Entertainment System: Other — Entertainment System — Entertainment Systems

Possible Causes

central junction box (CJB) fuse(s): 18(20A) 27(10)
battery junction box (BJB) fuse(s): 22 (20A) 25 (40A)
standard corporate protocol (SCP) communication network
circuit 29-MD15 (OG/BK) open or short to ground
circuit 31-MD15 (BK/GN) open (DM100I)
circuit 31-MD15A (BK/GN) open (CDX6)
circuit 75-MD15 (YE/GN) open
audio unit

Scheme 19

Scheme 19: PINPOINT TEST A: NO COMMUNICATION WITH THE AUDIO UNIT-CDX6 AND DM1 00i ONLY

Scheme 20

A1 CHECK THE VOLTAGE TO THE AUDIO UNIT Key in OFF position. Disconnect: Audio Unit C290b. Key in ON position. Measure the voltage between the audio unit C290b-1, circuit 29-MD15 (OG/BK), harness side and ground; and between the audio unit C290b-2, circuit 75-MD15 (YE/GN), harness side and ground. Are the voltages greater than 10 volts? Yes : GO to A2. No : REPAIR the circuit in question. REPEAT the data link diagnostic test.
A2 CHECK THE GROUND TO THE AUDIO UNIT Key in OFF position. Measure the resistance between the audio unit C290b-13, circuit 31 -MD15 (BK/GN), harness side and ground. Is the resistance less than 5 ohms? Yes : REFER to «MODULE COMMUNICATIONS NETWORK»(ref-207567) to continue diagnosis of the audio unit. No : REPAIR the circuit in question. REPEAT the data link diagnostic test.

central junction box (CJB) fuse(s): 2(5A) 18(20A) 27(10A)
circuit 10-MD15 (GY/OG) open or short to ground (navigation audio unit)
circuit 29-MD15 (OG/BK) open or short to ground
circuit 31-MD15A, (BK/GN) open
circuit 50-MD15 (GY/OG) short to power
circuit 75-MD15 (YE/GN) open or short to ground
audio unit

