1. Using the VCT Spark Plug Tube Seal Installer and Handle, install new VCT solenoid and/or spark plug tube seals. NOTE: Installation of new seals is only required if damaged seals were removed during disassembly of the engine. NOTE: Spark plug tube seal installation shown in illustration, VCT solenoid seal installation similar.
2. Apply an 8 mm (0.31 in) bead of Motorcraft High Performance Engine RTV Silicone to the engine front cover-to-LH cylinder head joints. NOTE: Failure to use Motorcraft High Performance Engine RTV Silicone may cause the engine oil to foam excessively and result in serious engine damage. NOTE: If the valve cover is not installed and the fasteners tightened within 4 minutes, the sealant must be removed and the sealing area cleaned. To clean the sealing area, use silicone gasket remover and metal surface prep. Failure to follow this procedure can cause future oil leakage. Late build vehicles
3. Using a new gasket, install the LH valve cover and tighten the 9 stud bolts. Tighten in the sequence shown in illustration below to 10 Nm (89 lb-in). Early build vehicles
4. Using a new gasket, install the LH valve cover and 11 stud bolts. Tighten in the sequence shown in illustration below to 10 Nm (89 lb-in). All vehicles
5. Connect the 3 LH fuel injector electrical connectors.
6. Attach all of the wiring harness retainers to the valve cover and the stud bolts.
7. Install the wiring harness retaining bracket and the 2 nuts. Tighten to 4 Nm (35 lb-in).
8. Connect the 2 engine control wiring harness electrical connectors.
9. Attach the 2 wiring harness retainers.
10. Connect the LH VCT solenoid electrical connector.
11. Install the oil level indicator.
12. Install the LH ignition coils. For additional information, refer to «ENGINE IGNITION - 3.5L»(ref-355995) .
13. Install the ACL outlet pipe. For additional information, refer to «REMOVAL AND INSTALLATION»(ref-355993-S28735189342010013000000) .

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces that enters the oil passages, coolant passages or the oil pan, may cause engine failure.

Note. Early build engines have 11 fastener valve covers, late built engines have 9 fastener valve covers. Do not attempt to install bolts in the 2 empty late build valve cover holes or damage to the valve cover will occur.

All vehicles

Scheme 12

1. Remove the RH ignition coils. For additional information, refer to «ENGINE IGNITION - 3.5L»(ref-355995) .
2. Remove the power steering fluid reservoir. For additional information, refer to «REMOVAL AND INSTALLATION»(ref-355943-S13224718292010013000000) .
3. Disconnect the Power Steering Pressure (PSP) switch electrical connector.
4. Disconnect the RH Catalyst Monitor Sensor (CMS) electrical connector and retainer.
5. Remove the PSP hose bracket nut from the valve cover stud bolt and position the bracket aside.
6. Disconnect the RH Heated Oxygen Sensor (HO2S) electrical connector.
7. Disconnect the RH Variable Camshaft Timing (VCT) electrical connector.
8. Disconnect the 3 RH fuel injector electrical connectors.
9. Detach all of the wiring harness retainers from the valve cover and the stud bolts.
10. Remove the A/C tube retaining clamp bolt.
11. Remove the 2 A/C tube retaining clamp bolts. Early build vehicles
12. Loosen the bolt, the 10 stud bolts and remove the RH valve cover. Discard the gasket. NOTE: It is necessary to reposition the A/C tubes to remove the valve cover. Late build vehicles
13. Loosen the 9 stud bolts and remove the RH valve cover. Discard the gasket. NOTE: It is necessary to reposition the A/C tubes to remove the valve cover. All vehicles
14. Inspect the VCT solenoid seals and the spark plug tube seals. Remove any damaged seals. Using the VCT Spark Plug Tube Seal Remover and Handle, remove the seal(s). NOTE: VCT solenoid seal removal shown in illustration, spark plug tube seal removal similar.
15. Clean the valve cover, cylinder head and engine front cover sealing surfaces with metal surface prep.

All vehicles

Scheme 13

Scheme 14

Scheme 15

1. Using the VCT Spark Plug Tube Seal Installer and Handle, install new VCT solenoid and/or spark plug tube seals. NOTE: Installation of new seals is only required if damaged seals were removed during disassembly of the engine. NOTE: Spark plug tube seal installation shown in illustration, VCT solenoid seal installation similar.
2. Apply an 8 mm (0.31 in) bead of Motorcraft High Performance Engine RTV Silicone to the engine front cover-to-RH cylinder head joints. NOTE: Failure to use Motorcraft High Performance Engine RTV Silicone may cause the engine oil to foam excessively and result in serious engine damage. NOTE: If the valve cover is not installed and the fasteners tightened within 4 minutes, the sealant must be removed and the sealing area cleaned. To clean the sealing area, use silicone gasket remover and metal surface prep. Failure to follow this procedure can cause future oil leakage. Late build vehicles
3. Using a new gasket, install the RH valve cover and tighten the 9 stud bolts. Tighten in the sequence shown in illustration below to 10 Nm (89 lb-in). Early build vehicles
4. Using a new gasket, install the RH valve cover, bolt and the 10 stud bolts. Tighten in the sequence shown in illustration to 10 Nm (89 lb-in). All vehicles
5. Position the A/C tubes and install the 2 retaining clamp bolts. Tighten to 10 Nm (89 lb-in).
6. Install the A/C tube retaining clamp bolt. Tighten to 8 Nm (71 lb-in).
7. Attach all of the wiring harness retainers to the valve cover and the stud bolts.
8. Connect the 3 LH fuel injector electrical connectors.
9. Connect the LH VCT electrical connector.
10. Connect the RH HO2S electrical connector.
11. Install the PSP hose bracket and nut. Tighten to 9 Nm (80 lb-in).
12. Connect the RH CMS electrical connector and retainer.
13. Connect the PSP switch electrical connector.
14. Install the power steering fluid reservoir. For additional information, refer to «REMOVAL AND INSTALLATION»(ref-355943-S13224718292010013000000) .
15. Install the RH ignition coils. For additional information, refer to «ENGINE IGNITION - 3.5L»(ref-355995) .

Scheme 16

ITEM DESCRIPTION TABLE

1. For additional information, refer to the appropriate procedures.
