Vehicle Check/Preparation

Before using the scan tool to perform any test, refer to any important Safety Notices and the necessary visual checks listed below.

Visual Checks

1. Inspect the air cleaner and inlet duct.
2. Check all engine vacuum hoses for damage, leaks, cracks, kinks and proper routing.
3. Check Electronic EC system wiring harness for proper connections, bent or broken pins, corrosion, loose wires and proper routing.
4. Check the powertrain control module (PCM), sensors, and actuators for physical damage.
5. Check the engine coolant for proper level and mixture.
6. Check the transmission fluid level and quality.
7. Make all necessary repairs before continuing with Quick Test.

Vehicle Preparation

1. Perform ALL safety steps required to start and run vehicle tests. Apply parking brake, place shift lever firmly into PARK position (NEUTRAL on manual transmission) and block drive wheels.
2. Turn off ALL electrical loads: radios, lamps, A/C, blower, and fans.
3. Start engine and bring up to normal operating temperature before running Quick Test.

Generic OBD II PID List

GENERIC OBD II PID LIST

Ford PID List

FORD PID LIST

Making Changes to the VID Block

A PCM which is programmed may require changes to be made to certain VID information to accommodate vehicle hardware. Refer to PCM/Module Reprogramming on the Scan Tool.

Drive Cycle Recommendations

1. Most OBDII monitors will complete more readily using a "steady foot" driving style during cruise or acceleration modes. Operating the throttle in a "smooth" fashion will minimize the time required for monitor completion.
2. Fuel tank level should be between 1/2 and 3/4 fill with 3/4 fill being the most desirable.
3. The Evaporative Monitor can only operate during the first 30 minutes of engine operation. When executing the procedure for this monitor, stay in part throttle mode and drive in a smooth fashion to minimize "fuel slosh".

For best result, follow each of the following steps as accurately as possible

Recreating the Fault

Recreating the fault is the first step in isolating the cause of the intermittent symptom. A thorough investigation should start with the customer information worksheet located in the Introduction. If Freeze Frame Data is available, it may help in recreating the conditions at the time of a Malfunction Indicator Lamp Diagnostic Trouble Code (MIL DTC). Listed below are some of the conditions for recreating the fault

Accumulating PCM Data

PCM data can be accumulated in a number of ways. This includes circuit measurements with a DVOM or scan tool PID data. Acquisition of PCM PID data using a scan tool is one of the easiest ways to gather information. Gather as much data as possible when the fault is occurring to prevent improper diagnosis. Data should be accumulated during different operating conditions and based on the customer description of the intermittent fault. Compare this data with the known good data values located in REFERENCE VALUES - CNG, FLEX-FUEL & GASOLINE in the Typical Diagnostic Reference Values. This will require recording data in four conditions for comparison: 1) KOEO, 2) HOT IDLE, 3) 48 km/h (30 mph), and 4) 89 km/h (55 mph).

Analyzing Data From Playback of Stored PIDs

Look for abnormal events or values that are clearly incorrect. Inspect the signals for abrupt or unexpected changes. For example, during a steady cruise most of the sensor values should be relatively stable. Sensors such as TP, MAF and RPM that change abruptly when the vehicle is traveling at a constant speed are clues to a possible fault area.

Look for agreement in related signals. For example, if TP is changed during acceleration, a corresponding change should occur in IAC, RPM and SPARK ADV PID.

Make sure the signals act in proper sequence. An increase in rpm after the TP is increased is expected. However, if rpm increases without a TP change, then a fault may exist.

Table Format (Scheme 141): Scroll through the PID data while analyzing the information. Look for sudden drops or spikes in the values. (Refer to the following TP example in (Scheme 141) ). Notice the major jump in the TP voltage while scrolling through the information. This example would require a smooth and progressive accelerator pedal travel during a key on and engine off mode.

Graph Format (Scheme 142): Scroll through the PID data while analyzing the information. Look for sudden drops or spikes in the linear lines showing the transformation of values to the line graph. This example would require smooth progressive accelerator pedal pressure with the key on and the engine off.

