Multifunction Electronic Modules: Diagnosis — Lincoln MKZ I facelift (2009-2012)

Diagnostic Trouble Code (DTC) Table

Note. Most powertrain (P-code) DTCs are diagnosed in the Powertrain Control/Emissions Diagnosis (PC/ED) manual. If the P-code retrieved is not listed below, refer to INTRODUCTION - GASOLINE MODELS and/or INTRODUCTION - HYBRID to continue diagnostics.

Note. The Smart Junction Box (SJB) is also known as the Generic Electronic Module (GEM).

Note. Some of these modules utilize a 5-character DTC followed by a 2-character failure-type code. The failure-type code provides information about specific fault conditions such as opens, or shorts to ground. Continuous memory DTCs have an additional 2-character DTC status code suffix to assist in determining DTC history.

DTC	Description	Source	Action
B0001:11	Driver Frontal Stage 1 Deployment Control: Circuit Short To Ground	Restraints Control Module (RCM)	REFER to PINPOINT TEST B: B0001:11 .
B0001:12	Driver Frontal Stage 1 Deployment Control: Circuit Short To Battery	RCM	REFER to PINPOINT TEST B: B0001:12 .
B0001:13	Driver Frontal Stage 1 Deployment Control: Circuit Open	RCM	REFER to PINPOINT TEST B: B0001:13 .
B0001:1A	Driver Frontal Stage 1 Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to PINPOINT TEST B: B0001:1A .
B0001:2B	Driver Frontal Stage 1 Deployment Control: Signal Cross Coupled	RCM	REFER to PINPOINT TEST AC: B0001:2B .
B0001:4A	Driver Frontal Stage 1 Deployment Control: Incorrect Component Installed	RCM	REFER to PINPOINT TEST AD: B0001:4A .
B0002:11	Driver Frontal Stage 2 Deployment Control: Circuit Short To Ground	RCM	REFER to PINPOINT TEST C: B0002:11 .
B0002:12	Driver Frontal Stage 2 Deployment Control: Circuit Short To Battery	RCM	REFER to PINPOINT TEST C: B0002:12 .
B0002:13	Driver Frontal Stage 2 Deployment Control: Circuit Open	RCM	REFER to PINPOINT TEST C: B0002:13 .
B0002:1A	Driver Frontal Stage 2 Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to PINPOINT TEST C: B0002:1A .
B0002:2B	Driver Frontal Stage 2 Deployment Control: Signal Cross Coupled	RCM	REFER to PINPOINT TEST AC: B0002:2B .
B0002:4A	Driver Frontal Stage 2 Deployment Control: Incorrect Component Installed	RCM	REFER to PINPOINT TEST AD: B0002:4A .
B0004:11	Driver Knee Bolster Deployment Control: Circuit Short To Ground	RCM	REFER to PINPOINT TEST D: B0004:11 .
B0004:12	Driver Knee Bolster Deployment Control: Circuit Short To Battery	RCM	REFER to PINPOINT TEST D: B0004:12 .
B0004:13	Driver Knee Bolster Deployment Control: Circuit Open	RCM	REFER to PINPOINT TEST D: B0004:13 .
B0004:1A	Driver Knee Bolster Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to PINPOINT TEST D: B0004:1A .
B0004:2B	Driver Knee Bolster Deployment Control: Signal Cross Coupled	RCM	REFER to PINPOINT TEST AC: B0004:2B .
B0004:4A	Driver Knee Bolster Deployment Control: Incorrect Component Installed	RCM	REFER to PINPOINT TEST AD: B0004:4A .
B0010:11	Passenger Frontal Stage 1 Deployment Control: Circuit Short To Ground	RCM	REFER to PINPOINT TEST E: B0010:11 .
B0010:12	Passenger Frontal Stage 1 Deployment Control: Circuit Short To Battery	RCM	REFER to PINPOINT TEST E: B0010:12 .
B0010:13	Passenger Frontal Stage 1 Deployment Control: Circuit Open	RCM	REFER to PINPOINT TEST E: B0010:13 .
B0010:1A	Passenger Frontal Stage 1 Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to PINPOINT TEST E: B0010:1A .
B0010:2B	Passenger Frontal Stage 1 Deployment Control: Signal Cross Coupled	RCM	REFER to PINPOINT TEST AC: B0010:2B .
B0010:4A	Passenger Frontal Stage 1 Deployment Control: Incorrect Component Installed	RCM	REFER to PINPOINT TEST AD: B0010:4A .
B0011:11	Passenger Frontal Stage 2 Deployment Control: Circuit Short To Ground	RCM	REFER to PINPOINT TEST F: B0011:11 .
B0011:12	Passenger Frontal Stage 2 Deployment Control: Circuit Short To Battery	RCM	REFER to PINPOINT TEST F: DTCS B0011:12 .
B0011:13	Passenger Frontal Stage 2 Deployment Control: Circuit Open	RCM	REFER to PINPOINT TEST F: B0011:13 .
B0011:1A	Passenger Frontal Stage 2 Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to PINPOINT TEST F: B0011:1A .
B0011:2B	Passenger Frontal Stage 2 Deployment Control: Signal Cross Coupled	RCM	REFER to PINPOINT TEST AC: B0011:2B .
B0011:4A	Passenger Frontal Stage 2 Deployment Control: Incorrect Component Installed	RCM	REFER to PINPOINT TEST AD: B0011:4A .
B0020:11	Left Side Airbag Deployment Control: Circuit Short To Ground	RCM	REFER to PINPOINT TEST G: B0020:11 .
B0020:12	Left Side Airbag Deployment Control: Circuit Short To Battery	RCM	REFER to PINPOINT TEST G: B0020:12 .
B0020:13	Left Side Airbag Deployment Control: Circuit Open	RCM	REFER to PINPOINT TEST G: B0020:13 .
B0020:1A	Left Side Airbag Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to PINPOINT TEST G: B0020:1A .
B0020:2B	Left Side Airbag Deployment Control: Signal Cross Coupled	RCM	REFER to PINPOINT TEST AC: B0020:2B .
B0020:4A	Left Side Airbag Deployment Control: Incorrect Component Installed	RCM	REFER to PINPOINT TEST AD: B0020:4A .
B0021:11	Left Curtain Deployment Control 1: Circuit Short To Ground	RCM	REFER to PINPOINT TEST H: B0021:11 .
B0021:12	Left Curtain Deployment Control 1: Circuit Short To Battery	RCM	REFER to PINPOINT TEST H: B0021:12 .
B0021:13	Left Curtain Deployment Control 1: Circuit Open	RCM	REFER to PINPOINT TEST H: B0021:13 .
B0021:1A	Left Curtain Deployment Control 1: Circuit Resistance Below Threshold	RCM	REFER to PINPOINT TEST H: B0021:1A .
B0021:2B	Left Curtain Deployment Control 1: Signal Cross Coupled	RCM	REFER to PINPOINT TEST AC: B0021:2B .
B0021:4A	Left Curtain Deployment Control 1: Incorrect Component Installed	RCM	REFER to PINPOINT TEST AD: B0021:4A .
B0028:11	Right Side Airbag Deployment Control: Circuit Short To Ground	RCM	REFER to PINPOINT TEST I: B0028:11 .
B0028:12	Right Side Airbag Deployment Control: Circuit Short To Battery	RCM	REFER to PINPOINT TEST I: B0028:12 .
B0028:13	Right Side Airbag Deployment Control: Circuit Open	RCM	REFER to PINPOINT TEST I: B0028:13 .
B0028:1A	Right Side Airbag Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to PINPOINT TEST I: B0028:1A .
B0028:2B	Right Side Airbag Deployment Control: Signal Cross Coupled	RCM	REFER to PINPOINT TEST AC: B0028:2B .
B0028:4A	Right Side Airbag Deployment Control: Incorrect Component Installed	RCM	REFER to PINPOINT TEST AD: B0028:4A .
B0029:11	Right Curtain Deployment Control 1: Circuit Short To Ground	RCM	REFER to PINPOINT TEST J: B0029:11 .
B0029:12	Right Curtain Deployment Control 1: Circuit Short To Battery	RCM	REFER to PINPOINT TEST J: B0029:12 .
B0029:13	Right Curtain Deployment Control 1: Circuit Open	RCM	REFER to PINPOINT TEST J: B0029:13 .
B0029:1A	Right Curtain Deployment Control 1: Circuit Resistance Below Threshold	RCM	REFER to PINPOINT TEST J: B0029:1A .
B0029:2B	Right Curtain Deployment Control 1: Signal Cross Coupled	RCM	REFER to PINPOINT TEST AC: B0029:2B .
B0029:4A	Right Curtain Deployment Control 1: Incorrect Component Installed	RCM	REFER to PINPOINT TEST AD: B0029:4A .
B0050:11	Driver Seatbelt Sensor: Circuit Short To Ground	RCM	REFER to PINPOINT TEST K: B0050:11 .
B0050:12	Driver Seatbelt Sensor: Circuit Short To Battery	RCM	REFER to PINPOINT TEST K: B0050:12 .
B0050:13	Driver Seatbelt Sensor: Circuit Open	RCM	REFER to PINPOINT TEST K: B0050:13 .
B0050:1D	Driver Seatbelt Sensor: Circuit Current Out Of Range	RCM	REFER to PINPOINT TEST K: B0050:1D .
B0050:2B	Driver Seatbelt Sensor: Signal Cross Coupled	RCM	REFER to PINPOINT TEST AC: B0050:2B .
B0050:4A	Driver Seatbelt Sensor: Incorrect Component Installed	RCM	REFER to PINPOINT TEST AD: B0050:4A .
B0052:11	Passenger Seatbelt Sensor: Circuit Short To Ground	RCM	REFER to PINPOINT TEST L: B0052:11 .
B0052:12	Passenger Seatbelt Sensor: Circuit Short To Battery	RCM	REFER to PINPOINT TEST L: B0052:12 .
B0052:13	Passenger Seatbelt Sensor: Circuit Open	RCM	REFER to PINPOINT TEST L: B0052:13 .
B0052:1D	Passenger Seatbelt Sensor: Circuit Current Out Of Range	RCM	REFER to PINPOINT TEST L: B0052:1D .
B0052:2B	Passenger Seatbelt Sensor: Signal Cross Coupled	RCM	REFER to PINPOINT TEST AC: B0052:2B .
B0052:4A	Passenger Seatbelt Sensor: Incorrect Component Installed	RCM	REFER to PINPOINT TEST AD: B0052:4A .
B0090:11	Left Frontal Restraints Sensor: Circuit Short To Ground	RCM	REFER to PINPOINT TEST M: B0090:11 .
B0090:4A	Left Frontal Restraints Sensor: Incorrect Component Installed	RCM	REFER to PINPOINT TEST AD: B0090:4A .
B0090:81	Left Frontal Restraints Sensor: Invalid Serial Data Received	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0090:93	Left Frontal Restraints Sensor: No Operation	RCM	REFER to PINPOINT TEST M: B0090:93 .
B0090:96	Left Frontal Restraints Sensor: Component Internal Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0091:11	Left Side Restraints Sensor 1: Circuit Short To Ground	RCM	REFER to PINPOINT TEST N: B0091:11 .
B0091:4A	Left Side Restraints Sensor 1: Incorrect Component Installed	RCM	REFER to PINPOINT TEST AD: B0091:4A .
B0091:81	Left Side Restraints Sensor 1: Invalid Serial Data Received	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0091:93	Left Side Restraints Sensor 1: No Operation	RCM	REFER to PINPOINT TEST N: B0091:93 .
B0091:96	Left Side Restraints Sensor 1: Component Internal Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0092:11	Left Side Restraints Sensor 2: Circuit Short To Ground	RCM	REFER to PINPOINT TEST O: B0092:11 .
B0092:4A	Left Side Restraints Sensor 2: Incorrect Component Installed	RCM	REFER to PINPOINT TEST AD: B0092:4A .
B0092:81	Left Side Restraints Sensor 2: Invalid Serial Data Received	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0092:93	Left Side Restraints Sensor 2: No Operation	RCM	REFER to PINPOINT TEST O: B0092:93 .
B0092:96	Left Side Restraints Sensor 2: Component Internal Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0095:11	Right Frontal Restraints Sensor: Circuit Short To Ground	RCM	REFER to PINPOINT TEST P: B0095:11 .
B0095:4A	Right Frontal Restraints Sensor: Incorrect Component Installed	RCM	REFER to PINPOINT TEST AD: B0095:4A .
B0095:81	Right Frontal Restraints Sensor: Invalid Serial Data Received	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0095:93	Right Frontal Restraints Sensor: No Operation	RCM	REFER to PINPOINT TEST P: B0095:93 .
B0095:96	Right Frontal Restraints Sensor: Component Internal Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0096:11	Right Side Restraints Sensor 1: Circuit Short To Ground	RCM	REFER to PINPOINT TEST O: B0096:11 .
B0096:4A	Right Side Restraints Sensor 1: Incorrect Component Installed	RCM	REFER to PINPOINT TEST AD: B0096:4A .
B0096:81	Right Side Restraints Sensor 1: Invalid Serial Data Received	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0096:93	Right Side Restraints Sensor 1: No Operation	RCM	REFER to PINPOINT TEST O: B0096:93 .
B0096:96	Right Side Restraints Sensor 1: Component Internal Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0097:11	Right Side Restraints Sensor 2: Circuit Short To Ground	RCM	REFER to PINPOINT TEST N: B0097:11 .
B0097:4A	Right Side Restraints Sensor 2: Incorrect Component Installed	RCM	REFER to PINPOINT TEST AD: B0097:4A .
B0097:81	Right Side Restraints Sensor 2: Invalid Serial Data Received	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0097:93	Right Side Restraints Sensor 2: No Operation	RCM	REFER to PINPOINT TEST N: B0097:93 .
B0097:96	Right Side Restraints Sensor 2: Component Internal Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00A0:09	Occupant Classification System: Component Failures	RCM	REFER to PINPOINT TEST S: B00A0:09 .
B00A0:4A	Occupant Classification System: Incorrect Component Installed	RCM	REFER to PINPOINT TEST S: B00A0:4A .
B00A0:54	Occupant Classification System: Missing Calibration	Occupant Classification System Module (OCSM)	REFER to PINPOINT TEST AE: B00A0:54 .
B00A0:63	Occupant Classification System: Circuit/Component Protection Time-Out	RCM	REFER to PINPOINT TEST S: B00A0:63 .
B00A0:64	Occupant Classification System: Signal Plausibility Failure	RCM	REFER to PINPOINT TEST S: B00A0:64 .
B00A0:67	Occupant Classification System: Signal Incorrect After Event	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00A0:68	Occupant Classification System: Event Information	RCM	REFER to PINPOINT TEST S: B00A0:68 .
B00A0:76	Occupant Classification System: Wrong Mounting Position	OCSM	REFER to PINPOINT TEST AE: B00A0:76 .
B00A0:97	Occupant Classification System: Component or System Operation Obstructed or Blocked	OCSM	REFER to PINPOINT TEST T: B00A0:97 .
B00B5:11	Driver Seat Track Position Restraints Sensor: Circuit Short To Ground	RCM	REFER to PINPOINT TEST Y: B00B5:11 .
B00B5:12	Driver Seat Track Position Restraints Sensor: Circuit Short To Battery	RCM	REFER to PINPOINT TEST Y: B00B5:12 .
B00B5:13	Driver Seat Track Position Restraints Sensor: Circuit Open	RCM	REFER to PINPOINT TEST Y: B00B5:13 .
B00B5:1D	Driver Seat Track Position Restraints Sensor: Circuit Current Out Of Range	RCM	REFER to PINPOINT TEST Y: B00B5:1D .
B00B5:2B	Driver Seat Track Position Restraints Sensor: Signal Cross Coupled	RCM	REFER to PINPOINT TEST AC: B00B5:2B .
B00B5:4A	Driver Seat Track Position Restraints Sensor: Incorrect Component Installed	RCM	REFER to PINPOINT TEST AD: B00B5:4A .
B00C0:12	Passenger Seat Occupant Classification Sensor "A": Circuit Short To Battery	OCSM	REFER to PINPOINT TEST U: B00C0:12 .
B00C0:13	Passenger Seat Occupant Classification Sensor "A": Circuit Open	OCSM	REFER to PINPOINT TEST U: B00C0:13 .
B00C0:1A	Passenger Seat Occupant Classification Sensor "A": Circuit Resistance Below Threshold	OCSM	REFER to PINPOINT TEST U: B00C0:1A .
B00C0:49	Passenger Seat Occupant Classification Sensor "A": Internal Electronic Failure	OCSM	REFER to PINPOINT TEST AE: B00C0:49 .
B00C0:81	Passenger Seat Occupant Classification Sensor "A": Invalid Serial Data Received	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00C1:12	Passenger Seat Occupant Classification Sensor "B": Circuit Short To Battery	OCSM	REFER to PINPOINT TEST V: B00C1:12 .
B00C1:13	Passenger Seat Occupant Classification Sensor "B": Circuit Open	OCSM	REFER to PINPOINT TEST V: B00C1:13 .
B00C1:1A	Passenger Seat Occupant Classification Sensor "B": Circuit Resistance Below Threshold	OCSM	REFER to PINPOINT TEST V: B00C1:1A .
B00C1:49	Passenger Seat Occupant Classification Sensor "B": Internal Electronic Failure	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00C1:81	Passenger Seat Occupant Classification Sensor "B": Invalid Serial Data Received	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00C2:12	Passenger Seat Occupant Classification Sensor "C": Circuit Short To Battery	OCSM	REFER to PINPOINT TEST W: B00C2:12 .
B00C2:13	Passenger Seat Occupant Classification Sensor "C": Circuit Open	OCSM	REFER to PINPOINT TEST W: B00C2:13 .
B00C2:1A	Passenger Seat Occupant Classification Sensor "C": Circuit Resistance Below Threshold	OCSM	REFER to PINPOINT TEST W: B00C2:1A .
B00C2:49	Passenger Seat Occupant Classification Sensor "C": Internal Electronic Failure	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00C2:81	Passenger Seat Occupant Classification Sensor "C": Invalid Serial Data Received	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00C3:12	Passenger Seat Occupant Classification Sensor "D": Circuit Short To Battery	OCSM	REFER to PINPOINT TEST X: B00C3:12 .
B00C3:13	Passenger Seat Occupant Classification Sensor "D": Circuit Open	OCSM	REFER to PINPOINT TEST X: B00C3:13 .
B00C3:1A	Passenger Seat Occupant Classification Sensor "D": Circuit Resistance Below Threshold	OCSM	REFER to PINPOINT TEST X: B00C3:1A .
B00C3:49	Passenger Seat Occupant Classification Sensor "D": Internal Electronic Failure	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00C3:81	Passenger Seat Occupant Classification Sensor "D": Invalid Serial Data Received	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00D5:11	Restraint System Passenger Disable Indicator: Circuit Short To Ground	RCM	REFER to PINPOINT TEST Z: B00D5:11 .
B00D5:12	Restraint System Passenger Disable Indicator: Circuit Short To Battery	RCM	REFER to PINPOINT TEST Z: B00D5:12 .
B00D5:13	Restraint System Passenger Disable Indicator: Circuit Open	RCM	REFER to PINPOINT TEST Z: B00D5:13 .
B00D5:4A	Restraint System Passenger Disable Indicator: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1030:12	Left Front Seat Heater: Circuit Short To Battery	HVAC module	REFER to SEATING .
B1030:14	Left Front Seat Heater: Circuit Short To Ground Or Open	HVAC module	REFER to SEATING .
B1031	SDARS Satellite Antenna Open	Audio Control Module (ACM)	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1032	SDARS Satellite Antenna Short	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1032:12	Right Front Seat Heater: Circuit Short To Battery	HVAC module	REFER to SEATING .
B1032:14	Right Front Seat Heater: Circuit Short To Ground Or Open	HVAC module	REFER to SEATING .
B103B	Thermoelectric Driver Overcurrent Low	Dual Climate Controlled Seat Module (DCSM)	REFER to PINPOINT TEST W: DTCS B103B AND B1111 .
B103C	Thermoelectric Driver Open Load	DCSM	REFER to PINPOINT TEST X: DTC B103C .
B103D	Blower Driver Overtemperature	DCSM	REFER to PINPOINT TEST Y: DTC B103D .
B106B	Tire Pressure Sensor Low Battery	Smart Junction Box (SJB)	REFER to PINPOINT TEST G: DTC B106B .
B106D	Tire Pressure Monitor System ( TPMS ) Initiators Not Configured	SJB	REFER to WHEELS & TIRES .
B106E	Solid State Driver Disabled Due to Short Circuit	Driver Door Module (DDM)	REFER to DRIVER DOOR MODULE (DDM) .
B106E	Solid State Driver Disabled Due to Short Circuit	Driver Seat Module (DSM)	REFER to DRIVER SEAT MODULE (DSM) .
B106E	Solid State Driver Disabled Due to Short Circuit	Interior Lighting Control Module (ILCM)	REFER to INTERIOR LIGHTING .
B106E	Solid State Driver Disabled Due to Short Circuit	SJB	REFER to SMART JUNCTION BOX (SJB) .
B106F	Module Disabled Due to External Fault	DDM	REFER to DRIVER DOOR MODULE (DDM) .
B106F	Module Disabled Due to External Fault	DSM	REFER to DRIVER SEAT MODULE (DSM) .
B106F	Module Disabled Due to External Fault	ILCM	REFER to INTERIOR LIGHTING .
B106F	Module Disabled Due to External Fault	SJB	REFER to SMART JUNCTION BOX (SJB) .
B1081:07	Left Temperature Damper Motor: Mechanical Failures	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1081:11	Left Temperature Damper Motor: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1081:12	Left Temperature Damper Motor: Circuit Short To Battery	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1081:13	Left Temperature Damper Motor: Circuit Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1082:07	Right Temperature Damper Motor: Mechanical Failures	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1082:11	Right Temperature Damper Motor: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1082:12	Right Temperature Damper Motor: Circuit Short To Battery	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1082:13	Right Temperature Damper Motor: Circuit Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1083:07	Recirculation Damper Motor: Mechanical Failures	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
B1083:11	Recirculation Damper Motor: Circuit Short To Ground	HVAC module	For non-Hybrid vehicles, REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1083:11	Recirculation Damper Motor: Circuit Short To Ground	HVAC module	For Hybrid vehicles, REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
B1083:12	Recirculation Damper Motor: Circuit Short To Battery	HVAC module	For non-Hybrid vehicles, REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1083:12	Recirculation Damper Motor: Circuit Short To Battery	HVAC module	For Hybrid vehicles, REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
B1083:13	Recirculation Damper Motor: Circuit Open	HVAC module	For non-Hybrid vehicles, REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1083:13	Recirculation Damper Motor: Circuit Open	HVAC module	For Hybrid vehicles, REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
B1086:07	Air Distribution Damper Motor: Mechanical Failures	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1086:11	Air Distribution Damper Motor: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1086:12	Air Distribution Damper Motor: Circuit Short To Battery	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1086:13	Air Distribution Damper Motor: Circuit Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B109E:42	Remote Keyless Entry: General Memory Failure	Instrument Panel Cluster (IPC)	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B109E:51	Remote Keyless Entry: Not Programmed	IPC	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B109E:86	Remote Keyless Entry: Signal Invalid	IPC	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B10A2:16	Crash Input: Circuit Voltage Below Threshold	Battery Energy Control Module (BECM)	REFER to HIGH VOLTAGE TRACTION BATTERY .
B10AF:12	Blower Fan Relay: Circuit Short To Battery	HVAC module	For non-Hybrid vehicles, REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B10AF:12	Blower Fan Relay: Circuit Short To Battery	HVAC module	For Hybrid vehicles, REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
B10AF:14	Blower Fan Relay: Circuit Short To Ground Or Open	HVAC module	For non-Hybrid vehicles, REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B10AF:14	Blower Fan Relay: Circuit Short To Ground Or Open	HVAC module	For Hybrid vehicles, REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
B10B8:00	Push Buttons: No Sub Type Information	HVAC module	For non-Hybrid vehicles, REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B10B8:00	Push Buttons: No Sub Type Information	HVAC module	For Hybrid vehicles, REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
B10B9:12	Blower Control: Circuit Short To Battery	HVAC module	For non-Hybrid vehicles, REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B10B9:12	Blower Control: Circuit Short To Battery	HVAC module	For Hybrid vehicles, REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
B10B9:14	Blower Control: Circuit Short To Ground Or Open	HVAC module	For non-Hybrid vehicles, REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B10B9:14	Blower Control: Circuit Short To Ground Or Open	HVAC module	For Hybrid vehicles, REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
B10D5:13	PATS Antenna: Circuit Open	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D7:05	PATS Key: System Programming Failures	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D7:51	PATS Key: Not Programmed	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D7:87	PATS Key: Missing Message	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D7:8F	PATS Key: Erratic	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D8:00	PATS Key Less Than Minimum Programmed: No Sub Type Information	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D9:87	PATS Transponder: Missing Message	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10DA:51	PATS PCM Identifier: Not Programmed	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10DA:61	PATS PCM Identifier: Signal Calculation Failure	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10DA:86	PATS PCM Identifier: Signal Invalid	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B1111	Driver Thermal Electric Device Control Overtemperature Fault	DCSM	REFER to SEATING .
B1113	Passenger Thermal Electric Device Control Overtemperature Fault	DCSM	REFER to SEATING .
