Security System and Locks System: Removal & Installation Mazda 3 BL

REAR DOOR LATCH AND LOCK ACTUATOR REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the following parts: Sail garnish (5 door) (See «SAIL GARNISH REMOVAL/INSTALLATION»(ref-345251-S27785837952009102000000) .) Rear door garnish (5 door) (See «REAR DOOR GARNISH REMOVAL/INSTALLATION»(ref-345249-S05432158822009102000000) .) Regulator handle (Vehicles with manual window system) (See «REGULATOR HANDLE REMOVAL»(ref-345254-S42341002012009102000000) .) (See «REGULATOR HANDLE INSTALLATION»(ref-345254-S15895405422009102000000) .) Rear door trim (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-345251-S27520553062009102000000) .) Rear door glass (See «REAR DOOR GLASS REMOVAL/INSTALLATION»(ref-345254-S04182570872009102000000) .) Rear door speaker (See «REAR DOOR SPEAKER REMOVAL/INSTALLATION»(ref-345255-S10542439702009102000000) .) Inner handle (See «INNER HANDLE REMOVAL/INSTALLATION»(ref-345243-S41653553822009102000000) ). Rear door unit (See «REAR DOOR UNIT REMOVAL/INSTALLATION»(ref-345256-S41105264602009102000000) .)
3. Pull the stopper of the rear door lock actuator connector in the direction of the arrow (1).
4. Disconnect the rear door lock actuator connector while pushing at point A.
5. Remove the rear door latch and lock actuator from the rear door unit.
6. Install in the reverse order of removal.

Scheme 38

1. The following actuator and switch are integrated with the rear door latch and lock actuator. Inspect the rear door latch and lock actuator according to each inspection procedure for the following items. Rear door lock actuator (See «REAR DOOR LOCK ACTUATOR INSPECTION»(ref-345243-S16346871092009102000000) ). Rear door latch switch (See «REAR DOOR LATCH SWITCH INSPECTION»(ref-345243-S34891092472009102000000) ).

Scheme 39

1. When inspecting the latch, press the latch lever using a flathead screwdriver or a similar tool.
2. Inspect for continuity between the rear door latch switch terminals. If not as specified, replace the rear door latch and lock actuator.

Scheme 40

1. Apply battery positive voltage and connect ground to the corresponding rear door lock actuator terminals, and inspect the rear door lock actuator operation. If not as specified, replace the rear door latch and lock actuator. LOCK ACTUATOR OPERATION Lock actuator operation Connection B+ GND Lock LH:D RH:C LH:C RH:D Unlock LH:C RH:D LH:D RH:C

Scheme 41

Scheme 42

1. Disconnect the negative battery cable.
2. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-345251-S30835481962009102000000) .)
3. Remove the liftgate side trim. (See «LIFTGATE SIDE TRIM REMOVAL/INSTALLATION»(ref-345251-S39658015982009102000000) .)
4. Remove the liftgate lower trim. (See «LIFTGATE LOWER TRIM REMOVAL/INSTALLATION»(ref-345251-S03083004052009102000000) .)
5. Disconnect the liftgate lock actuator connector and liftgate latch switch connector.
6. Detach the rod from the liftgate key cylinder.
7. Remove the clips.
8. Remove the bolts.
9. Remove the liftgate latch and lock actuator
10. Detach the cable from the liftgate latch and lock actuator.
11. Install in the reverse order of removal.

Scheme 43

Scheme 44

Scheme 45

1. When inspecting the latch, press the latch lever using a flathead screwdriver or a similar tool.
2. Inspect for continuity between the liftgate latch switch terminals. If not as specified, replace the liftgate latch and lock actuator.

Scheme 46

1. Remove the trunk end trim. (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-345251-S18838859652009102000000) .)
2. Remove the bolts, then remove the liftgate lock striker.
3. Install in the reverse order of removal.
4. Adjust the liftgate. (See «LIFTGATE ADJUSTMENT»(ref-345256-S09464405262009102000000) .)

Scheme 47

1. Apply battery positive voltage and connect ground to the corresponding liftgate lock actuator terminals, and inspect the liftgate lock actuator operation. If not as specified, replace the liftgate latch and lock actuator. LOCK ACTUATOR OPERATION Lock actuator operation Connection B+ GND Lock A B Unlock B A

Scheme 48

Scheme 49

1. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-345251-S30835481962009102000000) .)
2. Remove the liftgate side trim. (See «LIFTGATE SIDE TRIM REMOVAL/INSTALLATION»(ref-345251-S39658015982009102000000) .)
3. Remove the liftgate lower trim. (See «LIFTGATE LOWER TRIM REMOVAL/INSTALLATION»(ref-345251-S03083004052009102000000) .)
4. Remove the nuts.
5. Detach the cable.
6. Install in the reverse order of removal.

Scheme 50

Scheme 51

1. To remove the fuel-filler lid opener, remove the following procedure: 5 door Remove the hole cover on the trunk side trim. (RH) 4 door Remove the trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-345251-S18838859652009102000000) .) Slightly bend back the trunk side trim. (RH) (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-345251-S16631368612009102000000) .)
2. To remove the fuel-filler lid opener lever, remove the following part: Front scuff plate (Driver's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-345251-S03552764762009102000000) .)
3. When removing the fuel-filler lid opener cable, perform the following procedure: Remove the following parts: Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-345253-S19841861632009102000000) .) Rear scuff plate (Driver's side) (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-345251-S34770097052009102000000) .) Tire house trim (Driver's side) (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-345251-S27657366472009102000000) .) B-pillar lower trim (Driver's side) (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-345251-S05968899652009102000000) .) Partially peel back the floor covering so that the fuel-filler lid opener cable can be removed. Remove the fuel-filler lid opener cable from clips A.
4. Remove in the order indicated in the table.
5. Install in the reverse order of removal.

