FUSE SERVICE CAUTIONS

Scheme 2

Scheme 3

1. Disconnect the negative battery cable.
2. Remove the main fuse cover in the direction of the arrow while pressing the tab indicated in the figure. (Scheme 2): Identifying Main Fuse Cover Tab
3. Remove nuts A, B, and C shown in the figure. (Scheme 3): Identifying Main Fuse Nuts A, B, And C With Torque Specifications
4. Remove the main fuse.
5. Install in the reverse order of removal.

Scheme 4

Scheme 5

Scheme 6

1. Disconnect the negative battery cable.
2. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-517497-S28954925772012121200000).)
3. Press tabs A in the direction of the arrow (1) shown in the figure and pull the ignition switch in the direction of the arrow (2). (Scheme 4): Identifying Ignition Switch Pulling Direction
4. Pull the pin in the direction of the arrow shown in the figure and release the lock. (Scheme 5): Identifying Pin Pulling Direction
5. Pull the connector in the direction of the arrow (4) shown in the figure and remove it while pressing tab B in the direction of the arrow (3). (Scheme 6): Identifying Connector Pulling Direction
6. Remove the ignition switch.
7. Install in the reverse order of removal.

Scheme 7

Scheme 8

1. Disconnect the negative battery cable.
2. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-517497-S28954925772012121200000).)
3. Remove the ignition switch. (See «IGNITION SWITCH REMOVAL/INSTALLATION»(ref-517451-S08397417012012121200000).)
4. Verify that the continuity between the ignition switch terminals is as indicated in the table. (Scheme 7): Identifying Ignition Switch Terminals If not as indicated in the table, replace the ignition switch. (Scheme 8): Ignition Switch Continuity Chart

Scheme 9

Scheme 10

1. Disconnect the negative battery cable.
2. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-517497-S28954925772012121200000).)
3. Remove the coil antenna. (See «COIL ANTENNA REMOVAL/INSTALLATION»(ref-517460-S19909665262012121200000).)
4. Insert the key into the key cylinder and turn the ignition switch to the ACC position.
5. Disconnect the key reminder switch connector. (Scheme 9): Identifying Key Reminder Switch And Connector
6. Detach the key reminder switch tab. (Scheme 10): Identifying Key Reminder Switch And Tab
7. Install the key reminder switch in the direction of the arrow.
8. Install in the reverse order of removal.

Scheme 11

Scheme 12

Scheme 13

1. Disconnect the negative battery cable.
2. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-517497-S28954925772012121200000).)
3. Disconnect the key reminder switch connector. (Scheme 11): Identifying Key Reminder Switch And Connector
4. Verify that the continuity between the key reminder switch terminals is as indicated in the table. (Scheme 12): Identifying Key Reminder Switch Terminals If not as indicated in the table, replace the key reminder switch. (Scheme 13): Key Reminder Switch Continuity Chart

Identifying Relay Locations. Scheme 14

Relay Type

Scheme 15

Scheme 16

1. Verify that the continuity is as indicated in the table. (Scheme 15): Identifying Relay Terminals - Type A If not as indicated in the table, replace the relay. (Scheme 16): Relay Continuity Chart

Scheme 17

Scheme 18

1. Verify that the continuity is as indicated in the table. (Scheme 17): Identifying Relay Terminals - Type B If not as indicated in the table, replace the relay. (Scheme 18): Relay Continuity Chart

Scheme 19

Scheme 20

1. Verify that the continuity is as indicated in the table. (Scheme 19): Identifying Relay Terminals - Type C If not as indicated in the table, replace the relay. (Scheme 20): Relay Continuity Chart