B1117	Audio Steering Wheel Button Stuck	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B111B	Passenger Thermoelectric Driver Overcurrent Low	DCSM	REFER to SEATING .
B111C	Passenger Thermoelectric Driver Open Load	DCSM	REFER to SEATING .
B111D	Passenger Blower Driver Overtemperature	DCSM	REFER to SEATING .
B1138	Memory Full	SJB	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B1139	Invalid Transmitter Identification Code	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1193:00	Crash Event Storage Full and Locked: No Sub Type Information	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1193:00	Crash Event Storage Full and Locked: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B119F:01	GPS Antenna: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B119F:13	GPS Antenna: Circuit Open	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B11BA:1C	Steering Wheel Audio Switch Pack: Circuit Voltage Out Of Range	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B11BA:63	Steering Wheel Audio Switch Pack: Circuit/Component Protection Time-Out	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B11D5:68	Restraints Event - Vehicle Disabled: Event Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
B11D6:11	Driver Display Alert LED: Circuit Short To Ground	Side Obstacle Detection Control Module - Left (SOD-L)	REFER to SIDE AND REAR VISION .
B11D6:11	Driver Display Alert LED: Circuit Short To Ground	Side Obstacle Detection Control Module - Right (SOD-R)	REFER to SIDE AND REAR VISION .
B11D6:15	Driver Display Alert LED: Circuit Short To Battery Or Open	SOD-L	REFER to SIDE AND REAR VISION .
B11D6:15	Driver Display Alert LED: Circuit Short To Battery Or Open	SOD-R	REFER to SIDE AND REAR VISION .
B11D8:11	Restraint Event Notification: Circuit Short To Ground	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
B11D8:15	Restraint Event Notification: Circuit Short To Battery Or Open	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
B11D8:31	Restraint Event Notification: No Signal	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
B11D8:36	Restraint Event Notification: Signal Frequency Too Low	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
B11D8:37	Restraint Event Notification: Signal Frequency Too High	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
B11D8:38	Restraint Event Notification: Signal Frequency Incorrect	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
B11E5:11	Left HVAC Damper Position Sensor: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B11E5:15	Left HVAC Damper Position Sensor: Circuit Short To Battery Or Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B11E6:11	Right HVAC Damper Position Sensor: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B11E6:15	Right HVAC Damper Position Sensor: Circuit Short To Battery Or Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B11E7:11	Air Distribution Damper Position Sensor: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B11E7:15	Air Distribution Damper Position Sensor: Circuit Short To Battery Or Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B11EE:19	A/C Compressor: Circuit Current Above Threshold	Air Conditioning Compressor Module (ACCM)	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
B11EE:49	A/C Compressor: Internal Electronic Failure	ACCM	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
B11EE:4B	A/C Compressor: Over Temperature	ACCM	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
B11F0:11	Air Intake Damper Position Sensor: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
B11F0:15	Air Intake Damper Position Sensor: Circuit Short To Battery Or Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
B1201:1C	Steering Wheel Audio Switch Pack 2: Circuit Voltage Out Of Range	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1201:1C	Steering Wheel Audio Switch Pack 2: Circuit Voltage Out Of Range	Accessory Protocol Interface Module (APIM)	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1201:63	Steering Wheel Audio Switch Pack 2: Circuit/Component Protection Time-Out	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1201:63	Steering Wheel Audio Switch Pack 2: Circuit/Component Protection Time-Out	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1211:11	Driver Seatbelt Retractor Pretensioner Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1211:12	Driver Seatbelt Retractor Pretensioner Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1211:13	Driver Seatbelt Retractor Pretensioner Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1211:1A	Driver Seatbelt Retractor Pretensioner Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1211:2B	Driver Seatbelt Retractor Pretensioner Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1211:4A	Driver Seatbelt Retractor Pretensioner Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1214:11	Passenger Seatbelt Retractor Pretensioner Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1214:12	Passenger Seatbelt Retractor Pretensioner Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1214:13	Passenger Seatbelt Retractor Pretensioner Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1214:1A	Passenger Seatbelt Retractor Pretensioner Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1214:2B	Passenger Seatbelt Retractor Pretensioner Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1214:4A	Passenger Seatbelt Retractor Pretensioner Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B121C:01	Hard Drive: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1252:04	USB Port: System Internal Failures	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1252:11	USB Port: Circuit Short To Ground	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1299	Power Supply Sensor Circuit Short to Ground	Parking Aid Module (PAM)	REFER to PARKING AID .
B1302	Accessory Delay Relay Coil Circuit Failure	SJB	REFER to GLASS, FRAMES AND MECHANISMS .
B1304	Accessory Delay Relay Coil Circuit Short to Battery	SJB	REFER to GLASS, FRAMES AND MECHANISMS .
B1317	Battery Voltage High	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
B1317	Battery Voltage High	DDM	REFER to DRIVER DOOR MODULE (DDM) .
B1317	Battery Voltage High	DSM	REFER to DRIVER SEAT MODULE (DSM) .
B1317	Battery Voltage High	SJB	REFER to SMART JUNCTION BOX (SJB) .
B1318	Battery Voltage Low	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
B1318	Battery Voltage Low	ACM	REFER to CHARGING SYSTEM .
B1318	Battery Voltage Low	DDM	REFER to DRIVER DOOR MODULE (DDM) .
B1318	Battery Voltage Low	DSM	REFER to DRIVER SEAT MODULE (DSM) .
B1318	Battery Voltage Low	Front Controls Interface Module (FCIM)	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1318	Battery Voltage Low	Front Display Interface Module (FDIM)	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1318	Battery Voltage Low	SJB	REFER to SMART JUNCTION BOX (SJB) .
B1320	Driver Door Ajar Circuit Open	SJB	REFER to INTERIOR LIGHTING .
B1328	Passenger Door Ajar Circuit Open	SJB	REFER to INTERIOR LIGHTING .
B1331	Decklid Ajar Rear Door Circuit Failure	SJB	REFER to INTERIOR LIGHTING .
B1336	Door Ajar RR Circuit Open	SJB	REFER to INTERIOR LIGHTING .
B1342	ECU is Faulted	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
B1342	ECU is Faulted	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
B1342	ECU is Faulted	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1342	ECU is Faulted	DCSM	REFER to SEATING .
B1342	ECU is Faulted	DDM	REFER to DRIVER DOOR MODULE (DDM) .
B1342	ECU is Faulted	DSM	REFER to DRIVER SEAT MODULE (DSM) .
B1342	ECU is Faulted	FCIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1342	ECU is Faulted	FDIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1342	ECU is Faulted	ILCM	REFER to INTERIOR LIGHTING .
B1342	ECU is Faulted	PAM	CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new PAM . REFER to PARKING AID .
B1342	ECU is Faulted	PCM	CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new PCM. Refer to the appropriate Electronic Engine Control article for the procedure. REPEAT the self-test.
B1342	ECU is Faulted	SJB	REFER to SMART JUNCTION BOX (SJB) .
B1352	Ignition Key-In Circuit Failure	SJB	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B1472	Lamp Headlamp Input Circuit Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B1483	Brake Pedal Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
B1485	Brake Pedal Input Short to Battery	SJB	REFER to EXTERIOR LIGHTING .
B1510	Flash to Pass Switch Circuit Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B1520	Hood Switch Circuit Open	SJB	REFER to ANTI-THEFT - PERIMETER .
B1534	Memory 1 Switch Circuit Short to Ground	DDM	REFER to SEATING .
B1538	Memory 2 Switch Circuit Short to Ground	DDM	REFER to SEATING .
B1572	Door Ajar LR Circuit Open	SJB	REFER to INTERIOR LIGHTING .
B1578	Lamp Park Input Circuit Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B1624	Lamp Keypad Output Open Circuit	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1626	Lamp Keypad Output Short Circuit to Ground	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1663	Seat Driver Front Up/Down Motor Stalled	DSM	REFER to SEATING .
B1664	Seat Driver Rear Up/Down Motor Stalled	DSM	REFER to SEATING .
B1665	Seat Driver Forward/Backward Motor Stalled	DSM	REFER to SEATING .
B1666	Seat Driver Recline Motor Stalled	DSM	REFER to SEATING .
B1667	Mirror Driver Up/Down Motor Stalled	DDM	REFER to REAR VIEW MIRRORS .
B1668	Mirror Driver Right/Left Motor Stalled	DDM	REFER to REAR VIEW MIRRORS .
B1669	Mirror Passenger Up/Down Motor Stalled	DSM	REFER to REAR VIEW MIRRORS .
B1670	Mirror Passenger Right/Left Motor Stalled	DSM	REFER to REAR VIEW MIRRORS .
B1676	Battery Pack Voltage Out of Range	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
B1696	Autolamp On Circuit Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B1703	Seat Driver Recline Forward Switch Circuit Short To Battery	DSM	REFER to SEATING .
B1707	Seat Driver Recline Rearward Switch Circuit Short To Battery	DSM	REFER to SEATING .
B1711	Seat Driver Front Up Switch Circuit Short To Battery	DSM	REFER to SEATING .
B1715	Seat Driver Front Down Switch Circuit Short To Battery	DSM	REFER to SEATING .
B1719	Seat Driver Forward Switch Circuit Short To Battery	DSM	REFER to SEATING .
B1723	Seat Driver Rearward Switch Circuit Short To Battery	DSM	REFER to SEATING .
B1727	Seat Driver Rear Up Switch Circuit Short To Battery	DSM	REFER to SEATING .
B1731	Seat Driver Rear Down Switch Circuit Short To Battery	DSM	REFER to SEATING .
B1733	Mirror Driver Vertical Switch Circuit Failure	DDM	REFER to REAR VIEW MIRRORS .
B1737	Mirror Driver Horizontal Switch Circuit Failure	DDM	REFER to REAR VIEW MIRRORS .
B1741	Mirror Passenger Vertical Switch Circuit Failure	DDM	REFER to REAR VIEW MIRRORS .
B1745	Mirror Passenger Horizontal Switch Circuit Failure	DDM	REFER to REAR VIEW MIRRORS .
B1791	Autolamp Sensor Input Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B1793	Autolamp Sensor Input Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B1952	Seat Rear Up/Down Position Feedback Circuit Short To Battery	DSM	REFER to SEATING .
B1953	Seat Rear Up/Down Position Feedback Circuit Short To Ground	DSM	REFER to SEATING .
B1956	Seat Front Up/Down Position Feedback Circuit Short To Battery	DSM	REFER to SEATING .
B1957	Seat Front Up/Down Position Feedback Circuit Short To Ground	DSM	REFER to SEATING .
B1960	Seat Recline Forward/Backward Position Feedback Circuit Short To Battery	DSM	REFER to SEATING .
B1961	Seat Recline Forward/Backward Position Feedback Circuit Short To Ground	DSM	REFER to SEATING .
B1964	Seat Horizontal Forward/Rearward Position Feedback Circuit Short To Battery	DSM	REFER to SEATING .
B1965	Seat Horizontal Forward/Rearward Position Feedback Circuit Short To Ground	DSM	REFER to SEATING .
B19A1	Passenger Seat Cushion Blower Speed Short To Battery	DCSM	REFER to SEATING .
B19A2	Passenger Seat Back Blower Speed Short To Battery	DCSM	REFER to SEATING .
B19A3	Driver Seat Cushion Blower Speed Short To Battery	DCSM	REFER to SEATING .
B19A4	Driver Seat Back Blower Speed Short To Battery	DCSM	REFER to SEATING .
B19A5	Passenger Seat Cushion Blower Speed Short To Ground	DCSM	REFER to SEATING .
B19A6	Passenger Seat Back Blower Speed Short To Ground	DCSM	REFER to SEATING .
B19A7	Driver Seat Cushion Blower Speed Short To Ground	DCSM	REFER to SEATING .
B19A8	Driver Seat Back Blower Speed Short To Ground	DCSM	REFER to SEATING .
B1A01:01	Speaker #1: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A01:01	Speaker #1: General Electrical Failure	Audio Digital Signal Processing (DSP) module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A01:11	Speaker #1: Circuit Short To Ground	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A01:11	Speaker #1: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A01:12	Speaker #1: Circuit Short To Battery	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A01:12	Speaker #1: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A01:13	Speaker #1: Circuit Open	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A01:13	Speaker #1: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A02:01	Speaker #2: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A02:01	Speaker #2: General Electrical Failure	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A02:11	Speaker #2: Circuit Short To Ground	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A02:11	Speaker #2: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A02:12	Speaker #2: Circuit Short To Battery	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A02:12	Speaker #2: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A02:13	Speaker #2: Circuit Open	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A02:13	Speaker #2: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A03:01	Speaker #3: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A03:01	Speaker #3: General Electrical Failure	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A03:11	Speaker #3: Circuit Short To Ground	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A03:11	Speaker #3: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A03:12	Speaker #3: Circuit Short To Battery	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A03:12	Speaker #3: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A03:13	Speaker #3: Circuit Open	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A03:13	Speaker #3: Circuit Short To Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A04:01	Speaker #4: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A04:01	Speaker #4: General Electrical Failure	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A04:11	Speaker #4: Circuit Short To Ground	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A04:11	Speaker #4: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A04:12	Speaker #4: Circuit Short To Battery	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A04:12	Speaker #4: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A04:13	Speaker #4: Circuit Open	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A04:13	Speaker #4: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A05:01	Speaker #5: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A05:01	Speaker #5: General Electrical Failure	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A05:02	Speaker #5: General Signal Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A05:11	Speaker #5: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A05:12	Speaker #5: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A05:13	Speaker #5: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A06:01	Speaker #6: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A06:01	Speaker #6: General Electrical Failure	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A06:02	Speaker #6: General Signal Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A06:11	Speaker #6: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A06:12	Speaker #6: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A06:13	Speaker #6: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A07:01	Speaker #7: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A07:01	Speaker #7: General Electrical Failure	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A07:11	Speaker #7: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A07:12	Speaker #7: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A07:13	Speaker #7: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A08:01	Speaker #8: General Electrical Failure	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A08:11	Speaker #8: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A08:12	Speaker #8: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A08:13	Speaker #8: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A09:02	Speaker #9: General Signal Failure	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A09:11	Speaker #9: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A09:12	Speaker #9: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A09:13	Speaker #9: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A10:11	Speaker #10: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A10:12	Speaker #10: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A10:13	Speaker #10: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A11:11	Speaker #11: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A11:12	Speaker #11: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A11:13	Speaker #11: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A12:11	Speaker #12: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A12:12	Speaker #12: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A12:13	Speaker #12: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A56:21	Antenna: Signal Amplitude < Minimum	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A59:01	Sensor 5 Volt Supply: General Electrical Failure	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1A59:11	Sensor 5 Volt Supply: Circuit Short To Ground	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1A61:11	Cabin Temperature Sensor: Circuit Short To Ground	HVAC module	For non-Hybrid vehicles, REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1A61:11	Cabin Temperature Sensor: Circuit Short To Ground	HVAC module	For Hybrid vehicles, REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
B1A61:15	Cabin Temperature Sensor: Circuit Short To Battery Or Open	HVAC module	For non-Hybrid vehicles, REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1A61:15	Cabin Temperature Sensor: Circuit Short To Battery Or Open	HVAC module	For Hybrid vehicles, REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
B1A63:11	Right Solar Sensor: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1A63:15	Right Solar Sensor: Circuit Short To Battery Or Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1A64:11	Left Solar Sensor: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1A64:15	Left Solar Sensor: Circuit Short To Battery Or Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1A68:11	Ambient Temperature Sensor: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1A68:15	Ambient Temperature Sensor: Circuit Short To Battery Or Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1A69:11	Humidity Sensor: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
B1A69:15	Humidity Sensor: Circuit Short To Battery Or Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
B1A82:09	External Trip Switch: Component Failures	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B1A82:11	External Trip Switch: Circuit Short To Ground	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B1A82:13	External Trip Switch: Circuit Open	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B1A89:01	Satellite Antenna: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A89:13	Satellite Antenna: Circuit Open	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A98:88	LIN Bus Circuit #1: Bus Off	Headlamp Control Module (HCM)	REFER to EXTERIOR LIGHTING .
B1B71:11	Evaporator Temperature Sensor: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1B71:15	Evaporator Temperature Sensor: Circuit Short To Battery Or Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1C83:12	Rear Defog Relay: Circuit Short To Battery	HVAC module	REFER to GLASS, FRAMES AND MECHANISMS .
B1C83:14	Rear Defog Relay: Circuit Short To Ground Or Open	HVAC module	REFER to GLASS, FRAMES AND MECHANISMS .
B1D19:49	Compact Disc Unit: Internal Electronic Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1D19:4B	Compact Disc Unit: Over Temperature	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1D23:68	Overheat Sensor: Event Information	Power Steering Control Module (PSCM)	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
B1D64:01	Left Headlamp Swivelling Motor: General Electrical Failure	HCM	REFER to EXTERIOR LIGHTING .
B1D64:87	Left Headlamp Swivelling Motor: Missing Message	HCM	REFER to EXTERIOR LIGHTING .
B1D65:01	Right Headlamp Swivelling Motor: General Electrical Failure	HCM	REFER to EXTERIOR LIGHTING .
B1D65:87	Right Headlamp Swivelling Motor: Missing Message	HCM	REFER to EXTERIOR LIGHTING .
B1D78:13	Auxiliary Input: Circuit Open	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1D79:01	Microphone Input: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2008	Wipers On Signal Circuit Short To Ground	SJB	REFER to WIPERS AND WASHERS .
B2044	Left Rear Stop Lamp Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2045	Left Rear Stop Lamp Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2046	Right Rear Stop Lamp Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2047	Right Rear Stop Lamp Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2048	Left Rear Turn Lamp Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2049	Left Rear Turn Lamp Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2050	Right Rear Turn Lamp Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2051	Right Rear Turn Lamp Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2071	Hazard Switch Signal Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2100	Door Driver Key Cylinder Switch Failure	SJB	REFER to ANTI-THEFT - PERIMETER .
B2103	Antenna Not Connected	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2108	Trunk Key Cylinder Switch Failure	SJB	REFER to ANTI-THEFT - PERIMETER .
B213A	Digital Dimmer Switch Input Circuit Failure	SJB	REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION .
B2143	NVM Memory Failure	DSM	REFER to SEATING .
B2223	Mirror Driver Drive Circuit Failure	DDM	REFER to REAR VIEW MIRRORS .
B2224	Mirror Passenger Drive Circuit Failure	DSM	REFER to REAR VIEW MIRRORS .
B2254	Front Fog Lamp Switch Failure	SJB	REFER to EXTERIOR LIGHTING .
B2276	Less Than 2 Transmitters Programmed	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2281	Right Turn Switch Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2282	Left Turn Switch Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2312	Mirror Passenger Horizontal Feedback Potentiometer Circuit Failure	DSM	REFER to REAR VIEW MIRRORS .
B2314	Mirror Passenger Horizontal Feedback Potentiometer Circuit Short to Battery	DSM	REFER to REAR VIEW MIRRORS .
B2316	Mirror Passenger Vertical Feedback Potentiometer Circuit Failure	DSM	REFER to REAR VIEW MIRRORS .
B2318	Mirror Passenger Vertical Feedback Potentiometer Circuit Short To Battery	DSM	REFER to REAR VIEW MIRRORS .
B2320	Mirror Driver Horizontal Feedback Potentiometer Circuit Failure	DDM	REFER to REAR VIEW MIRRORS .