Scheme 21

Scheme 21: PINPOINT TEST B: THE AUDIO UNIT IS INOPERATIVE/DOES NOT OPERATE CORRECTLY

Scheme 22

Scheme 23

Scheme 24

B1 CHECK OPERATION OF THE AUDIO UNIT Key in ON position. Turn on the audio unit. Is the audio unit display illuminated? Yes : GO to B2. No : For navigation audio unit GO to B4 , all others GO to B5.
B2 CHECK FOR SOUND COMING FROM THE SPEAKERS Carry out the speaker walk-around test. Check for sound from the speakers. Is sound coming from the speakers? Yes : GO to B3. No : For navigation audio unit, Go To «PINPOINT TEST E: POOR QUALITY/DISTORTED SOUND OR NO SOUND FROM ONE OR MORE SPEAKERS (NOT ALL SPEAKERS)-NAVIGATION AUDIO UNIT ONLY»(ref-207564-S33132346572005113000000) . All others, Go To «PINPOINT TEST D: POOR QUALITY/DISTORTED SOUND OR NO SOUND FROM ONE OR MORE SPEAKERS (NOT ALL SPEAKERS)-EXCEPT NAVIGATION AUDIO UNIT»(ref-207564-S06718429052005113000000) .
B3 CARRY OUT CONTROLS AND FEATURES TEST Verify that all the audio system controls and features operate correctly; refer to the owner literature. Do all the controls and features operate correctly? Yes : The system is OK. No : REMOVE the audio unit and SEND it to an authorized audio system repair facility. REFER to «AUDIO UNIT»(ref-207564-S25479398902005113000000) . TEST the system for normal operation.
B4 VERIFY THE OPERATION OF THE POWER WINDOWS Verify that all the power windows and the roof opening panel operate correctly; refer to the owner literature. Do all the power windows and roof opening panel operate correctly? Yes : GO to B5. No : For power windows, REFER to «EXTERIOR TRIM»(ref-207571) . For roof opening panel, REFER to «INTERIOR TRIM»(ref-207570) .
B5 CHECK THE VOLTAGE TO THE AUDIO UNIT Key in OFF position. Disconnect: Audio Unit C290b (DM1 00i) (CDX6). Disconnect: Audio Unit C2253a (navigation audio unit). Key in ON position. Measure the voltage between the audio unit and ground as follows: CONNECTOR-PIN REFERENCE Audio Unit Connector-Pin Circuit CDX6 C290b-1 29-MD15 (OG/BK) CDX6 C290b-2 75-MD15(YE/GN) DM1 00i C290b-1 29-MD15 (OG/YE) DM1 00i C290b-2 75-MD15(YE/GN) navigation audio unit C2253a-1 29-MD15(OG/BK) navigation audio unit C2253a-2 10-MD15(GY/OG) Are the voltages greater than 10 volts? Yes : GO to B6. No : REPAIR the circuit in question. TEST the system for normal operation.
B6 CHECK THE GROUND TO THE AUDIO UNIT Key in OFF position. Measure the resistance between the audio unit (CDX6) (DM1 00i) C290b-13, circuit 31-MD15 (BK/GN), harness side and ground. Measure the resistance between the audio unit (navigation audio unit) C2253a-13, circuit 31-MD15B (BK/GN), harness side and ground; and between the audio unit C2253a-24, circuit 31-MD15A (BK/GN), harness side and ground. Are the resistances less than 5 ohms? Yes : GO to B7. No : REPAIR the circuit in question. TEST the system for normal operation.
B7 CHECK CIRCUIT 50-MD15 (GY/OG) FOR SHORT TO POWER WITH IGNITION IN ACC POSITION Key in ACCESSORY position. Measure the voltage between audio unit (CDX6) (DM1 00i) C290b-15, or navigation audio unit C2253a-15, circuit 50-MD15 (GY/OG), harness side and ground. Is any voltage present? Yes : REPAIR the circuit. TEST the system for normal operation. No : REMOVE the audio unit and SEND it to an authorized audio system repair facility. REFER to «AUDIO UNIT»(ref-207564-S25479398902005113000000) . TEST the system for normal operation.

antenna
antenna connections
noise suppression equipment
antenna isolator module
audio unit

Note. It is normal for an audible popping sound to be heard when turning the defroster on or off. Advise the customer of the condition.

