VECI Decal Location
The decal is typically located on the underside of the hood or on the radiator support sight shield.
Vehicle Certification Label Location
The vehicle certification label is typically located on the LH door or door post pillar.
PCM Locations
For PCM removal and installation procedures, refer to POWERTRAIN CONTROL MODULE (PCM) (2.5L), POWERTRAIN CONTROL MODULE (PCM) (3.0L) and POWERTRAIN CONTROL MODULE (PCM) (3.5L) .
- Focus, Transit Connect - engine compartment, driver side, front of battery.
- Flex, MKS, MKT, Taurus - engine compartment, passenger side, mounted to the cowl under the cowl panel grille
- Fusion, Milan, MKZ - engine compartment, driver side, under battery, mounted to the cowl.
- Mustang - front of engine compartment, passenger side, near fender, under the battery junction box (BJB).
- Crown Victoria, Grand Marquis, Town Car - engine compartment, driver side, fender mounted.
- Explorer, Explorer Sport Trac, Mountaineer - passenger side, near side cowl, behind the glove compartment.
- Edge, Expedition, F-Series, F-Super Duty, MKX, Navigator - passenger side of the engine compartment, mounted to the cowl.
- E-Series - engine compartment, driver side, near the cowl (access from the engine compartment).
Scheme 10
| Function | Description | Connector/Pin |
|---|---|---|
| VPWR | Voltage input to module | B51, B52 |
| PWRGND | Power ground | B67, B68, B69 |
| CSEGND | Case ground | B66 |
| SIGRTN | Signal return | B58, E58 |
| VREF | 5 volt reference | B33, E57 |
| KAPWR | Keep alive power | B54 |
140-PIN PCM POWER AND GROUNDS REFERENCE TABLE
Scheme 11
| Function | Description | Connector/Pin |
|---|---|---|
| VPWR | Voltage input to module | B35, B36 |
| PWRGND | Power ground | B47, B48, B49, B50 |
| CSEGND | Case ground | B10 |
| SIGRTN | Signal return | B41, E58, T41 |
| VREF | 5 volt reference | B40, E57 |
| KAPWR | Keep alive power | B45 |
170-PIN PCM POWER AND GROUNDS REFERENCE TABLE
Scheme 12
| Item | Number | Description |
|---|---|---|
| 1 | Body | |
| 2 | Engine | |
| 3 | Transmission |
ITEM DESCRIPTION TABLE
| Function | Description | Connector/Pin (E-Series, Expedition, F-150, Focus, Navigator, Transit Connect) | Connector/Pin (Escape, Mariner) | Connector/Pin (Flex GTDI, MKS 3.5L, MKT 3.5L, Taurus GTDI) | Connector/Pin (All Others) |
|---|---|---|---|---|---|
| VPWR | Voltage input to module | B67, B68 | B67, B68 | B35, B36, B51 | B51, B52, B53 |
| PWRGND | Power ground | B69, B70 | B69, B70 | B67, B68, B69, B70 | B67, B68, B69, B70 |
| CSEGND | Case ground | B50 | B50 | B50 | B66 |
| SIGRTN | Signal return | B58, E64, T40 | B56, E49, T41 | B56, E49, T41 | B58, E58 |
| VREF | 5 volt reference | B52, B66, E63 | B52, B66, E35 | B52, E35, T7 | B29, B64 |
| KAPWR | Keep alive power | B62 | B62 | B62 | B54 |
190-PIN PCM POWER AND GROUNDS REFERENCE TABLE
