HEADLIGHT AIMING

Note. The reflectors for the low and high beams are integrated. Therefore, perform the headlight aiming adjustment on either the low or high beam.

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

1. Point the headlight beams to a wall and verify that the headlight beams are as shown in the figure. (Scheme 2): Verifying Headlight Beams
2. Make a headlight adjustment screen as shown in the figure using double-weight, white paper. (Scheme 3): Headlight Adjustment Screen
3. Adjust the tire pressure to the specification.
4. Park the vehicle on level ground, in an unloaded condition.
5. Sit on the driver-side seat alone.
6. Put the white screen in front of the vehicle.
7. Line up the headlights with the white screen at a distance of 3 m {9.8 ft} apart.
8. Measure the height at the center of the headlight. (Scheme 4): Measuring Height At Center Of Headlight NOTE: Since the height of the vehicle varies depending on the vehicle situation, measure the height of the center of the headlight using the actual vehicle.
9. Align the center of the adjustment screen with the position indicated in the figure, then affix the screen to the wall. (Scheme 5): Aligning Center Of Adjustment Screen
10. Start the engine and charge the battery.
11. Turn on the headlight low beams.
12. Block the light of the headlight which is not adjusted.
13. Verify that the elbow point of the headlight is at the position indicated by the adjustment screen. If the elbow point is not at the position indicated by the adjustment screen, turn the adjustment screw as shown in the figure to adjust the elbow point to the position indicated by the adjustment screen. (Scheme 6): Turning Adjustment Screw To Adjust Elbow Point

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

1. Make a headlight adjustment screen as shown in the figure using double-weight, white paper. (Scheme 7): Identifying Headlight Adjustment Screen
2. Adjust the tire pressure to the specification.
3. Park the vehicle on level ground, in an unloaded condition.
4. Sit on the driver-side seat alone.
5. Put the wall in front of the vehicle.
6. Line up the headlights with the wall at a distance of 3 m {9.8 ft} apart.
7. Measure the height at the center of the headlight. (Scheme 8): Measuring Height At Center Of Headlight NOTE: Since the height of the vehicle varies depending on the vehicle situation, measure the height of the center of the headlight using the actual vehicle.
8. Align the center of the adjustment screen with the position indicated in the figure, then affix the screen to the wall. (Scheme 9): Aligning Center Of Adjustment Screen
9. Start the engine and charge the battery.
10. Turn on the headlight high beams.
11. Block the light of the headlight which is not adjusted using a partition.
12. Verify that the center of the hot zone (the bright part of high beam) is at the center of the headlight on the adjustment screen. (Scheme 10): Inspecting Center Of Hot Zone If the center of the hot zone is not at the center of the headlight on the adjustment screen, turn the adjustment screw to adjust the center of the hot zone. (Scheme 11): Turning Adjustment Screw To Adjust Center Of Hot Zone

Scheme 12

Scheme 13

1. Disconnect the negative battery cable.
2. Remove the fasteners and slightly bend back the mudguard. (LH only)
3. Disconnect the connector. (Scheme 12): Identifying Headlight Bulb Connector
4. Remove the rubber cover. (Scheme 13): Identifying Headlight Bulb Rubber Cover
5. Press the bulb retaining wire in the direction of the arrow to release the lock.
6. Remove the headlight bulb. CAUTION: A bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, heat of higher temperature than normal will build, shortening the life of the bulb. When replacing the bulb, hold the metal flange, not the glass.
7. Install in the reverse order of removal.

Scheme 14

1. Disconnect the negative battery cable.
2. Rotate the socket in the direction of the arrow (1) and remove it. (Scheme 14): Identifying Socket Rotate Direction
3. Remove the parking light bulb from the socket in the direction of the arrow (2).
4. Install in the reverse order of removal.

Scheme 15

1. Disconnect the negative battery cable.
2. Rotate the socket in the direction of the arrow (1) and remove it. (Scheme 15): Turn Light Bulb Removal
3. Remove the front turn light bulb from the socket in the direction of the arrow (2).
4. Install in the reverse order of removal.