Scheme 25

Scheme 25: PINPOINT TEST C: POOR RECEPTION

C1 CHECK THE AUDIO UNIT SIGNAL RECEPTION Check the audio unit signal reception with both the engine running and with the engine off. Is the audio unit signal reception noisy only with the engine running? Yes : GO to C2. No : GO to C8 .
C2 CHECK SUPPRESSION EQUIPMENT Check all required suppression equipment, radio frequency interference suppression bond, and the hood bonding strap for security, cleanliness, and metal-to-metal contact. Are the contacts clean, secure, and in metal-to-metal contact? Yes : GO to C3. No : INSTALL new radio frequency interference suppression bonds or related equipment. CLEAN or SECURE the connections as necessary. TEST the system for normal operation.
C3 CHECK THE CAPACITOR MOUNTING AND CONNECTING CIRCUITS NOTE: The capacitor mounting points are used to complete the electrical circuit and must be mounted securely to clean surfaces. Check the mounting and connecting circuits of the radio ignition interference capacitor(s) for security, cleanliness, and metal-to-metal contact. Refer to «ANTENNA»(ref-207564-S34594615802005113000000) . Are the contacts clean, secure, and in metal-to-metal contact? Yes : GO to C4. No : CLEAN or SECURE the connections as necessary. TEST the system for normal operation.
C4 CHECK THE RADIO IGNITION INTERFERENCE CAPACITOR(S) AND THE GENERATOR Check the operation of the radio ignition interference capacitor(s) by installing known good component(s). Check the generator by disconnecting the wiring harness from the voltage regulator. Key in START position. Check the operation of the audio unit. Is the noise eliminated? Yes : REPAIR or INSTALL new components as necessary. TEST the system for normal operation. No : GO to C5.
C5 CHECK THE IGNITION CIRCUITS Key in OFF position. Check the ignition circuits for correct routing, grounding, and security of connections. Are the circuits OK? Yes : GO to C6. No : REPAIR the circuit as necessary. TEST the system for normal operation.
C6 CHECK THE IGNITION SYSTEM Test the ignition system; refer to «INTAKE AIR, FUEL CHARGING, STARTING & ENGINE ELECTRONICS - 3.0L (4V) - LS»(ref-207555) (3.0L 4V) or «INTAKE AIR, FUEL CHARGING, STARTING & ENGINE ELECTRONICS - 3.9L - LS»(ref-207556) (3.9L). Is the ignition system OK? Yes : GO to C7. No : REPAIR the ignition system. REFER to «INTAKE AIR, FUEL CHARGING, STARTING & ENGINE ELECTRONICS - 3.0L (4V) - LS»(ref-207555) (3.0L 4V) or «INTAKE AIR, FUEL CHARGING, STARTING & ENGINE ELECTRONICS - 3.9L - LS»(ref-207556) (3.9L). TEST the system for normal operation.
C7 SUBSTITUTE THE AUDIO UNIT Key in OFF position. Substitute a known good audio unit. Key in START position. Check the operation of the audio unit. Is the noise eliminated? Yes : REMOVE the audio unit and SEND it to an authorized audio system repair facility. REFER to «AUDIO UNIT»(ref-207564-S25479398902005113000000) . TEST the system for normal operation. No : REINSTALL the original audio unit. USE a jumper cable to ground various parts of the vehicle to the frame (for example: engine, fenders, quarter panels, stone deflectors, air cleaner, body sheet metal). When the noise is eliminated, PROVIDE a permanent ground where necessary. TEST the system for normal operation.
C8 CHECK THE ANTENNA FOR DAMAGE Key in OFF position. Disconnect: Antenna Lead Terminal. Measure the resistance between the antenna cable lead terminal and the end of the antenna grid wire. Is the resistance less than 8 ohms? Yes : GO to C9. No : REPAIR the antenna. REFER to «ANTENNA»(ref-207564-S34594615802005113000000) .
C9 CHECK VOLTAGE TO ANTENNA ISOLATOR MODULE Disconnect: Antenna Isolator Module C4194. Key in ON position. Measure the voltage between the antenna isolator module C4194, circuit 29S-MD7 (OG/BU), harness side and ground. Is the voltage greater than 10 volts? Yes : GO to C10. No : REPAIR the circuit. TEST the system for normal operation.
C10 SUBSTITUTE ANTENNA ISOLATOR MODULE Key in OFF position. Substitute a known good antenna isolator module. Key in START position. Check the operation of the audio unit. Is the noise eliminated? Yes : INSTALL a new antenna isolator module. REFER to «ANTENNA»(ref-207564-S34594615802005113000000) . TEST the system for normal operation. No : GO to C11.
C11 SUBSTITUTE ANTENNA EXTENSION CABLE(S) Key in OFF position. Substitute a known good antenna cable(s) between the antenna isolator module and the audio unit. Key in START position. Check the operation of the audio unit. Is the noise eliminated? Yes : INSTALL a new antenna cable. REFER to «ANTENNA»(ref-207564-S34594615802005113000000) . TEST the system for normal operation. No : REINSTALL the original antenna cable. REMOVE the audio unit and SEND it to an authorized audio system repair facility. REFER to «AUDIO UNIT»(ref-207564-S25479398902005113000000) . TEST the system for normal operation.

central junction box (CJB) fuse 18 (20A)
battery junction box (BJB) fuse 25 (40A)
center imaging amplifier
speakers
audio unit
high resistance or short to ground in speaker circuits

