Interior Trim: Overview Mazda 3 BL

Scheme 28

Scheme 29

Scheme 30

Scheme 31

1. Disconnect the negative battery cable.
2. Remove the following parts: Front doors (See «FRONT DOOR REMOVAL/INSTALLATION» ) Side wall (See «SIDE WALL REMOVAL/INSTALLATION» ) Console (See «CONSOLE REMOVAL/INSTALLATION» ). Shift lever component (MTX) (See «SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(/mazda/3/bl-2008-2011/remont/manual-trans/#manual-transaxle-shift-mechanism) ) (See «SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(/mazda/3/bl-2008-2011/remont/manual-trans/#manual-transaxle-shift-mechanism).) Selector lever component (ATX) (See «SELECTOR LEVER COMPONENT REMOVAL/INSTALLATION»(/mazda/3/bl-2008-2011/remont/automatic-trans/#automatic-transaxle-shift-mechanism) ) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION» ). Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION» ) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION» ). PJB (See «PASSENGER JUNCTION BOX (PJB) REMOVAL/INSTALLATION»(/mazda/3/bl-2008-2011/remont/body-electrical/#control-system-body-accessories) ) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION».) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION» ). Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION» ) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION» ). Meter hood (See «METER HOOD REMOVAL/INSTALLATION» ). Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION» ) Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION».) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION» ). Center panel module (See «CENTER PANEL UNIT REMOVAL/INSTALLATION».) Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]» ) (See «CLIMATE CONTROL UNIT REMOVAL [MANUAL AIR CONDITIONER]».)(See «CLIMATE CONTROL UNIT INSTALLATION [MANUAL AIR CONDITIONER]».) LCD unit (See «LCD UNIT REMOVAL/INSTALLATION».) Rear heat duct (1) (See «REAR HEAT DUCT REMOVAL/INSTALLATION» ) Passenger-side air bag module (See «PASSENGER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION» ) Car-navigation unit (See «CAR-NAVIGATION UNIT REMOVAL/INSTALLATION» ) Windshield wiper arm and blade (See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION» ) Cowl grille (See «COWL GRILLE REMOVAL/INSTALLATION»(/mazda/3/bl-2008-2011/remont/exteriorinterior-trim/#exterior-trim) ) Cowl panel (See «COWL PANEL REMOVAL/INSTALLATION» ) Windshield wiper motor (See «WINDSHIELD WIPER MOTOR REMOVAL/INSTALLATION» )
3. Disconnect the dashboard harness connectors.
4. Remove in the order indicated in the illustration. WARNING: Removing the dashboard without supporting it can be dangerous. The dashboard may fall and injure you. Always perform the following procedure with at least another person.
5. Remove the dashboard.
6. Take the dashboard off from the front driver-side door opening.
7. Install in the reverse order of removal.

Scheme 32

Scheme 33

1. Disconnect the connector by pulling it in direction (2) while pressing the tab in direction (1).

Scheme 34

1. Disconnect the connector by pulling it in direction (2) while pressing the tab in direction (1).

Scheme 35

1. Remove the following parts: Front scuff plate (Driver's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION» ). Front side trim (Driver's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION» ). Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION».) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION» ).
2. Detach the fit of the upper column cover from the meter hood rubber.
3. Remove the upper column cover.
4. Remove the ignition key illumination.
5. Remove the screws.
6. Remove the lower column cover.
7. Install in the reverse order of removal.

Scheme 36

1. Disconnect the negative battery cable.
2. Detach the hood release lever from the lower panel. (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION».)
3. Remove the front scuff plate. (Driver's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION» ).
4. Remove the front side trim. (Driver's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION» ).
5. Remove the screw.
6. Pull the lower panel outward, and detach clips A and tab.
7. Disconnect the panel light control switch connector and the headlight leveling switch connector.
8. Remove the lower panel.
9. Install in the reverse order of removal.

Scheme 37

1. Remove the following parts: Front scuff plate (Driver's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION» ). Front side trim (Driver's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION» ). Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION» ). Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION».) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION» ).
2. Detach the fit of the meter hood rubber from the upper column cover.
3. Pull the meter hood outward and detach the tabs A and locator pins B.
4. Remove the meter hood.
5. Install in the reverse order of removal.

Scheme 38

1. Remove the front scuff plate. (Passenger's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION» ).
2. Remove the front side trim. (Passenger's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION» ).
3. Remove the decoration panel. (See «DECORATION PANEL REMOVAL/INSTALLATION» ).
4. Remove the screws.
5. Pull the glove compartment outward and detach clips A and tab B.
6. Remove the glove compartment.
7. Install in the reverse order of removal.

Scheme 39

1. Disconnect the negative battery cable.
2. Remove the following parts: A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION» ). Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION» ). Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION» ). Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION».) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION» ). Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION» ). Dashboard center panel (See «DASHBOARD CENTER PANEL REMOVAL/INSTALLATION» ). Meter hood (See «METER HOOD REMOVAL/INSTALLATION» ). Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION».) Dashboard garnish (See «DASHBOARD GARNISH REMOVAL/INSTALLATION» ).
3. Pull the driver-side ventilator grille outward and remove it.
4. Remove the screw, then remove the driver-side demister grille.
5. Install in the reverse order of removal.

Scheme 40

1. Disconnect the negative battery cable.
2. Remove the following parts: A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION» ). Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION» ). Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION» ). Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION» ). Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION» ). Dashboard center panel (See «DASHBOARD CENTER PANEL REMOVAL/INSTALLATION» ). Dashboard garnish (See «DASHBOARD GARNISH REMOVAL/INSTALLATION» ).
3. Pull the passenger-side ventilator grille outward and remove it.
4. Remove the screw, then remove the passenger-side demister grille.
5. Install in the reverse order of removal.

Scheme 41

1. Remove the decoration panel. (See «DECORATION PANEL REMOVAL/INSTALLATION» ).
2. Remove the dashboard center panel. (See «DASHBOARD CENTER PANEL REMOVAL/INSTALLATION» ).
3. Remove the screws, then remove the center ventilator grilles.
4. Install in the reverse order of removal.
