Interior Trim System: Removal & Installation Mazda 2 II рестайлинг

Dashboard Removal Note

1. Take the dashboard out through the opened front door.

Scheme 41

1. If the bolt falls off during the removal and installation procedure, remove it from the service hole shown in the figure. (Scheme 41): Service Hole

Scheme 42

1. When inserting the bolt on the dashboard side, verify that the through-hole positions of the air intake duct and A/C unit are aligned. (Scheme 42): Air Intake Duct, A/C Unit, And Dashboard

Scheme 43

1. Disassemble in the order indicated in the table. (Scheme 43): Exploded View Of Dashboard
2. Assemble in the reverse order of disassembly.

Scheme 44

1. Pull the meter hood in the direction of the arrow shown in the figure and remove it while detaching the clips. (Scheme 44): Meter Hood
2. Install in the reverse order of removal.

Scheme 45

Scheme 46

Scheme 47

1. Pull down the steering wheel.
2. Pull the upper column cover in the direction of the arrow in the order of (1) and (2), then remove the upper column cover while detaching the tabs and pins. (Scheme 45): Upper Column Cover
3. Rotate the steering wheel to the left and right until it reaches the positions shown in the figure and remove screws A. (Scheme 46): Lower Column Cover And Screw A
4. Pull up the steering wheel.
5. Remove screw B, then remove the lower column cover in the direction of the arrow (4) while keeping it open in the direction of the arrow (3) shown in the figure. (Scheme 47): Lower Column Cover
6. Install in the reverse order of removal.

Scheme 48

1. Push both ends of the inner-side glove compartment in the direction of the arrow (1) shown in the figure, detach the pins from the dashboard, and remove the glove compartment in the direction of the arrow (2). (Scheme 48): Removing Glove Compartment
2. Install in the reverse order of removal.

Scheme 49

1. Disconnect the negative battery cable.
2. Remove the following parts: Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-517497-S16065429912012121200000) ) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-517497-S41539597602012121200000) ) Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-517497-S31639085322012121200000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [F35M-R]»(ref-517501-S39688997572012121200000) ) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-517497-S42051367322012121200000) ) Front console component (See «FRONT CONSOLE COMPONENT REMOVAL/INSTALLATION»(ref-517497-S35138574242012121200000).) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-517460-S14332073362012121200000) )
3. Remove the screw, pull the lower panel in the direction of the arrow in the order of (1), (2), (3), (4) and remove the lower panel while detaching the clips and pins. (Scheme 49): Lower Panel (Driver'S Side)
4. Disconnect the switch connector.
5. Install in the reverse order of removal.

Scheme 50

1. Remove the front scuff plate. (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-517497-S16065429912012121200000) )
2. Remove the front side trim. (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-517497-S41539597602012121200000) )
3. Pull the lower panel in the direction of the arrow in the order of (1), (2), (3), (4) then remove it while detaching the clips and pins. (Scheme 50): Lower Panel (Passenger'S Side)
4. Install in the reverse order of removal.

Scheme 51

1. Route the wiring harness as shown in the figure and pull on the center ventilator grille in the direction of the arrow to remove it. (Scheme 51): Routing Wiring Harness

Installation

Note. The center ventilator grille service part is shipped with a center ventilator grille cover as a single unit. Before installing the center ventilator grille, remove the center ventilator grille cover.

Scheme 52

Scheme 53

Scheme 54

1. Insert a flathead screwdriver into the position shown in the figure. (Scheme 52): Detaching Center Ventilator Grille Hook
2. Move a flathead screwdriver in the direction of the arrow and detach the hook, while pull the center ventilator grille.
3. Remove the center ventilator grille in the direction of the arrow from the center ventilator grille cover. (Scheme 53): Center Ventilator Grille And Ventilator Grille Cover
4. Push the center ventilator grille in the direction of the arrow and install it. (Scheme 54): Center Ventilator Grille

Scheme 55

1. Remove the following parts: Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-517497-S16065429912012121200000).) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-517497-S41539597602012121200000).) Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-517497-S31639085322012121200000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [F35M-R]»(ref-517501-S39688997572012121200000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-517497-S42051367322012121200000).) Front console component (See «FRONT CONSOLE COMPONENT REMOVAL/INSTALLATION»(ref-517497-S35138574242012121200000).) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-517460-S14332073362012121200000).) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-517497-S40475635322012121200000).) Side panel (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-517497-S11977097702012121200000).)
2. Rotate the ventilator grille to the notch in the direction of the arrow (1) shown in the figure and pull it in the direction of the arrow (2) to remove it. (Scheme 55): Rotating Ventilator Grille To Notch
3. Install in the reverse order of removal.