Scheme 26

Scheme 26: PINPOINT TEST D: POOR QUALITY/DISTORTED SOUND OR NO SOUND FROM ONE OR MORE SPEAKERS (NOT ALL SPEAKER

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

D1 CHECK FOR SOUND Key in ON position. Turn on the audio unit. Carry out the speaker walk-around test. Do all speakers have poor quality/distorted sound or no sound? Yes : REMOVE the audio unit and SEND it to an authorized audio system repair facility. REFER to «AUDIO UNIT»(ref-207564-S25479398902005113000000) . TEST the system for normal operation. No : If the concern is with a center imaging speaker GO to D4 , all others GO to D2.
D2 CHECK FOR AN AUDIO SIGNAL OUTPUT TO THE SPEAKER WITH POOR QUALITY/DISTORTED SOUND OR NO SOUND Key in OFF position. Disconnect: Speaker(s) with poor quality/distorted sound or no sound. Key in ON position. Turn on the audio unit. Measure the voltage between pin 1 and pin 2 of the speaker with poor quality/distorted sound or no sound. Is there a fluctuating AC voltage? Yes : INSTALL a new speaker. REFER to «DOOR SPEAKER»(ref-207564-S14384138282005113000000) . TEST the system for normal operation. No : GO to D3.
D3 CHECK THE CIRCUITS BETWEEN THE SPEAKER(S) AND THE AUDIO UNIT FOR OPENS AND SHORTS TO GROUND Key in OFF position. Disconnect: Audio Unit C290b. Disconnect: Inoperative Audio Speaker(s). Measure the resistance between the speaker with poor quality/distorted sound and the audio unit, and between the audio unit and ground as follows: SPEAKER PIN REFERENCE Speaker Speaker Pin Audio Unit Pin Circuit LF C523 1 8 8-MD10 (WH/BK) LF C523 2 21 10-MD10 (GY/BK) RFC612 1 11 8-MD17 (WH/RD) RFC612 2 12 10-MD17 (GY/RD) LR C702 1 9 8-MD11 (WH/VT) LR C702 2 22 10-MD11 (GY/WH) RR C802 1 10 8-MD18 (WH) RR C802 2 23 10-MD18 (GY) Are the resistance(s) less than 5 ohms between the speaker connector(s) and the audio unit, and greater than 10,000 ohms between the audio unit connector and ground? Yes : REMOVE the audio unit and SEND it to an authorized audio system repair facility. REFER to «AUDIO UNIT»(ref-207564-S25479398902005113000000) . TEST the system for normal operation. No : REPAIR the circuit in question. TEST the system for normal operation.
D4 CHECK THE CENTER IMAGING SPEAKER OPERATION Key in ON position. Turn the audio unit on. Check the operation of the center imaging speakers. Are both center imaging speakers inoperative? Yes : GO to D5. No : GO to D11 .
D5 CHECK CIRCUIT 7-MD12 (YE) FOR POWER Key in OFF position. Disconnect: Center Imaging Amplifier C225. Key in ON position. Turn on the audio unit. Measure the voltage between the center imaging amplifier C225-13, circuit 7-MD12 (YE), harness side and ground. Is the voltage greater than 10 volts? Yes : GO to D6. No : GO to D10 .
D6 CHECK CIRCUIT 29-MD12 (OG/YE) FOR VOLTAGE Measure the voltage between the center imaging amplifier C225-16, circuit 29-MD12 (OG/YE), harness side and ground. Is the voltage greater than 10 volts? Yes : GO to D7. No : REPAIR the circuit. TEST the system for normal operation.
D7 CHECK GROUND CIRCUIT 31-MD12 (BK/YE) FOR OPEN Key in OFF position. Measure the resistance between the center imaging amplifier C225-15, circuit 31-MD12 (BK/YE), harness side and ground. Is the resistance less than 5 ohms? Yes : GO to D8. No : REPAIR the circuit. TEST the system for normal operation.