Scheme 16

Scheme 17

Scheme 18

1. Disconnect the negative battery cable.
2. Lift up the vehicle.
3. Remove the screw A shown in the figure and bend back the mudguard in the direction of the arrow. (Scheme 16): Identifying Screw A And Mudguard Bend Back Direction
4. Disconnect the connector. (Scheme 17): Identifying Front Fog Light, Pin, Screw And Connector
5. Remove the screw B.
6. Remove the front fog light component.
7. Remove the screw C. (Scheme 18): Front Fog Light From Cover With Torque Specifications
8. Remove the adjustment bolt.
9. Pull the front fog light in the direction of the arrow shown in the figure and remove it from the front fog light cover.
10. Install in the reverse order of removal.
11. Adjust the front fog light aiming. (See «FRONT FOG LIGHT AIMING»(ref-517509-S31234441092012121200000).)

Scheme 19

Scheme 20

1. Disconnect the negative battery cable.
2. Remove the screws shown in the figure and bend back the mudguard in the direction of the arrow. (Scheme 19): Identifying Screws And Mudguard Bend Back Direction
3. Disconnect the connector. (Scheme 20): Identifying Front Fog Light Bulb And Connector
4. Remove the front fog light bulb. CAUTION: A bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, heat of higher temperature than normal will build, shortening the life of the bulb. When replacing the bulb, hold the metal flange, not the glass.
5. Install in the reverse order of removal. (See «FRONT FOG LIGHT BULB INSTALLATION NOTE»(ref-517509-S36314574692012121200000).)

Scheme 21

Scheme 22

1. Install the front fog light bulb by turning it in the direction of the arrow. (Scheme 21): Identifying Front Fog Light Bulb Installation - LH (Scheme 22): Identifying Front Fog Light Bulb Installation - RH

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

1. Make a front fog light adjustment screen as shown in the figure using double-weight, white paper. (Scheme 23): Identifying Front Fog Light Adjustment Screen
2. Adjust the tire pressure to the specification.
3. Position the unloaded vehicle on a flat, level surface.
4. Seat one person in the driver's seat.
5. Line up the front fog lights with the white screen at a distance of 3 m {9.8 ft} apart.
6. Measure the height at the center of the front fog light. (Scheme 24): Measuring Height At Center Of Front Fog Light NOTE: Since the height of the vehicle varies depending on the vehicle situation, measure the height of the center of the front fog light using the actual vehicle.
7. Align the center of the adjustment screen with the position indicated in the figure, then affix the screen to the wall. (Scheme 25): Aligning Center Of Adjustment Screen
8. Place an object in front of the fog light not being adjusted to block its light beam.
9. Start the engine so that the battery remains charged.
10. Turn the front fog lights on.
11. Verify that brightness border line of the front fog light is at the position indicated on the adjustment screen. If the brightness border line is not at the position indicated on the adjustment screen, perform the following adjustment.
12. Remove the screws shown in the figure and bend back the mudguard. (Scheme 26): Identifying Screws And Mudguard
13. Loosen the adjustment bolt. (Scheme 27): Identifying Adjustment Bolt With Torque Specifications
14. Move the front fog light in the direction of the arrow shown in the figure to adjust the brightness border line to the position indicated on the adjustment screen. (Scheme 28): Identifying Front Fog Light Adjustment Directions
15. Tighten the adjustment bolt.
16. Install the screws and mudguard. (Scheme 29): Identifying Adjustment Bolt, Screws And Mudguard

Scheme 30

1. Disconnect the negative battery cable.
2. Move the side turn light in the direction of the arrow (1) (toward the vehicle rear) and detach the tab. (Scheme 30): Identifying Side Turn Light Removal
3. Pull area A of the side turn light in the direction of the arrow (2) and remove the side turn light.
4. Disconnect the connector.
5. Install in the reverse order of removal. CAUTION: Always assemble the side turn light with the tab towards the vehicle rear.