B2322	Mirror Driver Horizontal Feedback Potentiometer Circuit Short To Battery	DDM	REFER to REAR VIEW MIRRORS .
B2324	Mirror Driver Vertical Feedback Potentiometer Circuit Failure	DDM	REFER to REAR VIEW MIRRORS .
B2326	Mirror Driver Vertical Feedback Potentiometer Circuit Short To Battery	DDM	REFER to REAR VIEW MIRRORS .
B2404	Audio Steering Wheel Switch Circuit Fault	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2406	Audio Disc CD Player Internal Fault	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2425	Remote Keyless Entry Out Of Synchronization	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2477	Module Configuration Failure	ABS module	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	ACM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	DCSM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	DDM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	DSM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	FDIM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	ILCM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	PAM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	SJB	REFER to MODULE CONFIGURATION .
B2479	Park Brake Switch Circuit Short To Ground	SJB	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B2486	Climate Control Seat Module Voltage Out Of Range	DCSM	REFER to SEATING .
B2498	Headlamp Switch Multiple Signals Input Active	SJB	REFER to EXTERIOR LIGHTING .
B2572	Brake Shift Interlock Output Circuit Failure	SJB	For non-Hybrid vehicles, REFER to AUTOMATIC TRANSAXLE/TRANSMISSION EXTERNAL CONTROLS - AISIN AW21/6F35 .
B2572	Brake Shift Interlock Output Circuit Failure	SJB	For Hybrid vehicles, REFER to AUTOMATIC TRANSAXLE/TRANSMISSION EXTERNAL CONTROLS - HYBRID .
B2574	Drivers Door LOCK Switch Short To Ground	DDM	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2575	Drivers Door UNLOCK Switch Short To Ground	DDM	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2667	Liftglass Release Switch Circuit Failure	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2729	Cushion Over-Temp Detected	DCSM	REFER to SEATING .
B272A	Passenger Cushion Over-Temp Detected	DCSM	REFER to SEATING .
B272B	Passenger Back Over-Temp Detected	DCSM	REFER to SEATING .
B272C	Driver Differential Temperature Fault	DCSM	REFER to SEATING .
B272D	Passenger Differential Temperature Fault	DCSM	REFER to SEATING .
B272E	Driver Ignition Run/Blower Circuit Short to Ground	DCSM	REFER to SEATING .
B272F	Passenger Ignition Run/Blower Circuit Short to Ground	DCSM	REFER to SEATING .
B2730	Back-Over Temp Detected	DCSM	REFER to SEATING .
B2741	Sensor Cluster Defective	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
B2844	Ignition Fault	SJB	REFER to STEERING COLUMN SWITCHES .
B2868	Left Front Tire Pressure Sensor Fault	SJB	REFER to WHEELS & TIRES .
B2869	Right Front Tire Pressure Sensor Fault	SJB	REFER to WHEELS & TIRES .
B2870	Right Rear Tire Pressure Sensor Fault	SJB	REFER to WHEELS & TIRES .
B2871	Left Rear Tire Pressure Sensor Fault	SJB	REFER to WHEELS & TIRES .
B2872	Tire Pressure Sensor Fault	SJB	REFER to WHEELS & TIRES .
B287A	Tire Pressure System Fault	SJB	REFER to WHEELS & TIRES .
B2900	VIN Mismatch	4X4 control module	REFER to MODULE CONFIGURATION .
B2900	VIN Mismatch	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
B2924	Audio Button Stuck	FCIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2924	Audio Button Stuck	FDIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2947	Global Opening/Closing Circuit Open	SJB	REFER to GLASS, FRAMES AND MECHANISMS .
B2949	Global Opening/Closing Circuit Short to Battery	SJB	REFER to GLASS, FRAMES AND MECHANISMS .
B2965	Audio System Speaker Circuit Fault	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B29B7	White Lighting Output Circuit Open	SJB	REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION .
B29B8	White Lighting Output Circuit Short To Ground	SJB	REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION .
B2A20	Ignition Stuck In START	SJB	REFER to STEERING COLUMN SWITCHES .
B2A21	One or More Configuration Files Missing Or Corrupt	ILCM	REFER to MODULE CONFIGURATION .
B2A21	One or More Configuration Files Missing Or Corrupt	SJB	REFER to MODULE CONFIGURATION .
B2A22	Headlamp OFF Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2A23	High Beam Input Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2A24	Turn Signal Input Circuit Failure	SJB	REFER to EXTERIOR LIGHTING .
B2A25	Trim Panel Lock Switch Circuit Failure	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2A26	Keypad Switch Circuit Failure	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2A27	Right Front Turn Lamp Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2A28	Right Front Turn Lamp Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2A29	Left Front Turn Lamp Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2A2A	Left Front Turn Lamp Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2A2B	Left Corner Lamp Output Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2A2C	Right Corner Lamp Output Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2A2D	3rd Row Power Fold Circuit Short To Ground	SJB	REFER to SEATING .
B2A2E	Right Front Lamp Low Beam Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2A2F	Right Front Lamp Low Beam Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2A30	Left Front Lamp Low Beam Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2A31	Left Front Lamp Low Beam Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2A32	LED Backlighting Output Circuit Open	SJB	REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION .
B2A33	LED Backlighting Output Circuit Short To Ground	SJB	REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION .
B2A35	Interior Lighting Output Circuit Open	SJB	REFER to INTERIOR LIGHTING .
B2A36	Interior Lighting Output Circuit Short To Ground	SJB	REFER to INTERIOR LIGHTING .
B2A38	Floor Lamp Output Circuit Short To Ground	SJB	REFER to INTERIOR LIGHTING .
B2A39	Puddle Lamp Output Circuit Open	SJB	REFER to INTERIOR LIGHTING .
B2A3A	Puddle Lamp Output Circuit Short To Ground	SJB	REFER to INTERIOR LIGHTING .
B2B00	Ambient Light Zone 1 Red Circuit Open	ILCM	REFER to INTERIOR LIGHTING .
B2B01	Ambient Light Zone 1 Red Circuit Short to Ground	ILCM	REFER to INTERIOR LIGHTING .
B2B02	Ambient Light Zone 1 Green Circuit Open	ILCM	REFER to INTERIOR LIGHTING .
B2B03	Ambient Light Zone 1 Green Circuit Short to Ground	ILCM	REFER to INTERIOR LIGHTING .
B2B04	Ambient Light Zone 1 Blue Circuit Open	ILCM	REFER to INTERIOR LIGHTING .
B2B05	Ambient Light Zone 1 Blue Circuit Short to Ground	ILCM	REFER to INTERIOR LIGHTING .
B2B06	Ambient Light Zone 1 Signature Circuit Open	ILCM	REFER to INTERIOR LIGHTING .
B2B07	Ambient Light Zone 1 Signature Circuit Short to Ground	ILCM	REFER to INTERIOR LIGHTING .
B2B08	Ambient Light Zone 2 Red Circuit Open	ILCM	REFER to INTERIOR LIGHTING .
B2B09	Ambient Light Zone 2 Red Circuit Short to Ground	ILCM	REFER to INTERIOR LIGHTING .
B2B0A	Ambient Light Zone 2 Green Circuit Open	ILCM	REFER to INTERIOR LIGHTING .
B2B0B	Ambient Light Zone 2 Green Circuit Short to Ground	ILCM	REFER to INTERIOR LIGHTING .
B2B0C	Ambient Light Zone 2 Blue Circuit Open	ILCM	REFER to INTERIOR LIGHTING .
B2B0D	Ambient Light Zone 2 Blue Circuit Short to Ground	ILCM	REFER to INTERIOR LIGHTING .
B2B0E	Ambient Light Zone 2 Signature Circuit Open	ILCM	REFER to INTERIOR LIGHTING .
B2B0F	Ambient Light Zone 2 Signature Circuit Short to Ground	ILCM	REFER to INTERIOR LIGHTING .
B2B10	Ambient Light Zone 3 Red Circuit Open	ILCM	REFER to INTERIOR LIGHTING .
B2B11	Ambient Light Zone 3 Red Circuit Short to Ground	ILCM	REFER to INTERIOR LIGHTING .
B2B12	Ambient Light Zone 3 Green Circuit Open	ILCM	REFER to INTERIOR LIGHTING .
B2B13	Ambient Light Zone 3 Green Circuit Short to Ground	ILCM	REFER to INTERIOR LIGHTING .
B2B14	Ambient Light Zone 3 Blue Circuit Open	ILCM	REFER to INTERIOR LIGHTING .
B2B15	Ambient Light Zone 3 Blue Circuit Short to Ground	ILCM	REFER to INTERIOR LIGHTING .
B2B16	Ambient Light Zone 3 Signature Circuit Open	ILCM	REFER to INTERIOR LIGHTING .
B2B17	Ambient Light Zone 3 Signature Circuit Short to Ground	ILCM	REFER to INTERIOR LIGHTING .
B2B18	Ambient Light Switch Input Fault	ILCM	REFER to INTERIOR LIGHTING .
C0001:49	TCS Control Channel "A" Valve 1: Internal Electronic Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0002:49	TCS Control Channel "A" Valve 2: Internal Electronic Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0003:49	TCS Control Channel "B" Valve 1: Internal Electronic Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0004:49	TCS Control Channel "B" Valve 2: Internal Electronic Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0010:49	Left Front Inlet Control: Internal Electronic Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0011:49	Left Front Outlet Control: Internal Electronic Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0014:49	Right Front Inlet Control: Internal Electronic Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0015:49	Right Front Outlet Control: Internal Electronic Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0018:49	Left Rear Inlet Control: Internal Electronic Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0019:49	Left Rear Outlet Control: Internal Electronic Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C001C:49	Right Rear Inlet Control: Internal Electronic Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C001D:49	Right Rear Outlet Control: Internal Electronic Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0020:11	ABS Pump Motor Control: Circuit Short To Ground	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0020:12	ABS Pump Motor Control: Circuit Short To Battery	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0020:13	ABS Pump Motor Control: Circuit Open	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0020:71	ABS Pump Motor Control: Actuator Stuck	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0021:21	Brake Booster Performance: Signal Amplitude < Minimum	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0021:66	Brake Booster Performance: Signal Has Too Many Transitions/Events	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0021:77	Brake Booster Performance: Commanded Position Not Reachable	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0022:11	Brake Booster Solenoid: Circuit Short To Ground	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0022:12	Brake Booster Solenoid: Circuit Short To Battery	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0022:13	Brake Booster Solenoid: Circuit Open	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0022:14	Brake Booster Solenoid: Circuit Short To Ground Or Open	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0022:1D	Brake Booster Solenoid: Circuit Current Out Of Range	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0022:49	Brake Booster Solenoid: Internal Electronic Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0030:07	Left Front Tone Wheel: Mechanical Failures	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0031:01	Left Front Wheel Speed Sensor: General Electrical Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0031:29	Left Front Wheel Speed Sensor: Signal Invalid	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0031:2F	Left Front Wheel Speed Sensor: Signal Erratic	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0031:64	Left Front Wheel Speed Sensor: Signal Plausibility Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0033:07	Right Front Tone Wheel: Mechanical Failures	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0034:01	Right Front Wheel Speed Sensor: General Electrical Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0034:29	Right Front Wheel Speed Sensor: Signal Invalid	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0034:2F	Right Front Wheel Speed Sensor: Signal Erratic	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0034:64	Right Front Wheel Speed Sensor: Signal Plausibility Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0036:07	Left Rear Tone Wheel: Mechanical Failures	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0037:01	Left Rear Wheel Speed Sensor: General Electrical Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0037:29	Left Rear Wheel Speed Sensor: Signal Invalid	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0037:2F	Left Rear Wheel Speed Sensor: Signal Erratic	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0037:64	Left Rear Wheel Speed Sensor: Signal Plausibility Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0039:07	Right Rear Tone Wheel: Mechanical Failures	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C003A:01	Right Rear Wheel Speed Sensor: General Electrical Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C003A:29	Right Rear Wheel Speed Sensor: Signal Invalid	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C003A:2F	Right Rear Wheel Speed Sensor: Signal Erratic	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C003A:64	Right Rear Wheel Speed Sensor: Signal Plausibility Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0044:28	Brake Pressure Sensor "A": Signal Bias Level Out Of Range/Zero Adjustment Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0044:49	Brake Pressure Sensor "A": Internal Electronic Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0044:64	Brake Pressure Sensor "A": Signal Plausibility Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0048:11	Brake Booster Travel Sensor: Circuit Short To Ground	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0048:12	Brake Booster Travel Sensor: Circuit Short To Battery	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0048:64	Brake Booster Travel Sensor: Signal Plausibility Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0061:28	Lateral Acceleration Sensor: Signal Bias Level Out Of Range/Zero Adjustment Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0061:64	Lateral Acceleration Sensor: Signal Plausibility Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0063:28	Yaw Rate Sensor: Signal Bias Level Out Of Range/Zero Adjustment Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0063:64	Yaw Rate Sensor: Signal Plausibility Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C0089:11	TCS Disable Switch: Circuit Short To Ground	IPC	REFER to VEHICLE DYNAMIC SYSTEMS .
C100A:28	Brake Pedal Angle Sensor: Signal Bias Level Out Of Range/Zero Adjustment Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C100A:41	Brake Pedal Angle Sensor: General Checksum Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C100A:62	Brake Pedal Angle Sensor: Signal Compare Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C100A:64	Brake Pedal Angle Sensor: Signal Plausibility Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C100D:21	Brake Pedal Angle Sensor Circuit 1: Signal Amplitude < Minimum	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C100D:22	Brake Pedal Angle Sensor Circuit 1: Signal Amplitude > Maximum	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C100E:21	Brake Pedal Angle Sensor Circuit 2: Signal Amplitude < Minimum	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C100E:22	Brake Pedal Angle Sensor Circuit 2: Signal Amplitude > Maximum	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C100F:11	Brake Pedal Angle Sensor Supply: Circuit Short To Ground	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C100F:12	Brake Pedal Angle Sensor Supply: Circuit Short To Battery	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1011:1C	Brake Pedal Feel Simulator Cut-off Pressure Sensor: Circuit Voltage Out Of Range	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1011:1F	Brake Pedal Feel Simulator Cut-off Pressure Sensor: Circuit Intermittent	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1011:67	Brake Pedal Feel Simulator Cut-off Pressure Sensor: Signal Incorrect After Event	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1012:01	Brake Pedal Feel Simulator Cut-off Valve Solenoid: General Electrical Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1014:07	Brake System Total Volume Balance: Mechanical Failures	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1015:64	Vacuum Supply: Signal Plausibility Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1015:7A	Vacuum Supply: Fluid Leak Or Seal Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1015:7B	Vacuum Supply: Low Fluid Level	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1018:00	Regenerative Braking: No Sub Type Information	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1018:46	Regenerative Braking: Calibration/Parameter Memory Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1018:62	Regenerative Braking: Signal Compare Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C101A:1C	Vacuum Pressure Sensor: Circuit Voltage Out Of Range	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C101A:62	Vacuum Pressure Sensor: Signal Compare Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C101A:64	Vacuum Pressure Sensor: Signal Plausibility Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C101B:1C	Vacuum Pressure Sensor Circuit B: Circuit Voltage Out Of Range	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C101C:01	Brake Vacuum Pump: General Electrical Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C101C:71	Brake Vacuum Pump: Actuator Stuck	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1021:21	ABS Booster Control Pressure: Signal Amplitude < Minimum	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1021:22	ABS Booster Control Pressure: Signal Amplitude > Maximum	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1025:21	Brake Primary Circuit Overboost Pressure: Signal Amplitude < Minimum	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1025:22	Brake Primary Circuit Overboost Pressure: Signal Amplitude > Maximum	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1026:21	ABS Secondary Circuit Overboost Pressure: Signal Amplitude < Minimum	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1026:22	ABS Secondary Circuit Overboost Pressure: Signal Amplitude > Maximum	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1027:62	Master Cylinder (MC) to Primary Circuit Pressure: Signal Compare Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1028:62	ABS Primary Circuit Wheel Pressure: Signal Compare Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1029:00	ABS Primary Circuit Pressure Lower Than Secondary: No Sub Type Information	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C102A:62	Brake Secondary Circuit Pressure Mismatch Between Wheels: Signal Compare Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C102B:00	ABS Secondary Circuit Pressure Lower Than Primary: No Sub Type Information	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1095	ABS Hydraulic Pump Motor Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C109D	Low Vacuum Condition Detected	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C109E	Vacuum Sensor Circuit Fault	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C109F	Vacuum Sensor Signal Fault	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1108:11	Pedal Sensor(s) Supply Voltage: Circuit Short To Ground	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1108:12	Pedal Sensor(s) Supply Voltage: Circuit Short To Battery	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1108:1C	Pedal Sensor(s) Supply Voltage: Circuit Voltage Out Of Range	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1125	Brake Fluid Level Sensor Input Circuit Failure	SJB	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
C1133:28	Left Front Brake Pressure Sensor: Signal Bias Level Out Of Range/Zero Adjustment Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1133:49	Left Front Brake Pressure Sensor: Internal Electronic Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1133:64	Left Front Brake Pressure Sensor: Signal Plausibility Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1134:28	Right Front Brake Pressure Sensor: Signal Bias Level Out Of Range/Zero Adjustment Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1134:49	Right Front Brake Pressure Sensor: Internal Electronic Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1134:64	Right Front Brake Pressure Sensor: Signal Plausibility Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1135:28	Left Rear Brake Pressure Sensor: Signal Bias Level Out Of Range/Zero Adjustment Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1135:49	Left Rear Brake Pressure Sensor: Internal Electronic Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1135:64	Left Rear Brake Pressure Sensor: Signal Plausibility Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1136:28	Right Rear Brake Pressure Sensor: Signal Bias Level Out Of Range/Zero Adjustment Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1136:49	Right Rear Brake Pressure Sensor: Internal Electronic Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1136:64	Right Rear Brake Pressure Sensor: Signal Plausibility Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1145	Speed Wheel Sensor RF Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1155	Speed Wheel Sensor LF Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1165	Speed Wheel Sensor RR Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1175	Speed Wheel Sensor LR Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1233	Speed Wheel LF Input Signal Missing	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1234	Speed Wheel RF Input Signal Missing	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1235	Speed Wheel RR Input Signal Missing	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1236	Speed Wheel LR Input Signal Missing	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1277	Steering Wheel Angle 1 and 2 Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1278	Steering Wheel Angle 1 and 2 Signal Faulted	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1280	Yaw Rate Sensor Signal Fault	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1282	Lateral Accelerometer Signal Fault	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1288	Pressure Transducer Main/Primary Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1440	Pressure Transducer Main/Primary Signal Faulted	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1470	TCS Functions Temporarily Disabled (Thermal Brake Protection)	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1699	Left Rear Sensor Circuit Short To Vbat	PAM	REFER to PARKING AID .
C1700	Left Rear Sensor Circuit Failure Or Blockage	PAM	REFER to PARKING AID .
C1701	Left Rear Sensor Circuit Fault	PAM	REFER to PARKING AID .
C1702	Right Rear Sensor Circuit Short To Vbat	PAM	REFER to PARKING AID .
C1703	Right Rear Sensor Circuit Failure Or Blockage	PAM	REFER to PARKING AID .
C1704	Right Rear Sensor Circuit Fault	PAM	REFER to PARKING AID .
C1705	Left Rear Center Sensor Circuit Short To Vbat	PAM	REFER to PARKING AID .
C1706	Left Rear Center Sensor Circuit Failure	PAM	REFER to PARKING AID .
C1707	Left Rear Center Sensor Circuit Fault	PAM	REFER to PARKING AID .
C1742	Rear Sounder Circuit Failure	PAM	REFER to PARKING AID .
C1743	Rear Sounder Circuit Short To Vbatt	PAM	REFER to PARKING AID .