D8 CHECK FOR AN AUDIO SIGNAL OUTPUT TO THE AMPLIFIER Measure the voltage between the center imaging amplifier C225-1, circuit 1-MD12 (WH), harness side and the center imaging amplifier C225-2, circuit 2-MD12 (GY), harness side. Is there a fluctuating AC voltage? Yes : INSTALL a new center imaging amplifier. REFER to «AUDIO UNIT AMPLIFIER - CENTER IMAGING»(ref-207564-S38557927042005113000000) . TEST the system for normal operation. No : GO to D9.
D9 CHECK THE CIRCUITS BETWEEN THE AUDIO UNIT AND THE CENTER IMAGING AMPLIFIER FOR OPENS OR SHORTS TO GROUND Disconnect: Audio Unit C290b. Measure the resistance between the audio unit and the center imaging amplifier C225; and between the audio unit and ground as follows: AUDIO UNIT C290A PIN REFERENCE Audio Unit C290a Pin Center Imaging Amplifier C225 Pin Circuit 6 2 2-MD12 (GY) 5 1 1-MD12 (WH) Are the resistance(s) less than 5 ohms between the audio unit and the center imaging amplifier, and greater than 10,000 ohms between the audio unit and ground? Yes : REMOVE the audio unit and SEND it to an authorized repair facility. REFER to «AUDIO UNIT»(ref-207564-S25479398902005113000000) . TEST the system for normal operation. No : REPAIR the circuit in question. TEST the system for normal operation.
D10 CHECK CIRCUIT 7-MD12 (YE) FOR OPEN AND A SHORT TO GROUND Key in OFF position. Measure the resistance between the center imaging amplifier C225-13, circuit 7-MD12 (YE), harness side and the audio unit C290a-8, circuit 7-MD12 (YE), harness side; and between the center imaging amplifier C225-13, circuit 7-MD12 (YE), harness side and ground. Is the resistance less than 5 ohms between the center imaging amplifier and the audio unit and greater than 10,000 ohms between the center imaging amplifier and ground? Yes : REMOVE the audio unit and SEND it to an authorized audio system repair facility. REFER to «AUDIO UNIT»(ref-207564-S25479398902005113000000) . TEST the system for normal operation. No : REPAIR the circuit. TEST the system for normal operation.
D11 CHECK FOR AN AUDIO SIGNAL OUTPUT TO THE INOPERATIVE CENTER IMAGING SPEAKER Disconnect: Inoperative Center Imaging Speaker. Key in ON position. For the LH center imaging speaker, measure the voltage between the center imaging speaker C230-1, circuit 8-MD30 (WH/BU), harness side and C230-2, circuit 10-MD30 (GY/VT), harness side. For the RH center imaging speaker, measure the voltage between the center imaging speaker C231-1, circuit 8-MD31 (WH/GN), harness side and C231 -2, circuit 10-MD31 (GY/OG), harness side. Is there a fluctuating AC voltage? Yes : INSTALL a new center imaging speaker. REFER to «AUDIO UNIT AMPLIFIER - CENTER IMAGING»(ref-207564-S38557927042005113000000) . TEST the system for normal operation. No GO to D12.
D12 CHECK THE AUDIO SIGNAL CIRCUITS TO THE INOPERATIVE CENTER IMAGING SPEAKER FOR OPENS AND SHORT TO GROUND Key in OFF position. Disconnect: Center Imaging Amplifier C225. Measure the resistance between the inoperative center imaging speaker and the center imaging amplifier, and between the center imaging amplifier and ground in the following groups: AMPLIFIER PIN REFERENCE Speaker Amplifier Pin Center Imaging Speaker Pin Circuit LH C230 7 1 8-MD30 (WH/BU) LH C230 8 2 10-MD30 (GY/VT) RH C231 6 1 10-MD31 (GY/OG) RH C231 5 2 8-MD31 (WH/GN) Is the resistance less than 5 ohms between the center imaging amplifier and the inoperative center imaging speaker, and greater than 10,000 ohms between the center imaging amplifier and ground? Yes : INSTALL a new center imaging amplifier. REFER to «AUDIO UNIT AMPLIFIER - CENTER IMAGING»(ref-207564-S38557927042005113000000) . TEST the system for normal operation. No : REPAIR the circuit. TEST the system for normal operation.

