Interior Trim System: Overview Mazda 2 II facelift

Identifying Interior Trim Related Components (1 Of 3). Scheme 34

Identifying Interior Trim Related Components (2 Of 3). Scheme 35

Identifying Interior Trim Related Components (3 Of 3). Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

1. Disconnect the negative battery cable.
2. Remove the following parts: Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-517497-S18570108062012121200000).) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-517497-S06456173492012121200000).) Heat duct (passenger side) (See «HEAT DUCT COMPONENT REMOVAL/INSTALLATION»(ref-517465-S38916655892012121200000).) Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-517497-S31639085322012121200000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [F35M-R]»(/mazda/2/ii-facelift-2010-2014/remont/manual-trans/#manual-transaxle-shift-mechanism-f35m-r).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-517497-S42051367322012121200000).) Front console component (See «FRONT CONSOLE COMPONENT REMOVAL/INSTALLATION»(ref-517497-S35138574242012121200000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-517497-S16065429912012121200000).) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-517497-S41539597602012121200000).) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-517460-S14332073362012121200000).) Driver-side lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-517497-S40475635322012121200000).) Knee bolster (See «KNEE BOLSTER REMOVAL/INSTALLATION»(ref-517497-S07677910962012121200000).) Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-517434-S24290337822012121200000).) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-517483-S36596734772012121200000).) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-517497-S28954925772012121200000).) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-517497-S06688219392012121200000).) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-517450-S33673315542012121200000).) Combination switch (See «COMBINATION SWITCH REMOVAL/INSTALLATION»(ref-517509-S26871730712012121200000).) Center panel unit (vehicles with audio unit) (See «CENTER PANEL UNIT REMOVAL/INSTALLATION»(/mazda/2/ii-facelift-2010-2014/remont/entertainment-systems/#entertainment-system).) Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [MANUAL AIR CONDITIONER]»(ref-517453-S16187895192012121200000).) Shift lever (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [F35M-R]»(/mazda/2/ii-facelift-2010-2014/remont/manual-trans/#manual-transaxle-shift-mechanism-f35m-r).) Selector lever (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-517496-S37097310912012121200000).) Interlock cable (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-517496-S37097310912012121200000).) Passenger-side lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-517497-S40475635322012121200000).) Side panel (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-517497-S11977097702012121200000).) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-517497-S09928645462012121200000).) aa. Windshield wiper arm and blade (See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION»(ref-517471-S29993174052012121200000).) ab. Cowl grille (See «COWL GRILLE REMOVAL/INSTALLATION»(ref-517470-S32798879672012121200000).) ac. Sail garnish (See «SAIL GARNISH REMOVAL/INSTALLATION»(ref-517470-S08272166772012121200000).) ad. Windshield wiper motor (See «WINDSHIELD WIPER MOTOR REMOVAL/INSTALLATION»(ref-517471-S02257979132012121200000).) ae. Steering shaft cover (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-517483-S36596734772012121200000).) af. Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-517483-S36596734772012121200000).)
3. Disconnect antenna feeder No.2 from the antenna feeder No.1. (See «ANTENNA FEEDER NO.2 REMOVAL/INSTALLATION»(/mazda/2/ii-facelift-2010-2014/remont/entertainment-systems/#entertainment-system) )
4. Disconnect antenna feeder No.1 clip from the A-pillar inner panel.
5. Disconnect the dashboard wiring harness connectors.
6. Remove nuts A and bolts B then remove the dashboard bracket. (Scheme 37): Identifying Dashboard Bracket, Nuts A And Bolts B
7. Remove nut C and bolt D from the outside of the vehicle (upper dashboard area). (Scheme 38): Identifying Dashboard Nut C And Bolt D With Torque Specification
8. Remove nuts E and F shown in the figure. (Scheme 39): Identifying Glove Compartment Damper, A/C Unit, Nuts E And F
9. Disconnect the A/C unit related connector.
10. Remove the caps, remove bolts I and J. (See «Bolt I Removal/Installation Note»(ref-517497-S00481455412012121200000) ) (Scheme 40): Dashboard With Torque Specifications
11. Lift the dashboard in the direction of the arrow (1) shown in the figure, disconnect the A/C unit, and then rotate the dashboard in the direction of the arrow (2) and remove it from the vehicle. (See «Dashboard Removal Note»(ref-517497-S09195988822012121200000) )
12. Install in the reverse order of removal.
