TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | |
|---|---|---|
| Inboard Shoulder Screw | 15-31 (20-43) | |
| Latch-To-Seat Back Screw | 17-23 (23-31) | |
| Latch-To-Seat Cusion Screw | 33-44 (45-60) | |
| Safetly Belt Bolts | 23-31 (30-43) | |
| Safety Belt Buckle-To-Track Bolt | 23-31 (31-42) | |
| Seat Cushion Screw-Inboard | 15-19 (20-26) | |
| Seat Track Rear Nuts | 9-17 (12-23) | |
| Seat Track Rear Studs | 9-17 (12-23) | |
| Seat Track Front Bolts | 9-17 (12-23 | |
| Seat Assembly Bolts | 23-31 (30-43) | |
| Seat Track-To-Seat Screws | 9-17 (12-23) | |
| INCH Lbs. (N.m) | ||
| Motor & Transmission-To-Latch/Recliner Screws | 8-15 (.9-1.7) | |
| Cover Plate-To-Motor & Transmission Assembly Screws | 8-15 (.9-1.7) | |
| Safety Belt Buckle-To-Seat Bolt | 62-88 (7-10) | |
| Seat Shield-To-Track Nut | 62-88 (7-10) | |
TORQUE SPECIFICATIONS
