On-Board Diagnostic [Audio]: Overview Mazda 2 II рестайлинг

Entertainment Systems 4 illustrations ~258 words

SUPPLIER IDENTIFICATION PROCEDURE [AUDIO]

Note. When asking the supplier (service center) for repair or replacement, identify the supplier and fill in the Audio Repair Order Form using the following procedures.

Scheme 47

Scheme 47: Identification Using Label or Inscribed Lettering
Scheme 47: Identification Using Label or Inscribed Lettering
  1. Disconnect the negative battery cable.
  2. Remove the following parts: Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION».) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION».) Console panel (See «REAR CONSOLE REMOVAL/INSTALLATION».) Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION».) Side wall (See «SIDE WALL REMOVAL/INSTALLATION».) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [F35M-R]»(/mazda/2/ii-2010-2014/remont/manual-trans/#manual-transaxle-shift-mechanism-f35m-r).) Front console component (See «FRONT CONSOLE COMPONENT REMOVAL/INSTALLATION».) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION».) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION».) Center panel unit (See «CENTER PANEL UNIT REMOVAL/INSTALLATION»(/mazda/2/ii-2010-2014/remont/entertainment-systems/#entertainment-system).)
  3. Verify the supplier indicated on the label attached on each unit. (Scheme 47): Identifying Label On Center Panel Unit

Scheme 48

Scheme 48: Verify Using the Diagnostic Assist Function
Scheme 48: Verify Using the Diagnostic Assist Function

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50
  1. Switch the ignition to ACC or ON.
  2. Turn the audio unit power to on.
  3. While pressing the POWER/VOLUME switch, simultaneously press the Preset 5 switch for 3 s or more. (Scheme 48): Identifying POWER/VOLUME Switch
  4. Identify the supplier code by referring to the «LCD». (Scheme 49): Screen Display - Supplier Code LCD NOTE: The supplier code can also be identified from the DTC displays screen. (Scheme 50): Screen Display - Supplier Code
  5. To stop the diagnostic assist function, ignition is switched to off or turning off the audio unit power.
