Special Tool(s)
SPECIAL TOOL SPECIFICATION Powertrain Lift Table 014-00765
Scheme 13
| Item | Part Number | Description |
|---|---|---|
| 1 | W505274 | Stabilizer bar brackets-to-front subframe bolts (4 required) |
| 2 | W713000 | Power steering gear-to-front subframe bolts (2 required) |
| 3 | W714890 | Lower ball joint nuts (2 required) |
| 4 | W713156 | Lower roll restrictor bolt |
| 5 | 5R364 RH/5362 LH | Front subframe bracket |
| 6 | W710999 | Front subframe bracket bolts (4 required) |
| 7 | W714039 | Front subframe rear bolts (2 required) |
| 8 | W710714 | Front subframe front bolts (2 required) |
| 9 | W520515 | Power steering gear-to-front subframe nut (2 required) |
| 10 | W709474 | Power steering line routing bolt (2 required) |
| 11 | 5N356 | Front subframe assembly |
| 12 | 5L022 | Front subframe front bolt washers (2 required) |
PART NUMBER REFERENCE
Scheme 14
| Item | Part Number | Description |
|---|---|---|
| 1 | Underbody shield retainer (part of 10494A) (4 required) | |
| 2 | 10494 | Underbody shield |
| 3 | W714039 | Front subframe rearward bolt (2 required) |
| 4 | W710999 | Subframe support bracket bolt (4 required) |
| 5 | 5362 LH/5R364 RH | Subframe support bracket |
| 6 | W710714 | Front subframe forward bolt (2 required) |
| 7 | W712850 | Front engine roll restrictor bolt |
| 8 | W712856 | Rear engine roll restrictor bolt |
| 9 | 5L022 | Front subframe forward bolt washer (2 required) |
| 10 | 5N356 | Front subframe |
| 11 | W714890 | Lower ball joint nut (2 required) |
| 12 | W505274 | Stabilizer bar bracket bolt (4 required) |
PART NUMBER REFERENCE
SPECIAL TOOL SPECIFICATION Front Subframe Bushing Remover/Installer 204-362
Scheme 15
Scheme 16
- Remove the front subframe. For additional information, refer to «SUBFRAME - FRONT»(ref-376047-S06483049472010103100000) .
- Assemble the Front Subframe Bushing Remover/Installer to the front subframe.
- Press out the subframe bushing.
Scheme 17
Scheme 18
- Assemble the Front Subframe Bushing Remover/Installer to the front subframe with the new subframe bushing.
- Align the subframe bushing to the front subframe. Align the subframe bushing so that the voids are oriented in the fore-aft position.
- Press the new subframe bushing into the front subframe.
- Install the front subframe. For additional information, refer to «SUBFRAME - FRONT»(ref-376047-S06483049472010103100000) .
SPECIAL TOOL SPECIFICATION Powertrain Lift Table 014-00765
Scheme 19
| Item | Part Number | Description |
|---|---|---|
| 1 | 5N354 | Rear subframe assembly |
| 2 | W711270 | Rear subframe mounting bracket bolts (4 required) |
| 3 | W713714 | Rear subframe front mounting bolts (2 required) |
| 4 | W713714 | Rear subframe rear mounting bolts (2 required) |
| 5 | 5084 RH/5A111 LH | Rear subframe mounting bracket (2 required) |
| 6 | W710681 | Brake caliper bolt (4 required) |
| 7 | W505251 | Wheel opening parking brake cable bracket bolt |
| 8 | W505251 | Intermediate parking brake cable bracket bolt |
| 9 | W714033 | Rear shock lower bolt (2 required) |
| 10 | W500748 | Rear shock lower nut (2 required) |
| 11 | 2A635 RH/2A808 LH | Parking brake rear cable assembly |
| 12 | W790063 | Driveshaft bolt (6 required) |
PART NUMBER REFERENCE
Scheme 20
Scheme 21
Scheme 22
Scheme 23
Scheme 24
Scheme 25
Scheme 26
Scheme 27
- Measure and record the vehicle ride height. For additional information, refer to «SUSPENSION SYSTEM - GENERAL INFORMATION»(ref-375991) .
- Remove the rear wheels. For additional information, refer to «WHEELS AND TIRES»(ref-375990) .
- With a wax pencil, mark the relational alignment of the rear subframe to the underbody at the mounting locations.
- Remove and discard the 6 driveshaft bolts and position the driveshaft aside. To install, tighten the new bolts to 25 Nm (18 lb-ft).
- Remove and discard the sway bar link upper nuts and reposition the sway bar.
- Remove the rear shock lower bolts. To install, tighten to 175 Nm (125 lb-ft).
- Disconnect the main subframe electrical connector.
- Remove the intermediate parking brake cable bracket bolt from the frame. To install, tighten to 12 Nm (106 lb-in).
- Disconnect the intermediate parking brake cable from the front park brake cable.
- Remove the rear park brake cable bracket and reposition.
- Remove the wheel opening park brake cable bracket bolt and reposition the bracket.
- Remove the park brake cable from the caliper.
- Remove the rear brake caliper bolts. To install, tighten to 103 Nm (76 lb-ft).
- Remove the rear calipers and position aside. Attach to the body using mechanic's wire.
- Remove the 4 rear subframe bracket bolts. Discard the bolts. To install, tighten the new bolts to 55 Nm (41 lb-ft).
- Position the Powertrain Lift Table under the subframe.
- Remove and discard the 2 front bolts of the rear subframe. To install, tighten the new bolts to 200 Nm (148 lb-ft).
- Remove and discard the 2 rear bolts of the rear subframe. To install, tighten the new bolts to 200 Nm (148 lb-ft).
- To install, reverse removal procedure.
SPECIAL TOOL SPECIFICATION Remover/Installer, Rear Drive Unit (RDU) Bushing (65 mm) 204-618 Remover/Installer, Rear Drive Unit (RDU) Bushing (70 mm) 204-616
Scheme 28
| Item | Part Number | Description |
|---|---|---|
| 1 | 4B425AA | Rear Drive Unit (RDU) bushing - rear bushings |
| 2 | 5N354 | Rear subframe |
PART NUMBER REFERENCE
SPECIAL TOOL SPECIFICATION Remover/Installer, Rear Drive Unit (RDU) Bushing (65 mm) 204-618 Remover/Installer, Rear Drive Unit (RDU) Bushing (70 mm) 204-616
Scheme 29
| Item | Part Number | Description |
|---|---|---|
| 1 | 4B424A | Rear Drive Unit (RDU) bushing front bushings (2 required) |
| 2 | 5N354 | Rear subframe |
PART NUMBER REFERENCE
