SPECIFICATIONS
| Application | Specification |
|---|
| Compressor Type | Ford FS-10 10-Cyl. |
| Compressor Belt Tension | (1) |
| System Oil Capacity (2) |
| Without Auxiliary System | 9 ozs. |
| With Auxiliary System | 11 ozs. |
| Refrigerant (R-134a) Capacity |
| Without Auxiliary System | 37 ozs. |
| With Auxiliary System | 62 ozs. |
| System Operating Pressures |
| High Side | 125-230 (8.8-16.2 kg/cm 2 ) |
| Low Side | 25-45 (1.8-3.2 kg/cm 2 ) |
| (1) Serpentine belt tension is automatically adjusted by tensioner pulley. (2) Use YN-12c PAG Refrigerant Oil (Part No. F7AZ-19589-DA). |
| (1) | Serpentine belt tension is automatically adjusted by tensioner pulley. |
| (2) | Use YN-12c PAG Refrigerant Oil (Part No. F7AZ-19589-DA). |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Compressor Bolts | 15-22 (20-30) |
| Manifold & Tube Bolt | 14-18 (18-24) |
| Steering Column Support Nuts | 10-12 (14-16) |
| INCH Lbs. (N.m) |
| Accumulator-Drier Bracket Bolt | 80-100 (9-11) |
| Auxiliary A/C-Heater System |
| Assembly Bolts | 46-64 (5-7) |
| Outlet Line-To-Evap. Case | 71 (8) |
| Refrigerant Line Peanut Fittings | 71 (8) |
| Climate Control Assembly Screws | 18-26 (2-3) |
| Condenser Bracket Bolt | 66-92 (8-10) |
| Condenser Line Nuts | 61-82 (7-9) |
| Front Fender Splash Shield Bolts | 91-123 (10-14) |
| Heater Core Bracket Screws | 13-22 (1.5-3) |
| Heater Core Outlet Bracket Screws | 13-22 (1.5-3) |
| Instrument Panel |
| Brace Bolts | 62 (7) |
| Finish Panel Bolts | 18-22 (2-3) |
| Reinforcement Bolts | 53-72 (6-8) |
| Retaining Bolts | 18-22 (2-3) |
| Panel-To-Cowl Nuts | 52-72 (6-8) |
| Passenger Side Air Bag Module Screws | 72-92 (8-10) |
| Rear Console Bolts | 92-122 (10-14) |
| Steering Column Cover Bolts | 18-22 (2-3) |
| Steering Column Cover Reinforcement Nuts | 92-122 (10-14) |
Automatic A/C-Heater System Vacuum Diagram (Expedition & Navigator). Scheme 21
Scheme 21: Automatic A/C-Heater System Vacuum Diagram (Expedition & Navigator)
Automatic A/C-Heater System Wiring Diagram (2000 Expedition - 1 Of 3). Scheme 22
Scheme 22: Automatic A/C-Heater System Wiring Diagram (2000 Expedition - 1 Of 3)
Automatic A/C-Heater System Wiring Diagram (2000 Expedition - 2 Of 3). Scheme 23
Scheme 23: Automatic A/C-Heater System Wiring Diagram (2000 Expedition - 2 Of 3)
Automatic A/C-Heater System Wiring Diagram (2000 Expedition - 3 Of 3). Scheme 24
Scheme 24: Automatic A/C-Heater System Wiring Diagram (2000 Expedition - 3 Of 3)
Automatic A/C-Heater System Wiring Diagram (2000 Navigator - 1 Of 3). Scheme 25
Scheme 25: Automatic A/C-Heater System Wiring Diagram (2000 Navigator - 1 Of 3)
Automatic A/C-Heater System Wiring Diagram (2000 Navigator - 2 Of 3). Scheme 26
Scheme 26: Automatic A/C-Heater System Wiring Diagram (2000 Navigator - 2 Of 3)
Automatic A/C-Heater System Wiring Diagram (2000 Navigator - 3 Of 3). Scheme 27
Scheme 27: Automatic A/C-Heater System Wiring Diagram (2000 Navigator - 3 Of 3)
Automatic A/C-Heater System Wiring Diagram (2001 Expedition - 1 Of 3). Scheme 28
Scheme 28: Automatic A/C-Heater System Wiring Diagram (2001 Expedition - 1 Of 3)
Automatic A/C-Heater System Wiring Diagram (2001 Expedition - 2 Of 3). Scheme 29
Scheme 29: Automatic A/C-Heater System Wiring Diagram (2001 Expedition - 2 Of 3)
Automatic A/C-Heater System Wiring Diagram (2001 Expedition - 3 Of 3). Scheme 30
Scheme 30: Automatic A/C-Heater System Wiring Diagram (2001 Expedition - 3 Of 3)
Automatic A/C-Heater System Wiring Diagram (2001 Navigator - 1 Of 3). Scheme 31
Scheme 31: Automatic A/C-Heater System Wiring Diagram (2001 Navigator - 1 Of 3)
Automatic A/C-Heater System Wiring Diagram (2001 Navigator - 2 Of 3). Scheme 32
Scheme 32: Automatic A/C-Heater System Wiring Diagram (2001 Navigator - 2 Of 3)
Automatic A/C-Heater System Wiring Diagram (2001 Navigator - 3 Of 3). Scheme 33
Scheme 33: Automatic A/C-Heater System Wiring Diagram (2001 Navigator - 3 Of 3)