C1805	Mismatched PCM and/or ABS-TC Module	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1963	Stability Control Inhibit Warning	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1991	Module Calibration Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1996	Active Yaw and/or Roll Control Disabled	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1B00:28	Steering Angle Sensor: Signal Bias Level Out Of Range/Zero Adjustment Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1B00:29	Steering Angle Sensor: Signal Invalid	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1B00:2F	Steering Angle Sensor: Signal Erratic	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
C1B00:62	Steering Angle Sensor: Signal Compare Failure	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
C1B00:64	Steering Angle Sensor: Signal Plausibility Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1B14:11	Sensor Supply Voltage A: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
C1B14:12	Sensor Supply Voltage A: Circuit Short To Battery	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
C200B:2F	Steering Shaft Torque Sensor 1: Signal Erratic	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
C200B:61	Steering Shaft Torque Sensor 1: Signal Calculation Failure	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
C200B:62	Steering Shaft Torque Sensor 1: Signal Compare Failure	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
C200C:2F	Steering Shaft Torque Sensor 2: Signal Erratic	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
C200D:49	Motor Rotation Angle Sensor: Internal Electronic Failure	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
C2770	Longitudinal Acceleration Sensor Plausibility Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C2777	Sensor Cluster BUS Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C2780	ECU in Manufacturer Sub-State	SJB	NOTE: If DTC B2477 is also present, REFER to the Action for DTC B2477 in this DTC Table. REFER to WHEELS & TIRES .
P0512	Starter Request Circuit	PCM	REFER to STARTING SYSTEM .
P0532	A/C Refrigerant Pressure Sensor A Circuit Low	PCM	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
P0533	A/C Refrigerant Pressure Sensor A Circuit High	PCM	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
P0561:1C	System Voltage Unstable: Circuit Voltage Out Of Range	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
P0562	System Voltage Low	PCM	REFER to CHARGING SYSTEM .
P0562:00	System Voltage Low: No Sub Type Information	Transmission Control Module (TCM) (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0563	System Voltage High	PCM	REFER to CHARGING SYSTEM .
P0563:00	System Voltage High: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0572	Brake Switch A Circuit Low	PCM	REFER to CRUISE CONTROL .
P0573	Brake Switch A Circuit High	PCM	REFER to CRUISE CONTROL .
P0579	Cruise Control Multi-Function Input A Circuit Range/Performance	PCM	REFER to CRUISE CONTROL .
P0581	Cruise Control Multi-Function Input A Circuit High	PCM	REFER to CRUISE CONTROL .
P0601:00	Internal Control Module Memory Check Sum Error: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0603:00	Internal Control Module Keep Alive Memory ( KAM ) Error: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0604:00	Internal Control Module Random Access Memory ( RAM ) Error: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0605:42	Internal Control Module Read Only Memory ( ROM ) Error: General Memory Failure	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P0620	Generator Control Circuit	PCM	REFER to CHARGING SYSTEM .
P0625	Generator Field Terminal Circuit Low	PCM	REFER to CHARGING SYSTEM .
P0626	Generator Field Terminal Circuit High	PCM	REFER to CHARGING SYSTEM .
P062F	Internal Control Module EEPROM Error	SJB	REFER to SMART JUNCTION BOX (SJB) .
P062F:41	Internal Control Module EEPROM Error: General Checksum Failure	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P0645	A/C Clutch Relay Control Circuit	PCM	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
P0657:00	Actuator Supply Voltage A Circuit/Open: No Sub Type Information	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P065B	Generator Control Circuit Range/Performance	PCM	REFER to CHARGING SYSTEM .
P0706:00	Transmission Range Sensor A Circuit Range/Performance: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0706:00	Transmission Range Sensor A Circuit Range/Performance: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0707:00	Transmission Range Sensor A Circuit Low: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0707:00	Transmission Range Sensor A Circuit Low: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0708:00	Transmission Range Sensor A Circuit High: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0708:00	Transmission Range Sensor A Circuit High: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0710:00	Transmission Fluid Temperature Sensor A Circuit: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0711:00	Transmission Fluid Temperature Sensor A Circuit Range/Performance: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0711:00	Transmission Fluid Temperature Sensor A Circuit Range/Performance: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0712:00	Transmission Fluid Temperature Sensor A Circuit Low: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0712:00	Transmission Fluid Temperature Sensor A Circuit Low: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0713:00	Transmission Fluid Temperature Sensor A Circuit High: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0713:00	Transmission Fluid Temperature Sensor A Circuit High: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0715:00	Turbine/Input Shaft Speed Sensor A Circuit: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0716:00	Turbine/Input Shaft Speed Sensor A Circuit/Range/Performance: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0717:00	Turbine/Input Shaft Speed Sensor A Circuit No Signal: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0717:00	Turbine/Input Shaft Speed Sensor A Circuit No Signal: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0718:00	Turbine/Input Shaft Speed Sensor A Circuit Intermittent: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0720:00	Output Shaft Speed Sensor Circuit: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0721:00	Output Shaft Speed Sensor Circuit Range/Performance: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0721:00	Output Shaft Speed Sensor Circuit Range/Performance: No Sub Type Information	PCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0722:00	Output Shaft Speed Sensor Circuit No Signal: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0722:00	Output Shaft Speed Sensor Circuit No Signal: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0729:00	Gear 6 Incorrect Ratio: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0729:00	Gear 6 Incorrect Ratio: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P072C:00	Stuck in Gear 1: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P072D:00	Stuck in Gear 2: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P072E:00	Stuck in Gear 3: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P072F:00	Stuck in Gear 4: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0730:00	Incorrect Gear Ratio: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0731:00	Gear 1 Incorrect Ratio: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0732:00	Gear 2 Incorrect Ratio: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0733:00	Gear 3 Incorrect Ratio: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0733:00	Gear 3 Incorrect Ratio: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0734:00	Gear 4 Incorrect Ratio: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0734:00	Gear 4 Incorrect Ratio: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0735:00	Gear 5 Incorrect Ratio: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0735:00	Gear 5 Incorrect Ratio: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0736:00	Reverse Incorrect Ratio: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P073A:00	Stuck in Gear 5: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P073B:00	Stuck in Gear 6: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0740:00	Torque Converter Clutch Solenoid Circuit/Open: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0741:00	Torque Converter Clutch Solenoid Circuit Performance Or Stuck Off: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0742:00	Torque Converter Clutch Solenoid Circuit Stuck On: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0743:00	Torque Converter Clutch Solenoid Circuit Electrical: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0744:00	Torque Converter Clutch Solenoid Circuit Intermittent: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0748:00	Pressure Control Solenoid A Electrical: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0750:00	Shift Solenoid A: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0751:00	Shift Solenoid A Performance or Stuck Off: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0752:00	Shift Solenoid A Stuck On: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0753:00	Shift Solenoid A Electrical: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0755:00	Shift Solenoid B: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0756:00	Shift Solenoid B Performance or Stuck Off: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0757:00	Shift Solenoid B Stuck On: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0758:00	Shift Solenoid B Electrical: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0760:00	Shift Solenoid C: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0761:00	Shift Solenoid C Performance Or Stuck Off: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0762:00	Shift Solenoid C Stuck On: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0763:00	Shift Solenoid C Electrical: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0765:00	Shift Solenoid D: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0766:00	Shift Solenoid D Performance Or Stuck Off: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0767:00	Shift Solenoid D Stuck On: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0768:00	Shift Solenoid D Electrical: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0770:00	Shift Solenoid E: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0771:00	Shift Solenoid E Performance Or Stuck Off: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0772:00	Shift Solenoid E Stuck On: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0773:00	Shift Solenoid E Electrical: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0774:00	Shift Solenoid E Intermittent: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0780:00	Shift Malfunction: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P07AE:09	Transmission Friction Element ""G"" Performance/Stuck Off: Component Failures	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
P0812:12	Reverse Input Circuit: Circuit Short To Battery	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
P0813:00	Reverse Output Circuit: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0815	Upshift Switch Circuit	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION EXTERNAL CONTROLS - AISIN AW21/6F35 .
P0815	Upshift Switch Circuit	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION EXTERNAL CONTROLS - AISIN AW21/6F35 .
P0816	Downshift Switch Circuit	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION EXTERNAL CONTROLS - AISIN AW21/6F35 .
P0816	Downshift Switch Circuit	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION EXTERNAL CONTROLS - AISIN AW21/6F35 .
P0817:00	Starter Disable Circuit/Open: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0960:00	Pressure Control Solenoid A Control Circuit/Open: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0961:00	Pressure Control Solenoid A Control Circuit Range/Performance: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0962:00	Pressure Control Solenoid A Control Circuit Low: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0962:00	Pressure Control Solenoid A Control Circuit Low: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0963:00	Pressure Control Solenoid A Control Circuit High: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0963:00	Pressure Control Solenoid A Control Circuit High: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0973:00	Shift Solenoid A Control Circuit Low: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0973:00	Shift Solenoid A Control Circuit Low: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0974:00	Shift Solenoid A Control Circuit High: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0974:00	Shift Solenoid A Control Circuit High: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0976:00	Shift Solenoid B Control Circuit Low: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0976:00	Shift Solenoid B Control Circuit Low: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0977:00	Shift Solenoid B Control Circuit High: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0977:00	Shift Solenoid B Control Circuit High: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0978:00	Shift Solenoid C Control Circuit Range/Performance: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0979:00	Shift Solenoid C Control Circuit Low: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0979:00	Shift Solenoid C Control Circuit Low: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0980:00	Shift Solenoid C Control Circuit High: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0980:00	Shift Solenoid C Control Circuit High: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0981:00	Shift Solenoid D Control Circuit Range/Performance: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0982:00	Shift Solenoid D Control Circuit Low: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0982:00	Shift Solenoid D Control Circuit Low: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0983:00	Shift Solenoid D Control Circuit High: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P0983:00	Shift Solenoid D Control Circuit High: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0984:00	Shift Solenoid E Control Circuit Range/Performance: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0985:00	Shift Solenoid E Control Circuit Low: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0986:00	Shift Solenoid E Control Circuit High: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0997:00	Shift Solenoid F Control Circuit Range/Performance: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0998:00	Shift Solenoid F Control Circuit Low: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0999:00	Shift Solenoid F Control Circuit High: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P0A0A:00	High Voltage System Interlock Circuit: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0A0C:00	High Voltage System Interlock Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0A12:16	DC/DC Converter Enable Circuit Low: Circuit Voltage Below Threshold	DC to DC Converter Control Module (DC/DC)	REFER to HIGH VOLTAGE CONVERTER/INVERTER .
P0A7D:00	Hybrid Battery Pack State of Charge Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0A7E:00	Hybrid Battery Pack Over Temperature: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0A80:00	Replace Hybrid Battery Pack: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0A81:00	Hybrid Battery Pack Cooling Fan 1 Control Circuit/Open: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0A82:00	Hybrid Battery Pack Cooling Fan 1 Performance/Stuck Off: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0A8B:64	14 Volt Power Module System Voltage: Signal Plausibility Failure	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0A94:4B	DC/DC Converter Performance: Over Temperature	DC/DC	REFER to HIGH VOLTAGE CONVERTER/INVERTER .
P0A9D:00	Hybrid Battery Temperature Sensor A Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0A9E:00	Hybrid Battery Temperature Sensor A Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AA1:00	Hybrid Battery Positive Contactor Circuit Stuck Closed: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AA2:00	Hybrid Battery Positive Contactor Circuit Stuck Open: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AA4:00	Hybrid Battery Negative Contactor Circuit Stuck Closed: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AA5:00	Hybrid Battery Negative Contactor Circuit Stuck Open: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AA6:00	Hybrid Battery Voltage System Isolation Fault: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AA7:00	Hybrid Battery Voltage Isolation Sensor Circuit: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AA9:00	Hybrid Battery Voltage Isolation Sensor Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AAA:00	Hybrid Battery Voltage Isolation Sensor Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AAE:00	Hybrid Battery Pack Air Temperature Sensor A Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AAF:00	Hybrid Battery Pack Air Temperature Sensor A Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0ABC:00	Hybrid Battery Pack Voltage Sense A Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0ABD:00	Hybrid Battery Pack Voltage Sense A Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AC0:00	Hybrid Battery Pack Current Sensor A Circuit Range/Performance: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AC1:00	Hybrid Battery Pack Current Sensor A Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AC2:00	Hybrid Battery Pack Current Sensor A Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AC7:00	Hybrid Battery Temperature Sensor B Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AC8:00	Hybrid Battery Temperature Sensor B Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0ACC:00	Hybrid Battery Temperature Sensor C Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0ACD:00	Hybrid Battery Temperature Sensor C Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AD9:00	Hybrid Battery Positive Contactor Control Circuit/Open GM: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0ADA:00	Hybrid Battery Positive Contactor Control Circuit Range/Performance: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0ADC:00	Hybrid Battery Positive Contactor Control Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0ADD:00	Hybrid Battery Negative Contactor Control Circuit/Open: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0ADE:00	Hybrid Battery Negative Contactor Control Circuit Range/Performance: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AE0:00	Hybrid Battery Negative Contactor Control Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AE1:00	Hybrid Battery Precharge Contactor Circuit: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AE5:00	Hybrid Battery Precharge Contactor Control Circuit Range/Performance: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AE7:00	Hybrid Battery Precharge Contactor Control Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AEA:00	Hybrid Battery Temperature Sensor D Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AEB:00	Hybrid Battery Temperature Sensor D Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AF7:00	14 Volt Power Module Internal Temperature Too High: No Sub Type Information	DC/DC	REFER to HIGH VOLTAGE CONVERTER/INVERTER .
P0AFA:13	Hybrid Battery System Voltage Low: Circuit Open	DC/DC	REFER to HIGH VOLTAGE CONVERTER/INVERTER .
P0AFA:16	Hybrid Battery System Voltage Low: Circuit Voltage Below Threshold	ACCM	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
P0AFA:16	Hybrid Battery System Voltage Low: Circuit Voltage Below Threshold	DC/DC	REFER to HIGH VOLTAGE CONVERTER/INVERTER .
P0AFB:00	Hybrid Battery System Voltage High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AFB:17	Hybrid Battery System Voltage High: Circuit Voltage Above Threshold	ACCM	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
P0AFB:17	Hybrid Battery System Voltage High: Circuit Voltage Above Threshold	DC/DC	REFER to HIGH VOLTAGE CONVERTER/INVERTER .