speaker(s)
audio unit
audio amplifier
speaker circuit(s) open or short to ground

Scheme 34

Scheme 34: PINPOINT TEST E: POOR QUALITY/DISTORTED SOUND OR NO SOUND FROM ONE OR MORE SPEAKERS (NOT ALL SPEAKER

Scheme 35

Scheme 36

E1 CHECK FOR SOUND Key in ON position. Turn on the audio unit. Carry out the speaker walk-around test. Do all four speakers have poor quality/distorted sound or no sound? Yes : GO to E6 . No : GO to E2.
E2 CHECK FOR AN AUDIO SIGNAL OUTPUT TO THE SPEAKER WITH POOR QUALITY/DISTORTED SOUND OR NO SOUND Key in OFF position. Disconnect: Speaker(s) with poor quality/distorted sound or no sound. Key in ON position. Turn on the audio unit. Measure the voltage between pin 1 and pin 2 of the speaker with poor quality/distorted sound or no sound. Is there a fluctuating AC voltage? Yes : INSTALL a new speaker. REFER to «DOOR SPEAKER»(ref-207564-S14384138282005113000000) . TEST the system for normal operation. No : GO to E3.
E3 CHECK THE CIRCUITS BETWEEN THE SPEAKER(S) AND THE AUDIO AMPLIFIER Key in OFF position. Disconnect: Audio Amplifier C4208b. Disconnect: Inoperative Audio Speaker(s). Measure the resistance between the speaker with poor quality/distorted sound and the audio amplifier C4208b, and between the audio amplifier C4208b and ground as follows: SPEAKER PIN REFERENCE Speaker Speaker Pin Audio Amplifier Pin Circuit LF C523 1 7 8-MD10 (WH/BK) LF C523 2 8 10-MD10 (GY/BK) RFC612 1 3 8-MD17 (WH/RD) RFC612 2 4 10-MD17 (GY/RD) LR C702 1 5 8-MD11 (WH/VT) LR C702 2 6 10-MD11 (GY/WH) RR C802 1 1 8-MD18 (WH) RR C802 2 2 10-MD18 (GY) Are the resistance(s) less than 5 ohms between the speaker connector(s) and the audio amplifier, and greater than 10,000 ohms between the audio amplifier connector and ground? Yes : GO to E4. No : REPAIR the circuit in question. TEST the system for normal operation.
E4 CHECK FOR AN AUDIO OUTPUT SIGNAL TO THE AUDIO AMPLIFIER Key in OFF position. Disconnect: Audio Amplifier C4208a. Key in ON position. With the audio unit on, check for a fluctuating AC voltage (at the audio amplifier) between the signal circuits corresponding to the speaker with poor quality/distorted sound or no sound as follows: AUDIO AMPLIFIER C4208A PIN REFERENCE Speaker Audio Amplifier C4208a Pin Audio Amplifier C4208a Pin LF 4 8 RF 2 6 LR 7 3 RR 1 5 Is there a fluctuating AC voltage? Yes : REMOVE the audio amplifier and SEND it to an authorized audio system repair facility. REFER to «AUDIO UNIT AMPLIFIER - NAVIGATION»(ref-207564-S26421090462005113000000) . TEST the system for normal operation. No : GO to E5.
E5 CHECK THE CIRCUITS BETWEEN THE AUDIO UNIT AND THE AUDIO AMPLIFIER Key in OFF position. Disconnect: Audio Unit C2253d. Measure the resistance between the audio unit C2253d and the audio amplifier C4208a, corresponding to the speaker that has poor quality/distorted sound or no sound, as follows: AUDIO UNIT PIN REFERENCE Speaker Audio Unit Pin Audio Amplifier Pin Circuit LF 10 4 10-MD10A (GY/BK) RF 11 2 10-MD17A (GY/RD) LR 12 3 10-MD11A (GY/WH) RR 13 1 10-MD18A (GY) LF 1 8 8-MD10A (WH/BK) RF 2 6 8-MD17A (WH/RD) LR 3 7 8-MD11A (WH/VT) RR 4 5 8-MD18A (WH) Are the resistance(s) less than 5 ohms between the audio unit and the audio amplifier, and greater than 10,000 ohms between the audio amplifier connector and ground? Yes : REMOVE the audio unit and SEND it to an authorized audio system repair facility. REFER to «AUDIO UNIT»(ref-207564-S25479398902005113000000) . TEST the system for normal operation. No : REPAIR the circuit in question. TEST the system for normal operation.
E6 CHECK FOR POWER TO THE AUDIO AMPLIFIER Key in OFF position. Disconnect: Audio Amplifier C4208b. Key in ON position. Measure the voltage between the audio amplifier C4208b-14, circuit 30-MD27A (RD/WH), C4208b-15, circuit 30-MD27B (RD/WH), C4208b-16, circuit 30-MD27C (RD/WH), harness side and ground. Is the voltage greater than 10 volts? Yes : GO to E7. No : REPAIR the circuit. TEST the system for normal operation.
E7 CHECK FOR CORRECT GROUND FOR THE AUDIO AMPLIFIER Key in OFF position. Measure the resistance between the audio amplifier C4208b-9, circuit 31-MD27A (BK/WH), C4208b-10, circuit 31-MD27B (BK/WH), C4208b-11, circuit 31-MD27C (BK/WH), harness side and ground. Is the resistance less than 5 ohms? Yes : REMOVE the audio amplifier and SEND it to an authorized audio system repair facility. REFER to «AUDIO UNIT AMPLIFIER-NAVIGATION»(ref-207564-S38557927042005113000000) . TEST the system for normal operation. No : REPAIR the circuit. TEST the system for normal operation.

