PRECAUTION Mazda 3 MPS II facelift

Manual Transaxle - Overhaul (A26MX-R) 33 illustrations ~794 words

PRECAUTION

  1. Clean the transaxle exterior thoroughly using a steam cleaner or cleaning solvents before disassembly. WARNING: Using compressed air can cause dirt and other particles to fly out, causing injury to the eyes. Wear protective eye wear whenever using compressed air. CAUTION: Cleaning sealed bearings using cleaning fluids or a steam cleaner can wash the grease out of the bearing.
  2. Clean the removed parts using cleaning solvent, and dry them using compressed air.
  3. Clean out all holes and passages using compressed air, and check that there are no obstructions.
  4. Make sure each part is cleaned before assembling.
  5. Coat all movable parts with the specified oil.
  6. Replace parts whenever required.
  7. Remove old sealant from contact surfaces before applying new sealant.
  8. Assemble the parts within 10 min after applying sealant. Allow all sealant to cure at least 30 min after assembly before filling the transaxle with transaxle oil.
WARNINGAlthough the stand has a self-locking brake system, there is a possibility that the brake may not hold when the transaxle is held in a lopsided position on the stand. This would cause the transaxle to turn suddenly, causing serious injury. Never keep the transaxle tilted to one side. Always hold the rotating handle firmly when turning the transaxle.

Scheme 251

Scheme 251: Disassembly Components

Scheme 252

Scheme 252

Scheme 253

Scheme 253: Disassembly Procedure

Scheme 254

Scheme 254

Scheme 255

Scheme 255

Scheme 256

Scheme 256

Scheme 257

Scheme 257

Scheme 258

Scheme 258

Scheme 259

Scheme 259

Scheme 260

Scheme 260

Scheme 261

Scheme 261

Scheme 262

Scheme 262

Scheme 263

Scheme 263

Scheme 264

Scheme 264

Scheme 265

Scheme 265

Scheme 266

Scheme 266

Scheme 267

Scheme 267

Scheme 268

Scheme 268

Scheme 269

Scheme 269

Scheme 270

Scheme 270

Scheme 271

Scheme 271

Scheme 272

Scheme 272

Scheme 273

Scheme 273

Scheme 274

Scheme 274

Scheme 275

Scheme 275

Scheme 276

Scheme 276

Scheme 277

Scheme 277

Scheme 278

Scheme 278

Scheme 279

Scheme 279

Scheme 280

Scheme 280

Scheme 281

Scheme 281

Scheme 282

Scheme 282
  1. Assemble the SST.
  2. Lift the transaxle and mount it on the SST .
  3. Remove the drain plug and the oil level plug.
  4. Remove the neutral switch and back-up light switch.
  5. Remove the reverse idler shaft retaining bolt.
  6. Remove the straight pin.
  7. Remove the shift push pin and select push pin.
  8. Remove the select lever set and shift component.
  9. Remove the sealing cap, detent spring seat, detent spring and detent ball as shown in the figure.
  10. Remove the sealing caps. NOTE: The cast hexagon inner diameter of the plug is 27mm {1.063 in}.
  11. Remove the transaxle case fixing bolts. Front side fixing bolts Rear side fixing bolts
  12. Stretch the snap ring of the primary shaft rear bearing and secondary shaft (No. 1) rear bearing at the sealing cap hole, and remove the transaxle case. NOTE: If the transaxle case is not removed, pull the primary shaft from the clutch housing side.
  13. Remove the snap rings.
  14. Remove the oil pass.
  15. Remove the control rod bearings from the transaxle case using the SST .
  16. Remove the shift lever shaft bearing from the transaxle case using the SST .
  17. Remove the secondary shaft (No. 2) rear bearing outer race and bearing adjust shim from the transaxle case, using the SST .
  18. Remove the differential oil seal from the transaxle case using a flathead screwdriver.
  19. Remove the differential side bearing outer race and adjust shim from the transaxle case using the SST .
  20. Remove the magnet from the clutch housing.
  21. Remove the baffle plate.
  22. Remove the 5th/6th shift fork retaining bolt and reverse shift fork retaining bolt.
  23. Remove the reverse control rod.
  24. Remove the 5th/6th control rod.
  25. Remove the reverse shift fork and 5th/6th shift fork.
  26. Remove the 3rd/4th shift fork spring pin using a pin punch.
  27. Remove the 1st/2nd shift fork retaining bolt.
  28. Remove the 1st/2nd control rod.
  29. Remove the 3rd/4th control rod end (A and B) spring pin using a pin punch.
  30. Remove the 3rd/4th control rod (B), 3rd/4th control rod end (B), and 3rd/4th shift fork.
  31. Remove the snap ring using a flathead screwdriver, and remove the counter lever pivot.
  32. Remove the 3rd/4th control rod (A).
  33. Remove the 1st/2nd shift fork.
  34. Remove the counter lever.
  35. Remove each gear component. Remove the reverse idler gear component. Remove the secondary shaft (No. 2) component. Remove the primary shaft component and secondary shaft (No. 1) component at the same time. Remove the differential component. CAUTION: The oil funnel in the clutch housing can be damaged when removing the secondary shafts component.
  36. Remove the primary shaft bearing cover and secondary shaft (No. 1) bearing cover from the clutch housing.
  37. Pry and remove the roller guide for the secondary shaft (No. 1) front bearing using a flathead screwdriver as shown in the figure.
  38. Remove the secondary shaft (No. 1) front bearing using the SST .
  39. Remove the oil funnel of the secondary shaft (No. 1).
  40. Remove the primary shaft front bearing using the SST .
  41. Remove the primary shaft oil seal using a flathead screwdriver.
  42. Remove the secondary shaft (No. 2) front bearing outer race using the SST .
  43. Remove the oil funnel of the secondary shaft (No. 2).
  44. Remove the differential side bearing outer race from the clutch housing using the SST . NOTE: Wrap the SST with tape so that the SST tabs hook onto the bearing outer race as shown in the figure.
  45. Remove the differential oil seal from the clutch housing using a flathead screwdriver.
  46. Remove the control rod bearings, from the clutch housing.