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

1. Disconnect the negative battery cabl-e.
2. Remove the screws. (Scheme 31): Identifying Rear Combination Light Screws
3. To prevent scratches or damage, affix protective tape to the position shown in the figure. NOTE: When the rear combination light is removed from the body, perform the procedure after affixing protective tape to the body. Otherwise, the body could interfere with the rear combination light and cause scratching or damage to the body. (Scheme 32): Affixing Protective Tape To Rear Combination Light Body
4. Pull the rear combination light in the direction of the arrow shown in the figure, remove the hook from the clip, and remove the pin from the grommet. (Scheme 33): Identifying Hook, Clip, Pin And Grommet
5. Rotate the socket in the direction of the arrow shown in the figure and remove it. (Scheme 34): Removing Socket
6. Remove the wiring harness from the hook. (Scheme 35): Removing Wiring Harness From Hook
7. Remove the rear combination light.
8. Install in the reverse order of removal.

Scheme 36

1. Disconnect the negative battery cable.
2. Remove the rear combination light. (See «REAR COMBINATION LIGHT REMOVAL/INSTALLATION»(ref-517509-S13395268402012121200000).)
3. Remove the rear combination light bulbs. (Scheme 36): Identifying Bulb Positions
4. Install in the reverse order of removal.

Scheme 37

1. Disconnect the negative battery cable.
2. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-517497-S19239265502012121200000).)
3. Remove tabs A (4 locations). (Scheme 37): Identifying High Mount Brake Light Tabs
4. Remove the high-mount brake light while removing tabs B (4 locations).
5. Disconnect the connector.
6. Install in the reverse order of removal.

Scheme 38

Scheme 39

1. Disconnect the negative battery cable.
2. Pull the tabs shown in the figure in the direction of the arrow (1) and remove them in the direction of the arrow (2). (Scheme 38): Identifying License Plate Light Tabs Removal Direction
3. Pull out the wiring harness from the hook. (Scheme 39): Pulling Out Wiring Harness From Hook
4. Rotate the socket in the direction of the arrow as shown in the figure to remove it.
5. Remove the license plate light.
6. Install in the reverse order of removal.

Scheme 40

Scheme 41

1. Disconnect the negative battery cable.
2. Insert a tape-wrapped flathead screwdriver into the service hole, push it in the direction of the arrow, and remove the lens. (Scheme 40): Inserting Tape-Wrapped Flathead Screwdriver Into Service Hole
3. Remove the license plate light bulb. (Scheme 41): Identifying License Plate Light Bulb
4. Install in the reverse order of removal.

Scheme 42

Scheme 43

1. Disconnect the negative battery cable.
2. Disconnect the back-up light switch connector. (See «BACK-UP LIGHT SWITCH INSPECTION»(ref-517509-S14772224802012121200000).)
3. Verify that the continuity between the back-up light switch terminals is as indicated in the table. (Scheme 42): Identifying Back-Up Light Switch Connector Terminals If not as indicated in the table, replace the back-up light switch. (Scheme 43): Back-Up Light Switch Terminals Continuity Chart

Scheme 44

Scheme 45

1. Disconnect the negative battery cable and wait 1 min or more.
2. Remove the following parts: Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-517434-S24290337822012121200000).) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-517483-S36596734772012121200000).) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-517497-S28954925772012121200000).) Clock spring (See «CLOCK SPRING REMOVAL/INSTALLATION»(ref-517434-S19056807092012121200000).)
3. Disconnect the connector. (Scheme 44): Combination Switch, Connector And Bolt With Torque Specifications
4. Remove the bolt.
5. Detach the tab. (Scheme 45): Identifying Combination Switch Tab
6. Remove the combination switch.
7. Install in the reverse order of removal.