Scheme 52

1. Disconnect the negative battery cable.
2. Remove the trunk lid trim. (See «TRUNK LID TRIM REMOVAL/INSTALLATION»(ref-345251-S39133707592009102000000) .)
3. Detach the rod from the trunk lid key cylinder.
4. Disconnect the trunk lid key cylinder connector.
5. Remove the nuts, then remove the trunk lid key cylinder.
6. Install in the reverse order of removal.

Scheme 53

Scheme 54

1. Inspect for continuity between the trunk lid key cylinder push switch terminals. If not as specified, replace the trunk lid key cylinder.

TRUNK LID LATCH AND RELEASE ACTUATOR REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the trunk lid trim. (See «TRUNK LID TRIM REMOVAL/INSTALLATION»(ref-345251-S39133707592009102000000) .)
3. Disconnect the connector.
4. Remove the bolts.
5. Remove the trunk lid latch and release actuator.
6. Install in the reverse order of removal.

Scheme 55

Scheme 56

1. The following actuator and switch are integrated with the trunk lid latch and release actuator. Inspect the trunk lid latch and release actuator according to each inspection procedure for the following items. Trunk lid latch switch (See «TRUNK LID LATCH SWITCH INSPECTION»(ref-345243-S10021813512009102000000) .) Trunk lid release actuator (See «TRUNK LID RELEASE ACTUATOR INSPECTION»(ref-345243-S35662262952009111200000) .)

Scheme 57

Scheme 58

1. Disconnect the negative battery cable.
2. Remove the trunk lid trim. (See «TRUNK LID TRIM REMOVAL/INSTALLATION»(ref-345251-S39133707592009102000000) .)
3. Remove the trunk lid latch and release actuator. (See «TRUNK LID LATCH AND RELEASE ACTUATOR REMOVAL/INSTALLATION»(ref-345243-S40801389502009102000000) .)
4. Press the latch in using a flathead screwdriver to inspect the latch lever condition.
5. Apply battery positive voltage and connect the ground to each terminal, and then verify the operation. If not as indicated in the table, replace the trunk lid latch and release actuator. RELEASE ACTUATOR TERMINAL CHART Release actuator operation Terminal B+ Ground UNLATCH A B

Scheme 59

Scheme 60

Scheme 61

1. Disconnect the negative battery cable.
2. Remove the trunk lid trim. (See «TRUNK LID TRIM REMOVAL/INSTALLATION»(ref-345251-S39133707592009102000000) .)
3. Remove the trunk lid latch and release actuator. (See «TRUNK LID LATCH AND RELEASE ACTUATOR REMOVAL/INSTALLATION»(ref-345243-S40801389502009102000000) .)
4. Press the latch in using a flathead screwdriver to inspect the latch lever condition.
5. Verify that the continuity is as indicated in the table. If not as indicated in the table, replace the trunk lid latch and release actuator.

Scheme 62

1. Remove the trunk end trim. (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-345251-S18838859652009102000000) .)
2. Detach the trunk lid opener cable.
3. Remove the bolts, then remove the trunk lid striker.
4. Install in the reverse order of removal.
5. Adjust the trunk lid. (See «TRUNK LID ADJUSTMENT»(ref-345250-S33770455812009102000000) .)

Scheme 63

1. To remove the trunk lid opener lever, remove the following part: Front scuff plate (Driver's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-345251-S03552764762009102000000) .)
2. When removing the trunk lid opener cable, perform the following procedure: Remove the following parts: Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-345251-S18838859652009102000000) .) Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-345253-S19841861632009102000000) .) Rear scuff plate (Driver's side) (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-345251-S34770097052009102000000) .) Tire house trim (Driver's side) (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-345251-S27657366472009102000000) .) B-pillar lower trim (Driver's side) (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-345251-S05968899652009102000000) .) Partially peel back the floor covering so that the trunk lid opener cable can be removed. Remove the trunk lid opener cable from the trunk lid lock striker. Remove the trunk lid opener cable from the clips A.
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 64

1. Disconnect the negative battery cable.
2. Remove the map light. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-345247-S18086223702009102000000) .)
3. Disconnect the keyless control module connector.
4. Remove the screw, then remove the keyless control module.
5. Install in the reverse order of removal.
6. When replacing the keyless control module, register the transmitter ID codes. (See «TRANSMITTER ID CODE REGISTRATION»(ref-345243-S25313878152009102000000) ).

COIL ANTENNA REMOVAL/INSTALLATION

Note. Do not remove the coil antenna unless you are replacing it.

Scheme 65

1. Disconnect the negative battery cable.
2. Remove the following parts: Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-345243-S34551921912009102000000) ). Front scuff plate (Driver's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-345251-S03552764762009102000000) .) Front side trim (Driver's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-345251-S39582742522009102000000) .) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-345251-S05584420032009102000000) .) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-345251-S35932273802009102000000) .)
3. Disconnect the coil antenna connector.
4. Detach the steering lock tabs from the holes on the coil antenna.
5. Install in the reverse order of removal.
