Component Testing Lincoln Navigator II

Accessories Control Systems 39 illustrations ~386 words

Introduction

Component testing procedures are provided to determine whether a component is good or bad.

Testing information for each component includes a schematic, a view of the terminal locations and step-by-step test procedures. Terminal locations are identified by numbers or letters that may be on the component or next to it.

Scheme 6

Scheme 6: Introduction

The component connector MUST BE REMOVED before testing. To test a single circuit within the component, select that circuit under the column "Circuit to test". If you wish to test the complete component, perform all tests.

Connect the tester to the terminals shown in the second column and operate the component as shown in the third column.

Scheme 7

Scheme 7: Ignition switch (11572)

Scheme 8

Scheme 8: Multifunction Switch, Wiper/Washer Portion

Scheme 9

Scheme 9: Multifunction Switch, Turn Portion

Scheme 10

Scheme 10

Scheme 11

Scheme 11: Multifunction Switch, Lamp Portion

Scheme 12

Scheme 12: Headlamp switch, Exterior lamps

Scheme 13

Scheme 13: Headlamp switch, Interior lamps

Disconnect the ohmmeter; connect pin 6 using a fused (10A) jumper to 12V DC power and pin 4 to ground. Measure the voltage between pin 1 and pin 4 while rotating the thumbwheel from full illumination to no illumination. If the voltage smoothly decreases from near 12 volts to near 0 volts, the illumination dimmer is okay. If not, replace the main light switch.

Scheme 14

Scheme 14: Exterior rear view mirror switch (17B676) - Expedition

Scheme 15

Scheme 15: Exterior rear view mirror switch (17B676) - Navigator

Scheme 16

Scheme 16

Scheme 17

Scheme 17: Master window adjust switch (14529) - Expedition

Scheme 18

Scheme 18

Scheme 19

Scheme 19: Master window adjust switch (14529) - Navigator

Scheme 20

Scheme 20

Scheme 21

Scheme 21: Power window switch, RH side front - Expedition

Scheme 22

Scheme 22: Window adjust switch - Expedition

Scheme 23

Scheme 23: Window adjust switch Navigator

Scheme 24

Scheme 24: Power quarter window switch - Expedition

Scheme 25

Scheme 25: Power quarter window switch - Navigator

Scheme 26

Scheme 26: Door lock switch, driver side (14028), Door lock switch, passenger side (14028) - Expedition

Scheme 27

Scheme 27: Door lock switch, driver side (14028), Door lock switch, passenger side (14028) - Navigator

Scheme 28

Scheme 28: Power seat switch, left - Expedition

Scheme 29

Scheme 29

Scheme 30

Scheme 30: Power seat switch, left - Navigator

Scheme 31

Scheme 31

Scheme 32

Scheme 32

Scheme 33

Scheme 33: Power seat switch, right - Expedition

Scheme 34

Scheme 34

Scheme 35

Scheme 35: Power seat switch, right - Navigator

Scheme 36

Scheme 36

Scheme 37

Scheme 37

Scheme 38

Scheme 38: Third row folding seat switch, left

Scheme 39

Scheme 39: Third row folding seat switch, right

Scheme 40

Scheme 40: Lumbar adjust switch, left front (14B691), Lumbar adjust switch, right front

Scheme 41

Scheme 41: Adjustable pedal switch - without memory

Scheme 42

Scheme 42: Adjustable pedal switch - with memory

Scheme 43

Scheme 43: Relay-Mini ISO

Disconnect the ohmmeter; connect pins 30 and 85 to 12V DC power and pin 86 to ground. Measure voltage between pin 87 and pin 86. If the voltage is 12V, continue with the test. If not, replace the relay. Disconnect power from pin 85 and measure voltage between pin 87a and pin 86. If the voltage is 12V, the relay is okay. If not, replace the relay.

Scheme 44

Scheme 44: Relay - Micro ISO

Disconnect the ohmmeter; connect pins 2 and 3 to 12V DC power and pin 1 to ground. Measure voltage between pin 5 and pin 1. If the voltage is 12V, continue with the test, If not, replace the relay. Disconnect power from pin 2 and measure voltage between pin 4 and pin 1. If the voltage is 12V, the relay is okay. If not, replace the relay.
