Security System and Locks System: Overview Mazda 3 BK рестайлинг

Scheme 16

Scheme 17

Scheme 18

1. Disconnect the negative battery cable. (Vehicles with power window system or power outer mirror)
2. Fully roll up the front door glass.
3. Remove the following parts: Inner garnish (See «INNER GARNISH REMOVAL/INSTALLATION».) Regulator handle (Vehicles with manual window system) (See «REGULATOR HANDLE REMOVAL».) (See «REGULATOR HANDLE INSTALLATION».) Front door trim (See «FRONT DOOR TRIM REMOVAL/INSTALLATION».) Front outer handle (See «FRONT OUTER HANDLE REMOVAL/INSTALLATION» ).
4. Remove the rod from the front door key cylinder.
5. Turn the key cylinder in the direction indicated by the arrow and move the tab to the notch.
6. Pull the front door key cylinder outward to remove it.
7. Install in the reverse order of removal.

Scheme 19

1. Disconnect the negative battery cable.
2. Remove the following parts: Inner garnish (See «INNER GARNISH REMOVAL/INSTALLATION».) Regulator handle (Vehicles with manual window system) (See «REGULATOR HANDLE REMOVAL».) (See «REGULATOR HANDLE INSTALLATION».) Front door trim (See «FRONT DOOR TRIM REMOVAL/INSTALLATION».) Front door glass (See «FRONT DOOR GLASS REMOVAL/INSTALLATION».) Front door speaker (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION».) Inner handle (See «INNER HANDLE REMOVAL/INSTALLATION» ). Front door unit (See «FRONT DOOR UNIT REMOVAL/INSTALLATION».)
3. Pull the stopper of the front door lock actuator connector in the direction of the arrow (1).
4. Disconnect the front door lock actuator connector while pushing at point A.
5. Remove the front door latch and lock actuator from the front door unit.
6. Install in the reverse order of removal.