Scheme 46

1. Align the combination switch rib with the steering shaft guide and press the combination switch until it contacts. (Scheme 46): Aligning Combination Switch Rib With Steering Shaft Guide

Scheme 47

1. Disconnect the negative battery cable and wait 1 min or more.
2. Remove the following parts: Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-517434-S24290337822012121200000).) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-517483-S36596734772012121200000).) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-517497-S28954925772012121200000).) Clock spring (See «CLOCK SPRING REMOVAL/INSTALLATION»(ref-517434-S19056807092012121200000).)
3. Remove the combination switch. (See «COMBINATION SWITCH REMOVAL/INSTALLATION»(ref-517509-S26871730712012121200000).)
4. Press the tabs in the direction of the arrow (1) shown in the figure, then remove the light switch, and the wiper and washer switch (Scheme 47): Identifying Light Switch, And Wiper And Washer Switch
5. Assemble in the reverse order of disassembly.

Scheme 48

1. Disconnect the negative battery cable.
2. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-517497-S28954925772012121200000).)
3. Disconnect the connector. (Scheme 48): Identifying Light Switch Connector
4. Release the tab in the direction of the arrow (1) shown in the figure and remove the light switch in the direction of the arrow (2).
5. Install in the reverse order of removal.

Vehicles Without Auto Light System

Light switch

Identifying Light Switch Connector Terminals With Continuity Chart. Scheme 49

Turn switch

Identifying Turn Switch Connector Terminals With Continuity Chart. Scheme 50

Vehicles With Auto Light System

Light switch

Identifying Light Switch Connector Terminals With Continuity Chart. Scheme 51

Turn switch

Identifying Turn Switch Connector Terminals With Continuity Chart. Scheme 52

Scheme 53

Scheme 54

1. Disconnect the negative battery cable.
2. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-517497-S28954925772012121200000).)
3. Remove the light switch. (See «LIGHT SWITCH REMOVAL/INSTALLATION»(ref-517509-S38280772562012121200000).)
4. Verify that the continuity between the front fog light switch terminals is as indicated in the table using a circuit tester. (Scheme 53): Front Fog Light Switch Circuit Diagram If not as indicated in the table, replace the light switch. (Scheme 54): Front Fog Light Switch Continuity Chart

Scheme 55

1. Disconnect the negative battery cable.
2. Remove the following parts: Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-517497-S16065429912012121200000).) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-517497-S41539597602012121200000).) Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-517497-S31639085322012121200000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-517497-S42051367322012121200000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [F35M-R]»(ref-517501-S39688997572012121200000).) Front console component (See «FRONT CONSOLE COMPONENT REMOVAL/INSTALLATION»(ref-517497-S35138574242012121200000).) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-517497-S18570108062012121200000).) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-517497-S40475635322012121200000).) Center panel unit (See «CENTER PANEL UNIT REMOVAL/INSTALLATION»(ref-517455-S02022711012012121200000).)
3. Remove the hazard warning switch in the direction of the arrow (2) shown in the figure while pressing the tabs in the direction of the arrow (1). (Scheme 55): Hazard Warning Switch
4. Install in the reverse order of removal.

Scheme 56

Scheme 57

1. Disconnect the negative battery cable.
2. Remove the following parts: Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-517497-S16065429912012121200000).) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-517497-S41539597602012121200000).) Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-517497-S31639085322012121200000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-517497-S42051367322012121200000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [F35M-R]»(ref-517501-S39688997572012121200000).) Front console component (See «FRONT CONSOLE COMPONENT REMOVAL/INSTALLATION»(ref-517497-S35138574242012121200000).) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-517497-S18570108062012121200000).) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-517497-S40475635322012121200000).) Center panel unit (See «CENTER PANEL UNIT REMOVAL/INSTALLATION»(ref-517455-S02022711012012121200000).) Hazard warning switch (See «HAZARD WARNING SWITCH REMOVAL/INSTALLATION»(ref-517509-S42450510052012121200000).)
3. Verify that the continuity between the hazard warning switch terminals is as indicated in the table. (Scheme 56): Identifying Hazard Warning Switch Connector Terminals If not as indicated in the table, replace the hazard warning switch. (Scheme 57): Hazard Warning Switch Continuity Chart