P0AFC:04	Hybrid Battery Energy Control Module: System Internal Failures	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AFC:49	Hybrid Battery Energy Control Module: Internal Electronic Failure	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AFC:4A	Hybrid Battery Energy Control Module: Incorrect Component Installed	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AFC:67	Hybrid Battery Energy Control Module: Signal Incorrect After Event	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0AFD:00	Hybrid Battery Pack Temperature Too Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B10:00	Hybrid Battery Pack Current Sensor B Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B12:00	Hybrid Battery Pack Current Sensor B Circuit Intermittent/Erratic: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B1B:00	Hybrid Battery Pack Voltage Sense C Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B1C:00	Hybrid Battery Pack Voltage Sense C Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B24:00	Hybrid Battery A Voltage Unstable: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B25:00	Hybrid Battery A Voltage Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B36:00	High Voltage Service Disconnect Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B37:00	High Voltage Service Disconnect Open: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B3D:00	Hybrid Battery Voltage Sense A Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B3E:00	Hybrid Battery Voltage Sense A Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B42:00	Hybrid Battery Voltage Sense B Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B43:00	Hybrid Battery Voltage Sense B Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B47:00	Hybrid Battery Voltage Sense C Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B48:00	Hybrid Battery Voltage Sense C Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B4C:00	Hybrid Battery Voltage Sense D Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B4D:00	Hybrid Battery Voltage Sense D Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B51:00	Hybrid Battery Voltage Sense E Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B52:00	Hybrid Battery Voltage Sense E Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B56:00	Hybrid Battery Voltage Sense F Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B57:00	Hybrid Battery Voltage Sense F Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B5B:00	Hybrid Battery Voltage Sense G Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B5C:00	Hybrid Battery Voltage Sense G Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B60:00	Hybrid Battery Voltage Sense H Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B61:00	Hybrid Battery Voltage Sense H Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B65:00	Hybrid Battery Voltage Sense I Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B66:00	Hybrid Battery Voltage Sense I Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B6A:00	Hybrid Battery Voltage Sense J Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B6B:00	Hybrid Battery Voltage Sense J Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B6F:00	Hybrid Battery Voltage Sense K Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B70:00	Hybrid Battery Voltage Sense K Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B74:00	Hybrid Battery Voltage Sense L Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B75:00	Hybrid Battery Voltage Sense L Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B79:00	Hybrid Battery Voltage Sense M Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B7A:00	Hybrid Battery Voltage Sense M Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B7E:00	Hybrid Battery Voltage Sense N Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B7F:00	Hybrid Battery Voltage Sense N Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B83:00	Hybrid Battery Voltage Sense O Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B84:00	Hybrid Battery Voltage Sense O Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B88:00	Hybrid Battery Voltage Sense P Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B89:00	Hybrid Battery Voltage Sense P Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B8D:00	Hybrid Battery Voltage Sense Q Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B8E:00	Hybrid Battery Voltage Sense Q Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B92:00	Hybrid Battery Voltage Sense R Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B93:00	Hybrid Battery Voltage Sense R Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B97:00	Hybrid Battery Voltage Sense S Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B98:00	Hybrid Battery Voltage Sense S Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B9C:00	Hybrid Battery Voltage Sense T Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0B9D:00	Hybrid Battery Voltage Sense T Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0BA1:00	Hybrid Battery Voltage Sense U Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0BA2:00	Hybrid Battery Voltage Sense U Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0BA6:00	Hybrid Battery Voltage Sense V Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0BA7:00	Hybrid Battery Voltage Sense V Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0BAB:00	Hybrid Battery Voltage Sense W Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0BAC:00	Hybrid Battery Voltage Sense W Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0BB0:00	Hybrid Battery Voltage Sense X Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0BB1:00	Hybrid Battery Voltage Sense X Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0BB5:00	Hybrid Battery Voltage Sense Y Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0BB6:00	Hybrid Battery Voltage Sense Y Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0BBA:00	Hybrid Battery Voltage Sense Z Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0BBB:00	Hybrid Battery Voltage Sense Z Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0BC4:00	Hybrid Battery Temperature Sensor E Circuit Low: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0BC5:00	Hybrid Battery Temperature Sensor E Circuit High: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P0460:11	Fuel Level Sensor A Circuit: Circuit Short To Ground	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P0460:13	Fuel Level Sensor A Circuit: Circuit Open	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P1243:06	Second Fuel Pump Fault or Ground Fault: Algorithm Based Failures	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P1260	Theft Detected, Vehicle Immobilized	PCM	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
P1260:61	Theft Detected, Vehicle Immobilized: Signal Calculation Failure	TCM ( eCVT )	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) - HYBRID .
P1346:11	Fuel Level Sensor B Circuit: Circuit Short To Ground	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P1346:13	Fuel Level Sensor B Circuit: Circuit Open	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P1464	A/C Demand Out Of Self Test Range	PCM	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
P1534:01	Restraint Deployment Indicator Circuit: General Electrical Failure	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P1573:00	Throttle Position Not Available: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P1576:00	Pedal Position Not Available: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P1602	Immobilizer/ ECM Communication Error	PCM	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
P1622	Immobilizer ID Does Not Match	PCM	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
P1635	Tire/Axle Out of Acceptable Range	4X4 control module	REFER to MODULE CONFIGURATION .
P1636:00	Inductive Signature Chip Communication Error: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P163E:00	Transmission Control Module Programming Error: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P163F:00	Transmission ID Block Corrupted, Not Programmed: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P1657:00	CAN Link Chip Malfunction: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P1700:00	Transmission Indeterminate Failure (Failed to Neutral): No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P1701:00	Reverse Engagement Error: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P1702:00	Transmission Range Sensor Circuit Intermittent: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P1703	Brake Switch Out Of Self Test Range	PCM	REFER to CRUISE CONTROL .
P1705:00	Transmission Range Circuit Not Indicating Park/Neutral During Self Test: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P1706:00	High Vehicle Speed Observed in Park: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P1706:62	High Vehicle Speed Observed in Park: Signal Compare Failure	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P1711:00	Transmission Fluid Temperature Sensor Out Of Self Test Range: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P1719:00	Engine Torque Signal: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P1744:00	Torque Converter Clutch Solenoid Circuit Performance: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P174F:23	Traction Control Enable/Disable Switch Lamp Circuit: Signal Stuck Low	IPC	REFER to VEHICLE DYNAMIC SYSTEMS .
P1780:00	Transmission Control Switch (O/D Cancel) Circuit Out Of Self Test Range: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P1783:00	Transmission Fluid Pressure Sensor/Switch A Circuit Range/Performance: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P1824	4-Wheel Drive Clutch Relay Circuit Failure	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1825	4-Wheel Drive Clutch Relay Open Circuit	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1910	Reverse Lamp Control Circuit/Open	PCM (6F35)	REFER to EXTERIOR LIGHTING .
P1919:00	Engine Coolant Temperature Signal: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P1A0A:11	Immediate Shutdown Signal A: Circuit Short To Ground	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P1A0A:12	Immediate Shutdown Signal A: Circuit Short To Battery	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P1A0A:15	Immediate Shutdown Signal A: Circuit Short To Battery Or Open	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P1A0C:00	Hybrid Powertrain Control Module - Engine Disabled: No Sub Type Information	PCM	REFER to HIGH VOLTAGE CONVERTER/INVERTER .
P1A15:11	Immediate Shutdown Signal B: Circuit Short To Ground	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P1A15:12	Immediate Shutdown Signal B: Circuit Short To Battery	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P1A15:15	Immediate Shutdown Signal B: Circuit Short To Battery Or Open	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
P2600	Coolant Pump Control Circuit/Open	PCM	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
P2700:00	Transmission Friction Element A Apply Time Range/Performance: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P2701:00	Transmission Friction Element B Apply Time Range/Performance: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P2702:00	Transmission Friction Element C Apply Time Range/Performance: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P2703:00	Transmission Friction Element D Apply Time Range/Performance: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P2704:00	Transmission Friction Element E Apply Time Range/Performance: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P2705:00	Transmission Friction Element F Apply Time Range/Performance: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
P2757:00	Torque Converter Clutch Pressure Control Solenoid Control Circuit Perf or Stuck Off: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P2758:00	Torque Converter Clutch Pressure Control Solenoid Stuck On: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P2762:00	Torque Converter Clutch Pressure Control Solenoid Control Circuit Range/Perf: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P2763:00	Torque Converter Clutch Pressure Control Solenoid Control Circuit High: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P2764:00	Torque Converter Clutch Pressure Control Solenoid Control Circuit Low: No Sub Type Information	TCM (Aisin AW21)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21 .
P2783:00	Torque Converter Temperature Too High: No Sub Type Information	PCM (6F35)	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .
PXXXX	All other DTCs	PCM	REFER to INTRODUCTION - GASOLINE MODELS and/or INTRODUCTION - HYBRID .
U0001	High Speed CAN Communication Bus	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0001:88	High Speed CAN Communication Bus: Bus Off	ABS module	REFER to MODULE COMMUNICATIONS NETWORK .
U0001:88	High Speed CAN Communication Bus: Bus Off	DC/DC	REFER to MODULE COMMUNICATIONS NETWORK .
U0001:88	High Speed CAN Communication Bus: Bus Off	HCM	REFER to MODULE COMMUNICATIONS NETWORK .
U0001:88	High Speed CAN Communication Bus: Bus Off	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U0002:88	High Speed CAN Communication Bus Performance: Bus Off	IPC	REFER to MODULE COMMUNICATIONS NETWORK .
U0011:88	Medium Speed CAN Communication Bus Performance: Bus Off	IPC	REFER to MODULE COMMUNICATIONS NETWORK .
U0028:08	Vehicle Communication Bus A: Bus Signal/Message Failures	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0028:88	Vehicle Communication Bus A: Bus Off	RCM	REFER to MODULE COMMUNICATIONS NETWORK .
U0073:00	Control Module Communication Bus A Off: No Sub Type Information	TCM (Aisin AW21)	REFER to MODULE COMMUNICATIONS NETWORK .
U0074:00	Control Module Communication Bus "B" Off: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
U0100	Lost Communication With ECM /PCM	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
U0100	Lost Communication With ECM /PCM	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0100:00	Lost Communication With ECM /PCM "A": No Sub Type Information	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0100:00	Lost Communication With ECM /PCM "A": No Sub Type Information	ACCM	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
U0100:00	Lost Communication With ECM /PCM "A": No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0100:00	Lost Communication With ECM /PCM "A": No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
U0100:00	Lost Communication With ECM /PCM "A": No Sub Type Information	DC/DC	REFER to HIGH VOLTAGE CONVERTER/INVERTER .
U0100:00	Lost Communication With ECM /PCM "A": No Sub Type Information	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
U0100:00	Lost Communication With ECM /PCM "A": No Sub Type Information	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0100:00	Lost Communication With ECM /PCM "A": No Sub Type Information	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U0100:00	Lost Communication With ECM /PCM: No Sub Type Information	TCM (Aisin AW21)	REFER to MODULE COMMUNICATIONS NETWORK .
U0100:87	Lost Communication With ECM /PCM "A": Missing Message	HCM	REFER to EXTERIOR LIGHTING .
U0101	Lost Communication with TCM	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0101:00	Lost Communication with TCM: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
U0101:00	Lost Communication with TCM: No Sub Type Information	DC/DC	REFER to HIGH VOLTAGE CONVERTER/INVERTER .
U0101:00	Lost Communication with TCM: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0101:87	Lost Communication with TCM: Missing Message	HCM	REFER to EXTERIOR LIGHTING .
U0102:00	Lost Communication with Transfer Case Control Module: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U010F:00	Lost Communication With Air Conditioning Control Module: No Sub-Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0111:00	Lost Communication With Battery Energy Control Module "A": No Sub-Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0114	Lost Communication With Four-Wheel Drive Clutch Control Module	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0121	Lost Communication With Anti-Lock Brake System (ABS) Control Module	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
U0121:00	Lost Communication With Anti-Lock Brake System (ABS) Control Module: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0121:00	Lost Communication With Anti-Lock Brake System (ABS) Control Module: No Sub Type Information	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U0121:87	Lost Communication With Anti-Lock Brake System (ABS) Control Module: Missing Message	HCM	REFER to EXTERIOR LIGHTING .
U0126:87	Lost Communication With Steering Angle Sensor Module: Missing Message	HCM	REFER to EXTERIOR LIGHTING .
U0131:00	Lost Communication With Power Steering Control Module: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0131:87	Lost Communication With Power Steering Control Module: Missing Message	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0140	Lost Communication With Body Control Module ( GEM )	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0140	Lost Communication With Body Control Module ( GEM )	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0140	Lost Communication With Body Control Module ( GEM )	DDM	REFER to DRIVER DOOR MODULE (DDM) .
U0140	Lost Communication With Body Control Module ( GEM )	DSM	REFER to DRIVER SEAT MODULE (DSM) .
U0140	Lost Communication With Body Control Module ( GEM )	FCIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0140	Lost Communication With Body Control Module ( GEM )	FDIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0140	Lost Communication With Body Control Module ( GEM )	ILCM	REFER to INTERIOR LIGHTING .
U0140	Lost Communication With Body Control Module ( GEM )	PAM	REFER to PARKING AID .
U0140:00	Lost Communication With Body Control Module: No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0140:00	Lost Communication With Body Control Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0140:00	Lost Communication With Body Control Module: No Sub Type Information	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0140:00	Lost Communication With Body Control Module: No Sub Type Information	FCIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0140:00	Lost Communication With Body Control Module: No Sub Type Information	Global Positioning System Module (GPSM)	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0140:00	Lost Communication With Body Control Module: No Sub Type Information	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS (gasoline vehicles). REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID (hybrid vehicles).
U0140:00	Lost Communication With Body Control Module: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0151	Lost Communication With Restraints Control Module	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0151:00	Lost Communication With Restraints Control Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0151:00	Lost Communication With Restraints Control Module: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
U0151:00	Lost Communication With Restraints Control Module: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0151:00	Lost Communication With Restraints Control Module: No Sub Type Information	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0151:87	Lost Communication With Restraints Control Module: Missing Message	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0151:88	Lost Communication With Restraints Control Module: Bus Off	ABS module	REFER to MODULE COMMUNICATIONS NETWORK .
U0154:00	Lost Communication With Restraints Occupant Classification System Module: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0154:00	Lost Communication With Restraints Occupant Classification System Module: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0155	Lost Communication With Instrument Panel Cluster ( IC ) Control Module	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
U0155	Lost Communication With Instrument Panel Cluster ( IC ) Control Module	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0155	Lost Communication With Instrument Panel Cluster ( IC ) Control Module	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0155	Lost Communication With Instrument Panel Cluster ( IC ) Control Module	DSM	REFER to DRIVER SEAT MODULE (DSM) .
U0155	Lost Communication With Instrument Panel Cluster ( IC ) Control Module	FDIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0155	Lost Communication With Instrument Panel Cluster ( IC ) Control Module	PAM	REFER to PARKING AID .
U0155	Lost Communication With Instrument Panel Cluster ( IC ) Control Module	SJB	REFER to SMART JUNCTION BOX (SJB) .
U0155:00	Lost Communication With Instrument Panel Cluster ( IPC ) Control Module: No Sub Type Information	ACCM	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
U0155:00	Lost Communication With Instrument Panel Cluster ( IPC ) Control Module: No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0155:00	Lost Communication With Instrument Panel Cluster ( IPC ) Control Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0155:00	Lost Communication With Instrument Panel Cluster ( IPC ) Control Module: No Sub Type Information	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0155:00	Lost Communication With Instrument Panel Cluster ( IPC ) Control Module: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
U0155:00	Lost Communication With Instrument Panel Cluster ( IPC ) Control Module: No Sub Type Information	DC/DC	REFER to HIGH VOLTAGE CONVERTER/INVERTER .
U0155:00	Lost Communication With Instrument Panel Cluster ( IPC ) Control Module: No Sub Type Information	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0155:00	Lost Communication With Instrument Panel Cluster ( IPC ) Control Module: No Sub Type Information	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS (gasoline vehicles). REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID (hybrid vehicles).
U0155:00	Lost Communication With Instrument Panel Cluster ( IPC ) Control Module: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0155:87	Lost Communication With Instrument Panel Cluster ( IPC ) Control Module: Missing Message	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0155:87	Lost Communication With Instrument Panel Cluster ( IPC ) Control Module: Missing Message	HCM	REFER to EXTERIOR LIGHTING .
U0159	Lost Communication With Parking Assist Control Module ( PAM )	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0159:00	Lost Communication With Parking Assist Control Module "A": No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0159:00	Lost Communication With Parking Assist Control Module "A": No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0161:00	Lost Communication With Compass Module: No Sub Type Information	IPC	REFER to ELECTRONIC COMPASS .
U0162:00	Lost Communication With Navigation Display Module: No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0163:00	Lost Communication With Navigation Control Module: No Sub Type Information	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS (gasoline vehicles). REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID (hybrid vehicles).
U0163:00	Lost Communication With Navigation Control Module: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0164	Lost Communication With HVAC Control Module ( EATC )	FCIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0164	Lost Communication With HVAC Control Module ( EATC )	FDIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0164:00	Lost Communication With HVAC Control Module: No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0164:00	Lost Communication With HVAC Control Module: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U016A:00	Lost Communication With Global Positioning System Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0184	Lost Communication With Radio ( ACM )	FCIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0184	Lost Communication With Radio ( ACM )	FDIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0184:00	Lost Communication With Radio: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0184:00	Lost Communication With Radio: No Sub Type Information	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0184:00	Lost Communication With Radio: No Sub Type Information	FCIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0184:00	Lost Communication With Radio: No Sub Type Information	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0184:00	Lost Communication With Radio: No Sub- Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0197	NOTE: The telephone control module is defined by the IDS as the APIM . Lost Communication With Telephone Control Module	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0197	Lost Communication With Telephone Control Module	FDIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0197:00	Lost Communication With Telephone Control Module: No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0197:00	Lost Communication With Telephone Control Module: No Sub Type Information	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0197:00	Lost Communication With Telephone Control Module: No Sub Type Information	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0208:00	Lost Communication With "Seat Control Module A": No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0232:00	Lost Communication With Side Obstacle Detection Control Module - Left: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0233:00	Lost Communication With Side Obstacle Detection Control Module - Right: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0238	Lost Communication With Digital Audio Control Module "D" ( DSP )	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0238	Lost Communication With Digital Audio Control Module "D" ( DSP )	FDIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0238:00	Lost Communication With Digital Audio Control Module "D": No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0253:00	Lost Communication With Accessory Protocol Interface Module: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0255	Lost Communication With Front Controls Interface Module	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0255:00	Lost Communication With Front Display Interface Module: No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0255:00	Lost Communication With Front Display Interface Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0256	Lost Communication With Front Display Interface Module	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0256:00	Lost Communication With Front Controls Interface Module: No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0256:00	Lost Communication With Front Controls Interface Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0256:00	Lost Communication With Front Controls Interface Module: No Sub Type Information	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS (gasoline vehicles). REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID (hybrid vehicles).
