Sunroof: Overhaul Mazda 3 BK рестайлинг

Rear Drip Assembly Note

Note. If the rear drip is removed, butyl seal must be applied when re-installing.

Scheme 11

1. Apply a 6.0-8.0 mm {0.24-0.31 in} wide line of butyl seal to the area shown in the figure.

Note. If the guide is removed, initial position setting of the sunroof motor will be required. After installing the sunroof unit, perform initial position setting using the following procedure.

1. Press the TILT UP switch to fully tilt up the glass panel.
2. When the glass panel reaches the fully tilt up position, temporarily release the TILT UP switch and press it again for approx. 13 s continuously. Continue pressing the switch until the glass panel automatically stops at the fully tilt up position after reaching the mechanical lock position.
3. When the glass panel stops at the fully tilt up position, temporarily release the TILT UP switch, then press it again within 5 s and hold. NOTE: Press the TILT UP switch continuously until the glass panel opens to the fully open position, returns to the fully closed position and then stops.
4. Release the TILT UP switch when the glass panel stops at the fully closed position.

Scheme 12

1. Disconnect the negative battery cable.
2. Remove the following parts: Console (4 door) (See «CONSOLE REMOVAL/INSTALLATION»(ref-274485-S26173577602007121800000) .) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-274485-S34078087152007121800000) .) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-274503-S40694109052007121800000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-274485-S30785211232007121800000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-274485-S13641334712007121800000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-274485-S36482650312007121800000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-274485-S18282289132007121800000) .) Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-274457-S14827575882007121800000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-274485-S07747302772007121800000) .) Trunk side upper trim (5 door) (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-274485-S19846250732007121800000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-274485-S35193962202007121800000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-274508-S30451887322007121800000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-274485-S08806061822007121800000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-274485-S37517100592007121800000) .) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-274485-S08215786902007121800000) .)
3. Disconnect the sunroof motor connector.
4. Remove the screws, then remove the sunroof motor.
5. Install in the reverse order of removal. NOTE: If the glass panel or the sunroof motor is moved with the sunroof motor removed, initial position setting of the sunroof motor will be required. Perform initial position setting referring to the Sunroof Motor Assembly Note. (See «SUNROOF UNIT DISASSEMBLY/ASSEMBLY»(ref-274518-S41417324162007121800000) ).

1. Measure the voltage at each terminal (other than terminal G). If not as specified, inspect the parts listed under "Inspection item" and the related wiring harnesses.
2. Disconnect the negative battery cable.
3. Verify that continuity at terminal G is as indicated in the Terminal Voltage Table (Reference).
4. If the parts and wiring harnesses are normal but the system still does not work properly, replace the sunroof relay.

Scheme 13

CONNECTOR TERMINAL REFERENCE

Scheme 14

1. Remove the following parts: Console (4 door) (See «CONSOLE REMOVAL/INSTALLATION»(ref-274485-S26173577602007121800000) .) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-274485-S34078087152007121800000) .) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-274503-S40694109052007121800000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-274485-S30785211232007121800000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-274485-S13641334712007121800000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-274485-S36482650312007121800000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-274485-S18282289132007121800000) .) Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-274457-S14827575882007121800000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-274485-S07747302772007121800000) .) Trunk side upper trim (5 door) (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-274485-S19846250732007121800000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-274485-S35193962202007121800000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-274508-S30451887322007121800000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-274485-S08806061822007121800000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-274485-S37517100592007121800000) .) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-274485-S08215786902007121800000) .) Front door (See «FRONT DOOR REMOVAL/INSTALLATION»(ref-274500-S35071040652007121800000) .) Dashboard (See «DASHBOARD REMOVAL/INSTALLATION»(ref-274485-S32231288762007121800000) .)
2. Disconnect the front drain hose from the sunroof frame.
3. Remove the front drain hose from the clips.
4. Pull the front drain hose into the vehicle interior and remove the front drain hose.
