Quick Release Connector Type

CAUTIONThere are five types of quick release connectors. Verify the type and location, and install/remove properly.

Scheme 36

Scheme 36: California emission regulation applicable model

Scheme 37

Scheme 37: Except for California emission regulation applicable model

When using SST 49 E042 001

Note. If the quick release connector is removed, replace the retainer with a new one.

Scheme 38

Scheme 38: When using SST 49 E042 001

Scheme 39

Scheme 39
  1. Follow "BEFORE SERVICE PRECAUTION" and remove dirt from the connecting surfaces before performing any work operations.(See «BEFORE SERVICE PRECAUTION [LF, L3]»(ref-345209-S03614746822009102000000) .)
  2. Set the SST parallel to the quick release connector. NOTE: The quick release connector can be removed by pushing the center of the retainer tabs. The retainer is attached to the pipe even after the connector is disconnected.
  3. Hold the center of the retainer tabs with the SST ends and press the retainer.
  4. Pull the connector side and disconnect the quick release connector.
  5. Raise a retainer tab using the SST and remove the retainer.
  6. Cover the disconnected quick release connector and fuel pipe with vinyl sheeting or a similar material to prevent it from scratches or dirt.

Scheme 40

Scheme 40: Type C Removal
  1. Move the retainer upward using a small flathead screwdriver or a similar tool.
  2. Pull out the evaporative hose straight from the joint port and disconnect it.
  3. Cover the disconnected quick release connector and joint port with vinyl sheeting or a similar material to prevent it from becoming scratched or dirty.

Scheme 41

Scheme 41: Type D Removal
  1. Squeeze the release tab until the locks are released.
  2. Pull the quick release connector straight outward.
  3. Cover the disconnected quick release connector and joint port with vinyl sheeting or a similar material to prevent it from becoming scratched or dirty.

Scheme 42

Scheme 42: Type E Removal

Scheme 43

Scheme 43
  1. Squeeze the locking coupler until the locking tab opens and releases. NOTE: The locking coupler has two internal locking tabs which retain the joint port. Be sure that the squeezing place on the locking coupler is squeezed until it can be released from the joint port.
  2. Pull the quick release connector straight outward.
  3. Cover the disconnected quick release connector and joint port with vinyl sheeting or a similar material to prevent it from becoming scratched or dirty.