U0298:00	Lost Communication With DC to DC Converter Control Module "A": No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
U0298:00	Lost Communication With DC to DC Control Module "A": No Sub-Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0298:87	Lost Communication With DC to DC Converter Control Module "A": Missing Message	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U029A:00	Lost Communication with Hybrid Battery Pack Sensor Module: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
U0300:00	Internal Control Module Software Incompatibility: No Sub Type Information	DC/DC	REFER to HIGH VOLTAGE CONVERTER/INVERTER .
U0300:00	Internal Control Module Software Incompatibility: No Sub Type Information	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U0300:00	Internal Control Module Software Incompatibility: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0300:05	Internal Control Module Software Incompatibility: System Programming Failures	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
U0300:51	Internal Control Module Software Incompatibility: Not Programmed	ABS module	REFER to MODULE CONFIGURATION .
U0335:00	Software Incompatibility with Hybrid Battery Energy Control Module: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
U0336:00	Software Incompatibility with Restraints Control Module: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
U0401	Invalid Data Received from ECM /PCM A	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
U0401	Invalid Data Received from ECM /PCM A	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0401:00	Invalid Data Received from ECM /PCM A: No Sub Type Information	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0401:00	Invalid Data Received From ECM /PCM "A": No Sub Type Information	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0401:00	Invalid Data Received From ECM /PCM "A": No Sub Type Information	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U0401:66	Invalid Data Received From ECM /PCM "A": Signal Has Too Many Transitions/Events	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
U0401:68	Invalid Data Received From ECM /PCM "A": Event Information	ACCM	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
U0401:68	Invalid Data Received From ECM /PCM "A": Event Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
U0401:68	Invalid Data Received From ECM /PCM "A": Event Information	DC/DC	REFER to HIGH VOLTAGE CONVERTER/INVERTER .
U0401:68	Invalid Data Received From ECM /PCM "A": Event Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0401:86	Invalid Data Received from ECM /PCM A: Signal Invalid	HCM	REFER to EXTERIOR LIGHTING .
U0402	Invalid Data Received from TCM	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0402:68	Invalid Data Received from TCM : Event Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
U0402:68	Invalid Data Received from TCM : Event Information	DC/DC	REFER to HIGH VOLTAGE CONVERTER/INVERTER .
U0402:68	Invalid Data Received from TCM : Event Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0402:86	Invalid Data Received from TCM : Signal Invalid	HCM	REFER to EXTERIOR LIGHTING .
U040A:68	Invalid Data Received from Air Conditioning Control Module: Event Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U040A:81	Invalid Data Received From Air Conditioning Control Module: Invalid Serial Data Received	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0412:68	Invalid Data Received from Battery Energy Control Module A: Event Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0414	Invalid Data Received From Four-Wheel Drive Clutch Control Module	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0415	Invalid Data Received from Anti-Lock Brake System (ABS) Control Module	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
U0415:00	Invalid Data Received From Anti-Lock Brake System (ABS) Control Module: No Sub Type Information	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U0415:68	Invalid Data Received from Anti-Lock Brake System (ABS) Control Module: Event Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0415:86	Invalid Data Received From Anti-Lock Brake System (ABS) Control Module: Signal Invalid	HCM	REFER to EXTERIOR LIGHTING .
U0420:87	Invalid Data Received From Power Steering Control Module: Missing Message	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0422:00	Invalid Data Received From Body Control Module: No Sub Type Information	APIM	REFER to MODULE COMMUNICATIONS NETWORK .
U0422:68	Invalid Data Received From Body Control Module: Event Information	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS (gasoline vehicles). REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID (hybrid vehicles).
U0422:68	Invalid Data Received From Body Control Module: Event Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0423:00	Invalid Data Received From Instrument Panel Cluster ( IPC ) Control Module: No Sub Type Information	APIM	REFER to MODULE COMMUNICATIONS NETWORK .
U0423:64	Invalid Data Received From Instrument Panel Cluster ( IPC ) Control Module: Signal Plausibility Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0423:68	Invalid Data Received From Instrument Panel Cluster ( IPC ) Control Module: Event Information	ACCM	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
U0423:68	Invalid Data Received From Instrument Panel Cluster ( IPC ) Control Module: Event Information	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS (gasoline vehicles). REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID (hybrid vehicles).
U0423:86	Invalid Data Received From Instrument Panel Cluster ( IPC ) Control Module: Signal Invalid	HCM	REFER to EXTERIOR LIGHTING .
U0424:68	Invalid Data Received From HVAC Control Module: Event Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
U0428:86	Invalid Data Received From Steering Angle Sensor Module: Signal Invalid	HCM	REFER to EXTERIOR LIGHTING .
U0430:68	Invalid Data Received From Tire Pressure Monitor Module: Event Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0452	Invalid Data Received From Restraints Control Module	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0452:00	Invalid Data Received From Restraints Control Module: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
U0452:29	Invalid Data Received From Restraints Control Module: Signal Invalid	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0452:68	Invalid Data Received from Restraints Control Module: Event Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0462:00	Invalid Data Received from Compass Module: No Sub Type Information	IPC	REFER to ELECTRONIC COMPASS .
U0462:68	Invalid Data Received From Compass Module: Event Information	IPC	REFER to ELECTRONIC COMPASS .
U0464:68	Invalid Data Received From Navigation Control Module: Event Information	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
U046B:00	Invalid Data Received From Global Positioning System Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0485:00	Invalid Data Received From Radio: No Sub Type Information	APIM	REFER to MODULE COMMUNICATIONS NETWORK .
U0533:68	Invalid Data Received from Side Obstacle Detection Control Module-Left: Event Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0534:68	Invalid Data Received from Side Obstacle Detection Control Module-Right: Event Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0554:00	Invalid Data Received From Accessory Protocol Interface Module: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0557:68	Invalid Data Received From Front Controls Interface Module "A": Event Information	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS (gasoline vehicles). REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID (hybrid vehicles).
U0599:68	Invalid Data Received From DC to DC Converter Control Module "A": Event Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
U0599:68	Invalid Data Received from DC to DC Converter Control Module "A": Event Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0599:81	Invalid Data Received From DC to DC Converter Control Module "A": Invalid Serial Data Received	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U1000:00	Solid State Driver Protection Activated - Driver Disabled: No Sub Type Information	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS (gasoline vehicles). REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID (hybrid vehicles).
U1003:49	System Clock: Internal Electronic Failure	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
U1006:00	Sub Network CAN Initialization Failure: No Sub Type Information	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
U1901	CAN Network #2 Communication Bus Fault - Receive Error	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U200D:12	Control Module Output Power A: Circuit Short To Battery	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
U200D:12	Control Module Output Power A: Circuit Short To Battery	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U200D:13	Control Module Output Power A: Circuit Open	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
U2011:49	Motor: Internal Electronic Failure	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U2011:61	Motor: Signal Calculation Failure	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U2013:63	Switch Pack: Component Failures	FCIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:09	Control Module Hardware: Component Failures	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:41	Control Module Hardware: General Checksum Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:41	Control Module Hardware: General Checksum Failure	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:41	Control Module Hardware: General Checksum Failure	FCIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:42	Control Module Hardware: General Memory Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:42	Control Module Hardware: General Memory Failure	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:42	Control Module Hardware: General Memory Failure	FCIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:4B	Control Module Hardware: Over Temperature	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:96	Control Module Hardware: Component Internal Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:96	Control Module Hardware: Component Internal Failure	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U201A:51	Control Module Main Calibration Data: Not Programmed	ACM	REFER to MODULE CONFIGURATION .
U201A:51	Control Module Main Calibration Data: Not Programmed	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U201A:51	Control Module Main Calibration Data: Not Programmed	FCIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2050	No Application Present	4X4 control module	REFER to MODULE CONFIGURATION .
U2050	No Application Present	ABS module	REFER to MODULE CONFIGURATION .
U2050	No Application Present	ACM	REFER to MODULE CONFIGURATION .
U2050	No Application Present	DCSM	REFER to MODULE CONFIGURATION .
U2050	No Application Present	DDM	REFER to MODULE CONFIGURATION .
U2050	No Application Present	DSM	REFER to MODULE CONFIGURATION .
U2050	No Application Present	FCIM	REFER to MODULE CONFIGURATION .
U2050	No Application Present	FDIM	REFER to MODULE CONFIGURATION .
U2050	No Application Present	ILCM	REFER to MODULE CONFIGURATION .
U2050	No Application Present	SJB	REFER to MODULE CONFIGURATION .
U2051	One or More Calibration Files Missing/Corrupt	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
U2051	One or More Calibration Files Missing/Corrupt	ACM	REFER to MODULE CONFIGURATION .
U2051	One or More Calibration Files Missing/Corrupt	FCIM	REFER to MODULE CONFIGURATION .
U2051	One or More Calibration Files Missing/Corrupt	FDIM	REFER to MODULE CONFIGURATION .
U2051	One or More Calibration Files Missing/Corrupt	PAM	REFER to MODULE CONFIGURATION .
U2100:00	Initial Configuration Not Complete: No Sub Type Information	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U2100:00	Initial Configuration Not Complete: No Sub Type Information	ACM	REFER to MODULE CONFIGURATION .
U2100:00	Initial Configuration Not Complete: No Sub Type Information	APIM	REFER to MODULE CONFIGURATION .
U2100:00	Initial Configuration Not Complete: No Sub Type Information	Audio DSP module	REFER to MODULE CONFIGURATION .
U2100:00	Initial Configuration Not Complete: No Sub Type Information	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS (gasoline vehicles). REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID (hybrid vehicles).
U2100:00	Initial Configuration Not Complete: No Sub Type Information	IPC	REFER to MODULE CONFIGURATION .
U2100:00	Initial Configuration Not Complete: No Sub Type Information	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U2100:00	Initial Configuration Not Complete: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U2100:00	Initial Configuration Not Complete: No Sub Type Information	SOD-L	REFER to MODULE CONFIGURATION .
U2100:00	Initial Configuration Not Complete: No Sub Type Information	SOD-R	REFER to MODULE CONFIGURATION .
U2100:41	Initial Configuration Not Complete: General Checksum Failure	ABS module	REFER to MODULE CONFIGURATION .
U2100:56	Initial Configuration Not Complete: Invalid/Incompatible Configuration	ABS module	REFER to MODULE CONFIGURATION .
U2101:00	Control Module Configuration Incompatible: No Sub Type Information	ACM	REFER to MODULE CONFIGURATION .
U2101:00	Control Module Configuration Incompatible: No Sub Type Information	APIM	REFER to MODULE CONFIGURATION .
U2101:00	Control Module Configuration Incompatible: No Sub Type Information	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2101:00	Control Module Configuration Incompatible: No Sub Type Information	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U2200:00	Control Module Configuration Memory Corrupt: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U2472	Unexpected Ignition State	SJB	REFER to STEERING COLUMN SWITCHES .
U2473	Unexpected Vehicle Speed ( VSS )	SJB	REFER to SMART JUNCTION BOX (SJB) .
U3000:04	Control Module: System Internal Failures	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3000:04	Control Module: System Internal Failures	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
U3000:04	Control Module: System Internal Failures	DC/DC	REFER to HIGH VOLTAGE CONVERTER/INVERTER .
U3000:04	Control Module: System Internal Failures	HCM	REFER to EXTERIOR LIGHTING .
U3000:09	Control Module: Component Failure	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3000:41	Control Module: General Checksum Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U3000:41	Control Module: General Checksum Failure	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3000:41	Control Module: General Checksum Failure	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
U3000:41	Control Module: General Checksum Failure	DC/DC	REFER to HIGH VOLTAGE CONVERTER/INVERTER .
U3000:41	Control Module: General Checksum Failure	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3000:41	Control Module: General Checksum Failure	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS (gasoline vehicles) . REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID (hybrid vehicles) .
U3000:41	Control Module: General Checksum Failure	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U3000:41	Control Module: General Checksum Failure	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U3000:42	Control Module: General Memory Failure	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3000:42	Control Module: General Memory Failure	DC/DC	REFER to HIGH VOLTAGE CONVERTER/INVERTER .
U3000:42	Control Module: General Memory Failure	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3000:42	Control Module: General Memory Failure	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U3000:43	Control Module: Special Memory Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U3000:43	Control Module: Special Memory Failure	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U3000:44	Control Module: Data Memory Failure	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U3000:44	Control Module: Data Memory Failure	SOD-L	REFER to PINPOINT TEST H: DTC U3000:44 OR DTC U3000:49 .
U3000:44	Control Module: Data Memory Failure	SOD-R	REFER to PINPOINT TEST H: DTC U3000:44 OR DTC U3000:49 .
U3000:45	Control Module: Program Memory Failure	DC/DC	REFER to HIGH VOLTAGE CONVERTER/INVERTER .
U3000:45	Control Module: Program Memory Failure	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U3000:46	Control Module: Calibration/Parameter Memory Failure	BECM	REFER to HIGH VOLTAGE TRACTION BATTERY .
U3000:46	Control Module: Calibration/Parameter Memory Failure	HCM	REFER to EXTERIOR LIGHTING .
U3000:46	Control Module: Calibration/Parameter Memory Failure	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U3000:46	Control Module: Calibration/Parameter Memory Failure	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U3000:46	Control Module: Calibration/Parameter Memory Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U3000:47	Control Module: Watchdog/Safety Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U3000:49	Control Module: Internal Electronic Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U3000:49	Control Module: Internal Electronic Failure	ACCM	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
U3000:49	Control Module: Internal Electronic Failure	DC/DC	REFER to HIGH VOLTAGE CONVERTER/INVERTER .
U3000:49	Control Module: Internal Electronic Failure	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID .
U3000:49	Control Module: Internal Electronic Failure	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U3000:49	Control Module: Internal Electronic Failure	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U3000:49	Control Module: Internal Electronic Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U3000:49	Control Module: Internal Electronic Failure	SOD-L	REFER to PINPOINT TEST H: DTC U3000:44 OR DTC U3000:49 .
U3000:49	Control Module: Internal Electronic Failure	SOD-R	REFER to PINPOINT TEST H: DTC U3000:44 OR DTC U3000:49 .
U3000:4A	Control Module: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U3000:4B	Control Module: Over Temperature	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U3000:53	Control Module: Deactivated	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U3000:54	Control Module: Missing Calibration	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U3000:61	Control Module: Signal Calculation Failure	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U3000:72	Control Module: Actuator Stuck Open	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U3000:88	Control Module: Bus Off	APIM	REFER to MODULE COMMUNICATIONS NETWORK .
U3000:96	Control Module: Component Internal Failure	DC/DC	REFER to HIGH VOLTAGE CONVERTER/INVERTER .
U3000:96	Control Module: Component Internal Failure	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U3001:00	Control Module Improper Shutdown: No Sub Type Information	BECM	REFER to PINPOINT TEST AF: DTCS U3001:00 .
U3002:62	Vehicle Identification Number: Signal Compare Failure	ABS module	REFER to PINPOINT TEST Z: DTC U3002:62 .
U3002:62	Vehicle Identification Number: Signal Compare Failure	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS (gasoline vehicles) . REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS - HYBRID (hybrid vehicles) .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	ABS module	REFER to PINPOINT TEST O: DTCS U3003:16 AND 17 .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	ACM	REFER to PINPOINT TEST AO: DTC B1318 OR DTC U3003:16 (AUDIO CONTROL MODULE (ACM)) .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	APIM	REFER to PINPOINT TEST AQ: DTC U3003:16 (ACCESSORY PROTOCOL INTERFACE MODULE (APIM)) .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	Audio DSP module	REFER to PINPOINT TEST AS: DTC U3003:16 (AUDIO DIGITAL SIGNAL PROCESSING (DSP) MODULE) .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	BECM	REFER to PINPOINT TEST AF: U3003:16 .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	DC/DC	REFER to PINPOINT TEST H: DTC U3003:16 .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	FCIM	REFER to PINPOINT TEST AU: DTC B1318 OR DTC U3003:16 (FRONT CONTROLS INTERFACE MODULE (FCIM)) .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	GPSM	REFER to PINPOINT TEST AX: DTC U3003:16 GLOBAL POSITIONING SYSTEM MODULE (GPSM)) .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	HCM	REFER to PINPOINT TEST AH: DTC U3003:16 .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	HVAC module	REFER to PINPOINT TEST H: DTCS U3003:16 AND 17 .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	IPC	REFER to PINPOINT TEST BX: DTC U3003:16 .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	OCSM	REFER to PINPOINT TEST AI: DTCS U3003:16 AND U3003:17 .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	RCM	REFER to PINPOINT TEST AI: DTCS U3003:16 AND U3003:17 .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	ABS module	REFER to PINPOINT TEST O: DTCS U3003:16 AND 17 .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	ACM	REFER to PINPOINT TEST AP: DTC U3003:17 (AUDIO CONTROL MODULE (ACM)) .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	APIM	REFER to PINPOINT TEST AR: DTC U3003:17 (ACCESSORY PROTOCOL INTERFACE MODULE (APIM)) .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	Audio DSP module	REFER to PINPOINT TEST AT: DTC U3003:17 (AUDIO DIGITAL SIGNAL PROCESSING (DSP) MODULE) .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	BECM	REFER to PINPOINT TEST AF: U3003:17 .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	DC/DC	REFER to PINPOINT TEST I: DTC U3003:17 .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	FCIM	REFER to PINPOINT TEST AV: DTC U3003:17 (FRONT CONTROLS INTERFACE MODULE (FCIM)) .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	GPSM	REFER to PINPOINT TEST AY: DTC U3003:17 (GLOBAL POSITIONING SYSTEM MODULE (GPSM)) .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	HCM	REFER to PINPOINT TEST AI: DTC U3003:17 .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	HVAC module	REFER to PINPOINT TEST H: DTCS U3003:16 AND 17 .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	IPC	REFER to PINPOINT TEST BY: DTC U3003:17 .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	OCSM	REFER to PINPOINT TEST AI: DTCS U3003:16 AND U3003:17 .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	RCM	REFER to PINPOINT TEST AI: DTCS U3003:16 AND U3003:17 .
U3003:62	Battery Voltage: Signal Compare Failure	BECM	REFER to PINPOINT TEST AG: DTC U3003:62 .
U3003:62	Battery Voltage: Signal Compare Failure	DC/DC	REFER to PINPOINT TEST J: DTC U3003:62 .
U3003:68	Battery Voltage: Event Information	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U300A:62	Ignition Switch: Signal Compare Failure	IPC	REFER to PINPOINT TEST BZ: DTC U300A:62 OR U300A:64 .
U300A:64	Ignition Switch: Signal Plausibility Failure	IPC	REFER to PINPOINT TEST BZ: DTC U300A:62 OR U300A:64 .

