Engine performance 1.5l — Wiring diagram engine performance 1.5l Mazda 2 II facelift

Components on these wiring diagrams 56

Click a component to highlight it on every diagram it appears on.

• A/F Sensor
• Accelerator Pedal Position Sensor
• Actuator
• Actuator Position Sensor
• Brake Switch
• Camshaft Position Sensor
• Check Engine Ind
• Check Engine Ind Check Fuel Cap Ind
• Clutch Pedal Position Switch
• Condenser
• Control Solenoid
• Control Valve Body
• Crankshaft Position Sensor
• Cv Solenoid Valve
• Engine Compt
• Engine Coolant Temperature Sensor 1
• Engine Coolant Temperature Sensor 2
• Evaporator Temperature Sensor
• Fuel Gauge Sender Unit
• Fuel Gauge Sender Unit Fuel Pump Unit
• Fuel Injectors
• Fuel Tank Pressure Sensor
• Fuel — Pump
• Fuel — Pump Relay
• Heated Oxygen Sensor
• Ignition Coils
• Input/Turbine Speed Sensor
• Instrument — Cluster
• Knock Sensor
• Left "C" Pillar
• Malfunction Ind
• Manifold Absolute Pressure Sensor
• Mass Air Flow/ Intake Air Temperature Sensor
• Microcomputer
• Neutral Switch
• Neutral Switch Left "A" Pillar
• O/D Off Switch
• Oil Control Valve
• Position Sensor
• Pressure
• Pressure Control Solenoid
• Purge Solenoid Valve
• Right End Of Dash
• Shift Solenoid A
• Shift Solenoid B
• Shift Solenoid C
• Shift Solenoid D
• Shift Solenoid E
• Side Of Dash
• Throttle Body
• Throttle Position Sensor
• Throttle Valve Actuator
• Transaxle Fluid Temperature Sensor
• Transaxle Range Switch
• Variable Tumble Shutter Valve
• Vehicle Speed Sensor