Scheme 56

Scheme 57

1. Remove the fastener. (Scheme 56): Identifying Side Wall And Fastener (Right-Side)
2. Pull the side wall in the direction of the arrow in the order of (1) and (2), then remove it while detaching clips A and tab B. (Scheme 57): Pulling Side Wall (Right-Side)
3. Install in the reverse order of removal.

Scheme 58

Scheme 59

1. Remove the fastener. (Scheme 58): Identifying Side Wall And Fastener (Left-Side)
2. Pull the side wall in the direction of the arrow in the order of (1) and (2), then remove it while detaching clips A and B and tab C. (Scheme 59): Pulling Side Wall (Left-Side)
3. Install in the reverse order of removal.

Scheme 60

1. Disconnect the negative battery cable (vehicles with tweeter).
2. Pull the inner garnish in the direction of the arrow shown in the figure and remove it while detaching the clips. (Scheme 60): Inner Garnish
3. Disconnect the tweeter connector (vehicles with tweeter).
4. Install in the reverse order of removal.

Scheme 61

1. Partially peel back the seaming welt.
2. Remove the following parts: Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-517497-S16065429912012121200000).) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-517497-S41539597602012121200000).) Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-517497-S31639085322012121200000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [F35M-R]»(ref-517501-S39688997572012121200000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-517497-S42051367322012121200000).) Front console component (See «FRONT CONSOLE COMPONENT REMOVAL/INSTALLATION»(ref-517497-S35138574242012121200000).) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-517460-S14332073362012121200000).) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-517497-S40475635322012121200000).)
3. Pull the side panel in the direction of the arrow shown in the figure and remove it while detaching clips A and B. (Scheme 61): Side Panel
4. Install in the reverse order of removal.

Scheme 62

1. While pressing the hook inside the service hole in the direction of the arrow (1) shown in the figure, pull the dashboard under cover in the direction of the arrow (2), and then remove the hook and the guide pin. (Scheme 62): Identifying Hook And Locating Service Hole
2. Remove the dashboard under cover.
3. Install in the reverse order of removal.

Scheme 63

Scheme 64

1. Shift lever to neutral position.
2. Remove the following parts: Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-517497-S31639085322012121200000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-517497-S42051367322012121200000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [F35M-R]»(ref-517501-S39688997572012121200000).)
3. Remove the screws, then pull the lower side of the front console component in the direction of the arrow, and remove the clips. (Scheme 63): Pulling Lower Side Of Front Console Component CAUTION: Affix protective tape to the AT shift panel to prevent scratches or damage. (ATX) (Scheme 64): Identifying AT Shift Panel Protective Tape Applying Area
4. Install the boot panel and front console as a single unit.
5. Install in the reverse order of removal.

Scheme 65

1. Disassemble in the order indicated in the table. (Scheme 65): Identifying Front Console And Boot Panel (ATX)
2. Assemble in the reverse order of disassembly.

Scheme 66

1. Disassemble in the order indicated in the table. (Scheme 66): Identifying Front Console, Boot Panel, Set Panel And Boot (MTX)
2. Assemble in the reverse order of disassembly.

Scheme 67

Scheme 68

Scheme 69

1. Disconnect the negative battery cable.
2. Pull the console panel in the direction of the arrow (1), (2) shown in the figure and remove it while detaching hooks A, tab B, and the hooks C. (Scheme 67): Pulling Console Panel
3. Disconnect the cigarette lighter connector, auxiliary jack connector and door lock switch connector (vehicles with auxiliary jack).
4. Remove nut D, then remove the clip F. (Scheme 68): Identifying Rear Console, Clip F, Pin E And Nut D
5. Pull up the rear console in the direction of the arrow (3) shown in the figure, remove clips G, move the rear console in the direction of the arrow (4), and remove it avoiding the parking brake lever. (Scheme 69): Pulling Up Rear Console CAUTION: When moving the rear console in the direction of the arrow (4), be careful not to damage pins E and H.
6. Install in the reverse order of removal.

