Electronic Power Steering (Eps): Specifications Mazda 2 II рестайлинг

Electronic Steering 3 illustrations ~138 words

Torque formula

Torque unitFormula
N.mN.mx[L/A]
Kgf.mKgf.mx[L/A]
Ft.lbfFt.lbfx[L/A]

Scheme 1

Scheme 1: Boot Clamp Assembly Note
Scheme 1: Boot Clamp Assembly Note
  1. Assemble the boot clamp to the steering gear.
  2. Crimp the boot clamp using the SST. (Scheme 1): Crimping Boot Clamp Using SST
  3. Rotate the by hand and verify that it is securely installed to the boot clamp.

Scheme 2

Scheme 2: Tie-rod End Assembly Note
Scheme 2: Tie-rod End Assembly Note

Scheme 3

Scheme 3
Scheme 3
  1. Align the alignment marks made before removal and assemble the tie-rod end to the tie rod. (Scheme 2): Aligning Alignment Marks On Tie-Rod End To Tie Rod If there are no alignment marks, go to the next step.
  2. Adjust dimension A shown in the figure to the standard, then assemble the tie-rod end. (Scheme 3): Adjusting Dimension A Of Tie-Rod End Standard Dimension A 29.6-45.6 mm {1.17-1.79 in} (difference between left and right 3 mm {0.1 in} or less.)