Scheme 58

1. Disconnect the negative battery cable.
2. Remove the following parts: A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-517497-S09928645462012121200000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-517497-S19003006492012121200000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-517497-S00704867052012121200000).) Rain sensor cover (vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-517471-S39323855762012121200000).)
3. Set the headliner out of the way.
4. Release the tabs in the direction of the arrow (1) shown in the figure and remove the interior light in the direction of the arrow (2). (Scheme 58): Identifying Interior Light Tabs
5. Disconnect the interior light connector.
6. Install in the reverse order of removal.

Scheme 59

1. Disconnect the negative battery cable.
2. Insert a tape-wrapped flathead screwdriver into the service hole, push it in the direction indicated by the arrow, and remove the lens. (Scheme 59): Removing Interior Light Bulb Lens And Bulb
3. Remove the interior light bulb.
4. Install in the reverse order of removal.

Scheme 60

Scheme 61

1. Remove the following parts: A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-517497-S09928645462012121200000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-517497-S19003006492012121200000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-517497-S00704867052012121200000).) Rain sensor cover (vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-517471-S39323855762012121200000).) Interior light (See «INTERIOR LIGHT REMOVAL/INSTALLATION»(ref-517509-S12866991252012121200000).)
2. Verify that the continuity between the interior light terminals is as indicated in the table. (Scheme 60): Identifying Interior Light Connector Terminals If not as indicated in the table, replace the interior light. (Scheme 61): Interior Light Continuity Chart

Scheme 62

1. Disconnect the negative battery cable.
2. Insert hand through the service hole, release the tab in the direction of the arrow (1) shown in the figure, and pull area A in the direction of the arrow (2) to remove the cargo compartment light.
3. Disconnect the cargo compartment light connector. (Scheme 62): Cargo Compartment Light And Connector
4. Install in the reverse order of removal.

Scheme 63

1. Disconnect the negative battery cable.
2. Remove the cargo compartment light. (See «CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION»(ref-517509-S34528230052012121200000).)
3. Remove the cargo compartment light bulb. (Scheme 63): Identifying Cargo Compartment Light Bulb
4. Install in the reverse order of removal.

Scheme 64

Scheme 65

1. Disconnect the negative battery cable.
2. Remove the cargo compartment light. (See «CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION»(ref-517509-S34528230052012121200000).)
3. Verify that the continuity between the cargo compartment light terminals is as indicated in the table. (Scheme 64): Identifying Cargo Compartment Light Connector Terminals If not as indicated in the table, replace the cargo compartment light. (Scheme 65): Cargo Compartment Light Continuity Chart

Scheme 66

1. Connect the M-MDS(IDS) to the DLC-2. (Scheme 66): Identifying DLC-2 Location
2. After vehicle identification, the following can be selected from the M-MDS initialization screen. Select the "Module Programming"
3. Then, select items from the screen menu in the following order. Select "Programmable Parameters" Select "BCM/GEM"
4. Select an item name, and then select option. M-MDS display Function Initial setting Setting content Control unit Rain Light Sensor Illuminance setting The auto light system sensitivity can be adjusted. Standard (Except Japan) Extra High (Except Japan)/High (Except Japan)/Standard (Except Japan)/Low (Except Japan)/Extra Low (Except Japan) BCM NOTE: Other than the above conditions, a "Japan Only" contents is also displayed, however, do not select the contents because it is for use in Japan Only. If the mode is set to "Extra High (Except Japan)" and "High (Except Japan)", the illumination level for illuminating the TNS and headlight increases. Therefore, the TNS and headlights illuminate when the ambient light is brighter than when the level is set to "Standard (Except Japan)". In addition, if the mode is set to "Low (Except Japan)" and "Extra Low (Except Japan)", the illumination level for illuminating the TNS and headlights decreases. Therefore, the TNS and headlights illuminate when the ambient light is lower than when the level is set to "Standard (Except Japan)".