Scheme 141

Scheme 142

Peripheral Inputs

Some signals may require certain peripherals or auxiliary tools for diagnosis. These tools include the Auxiliary Adapter and Pressure/Vacuum Adapter. In some cases, these devices can be inserted into the measurement jacks of the scan tool or multimeter. For example, connecting an electronic fuel pressure gauge to monitor and record the fuel pressure voltage reading and capturing the data would help find the fault.

Comparing PCM Data

After the PCM values have been acquired, it is necessary to determine the fault area. Typically, it will require the comparison of the actual values from the vehicle to the typical values from the TYPICAL DIAGNOSTIC REFERENCE VALUES . The charts apply to different vehicle applications (i.e., model, engine, transmission, etc.).

Obtain Freeze Frame Data

Freeze Frame Data can be helpful in duplicating and diagnosing adaptive fuel concerns. This data (a snapshot of certain PID values, recorded at the time the DTC was stored in Continuous Memory) is helpful to determine how the vehicle was being driven when the fault occurred, and can be especially useful on intermittent concerns. Freeze Frame Data, in many cases, can help to isolate possible areas of concern as well as rule out others. Refer to FREEZE FRAME DATA for a more detailed description of this data.

Using the LONGFT1 and LONGFT2 (dual bank engines) PIDs

The LONGFT1/2 PIDs can be useful for diagnosing fuel trim concerns. A negative PID value indicates that fuel is being reduced to compensate for a rich condition, while a positive PID value indicates that fuel is being increased to compensate for a lean condition. It is important to know that there is a separate LONGFT value that is used for each rpm/load point of engine operation. When viewing the LONGFT1/2 PIDs, the values may change a great deal as the engine is operated at different rpm and load points. This is because the fuel system may have learned corrections for fuel delivery concerns that can change as a function of engine rpm and load. The LONGFT1/2 PIDs will display the fuel trim currently being used at that rpm and load point. Observing these changes in LONGFT1/2 can help when diagnosing fuel system concerns. For example

1. A contaminated MAF sensor would result in matching LONGFT1/2 correction values that are negative at idle (reducing fuel), but positive (adding fuel) at higher rpm and loads.
2. LONGFT1 values that differ greatly from LONGFT2 values would rule out concerns that are common for both banks (for example, fuel pressure concerns, MAF sensor, etc. could be ruled out).
3. Vacuum leaks would result in large rich corrections (positive LONGFT1/2 value) at idle, but little or no correction at higher rpm and loads.
4. A plugged fuel filter will result in no correction at idle, but large rich corrections (positive LONGFT1/2 value) at high rpm and load.

Air Measurement System

With this condition, the engine may actually run rich or lean of stoichiometry (14.7:1 air/fuel ratio) if the Powertrain Control Module (PCM) is not able to compensate enough to correct for the condition. One possibility is that the mass of air entering the engine is actually greater than what the MAF sensor is indicating to the PCM. For example, with a contaminated MAF sensor, the engine would run lean at higher rpm because the PCM would deliver fuel for less air than is actually entering the engine.

Examples: MAF sensor measurement inaccurate (corroded connector, contamination/dirty (a contaminated MAF sensor will typically result in a rich system at low airflows (PCM will reduce fuel) and a lean system at high airflows (PCM will increase fuel), etc).

Vacuum Leaks/Unmetered Air

With this condition, the engine may actually run lean of stoichiometry (14.7:1 air/fuel ratio) if the Powertrain Control Module (PCM) is not able to compensate enough to correct for the condition. This condition can be caused by unmetered air entering the engine, or due to a MAF malfunction. In this situation, the volume of air entering the engine is actually greater than what the MAF sensor is indicating to the PCM. Vacuum leaks will normally be most apparent when high manifold vacuum is present (for example, during idle or light throttle). If freeze frame data indicates that the fault occurred at idle, a check for vacuum leaks/unmetered air might be the best starting point.