NOTE
If DTC B2477 is also present, REFER to the Action for DTC B2477 in this DTC Table.

NOTE
The telephone control module is defined by the IDS as the APIM .

DIAGNOSTIC TROUBLE CODE (DTC) TABLE

Inspection and Verification

Verify the customer concern.
Visually inspect for obvious signs of electrical damage. VISUAL INSPECTION TABLE Electrical Smart Junction Box (SJB) fuse 12 (7.5A) Wiring, terminals or connectors Driver Door Module (DDM)
If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
If the cause is not visually evident, connect the scan tool to the Data Link Connector (DLC). NOTE: Make sure to use the latest scan tool software release.
If the scan tool does not communicate with the VCM : Check the VCM connection to the vehicle. Check the scan tool connection to the VCM . Refer to «PINPOINT TEST AF: NO POWER TO THE SCAN TOOL»(ref-355946-S03084164432010013000000) , to diagnose no power to the scan tool. NOTE: The Vehicle Communication Module (VCM) LED prove-out confirms power and ground from the DLC are provided to the VCM .
If the scan tool does not communicate with the vehicle: Verify the ignition key is in the ON position. Verify the scan tool operation with a known good vehicle. Refer to «PINPOINT TEST A: THE PCM DOES NOT RESPOND TO THE SCAN TOOL»(ref-355946-S02817008552010013000000) to diagnose no response from the PCM.
Carry out the network test. If the scan tool responds with no communication for one or more modules, refer to «INSPECTION AND VERIFICATION»(ref-355946-S34749853742010013000000) . If the network test passes, retrieve and record the continuous memory DTCs.
Clear the continuous DTCs and carry out the self-test diagnostics for the DDM .
If the DTCs retrieved are related to the concern, go to «DTC TABLES»(ref-355947-S07378034572010013000000) . For all other DTCs, refer to «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(ref-355947-S19553737032010013000000) .
If no DTCs related to the concern are retrieved, GO to «SYMPTOM TABLE»(ref-355947-S00908224352010013000000) .

DTC Tables

DTC	Description	Action
B106E	Solid State Driver Disabled Due to Short Circuit	Go To PINPOINT TEST A .
B106F	Module Disabled Due to External Fault	Go To PINPOINT TEST A .
B1317	Battery Voltage High	Go To PINPOINT TEST B .
B1318	Battery Voltage Low	Go To PINPOINT TEST C .
B1342	ECU Is Faulted	CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new Driver Door Module (DDM). REFER to Removal and Installation . TEST the system for normal operation.
B2477	Module Configuration Failure	REFER to DTC TABLE .
U0140	Lost Communication With Body Control Module ( GEM )	Go To PINPOINT TEST D .
U2050	No Application Present	REFER to MODULE CONFIGURATION .
All other DTCs		REFER to DIAGNOSTIC TROUBLE CODE (DTC) TABLE .

DRIVER DOOR MODULE (DDM) DTC TABLE

Symptom Table

Condition	Possible Sources	Action
No communication with the Driver Door Module (DDM)	Fuse Wiring, terminals or connectors DDM	REFER to PINPOINT TEST X: THE DRIVER DOOR MODULE (DDM) DOES NOT RESPOND TO THE SCAN TOOL .

SYMPTOM TABLE

PINPOINT TEST A: DTCs B106E, B106F

Note. If DTC B106F is present and the DDM is to be replaced, the fault condition must be corrected first. Failure to correct the fault condition first may cause damage to the new DDM , resulting in a repeat repair.

A1 REVIEW THE DTCs Review the DTCs from the DDM self-test. Is only DTC B106F present? Yes: INSTALL a new DDM . REFER to «DRIVER DOOR MODULE (DDM)»(ref-355947-S03477812432010013000000) . TEST the system for normal operation. No: CORRECT any DTCs present other than DTC B106E (DTC B106F may also be present). REFER to «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(ref-355947-S19553737032010013000000) . After the repair, GO to A2 .
A2 CARRY OUT THE DDM SELF-TEST Carry out the DDM self-test. Is only DTC B106F present? Yes: INSTALL a new DDM . REFER to «Removal and Installation»(ref-355947-S18294268812010013000000) . TEST the system for normal operation. No: The system is operating correctly at this time. The concern was caused by a fault in one of the output circuits, which is no longer present.

Pinpoint Test B: DTC B1317

Refer to the appropriate SYSTEM WIRING DIAGRAMS article for schematic and connector information.

Note. DTC B1317 may be stored in the module memory due to previous battery charging or vehicle jump starting events.

B1 CHECK FOR DTC B1317, B1676 OR P0563 SET IN OTHER MODULES Ignition ON. Enter the following diagnostic mode on the scan tool: (All CMDTCs) Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC B1317, B1676 or P0563 (PCM) set in more than one module? Yes: REFER to «CHARGING SYSTEM»(ref-355931) to diagnose an overcharging condition. No: GO to B2 .
B2 CHECK THE BATTERY VOLTAGE Turn off all interior/exterior lights and accessories. Start and run the engine at approximately 2,000 rpm for 3 minutes while monitoring the battery voltage. Does the battery voltage rise to 15.5 volts or higher? Yes: REFER to «CHARGING SYSTEM»(ref-355931) to diagnose an overcharging condition. No: GO to B3 .
B3 RECHECK FOR DTC B1317 Turn the engine off. Ignition ON. Enter the following diagnostic mode on the scan tool: DDM Self-Test. Clear the continuous memory DTCs. Carry out the DDM self-test. Is DTC B1317 present? Yes: INSTALL a new DDM . REFER to «Removal and Installation»(ref-355947-S18294268812010013000000) . TEST the system for normal operation. No: The system is operating normally at this time. The DTC may have been set previously during battery charging or while jump starting the vehicle.

Pinpoint Test C: DTC B1318

Refer to the appropriate SYSTEM WIRING DIAGRAMS article for schematic and connector information.

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Note. Failure to disconnect the battery when instructed will result in false resistance readings. Refer to BATTERY DISCONNECT .

Scheme 243

Scheme 243: PINPOINT TEST C: DTC B1318

Scheme 244

C1 RECHECK THE DDM DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: DDM Self-Test. Clear the DTCs. Repeat the DDM self-test. Is DTC B1318 still present? Yes: GO to C2 . No: The system is operating normally at this time. The DTC may have been set previously during battery charging or while jump starting the vehicle.
C2 CHECK FOR CHARGING SYSTEM DTCs IN THE PCM Enter the following diagnostic mode on the scan tool: PCM Self-Test. Retrieve the continuous memory DTCs from the PCM. Is DTC P0620, P0625, P0626 or P065B set in the PCM? Yes: REFER to «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(ref-355931-S42235723192010013000000) . No: GO to C3 .
C3 CHECK THE BATTERY CONDITION AND STATE OF CHARGE Ignition OFF. Check the battery condition and verify the battery is fully charged. Refer to «PINPOINT TEST A: BATTERY CONDITION TEST»(ref-355968-S31115854422010013000000) . Is the battery OK and fully charged? Yes: GO to C4 . No: REFER to «CHARGING SYSTEM»(ref-355931) .
C4 CHECK THE DDM VOLTAGE SUPPLY Measure and record the voltage at the battery. Disconnect: DDM C568b. Ignition ON. Measure the voltage between the DDM C568b-1, circuit SBP12 (GN/RD), harness side and ground. Is the voltage within 0.2 volt of the recorded battery voltage? Yes: GO to C5 . No: REPAIR the circuit for high resistance. CLEAR the DTCs. REPEAT the self-test.
C5 CHECK THE DDM GROUND CIRCUIT Ignition OFF. Disconnect: Negative Battery Cable. Measure the resistance between the DDM C568b-24, circuit GD126 (BK/WH), harness side and ground. Is the resistance less than 5 ohms? Yes: GO to C6 . No: REPAIR the circuit for high resistance. TEST the system for normal operation.
C6 CHECK FOR CORRECT DDM OPERATION Connect: Negative Battery Cable. Disconnect the DDM connectors. Check for: corrosion damaged pins pushed-out pins Connect the DDM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes: INSTALL a new DDM . REFER to «Removal and Installation»(ref-355947-S18294268812010013000000) . TEST the system for normal operation. No: The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

Pinpoint Test D: DTC U0140

Refer to the appropriate SYSTEM WIRING DIAGRAMS article for schematic and connector information.

D1 VERIFY CUSTOMER CONCERN Ignition ON. Verify there is an observable symptom present. Is an observable symptom present? Yes: GO to D2 . No: The system is operating normally at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
D2 CHECK THE COMMUNICATION NETWORK Ignition ON. Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the SJB pass the network test? Yes: GO to D3 . No: REFER to «INSPECTION AND VERIFICATION»(ref-355946-S34749853742010013000000) .
D3 RETRIEVE THE RECORDED DTCs FROM THE SELF-TEST Check for recorded DDM DTCs from the self-test. Is DTC B1317 or DTC B1318 recorded? Yes: For DTC B1317, Go To «PINPOINT TEST B»(ref-355947-S10317618072010013000000) . For DTC B1318, Go To «PINPOINT TEST C»(ref-355947-S39114020022010013000000) . No: GO to D4 .
D4 RECHECK THE DDM DTCs NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during Programmable Module Installation (PMI) or the PMI may not have been carried out. Clear the DTCs. Repeat the DDM self-test. Is DTC U0140 still present? Yes: GO to D5 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
D5 CHECK FOR DTC U0140/U0140:00 SET IN OTHER MODULES Clear all DTCs. Ignition OFF. Ignition ON. Wait 10 seconds. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0140/U0140:00 set in other modules? Yes: INSTALL a new SJB . REFER to «Installation»(ref-355947-S38460867092010013000000) . No: INSTALL a new DDM . REFER to «Removal and Installation»(ref-355947-S18294268812010013000000) .

Pinpoint Test D

D5 VCM

NOTE: The Vehicle Communication Module (VCM) LED prove-out confirms power and ground from the DLC are provided to the VCM .

D8 DSM

DTC Charts

DTC	Description	Action
B106E	Solid State Driver Disabled Due to Short Circuit	Go To PINPOINT TEST E .
B106F	Module Disabled Due to External Fault	Go To PINPOINT TEST E .
B1317	Battery Voltage High	Go To PINPOINT TEST F .
B1318	Battery Voltage Low	Go To PINPOINT TEST G .
B1342	ECU is Faulted	CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new Driver Seat Module (DSM). REFER to Removal and Installation . TEST the system for normal operation.
B2477	Module Configuration Failure	REFER to DTC TABLE .
U0140	Lost Communication With Body Control Module ( GEM )	Go To PINPOINT TEST H .
U0155	Lost Communication With Instrument Panel Cluster ( IC ) Control Module	Go To PINPOINT TEST I .
U2050	No Application Present	REFER to DTC TABLE .
All other DTCs		REFER to DIAGNOSTIC TROUBLE CODE (DTC) TABLE .

DRIVER SEAT MODULE (DSM) DTC TABLE

Condition	Possible Sources	Action
No communication with the Driver Seat Module (DSM)	Fuse Wiring, terminals or connectors DSM	REFER to PINPOINT TEST Z: THE DRIVER SEAT MODULE (DSM) DOES NOT RESPOND TO THE SCAN TOOL .

SYMPTOM TABLE

PINPOINT TEST E: DTCs B106E, B106F

Note. If DTC B106F is present, the fault condition must be corrected prior to installing a new DSM . Failure to correct the fault condition first may cause damage to the new DSM , resulting in a repeat repair.

E1 REVIEW THE DTCs Review the DTCs from the DSM self-test. Are DTCs B106F and B1342 present? Yes: CORRECT the cause of any other DTCs present. When the other DTCs are corrected, INSTALL a new DSM . REFER to «Removal and Installation»(ref-355947-S20159905812010013000000) . TEST the system for normal operation. No: GO to E2 .
E2 REPAIR OTHER DTCs Repair the cause of any DTCs present, other than DTC B106E. Refer to «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(ref-355947-S19553737032010013000000) . Clear the DTCs. Carry out the DSM self-test. Is DTC B106E still present? Yes: The fault causing the output state to be disabled is still present. REPAIR the cause of the concern. CLEAR the DTCs. REPEAT the self-test. No: The system is operating correctly at this time. The concern was caused by a fault in one of the output circuits.

Pinpoint Test F: DTC B1317

Refer to the appropriate SYSTEM WIRING DIAGRAMS article for schematic and connector information.

Note. DTC B1317 may be stored in the module memory due to previous battery charging or vehicle jump starting events.

