PCM Connector Connection Note
| CAUTION | If the PCM connector is inserted at an angle and the lever is moved, the connector could be damaged. Verify that the PCM connector is inserted straight. |
Caution For PCM Connector Installation. Scheme 11
Scheme 11: Caution For PCM Connector Installation
Scheme 12
Scheme 13
- Verify that the PCM connector lever is tilted towards the wiring harness side as shown in the figure. (Scheme 12): Identifying PCM Connector Lever And Wiring Harness
- Insert the PCM connector straight until it contacts the PCM and verify that the lever reverts upward naturally.
- Push the lever until a click is heard. (Scheme 13): Pushing Lever Until Click Heard