Scheme 70

1. Remove the driver-side front scuff plate. (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-517497-S16065429912012121200000) )
2. Partially peel back the seaming welt.
3. Remove the fastener. (Scheme 70): Front Side Trim Fastener (Driver-Side)
4. Pull the front side trim in the direction of the arrow shown in the figure and remove it while detaching the clips.
5. Install in the reverse order of removal.

Scheme 71

1. Remove the passenger-side front scuff plate. (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-517497-S16065429912012121200000) )
2. Partially peel back the seaming welt.
3. Remove the cap nut. (Scheme 71): Front Side Trim Fastener (Passenger-Side)
4. Pull the front side trim in the direction of the arrow shown in the figure and remove it while detaching the clips.
5. Install in the reverse order of removal.

Scheme 72

Scheme 73

Scheme 74

1. Partially peel back the seaming welt.
2. Pull the upper end of the A-pillar trim in the direction of the arrow shown in the figure and remove clips A and B. (Scheme 72): Identifying Clips A And B
3. Cut the lead wire connecting clip B and grommet using a nipper and pull out the A-pillar trim in the direction of the arrow shown in the figure. (Scheme 73): Pulling Out A-Pillar Trim CAUTION: When pulling out the A-pillar trim, be careful not to damage the tabs.
4. Move the hook in the direction of arrows (1) and (2) shown in the figure using a flathead screwdriver and detach it from the A-pillar inner panel. (Scheme 74): Detaching Hook From A-Pillar Inner Panel
5. Remove the grommet in the direction of the arrow (3) shown in the figure.
6. When installing the A-pillar trim, install the new clip B and grommet to the A-pillar trim in advance.
7. Install in the reverse order of removal.

Scheme 75

Scheme 76

Scheme 77

1. Remove the following parts: Adjuster anchor cover (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-517512-S34297045012012121200000).) Upper anchor installation bolts of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-517512-S34297045012012121200000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-517497-S16065429912012121200000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-517497-S24677427962012121200000).)
2. Partially peel back the seaming welt.
3. Remove the B-pillar lower trim. (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-517497-S21048004882012121200000).)
4. Grasp the lower end of the B-pillar upper trim, pull it in the direction of the arrow shown in the figure, and remove hooks A, guide pin B, pins C, and clip D. (Scheme 75): Removing Hook From B-Pillar Upper Trim
5. Remove the B-pillar upper trim in the direction of the arrow shown in the figure. (Scheme 76): Removing B-Pillar Upper Trim CAUTION: When removing the B-pillar upper trim, be careful not to damage the tabs.
6. If there is a remaining clip D, rotate it 90° in the direction of the arrow shown in the figure and remove it. (Scheme 77): Identifying Clip D
7. Remove clip D and install it to the B-pillar upper trim.
8. Install in the reverse order of removal.

Scheme 78

1. Remove the front scuff plate. (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-517497-S16065429912012121200000).)
2. Remove the rear scuff plate. (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-517497-S24677427962012121200000).)
3. Partially peel back the seaming welt.
4. Pull the B-pillar lower trim in the direction of the arrow shown in the figure, detach tabs A, pins B, clips C, pins D, then remove the B-pillar lower trim. (Scheme 78): Pulling B-Pillar Lower Trim
5. Install in the reverse order of removal.

