Removal and Installation
Front interior lamp
Pinpoint Test P
P3
Second or third row interior lamp
- Second or third row interior lamp
P5
All interior lamps
- All interior lamps
Scheme 31
| Item | Part Number | Description |
|---|---|---|
| 1 | Interior Lighting Control Module (ILCM) bolts (2 required) | |
| 2 | 13E702 | ILCM |
| 3 | ILCM electrical connector (part of 13E720) |
ITEM DESCRIPTION TABLE
- Remove the floor console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-356634) .
- Remove the 2 bolts and the Interior Lighting Control Module (ILCM).
- Disconnect the electrical connector.
- To install, reverse the removal procedure.
Scheme 32
| Item | Part Number | Description |
|---|---|---|
| 1 | 74077D82 | Center instrument panel finish panel |
| 2 | 13D806 | Ambient lighting select switch |
| 3 | 13D806 | Ambient lighting dimmer switch |
ITEM DESCRIPTION TABLE
- Remove the center instrument panel finish panel. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-356634) .
- Release the tabs and remove the ambient lighting switch. NOTE: The ambient lighting switch is removed by releasing the tabs and pushing from behind.
- Squeeze the retaining tabs and remove the ambient lighting switch.
- To install, reverse the removal procedure.