Examples: Loose, leaking or disconnected vacuum lines, intake manifold gaskets or o-rings, throttle body gaskets, brake booster, air inlet tube, stuck/frozen/aftermarket PCV valve, unseated engine oil dipstick, etc.

Insufficient Fueling

With this condition, the engine may actually run lean of stoichiometry (14.7:1 air/fuel ratio) if the PCM is not able to compensate enough to correct for the condition. This condition can be caused by a fuel delivery system concern that restricts or limits the amount of fuel being delivered to the engine. This condition will normally be most apparent when the engine is under a heavy load and at high rpm, when a higher volume of fuel is required. If freeze frame data indicates that the fault occurred under a heavy load and at higher rpm, a check of the fuel delivery system (checking fuel pressure with engine under a load) might be the best starting point.

Examples: low fuel pressure (fuel pump, fuel filter, fuel leaks, restricted fuel supply lines), fuel injector concerns, etc.

Exhaust System Leaks

In this type of condition, the engine may actually be running rich of stoichiometry (14.7:1 air / fuel ratio) because the fuel control system is adding fuel to compensate for a perceived (not actual) lean condition. This condition is caused by oxygen (air) entering the exhaust system from an external source. The HO2S will react to this exhaust leak by increasing fuel delivery. This condition will cause the exhaust gas mixture from the cylinder to be rich.

Examples: Exhaust system leaks upstream or near HO2S, poorly welded/leaking HO2S boss, malfunctioning Secondary Air Injection system, etc.

With this condition, the engine may actually run rich or lean of stoichiometry (14.7:1 air/fuel ratio) if the Powertrain Control Module (PCM) is not able to compensate enough to correct for the condition. One possibility is that the mass of air entering the engine is actually less than what the MAF sensor is indicating to the PCM. For example, with a contaminated MAF sensor, the engine would run rich at idle because the PCM would deliver fuel for more air than is actually entering the engine.

Examples: MAF sensor measurement inaccurate (corroded connector, contamination/dirty (a contaminated MAF sensor will typically result in a rich system at low airflows (PCM will reduce fuel) and a lean system at high airflows (PCM will increase fuel), etc.).

Fuel System

With this condition, the engine may actually run rich of stoichiometry (14.7:1 air/fuel ratio) if the Powertrain Control Module (PCM) is not able to compensate enough to correct for the condition. This situation can be caused by a fuel delivery system that is delivering excessive fuel to the engine.

Examples

1. Fuel pressure regulator causes excessive fuel pressure (system rich at all airflows)(fuel pressure can be intermittent, going to pump deadhead pressure, then returning to normal after engine is turned off then restarted).
2. Fuel pressure regulator vacuum hose off (causes excessive fuel pressure at idle, system rich at idle airflows).
3. Fuel pressure regulator diaphragm ruptured (fuel leaking into intake manifold, system rich at lower airflows).
4. Fuel return line crimped/damaged (fuel pressure high, system rich at lower airflows).
5. Fuel injector leaks (injector delivers extra fuel).
6. EVAP canister purge valve leak (if canister is full of vapors, introduces extra fuel).
7. Fuel rail pressure sensor (electronic returnless fuel systems) concern causes sensor to indicate lower pressure than actual. PCM commands higher pressure to the fuel pump driver module (FPDM), causing high fuel pressure (system rich at all airflows).

Base Engine

Engine oil contaminated with fuel can contribute to a rich running engine.

Open Circuit (Continuity)

Disconnect PCM. Measure the harness resistance between the suspect circuit at the harness connector and the appropriate PCM harness connector pin or PCM breakout box (if available). The resistance must be less than 5.0 ohms.

Shorts to Ground

Measure the harness resistance between the suspect circuit at the harness connector and a reliable ground (B-, chassis gnd or PWR GND at the PCM breakout box, if available). The resistance must be greater than 10,000 ohms.

Shorts to Power

Key ON to power up circuit. Measure voltage between the suspect circuit at the harness connector and a reliable ground. The voltage must be less than 1.0 volt.