Scheme 79

Scheme 80

Scheme 81

1. Remove the following parts: Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-517497-S24677427962012121200000).) Rear seat back (See «REAR SEAT BACK REMOVAL/INSTALLATION»(ref-517469-S14714727372012121200000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-517469-S42666434332012121200000).) Lower anchor installation bolts of the rear seat belt (See «REAR SEAT BELT REMOVAL/INSTALLATION»(ref-517512-S13776436602012121200000).) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-517497-S36327941942012121200000).)
2. Partially peel back the seaming welt.
3. Remove the trunk side trim. (See NO.4 CANNOT TUNE (SEEK DOES NOT STOP) [RADIO].)
4. Pull the C-pillar trim in the direction of the arrow shown in the figure and remove it while detaching clips A and B. (Scheme 79): Pulling C-Pillar Trim
5. Cut the lead wire connecting clip B and grommet using a wire cutters. (Scheme 80): Cutting Lead Wire Connecting Clip B And Grommet
6. Pull out the rear seat belt lower anchor and remove the C-pillar trim.
7. Move the hook in the direction of arrows (1) and (2) shown in the figure using a flathead screwdriver and detach it from the rear pillar inner panel. (Scheme 81): Detaching Hook From Rear Pillar Inner Panel
8. Remove the grommet in the direction of the arrow (3) shown in the figure.
9. When installing the C-pillar trim, install the new clip and new grommet to the C-pillar trim in advance.
10. Install in the reverse order of removal.

Scheme 82

Scheme 83

1. Detach tab A while pulling the front scuff plate in the direction of the arrow (1) shown in the figure, then detach tab B, pins C, and clips D while pulling in the direction of the arrow (2). (Scheme 82): Detaching Tab B, Pins C, And Clips D From Front Scuff Plate (Front Side)
2. Detach tab A while pulling the front scuff plate in the direction of the arrow (3) shown in the figure, pull the front scuff plate in the direction of the arrow (4), and remove it while detaching tab B, pin C, and clip D. (Scheme 83): Detaching Tab B, Pins C, And Clips D From Front Scuff Plate (Rear Side)
3. Install in the reverse order of removal.

Scheme 84

Scheme 85

1. Detach tab A while pulling the rear scuff plate in the direction of the arrow (1) shown in the figure, then detach clip B, and pin C while pulling in the direction of the arrow (2). (Scheme 84): Detach Clip B And Pin C From Rear Scuff Plate (Front Side)
2. Detach tab A while pulling the rear scuff plate in the direction of the arrow (3) shown in the figure, pull the rear scuff plate in the direction of the arrow (4), and remove it while detaching clip B, pin C and tab D. (Scheme 85): Detach Clip B And Pin C From Rear Scuff Plate (Rear Side)
3. Install in the reverse order of removal.

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

1. Disconnect the negative battery cable.
2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-517497-S04981279332012121200000) )
3. Pull the cover of inner handle while remove the tabs. (Scheme 86): Identifying Inner Handle Cover, Tab And Screws
4. Remove the screw.
5. Pull in the direction of the arrow shown in the figure and remove clips A from the door inner panel using a fastener remover. (Scheme 87): A Clips At Door Inner Panel
6. Remove the front door trim in the direction of the arrow shown in the figure. (Scheme 88): Removing Front Door Trim
7. Remove the inner handle and move the front door trim in the direction of the arrow shown in the figure. (Scheme 89): Removing Inner Handle
8. Turn the inner handle 90° in the direction of the arrow and remove it from the front door trim. (Scheme 90): Turning Inner Handle
9. Disconnect the driver-side power outer mirror switch connector, driver-side power window main switch connector, and passenger-side power window subswitch connector.
10. Install in the reverse order of removal.

Scheme 91

1. Disassemble in the order shown in the figure. (Scheme 91): Identifying Front Door Trim Related Components
2. Assemble in the reverse order of disassembly.

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

1. Disconnect the negative battery cable.
2. Remove the sail inner garnish. (See «SAIL INNER GARNISH REMOVAL/INSTALLATION»(ref-517497-S22580429252012121200000) )
3. Pull the cover of inner handle while remove the tabs. (Scheme 92): Identifying Inner Handle Cover, Tab And Screws
4. Remove the screw.
5. Pull in the direction of the arrow shown in the figure and remove clips A from the door inner panel using a fastener remover. (Scheme 93): Removing Clips A From Door Inner Panel Using Fastener Remover
6. Remove the rear door trim in the direction of the arrow shown in the figure. (Scheme 94): Removing Rear Door Trim
7. Remove the inner handle and move the rear door trim in the direction of the arrow shown in the figure. (Scheme 95): Removing Inner Handle
8. Turn the inner handle 90° in the direction of the arrow and remove it from the rear door trim. (Scheme 96): Turning Inner Handle
9. Disconnect the power window subswitch connector.
10. Install in the reverse order of removal.

