Engine Cooling System: Specifications Lincoln MKS I

Cooling System (Mechanical) 1 illustration ~395 words

GENERAL SPECIFICATIONS

ItemSpecification
Pressure Tests
Complete cooling system maximum pressure96 kPa (14 psi)
Pressure relief cap96 kPa (14 psi)
Radiator (out of vehicle)138 kPa (20 psi)
Thermostat Opening Temperatures
Starts to open82°C (180°F)
Fully open95°C (203°F)

GENERAL SPECIFICATIONS

TORQUE SPECIFICATIONS

DescriptionNmLb-ftLb-in
A/C condenser-to-Charge Air Cooler (CAC) bolts653
A/C condenser-to-radiator bolts653
Block heater4030
CAC adapter bolts871
CAC outlet pipe clamps544
CAC-to-radiator bolts653
CAC tube clamps544
Coolant pump bolts (1)
Coolant tube banjo bolts4030
Coolant tube bracket nut1089
Cooling fan motor and shroud bolts653
Degas bottle bolts980
Engine oil filter (2)
Oil pan drain plug2720
Primary timing chain guide bolts1089
Primary timing chain tensioner bolts1089
RH cylinder head ground wire bolt1089
Thermostat housing bolts1089
Thermostat housing cover bolts1089
Transaxle shift cable bracket bolts12106
Variable Camshaft Timing (VCT) oil control solenoid housing bolts (1)
(1) Refer to the appropriate procedure(s). (2) Tighten to 5 Nm (44 lb-in) plus an additional 180 degrees.
(1)Refer to the appropriate procedure(s).
(2)Tighten to 5 Nm (44 lb-in) plus an additional 180 degrees.

TORQUE SPECIFICATIONS

Note. The engine cooling system is filled with Motorcraft® Specialty Green Engine Coolant. Mixing coolant types degrades the corrosion protection of Motorcraft® Specialty Green Engine coolant.

Note. Genuine Mazda® Extended Life Coolant and Motorcraft® Specialty Green Engine Coolant are very sensitive to light. Do NOT allow these products to be exposed to ANY LIGHT for more than a day or two. Extended light exposure causes these products to degrade.

Note. Stop-leak style pellets/products must not be used as an additive in this engine cooling system. The addition of stop-leak style pellets/products can clog or damage the cooling system, resulting in degraded cooling system performance and/or failure.

The cooling system components are the

Scheme 1

Scheme 1: Engine Cooling
  1. block heater (if equipped).
  2. radiator.
  3. bypass tube.
  4. turbocharger coolant tubes.
  5. pressure relief cap.
  6. degas bottle.
  7. radiator draincock.
  8. coolant pump.
  9. Engine Coolant Temperature (ECT) indicator unit.
  10. thermostat (cold side).
  11. variable speed fan motor assembly.
  12. fan control module.
  13. engine block coolant weep hole.

The coolant pump is located under the engine front cover mounted to the block. A weep hole is provided on the front left side of the engine behind the generator. It is adjacent to a 13.5 mm (0.531 in) cup plug. This plug and weep hole create a reservoir for normal coolant seepage and evaporation. Every coolant pump will have some leakage past the dynamic mechanical seal. Dampness and crusting around the weep hole is acceptable and an expected result of normal engine operation. Coolant spray or leakage amounts great enough to puddle should be addressed.

Engine coolant provides freeze protection, boil protection, cooling efficiency and corrosion protection to the engine and cooling components. In order to obtain these protections, the engine coolant must be maintained at the correct concentration and fluid level in the degas bottle.

When adding engine coolant, use a 50/50 mixture of engine coolant and distilled water.

To maintain the integrity of the coolant and the cooling system

  1. add Motorcraft® Specialty Green Engine Coolant.
  2. do not add/mix different coolant types. Mixing coolants may degrade the coolant's corrosion protection.
  3. do not add alcohol, methanol or brine, or any engine coolants mixed with alcohol or methanol antifreeze. These can cause engine damage from overheating or freezing.
  4. Ford Motor Company does NOT recommend the use of recycled engine coolant in vehicles.