F1 CHECK FOR DTC B1317, B1676 OR P0563 SET IN OTHER MODULES Ignition ON. Enter the following diagnostic mode on the scan tool: Retrieve All CMDTCs Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC B1317, B1676 or P0563 (PCM) set in more than one module? Yes: REFER to «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(ref-355931-S42235723192010013000000) to diagnose an overcharging condition. No: GO to F2 .
F2 CHECK THE BATTERY VOLTAGE Turn off all interior/exterior lights and accessories. Start and run the engine at approximately 2,000 rpm for 3 minutes while monitoring the battery voltage. Does the battery voltage rise to 15.5 volts or higher? Yes: REFER to «CHARGING SYSTEM»(ref-355931) to diagnose an overcharging condition. No: GO to F3 .
F3 RECHECK FOR DTC B1317 Turn the engine off. Ignition ON. Enter the following diagnostic mode on the scan tool: DSM Self-Test. Clear the continuous memory DTCs. Carry out the DSM self-test. Is DTC B1317 present? Yes: INSTALL a new DSM . REFER to «Removal and Installation»(ref-355947-S20159905812010013000000) . TEST the system for normal operation. No: The system is operating normally at this time. The DTC may have been set previously during battery charging or while jump starting the vehicle.

Pinpoint Test G: DTC B1318

Refer to the appropriate SYSTEM WIRING DIAGRAMS article for schematic and connector information.

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Note. Failure to disconnect the battery when instructed will result in false resistance readings. Refer to BATTERY DISCONNECT .

Scheme 245

Scheme 245: PINPOINT TEST G: DTC B1318

Scheme 246

Scheme 247

G1 RECHECK THE DSM DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: DSM Self-Test. Clear the DTCs. Repeat the DSM self-test. Is DTC B1318 still present? Yes: GO to G2 . No: The system is operating normally at this time. The DTC may have been set previously during battery charging or while jump starting the vehicle.
G2 CHECK FOR CHARGING SYSTEM DTCs IN THE PCM Enter the following diagnostic mode on the scan tool: PCM Self-Test. Retrieve the continuous memory DTCs from the PCM. Is DTC P0620, P0625, P0626 or P065B set in the PCM? Yes: REFER to «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(ref-355931-S42235723192010013000000) . No: GO to G3 .
G3 CHECK THE BATTERY CONDITION AND STATE OF CHARGE Ignition OFF. Check the battery condition and verify the battery is fully charged. Refer to «PINPOINT TEST A: BATTERY CONDITION TEST»(ref-355968-S31115854422010013000000) . Is the battery OK and fully charged? Yes: GO to G4 . No: REFER to «PINPOINT TEST B: SYSTEM VOLTAGE LOW OR BATTERY IS DISCHARGED»(ref-355931-S10511114692010013000000) .
G4 CHECK THE DSM VOLTAGE SUPPLY Measure and record the voltage at the battery. Disconnect: DSM C3299a. Ignition ON. Measure the voltage between the DSM C3299a-1, circuit SBB32 (VT/RD), harness side and ground. Is the voltage within 0.2 volt of the recorded battery voltage? Yes: GO to G5 . No: REPAIR the circuit for high resistance. CLEAR the DTCs. REPEAT the self-test.
G5 CHECK THE DSM GROUND CIRCUITS Ignition OFF. Disconnect: Negative Battery Cable. Disconnect: DSM C3299b. Measure the resistance between the DSM C3299a-2, circuit GD126 (BK/WH), harness side and ground. Measure the resistance between the DSM C3299b-24, circuit GD126 (BK/WH), harness side and ground. Are the resistances less than 5 ohms? Yes: CONNECT the negative battery cable. GO to G6 . No: REPAIR the circuit for high resistance. CONNECT the negative battery cable. TEST the system for normal operation.
G6 CHECK FOR CORRECT DSM OPERATION Disconnect the DSM connectors. Check for: corrosion damaged pins pushed-out pins Connect the DSM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes: INSTALL a new DSM . REFER to «Removal and Installation»(ref-355947-S20159905812010013000000) . TEST the system for normal operation. No: The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

Pinpoint Test H: DTC U0140

Refer to the appropriate SYSTEM WIRING DIAGRAMS article for schematic and connector information.

H1 VERIFY CUSTOMER CONCERN Ignition ON. Verify there is an observable symptom present. Is an observable symptom present? Yes: GO to H2 . No: The system is operating normally at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
H2 CHECK THE COMMUNICATION NETWORK Ignition ON. Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the SJB pass the network test? Yes: GO to H3 . No: REFER to «INSPECTION AND VERIFICATION»(ref-355946-S34749853742010013000000) .
H3 RETRIEVE THE RECORDED DTCs FROM THE SELF-TEST Check for recorded DSM DTCs from the self-test. Is DTC B1317 or DTC B1318 recorded? Yes: For DTC B1317, Go To «PINPOINT TEST F»(ref-355947-S29422150082010013000000) . For DTC B1318, Go To «PINPOINT TEST G»(ref-355947-S05863424912010013000000) . No: GO to H4 .
H4 RECHECK THE DSM DTCs NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during Programmable Module Installation (PMI) or the PMI may not have been carried out. Clear the DTCs. Repeat the DSM self-test. Is DTC U0140 still present? Yes: GO to H5 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
H5 CHECK FOR DTC U0140/U0140:00 SET IN OTHER MODULES Clear all DTCs. Ignition OFF. Ignition ON. Wait 10 seconds. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0140/U0140:00 set in other modules? Yes: INSTALL a new SJB . REFER to «Installation»(ref-355947-S38460867092010013000000) . No: INSTALL a new DSM . REFER to «Removal and Installation»(ref-355947-S20159905812010013000000) .

Pinpoint Test I: DTC U0155

Refer to the appropriate SYSTEM WIRING DIAGRAMS article for schematic and connector information.

I1 VERIFY CUSTOMER CONCERN Ignition ON. Verify there is an observable symptom present. Is an observable symptom present? Yes: GO to I2 . No: The system is operating normally at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
I2 CHECK THE COMMUNICATION NETWORK Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the IPC pass the network test? Yes: GO to I3 . No: REFER to «INSPECTION AND VERIFICATION»(ref-355946-S34749853742010013000000) .
I3 RETRIEVE THE RECORDED DTCs FROM THE SELF-TEST Check for recorded DSM DTCs from the self-test. Is DTC B1317 or B1318 recorded? Yes: For DTC B1317, Go To «PINPOINT TEST F»(ref-355947-S29422150082010013000000) . For DTC B1318, Go To «PINPOINT TEST G»(ref-355947-S05863424912010013000000) . No: GO to I4 .
I4 RECHECK THE DSM DTCs NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during Programmable Module Installation (PMI) or the PMI may not have been carried out. Clear the DTCs. Repeat the DSM self-test. Is DTC U0155 still present? Yes: GO to I5 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
I5 CHECK FOR DTC U0155/U0155:00 SET IN OTHER MODULES Clear all DTCs. Ignition OFF. Ignition ON. Wait 10 seconds. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0155/U0155:00 set in other modules? Yes: INSTALL a new IPC . REFER to «INSTALLATION»(ref-355951-S06007022282010013000000) . No: INSTALL a new DSM . REFER to «Removal and Installation»(ref-355947-S20159905812010013000000) .

Note. The Smart Junction Box (SJB) is also known as the Generic Electronic Module (GEM).

Pinpoint Test I

I5 VCM

NOTE: The Vehicle Communication Module (VCM) LED prove-out confirms power and ground from the DLC are provided to the VCM .

I8 SJB

DTC	Description	Action
B106E	Solid State Driver Disabled Due to Short Circuit	Go To PINPOINT TEST J .
B106F	Module Disabled Due to External Fault	Go To PINPOINT TEST J .
B1317	Battery Voltage High	Go To PINPOINT TEST K .
B1318	Battery Voltage Low	Go To PINPOINT TEST L .
B1342	ECU is Faulted	CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new Smart Junction Box (SJB). REFER to Installation . TEST the system for normal operation.
B2477	Module Configuration Failure	CONFIGURE the SJB . REFER to MODULE CONFIGURATION . CLEAR the DTCs. RETRIEVE the DTCs and VERIFY successful module configuration. If DTC B2477 is retrieved again, INSTALL a new SJB . REFER to Installation . REPEAT the self-test.
C2780	ECU in Manufacturer Sub-State	NOTE: If DTC B2477 is also present, REFER to Action for DTC B2477 in this DTC Table. This DTC is only present when a new SJB is installed, or the SJB is configured. REFER to TIRE PRESSURE MONITORING SYSTEM (TPMS) SENSOR TRAINING , then CARRY OUT the SJB self-test in order to clear this DTC.
P062F	Internal Control Module EEPROM Error	CONFIGURE the SJB . REFER to MODULE CONFIGURATION to carry out Programmable Module Installation (PMI). CLEAR the DTCs. REPEAT the self-test. If DTC P062F is retrieved again, INSTALL a new SJB . REFER to Installation . TEST the system for normal operation.
U0155	Lost Communication With Instrument Panel Cluster ( IC ) Control Module	Go To PINPOINT TEST M .
U2050	No Application Present	CONFIGURE the SJB . REFER to MODULE CONFIGURATION . CLEAR the DTCs. RETRIEVE the DTCs and VERIFY successful module configuration. If DTC U2050 is retrieved again, INSTALL a new SJB . REFER to Installation . REPEAT the self-test.
U2472	Unexpected Ignition State	REFER to PINPOINT TEST G: DTCS B2844 AND U2472 .
U2473	Unexpected Vehicle Speed ( VSS )	Sets during the self-test if the vehicle speed exceeds 5 km/h (3 mph), or the vehicle speed cannot be determined.
All other DTCs		REFER to DIAGNOSTIC TROUBLE CODE (DTC) TABLE .

NOTE
If DTC B2477 is also present, REFER to Action for DTC B2477 in this DTC Table.

SMART JUNCTION BOX (SJB) DTC TABLE

Condition	Possible Sources	Action
No communication with the Smart Junction Box (SJB)	Fuse Wiring, terminals or connectors SJB	REFER to PINPOINT TEST U: THE SMART JUNCTION BOX (SJB) DOES NOT RESPOND TO THE SCAN TOOL .

SYMPTOM TABLE

PINPOINT TEST J: DTCs B106E, B106F

Note. If DTC B106F is present and a new SJB is to be installed, the fault condition must be corrected first. Failure to correct the fault condition first may cause damage to the new SJB , resulting in a repeat repair.

Note. If DTC B106F is present, DTC B1342 may also be present. At this time, ignore these DTCs and follow the necessary diagnostics to resolve DTC B106E and any other DTCs that are present. DTC B106E is present only when there is another DTC due to a software issue or a circuitry issue that must be resolved before another self-test is run. Each time a self-test is run, one of the 3 thresholds is used. Once the 3 thresholds are used, DTCs B106F and B1342 is present and the SJB must be replaced. All other DTCs MUST be resolved first, or else the new SJB begins to have its 3 thresholds used with each self-test that is run.

J1 REVIEW THE DTCs Review the DTCs from the SJB self-test. Are only DTCs B106E and B106F present? Yes: INSTALL a new SJB . REFER to «Installation»(ref-355947-S38460867092010013000000) . TEST the system for normal operation. No: CORRECT any DTCs present other than DTCs B106E and B106F. REFER to «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(ref-355947-S19553737032010013000000) . After the repair, GO to J2 .
J2 CARRY OUT THE SJB SELF-TEST Carry out the SJB self-test. Is only DTC B106F present (DTC B1342 may also be present)? Yes: INSTALL a new SJB . REFER to «Installation»(ref-355947-S38460867092010013000000) . TEST the system for normal operation. No: The system is operating correctly at this time. The concern was caused by a fault in one of the output circuits.

Pinpoint Test K: DTC B1317

Refer to the appropriate SYSTEM WIRING DIAGRAMS article for schematic and connector information.

Note. DTC B1317 may be stored in the module memory due to previous battery charging or vehicle jump starting events.

K1 CHECK FOR DTC B1317, B1676 OR P0563 SET IN OTHER MODULES Ignition ON. Enter the following diagnostic mode on the scan tool: Retrieve All CMDTCs Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC B1317, B1676 or P0563 (PCM) set in more than one module? Yes: REFER to «DIAGNOSIS AND TESTING»(ref-355931-S27320907842010013000000) to diagnose an overcharging condition. No: GO to K2 .
K2 CHECK THE BATTERY VOLTAGE Turn off all interior/exterior lights and accessories. Start and run the engine at approximately 2,000 rpm for 3 minutes while monitoring the battery voltage. Does the battery voltage rise to 15.5 volts or higher? Yes: REFER to «DIAGNOSIS AND TESTING»(ref-355931-S27320907842010013000000) to diagnose an overcharging condition. No: GO to K3 .
K3 RECHECK FOR DTC B1317 Turn the engine off. Ignition ON. Enter the following diagnostic mode on the scan tool: SJB Self-Test. Clear the continuous memory DTCs. Carry out the SJB self-test. Is DTC B1317 present? Yes: INSTALL a new SJB . REFER to «Installation»(ref-355947-S38460867092010013000000) . TEST the system for normal operation. No: The system is operating normally at this time. The DTC may have been set previously during battery charging or while jump starting the vehicle.

Pinpoint Test L: DTC B1318

Refer to the appropriate SYSTEM WIRING DIAGRAMS article for schematic and connector information.

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Note. Failure to disconnect the battery when instructed will result in false resistance readings. Refer to BATTERY DISCONNECT .

Scheme 248

Scheme 248: PINPOINT TEST L: DTC B1318

Scheme 249

L1 RECHECK THE SJB DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: SJB Self-Test. Clear the DTCs. Repeat the SJB self-test. Is DTC B1318 still present? Yes: GO to L2 . No: The system is operating normally at this time. The DTC may have been set previously during battery charging or while jump starting the vehicle.
L2 CHECK FOR CHARGING SYSTEM DTCs IN THE PCM Enter the following diagnostic mode on the scan tool: PCM Self-Test. Retrieve the continuous memory DTCs from the PCM. Is DTC P0620, P0625, P0626 or P065B set in the PCM? Yes: REFER to «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(ref-355931-S42235723192010013000000) . No: GO to L3 .
L3 CHECK THE BATTERY CONDITION AND STATE OF CHARGE Ignition OFF. Check the battery condition and verify the battery is fully charged. Refer to «PINPOINT TEST A: BATTERY CONDITION TEST»(ref-355968-S31115854422010013000000) . Is the battery OK and fully charged? Yes: GO to L4 . No: REFER to «CHARGING SYSTEM»(ref-355931) .
L4 CHECK THE SJB VOLTAGE SUPPLY Measure and record the voltage at the battery. Disconnect: SJB C2280g. Measure the voltage between the SJB C2280g-1, circuit SDC02 (RD), harness side and ground. Is the voltage within 0.2 volt of the recorded battery voltage? Yes: GO to L5 . No: REPAIR the circuit for high resistance. CLEAR the DTCs. REPEAT the self-test.
L5 CHECK THE SJB GROUND CIRCUITS Disconnect: Negative Battery Cable. Disconnect: SJB C2280d. Measure the resistance between the SJB C2280d-8, circuit GD126 (BK/WH), harness side and ground; and between the SJB C2280d-12, circuit GD126 (BK/WH), harness side and ground Is the resistance less than 5 ohms? Yes: CONNECT the negative battery cable. GO to L6 . No: REPAIR the circuit for high resistance. CONNECT the negative battery cable. TEST the system for normal operation.
L6 CHECK FOR CORRECT SJB OPERATION Disconnect the SJB connectors. Check for: corrosion damaged pins pushed-out pins Connect the SJB connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes: INSTALL a new SJB . REFER to «Installation»(ref-355947-S38460867092010013000000) . TEST the system for normal operation. No: The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

PINPOINT TEST M: DTC U0155

M1 VERIFY CUSTOMER CONCERN Ignition ON. Verify that there is an observable symptom present. Is an observable symptom present? Yes: GO to M2 . No: The system is operating normally at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
M2 CHECK THE COMMUNICATION NETWORK Ignition ON. Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the IPC pass the network test? Yes: GO to M3 . No: REFER to «INSPECTION AND VERIFICATION»(ref-355946-S34749853742010013000000) .
M3 RETRIEVE THE RECORDED DTCs FROM THE SELF-TEST Check for recorded SJB DTCs from the self-test. Is DTC B1317 or DTC B1318 recorded? Yes: For DTC B1317, Go To «PINPOINT TEST K»(ref-355947-S01794753572010013000000) . For DTC B1318, Go To «PINPOINT TEST L»(ref-355947-S26795081522010013000000) . No: GO to M4 .
M4 RECHECK THE SJB DTCs NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during Programmable Module Installation (PMI) or the PMI may not have been carried out. Clear the DTCs. Repeat the SJB self-test. Is DTC U0155 still present? Yes: GO to M5 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
M5 CHECK FOR DTC U0155 SET IN OTHER MODULES Clear all DTCs. Ignition OFF. Ignition ON. Wait 10 seconds. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0155 (or DTC U0155:00) set (if applicable) in the 4X4 control module, ABS module , ACCM , ACM , APIM , audio DSP module, BPSM , DC/DC , DSM , FDIM , GPSM , HVAC module, PAM , or RCM ? Yes: INSTALL a new IPC . REFER to «INSTALLATION»(ref-355951-S06007022282010013000000) . No: INSTALL a new SJB . REFER to «Installation»(ref-355947-S38460867092010013000000) .

Multifunction Electronic Modules: Diagnosis Lincoln MKZ I facelift

Diagnostic Trouble Code (DTC) Table

Inspection and Verification

DTC Tables

Symptom Table

PINPOINT TEST A: DTCs B106E, B106F

Pinpoint Test B: DTC B1317

Pinpoint Test C: DTC B1318

Scheme 243

Scheme 244

Pinpoint Test D: DTC U0140

Pinpoint Test D

DTC Charts

PINPOINT TEST E: DTCs B106E, B106F

Pinpoint Test F: DTC B1317

Pinpoint Test G: DTC B1318

Scheme 245

Scheme 246

Scheme 247

Pinpoint Test H: DTC U0140

Pinpoint Test I: DTC U0155

Pinpoint Test I

PINPOINT TEST J: DTCs B106E, B106F

Pinpoint Test K: DTC B1317

Pinpoint Test L: DTC B1318

Scheme 248

Scheme 249

PINPOINT TEST M: DTC U0155

More articles — Multifunction Electronic Modules

Login / Signup

Enter the code

You have successfully logged in!
