Charging System (L3 with TC): Overview Mazda 3 BK рестайлинг

Scheme 26

Scheme 27

1. Remove in the order indicated in the table.
2. Install in the reverse order of removal.

Scheme 28

Scheme 29

Scheme 30

1. Install the PCM cover hook to the PCM box hole.
2. Install with PCM cover hooks A aligned with the PCM box and PCM bracket holes at two points.
3. Install the PCM cover to the PCM box hook.

Scheme 31

1. Assemble the battery clamp so that the arrow on it is pointed toward the front of the vehicle.

Scheme 32

1. Assemble with battery box hooks B aligned with the battery tray holes at two points.

Scheme 33

Scheme 34

1. Install with battery cover hooks C aligned with the battery tray holes at two points.
2. Set the battery cover to battery tray hooks D at two points.