Scheme 97

1. Disassemble in the order indicated in the figure. (Scheme 97): Identifying Rear Door Trim Related Components
2. Assemble in the reverse order of disassembly.

Scheme 98

1. Grasp the upper end of the sail inner garnish, pull the sail inner garnish in the direction of the arrow shown in the figure, and remove it while detaching the clips. (Scheme 98): Removing Sail Inner Garnish Clips
2. Install in the reverse order of removal.

Scheme 99

Scheme 100

Scheme 101

1. Disconnect the negative battery cable.
2. Remove the following parts: Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-517497-S24677427962012121200000).) Rear seat back (See «REAR SEAT BACK REMOVAL/INSTALLATION»(ref-517469-S14714727372012121200000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-517469-S42666434332012121200000).) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-517497-S36327941942012121200000).)
3. Remove the screw A and fastener B. (Scheme 99): Identifying Screw A And Fastener B Of Trunk Side Trim
4. Pull the trunk side trim in the direction of the arrow in the order of (1) and (2), then remove the clips C. (Scheme 100): Removing Clips C From Trunk Side Trim
5. Pull the trunk side trim in the direction of the arrow in the order of (3) and remove it while detaching pins D, tabs E, and pin F. (Scheme 101): Detaching Pins D, Tabs E And Pin F From Trunk Side Trim
6. Disconnect the cargo compartment light connector.
7. Install in the reverse order of removal.

Scheme 102

1. Open the liftgate.
2. Remove the trunk mat.
3. Partially peel back the seaming welt.
4. Remove the fasteners. (Scheme 102): Pulling Trunk End Trim
5. Pull the trunk end trim in the direction of the arrow shown in the figure and remove it while detaching the hooks, tabs, clips, and pins.
6. Install in the reverse order of removal.

LIFTGATE UPPER TRIM REMOVAL/INSTALLATION

Liftgate Upper Trim Removal Caution. Scheme 103

Scheme 104

Scheme 105

1. Pull the end of liftgate upper trim outward and detach clip A, tabs B, C, pins D, and clips E. (Scheme 104): Detach Clip A, Tabs B, C, Pins D, And Clips E From End Of Liftgate Upper Trim
2. Remove the clip F then remove the liftgate upper trim. (Scheme 105): Removing Liftgate Upper Trim With Clip F
3. Install in the reverse order of removal.

Scheme 106

1. Remove the fasteners. (Scheme 106): Identifying Liftgate Lower Trim And Fasteners
2. Remove the liftgate lower trim.
3. Install in the reverse order of removal.

Scheme 107

Scheme 108

1. Insert a fastener remover in the position indicated by the arrow in the figure and detach tabs A. (Scheme 107): Detaching Liftgate Recess Tabs A
2. Remove the liftgate recess in the direction of the arrow shown in the figure avoiding tabs B. (Scheme 108): Removing Liftgate Recess
3. Install in the reverse order of removal.

Scheme 109

Scheme 110

1. Remove the screw, move the sunvisor in the direction of the arrow, and remove the sunvisor. (Scheme 109): Removing Sunvisor With Screw
2. Remove the center adaptor (sunvisor stopper) from the body using a fastener remover. (Scheme 110): Removing Center Adaptor (Sunvisor Stopper) From Body
3. Install in the reverse order of removal.

Scheme 111

Scheme 112

1. Insert a fastener remover into the assist handle service hole and remove the assist handle cover. (Scheme 111): Removing Assist Handle Cover
2. Insert the fastener remover in the position indicated by the arrow shown in the figure, push down the clip by moving the fastener remover in the direction of the arrow, and remove the assist handle from the assist handle bracket while shaking the assist handle up and down. (Scheme 112): Removing Assist Handle From Assist Handle Bracket CAUTION: When inserting a fastener remover, be careful not to damage the tabs.

