Washer System & Wiper System: Other Mazda 3 BK рестайлинг

Wiper/washer Systems 2 illustrations ~260 words

REAR WASHER NOZZLE CLEANING

  1. Clean the rear washer nozzle. (See «WINDSHIELD WASHER NOZZLE CLEANING»(ref-274495-S20187584122007121800000) ).

Scheme 41

Scheme 41: REAR WASHER HOSE REMOVAL/INSTALLATION
Scheme 41: REAR WASHER HOSE REMOVAL/INSTALLATION

Scheme 42

Scheme 42
Scheme 42
  1. Disconnect the negative battery cable.
  2. Slightly bend back the mudguard (RH).
  3. Disconnect the rear washer hose A from the washer tank.
  4. Remove rear washer hose A from clips A.
  5. Remove A-pillar trim (RH). (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-274485-S34078087152007121800000) .)
  6. Remove the glove compartment. (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-274485-S41115019472007121800000) )
  7. Remove the dashboard garnish. (See «DASHBOARD GARNISH REMOVAL/INSTALLATION»(ref-274485-S41566692142007121800000) )
  8. Disconnect joint pipe, then remove the rear washer hose A.
  9. Remove rear washer hose B from the clips B.
  10. Remove the following parts: Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-274503-S40694109052007121800000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-274485-S30785211232007121800000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-274485-S13641334712007121800000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-274485-S36482650312007121800000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-274485-S18282289132007121800000) .) Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-274457-S14827575882007121800000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-274485-S07747302772007121800000) .) Trunk side upper trim (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-274485-S19846250732007121800000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-274485-S35193962202007121800000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-274508-S30451887322007121800000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-274485-S08806061822007121800000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-274485-S37517100592007121800000) .)
  11. Disconnect the joint pipe B.
  12. Remove the headliner. (See «HEADLINER REMOVAL/INSTALLATION»(ref-274485-S08215786902007121800000) )
  13. Remove rear washer hose B and the tapes.
  14. Remove clips C from the body.
  15. Disconnect the joint pipe C, then remove rear washer hose C.
  16. Remove rear washer hose D from the rear washer nozzle.
  17. Install in the reverse order of removal.
