Scheme 1
Scheme 2
Scheme 3
- Remove the brake calliper component and disc plate.
- Remove the wheel hub bolt using the SST as shown in the figure. NOTE: When removing the wheel hub bolts, perform the work between range A shown in the figure to assure a space for the bolt removal.
- Place a new wheel hub bolt in the wheel hub.
- Install the wheel hub by placing a proper sized washer on the hub, and tightening the nut as shown in the figure.
Scheme 4
- Install the magnetic base and dial gauge as shown in the figure and measure the wheel bearing axial excessive play. If it exceeds the maximum specification, replace the wheel hub bearing. Maximum front wheel bearing play 0.05 mm {0.002 in}
