Entertainment System: Other Mazda 3 BK рестайлинг

Mazdaspeed3

Note. The center roof antenna has a built-in antenna amplifier.

Scheme 37

1. Turn the audio unit on and select the radio, then measure the voltage at center roof antenna connector terminal A. If the voltage is B+, go to the «FEEDER LINE INSPECTION»(ref-274460-S12786296282007121800000) . If the voltage is not B+, inspect the audio unit or antenna feeder.

Scheme 38

Scheme 39

1. Verify that there is no continuity between the center roof antenna terminals A and E using an ohmmeter.
2. Inspect for continuity between the center roof antenna terminals using an ohmmeter. If not as indicated in the table, replace the center roof antenna.

Scheme 40

Scheme 41

1. Verify that there is no continuity between the center roof antenna terminals A and C.
2. Inspect for continuity between the center roof antenna terminals. If not as indicated in the table, replace the center roof antenna.

Scheme 42

1. Disconnect the negative battery cable.
2. Remove the following parts: Front scuff plate (Passenger's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-274485-S30785211232007121800000) .) Front side trim (Passenger's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-274485-S23405913072007121800000) .) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-274485-S00945702122007121800000) .) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-274485-S41115019472007121800000) .) Car-navigation unit (See «CAR-NAVIGATION UNIT REMOVAL/INSTALLATION»(ref-274460-S22616554862007121800000) ). PJB (See «PASSENGER JUNCTION BOX (PJB) REMOVAL/INSTALLATION»(ref-274501-S23137470742007121800000) .)
3. Remove in the order indicated in the illustration.
4. Install in the reverse order of removal.

Scheme 43

Scheme 44

Scheme 45

1. Verify that there is no continuity between the front antenna feeder terminal A and B.
2. Verify that the continuity is as indicated in the table. If not as indicated in the table, replace the front antenna feeder.

Scheme 46

Scheme 47

1. Verify that there is no continuity between the front antenna feeder terminal A and B.
2. Verify that the continuity is as indicated in the table. If not as indicated in the table, replace the rear antenna feeder No. 1 or No. 2.

Scheme 48

1. Disconnect the negative battery cable.
2. Remove the driver-side air bag module. (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-274459-S21603135672007121800000) .)
3. Remove the steering wheel. (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-274450-S03065289442007121800000) .)
4. Remove in the order indicated in the illustration.
5. Install in the reverse order of removal.

Scheme 49

1. install the audio control switch so that the audio control switch wiring harness passes behind the steering wheel as shown in the figure.

Scheme 50

Scheme 51

1. Disconnect the negative battery cable.
2. Remove the driver-side air bag module. (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-274459-S21603135672007121800000) .)
3. Disconnect the audio control switch connector.
4. Verify the resistance and continuity between the audio control switch terminals. If the resistance and continuity are not as indicated in the tables, replace the audio control light switch. R: Resistance. See the table. RESISTANCE SPECIFICATION Switch position Resistance (ohm) VOL-button ON 51-56 VOL+ button ON 140-154 AUTO SCAN button ON 286-315 PRESET button ON 534-589 MODE button ON 985-1,080 MUTE button ON 1,940-2,130 OFF 4,800-5,290

Scheme 52

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the illustration.
3. Install in the reverse order of removal.

Scheme 53

1. Pry the car-navigation control switch from the console using a flathead screwdriver wrapped with protective tape.

Scheme 54

1. Operate the car-navigation control switch and verify that the car-navigation system operates normally. If the system does not operate normally, go to the next step.
2. Inspect the wiring harness between the LCD unit and the car-navigation control switch for an open circuit, power short, or a short to ground. If there is any malfunction in the wiring harnesses, repair or replace the applicable wiring harness. If the wiring harnesses are normal, replace the car-navigation control switch.

Scheme 55

1. Disconnect the negative battery cable.
2. Remove the ashtray panel. (See «CONSOLE REMOVAL/INSTALLATION»(ref-274485-S26173577602007121800000) .)
3. Remove in the order indicated in the illustration.
4. Install in the reverse order of removal.

Scheme 56

Scheme 57

Scheme 58

1. Insert a tape-wrapped flathead screwdriver into the socket hole and push on the ring projection to lift the socket outward.
2. Lift out the socket until the ring projection locks into the lower socket hole as shown in the figure.
3. From the rear of the ashtray, insert a tape-wrapped flathead screwdriver between the socket and the ring as shown in the figure.
4. While lifting the ring projection with the flathead screwdriver, push out and remove the socket.

Scheme 59

1. Pull the ring outward while pressing the tabs.
