" on the radiator cap itself or the surrounding area. Use FL22 when replacing the coolant. (2) According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or kilometer period to ensure long-term reliability.