Scheme 113

1. Insert the assist handle in the assist handle bracket.
2. Push the assist handle cover in the direction of the arrow shown in the figure to install the assist handle. (Scheme 113): Pushing Assist Handle Cover

Scheme 114

Scheme 115

1. Disconnect the negative battery cable.
2. Partially peel back the seaming welt.
3. Remove the following parts: A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-517497-S09928645462012121200000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-517497-S16065429912012121200000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-517497-S24677427962012121200000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-517497-S21048004882012121200000).) Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-517512-S34297045012012121200000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-517497-S24122276052012121200000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-517469-S42666434332012121200000).) Rear seat back (See «REAR SEAT BACK REMOVAL/INSTALLATION»(ref-517469-S14714727372012121200000).) Rear seat belt lower anchor installation bolt (See «REAR SEAT BELT REMOVAL/INSTALLATION»(ref-517512-S13776436602012121200000).) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-517497-S36327941942012121200000).) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-517497-S24387845502012121200000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-517497-S12505371382012121200000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-517497-S19003006492012121200000).) Rain sensor cover (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-517471-S39323855762012121200000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-517497-S00704867052012121200000).)
4. Disconnect the rain sensor connector (vehicles with auto light/wiper system).
5. Disconnect the rear window washer hose. (Scheme 114): Rear Window Washer Hose
6. Disconnect the roof wiring harness connector.
7. Remove the fasteners.
8. Take the headliner out from the opened liftgate. (Scheme 115): Removing Headliner
9. Install in the reverse order of removal.

Scheme 116

1. Disconnect the negative battery cable.
2. Remove the following parts: A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-517497-S09928645462012121200000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-517497-S16065429912012121200000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-517497-S24677427962012121200000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-517497-S21048004882012121200000).) Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-517512-S34297045012012121200000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-517497-S24122276052012121200000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-517469-S42666434332012121200000).) Rear seat back (See «REAR SEAT BACK REMOVAL/INSTALLATION»(ref-517469-S14714727372012121200000).) Rear seat belt lower anchor installation bolt (See «REAR SEAT BELT REMOVAL/INSTALLATION»(ref-517512-S13776436602012121200000).) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-517497-S36327941942012121200000).) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-517497-S24387845502012121200000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-517497-S12505371382012121200000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-517497-S19003006492012121200000).) Rain sensor cover (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-517471-S39323855762012121200000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-517497-S00704867052012121200000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-517497-S35571472892012121200000).)
3. Pinch the tab using pincers, remove clips A and B, then remove the shock-absorbing pad in the direction of the arrow shown in the figure. (Scheme 116): Shock-Absorbing Pad And Clips A And B
4. Install in the reverse order of removal.

Scheme 117

1. Disconnect the negative battery cable.
2. Remove the following parts: Driver-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-517497-S16065429912012121200000).) Driver-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-517497-S41539597602012121200000).) Rear console (See. REAR CONSOLE REMOVAL/INSTALLATION) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [F35M-R]»(ref-517501-S39688997572012121200000).) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-517460-S14332073362012121200000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-517497-S42051367322012121200000).) Front console component (See «FRONT CONSOLE COMPONENT REMOVAL/INSTALLATION»(ref-517497-S35138574242012121200000).) Driver-side lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-517497-S40475635322012121200000).)
3. Remove the bolts and nut. (Scheme 117): Identifying Knee Bolster, Bolts And Nut
4. Remove the knee bolster.
5. Install in the reverse order of removal.

Scheme 118

Scheme 119

1. Disconnect the negative battery cable.
2. Remove the following parts: Front seat (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-517469-S34704669672012121200000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-517469-S42666434332012121200000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-517497-S16065429912012121200000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-517497-S24677427962012121200000).) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-517497-S41539597602012121200000).) Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-517497-S31639085322012121200000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [F35M-R]»(ref-517501-S39688997572012121200000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-517497-S42051367322012121200000).) Front console component (See «FRONT CONSOLE COMPONENT REMOVAL/INSTALLATION»(ref-517497-S35138574242012121200000).) Steering shaft cover (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-517483-S36596734772012121200000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-517497-S21048004882012121200000).) Lower anchor installation bolts on the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-517512-S34297045012012121200000).)
3. Remove the nuts, then remove the rear console bracket in the direction of the arrow shown in the figure. (Scheme 118): Rear Console Bracket With Nuts
4. Cut the floor covering at the position indicated by the arrow (1) in the figure using scissors, detach the fasteners, then remove the floor covering in the direction of the arrow (2). (Scheme 119): Locating Floor Covering Fasteners NOTE: The cut part does not need to match up when installing the floor covering.
5. Take the floor covering out from the opened liftgate.
6. Install in the reverse order of removal.