subwoofer amplifier
subwoofer speaker(s)
audio unit
circuit 1-MD19 (WH/RD) open or short to ground
circuit 2-MD19 (GY/RD) open or short to ground
circuit 7-MD19 (YE/RD) open or short to ground
circuit 8-MD21 (WH/BU) open or short to ground
circuit 8-MD22 (WH/GN) open or short to ground
circuit 10-MD21 (GY/VT) open or short to ground
circuit 10-MD22 (GY/OG) open or short to ground
circuit 30-MD19A (RD/BU) open or short to ground
circuit 31-MD19 (BK/BU)open

Scheme 37

Scheme 37: PINPOINT TEST F: THE SUBWOOFER IS INOPERATIVE-CDX6 ONLY

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

F1 CHECK THE SUBWOOFER OPERATION Key in ON position. Turn the audio unit on. Check the operation of the subwoofer speakers. Are both subwoofer speakers inoperative? Yes : GO to F2. No : GO to F7 .
F2 CHECK CIRCUIT 7-MD19 (YE/RD) FOR POWER Key in OFF position. Disconnect: Subwoofer Amplifier C466a. Key in ON position. Turn on the audio unit. Measure the voltage between the subwoofer amplifier C466a-1, circuit 7-MD19 (YE/RD), harness side and ground. Is the voltage greater than 10 volts? Yes : GO to F3. No : GO to F9 .
F3 CHECK CIRCUIT 30-MD19A (RD/BU) FOR VOLTAGE Measure the voltage between the subwoofer amplifier C466a-5, circuit 30-MD19A (RD/BU), harness side and ground. Is the voltage greater than 10 volts? Yes : GO to F4. No : REPAIR the circuit. TEST the system for normal operation.
F4 CHECK GROUND CIRCUIT 31-MD19 (BK/BU) Key in OFF position. Measure the resistance between the subwoofer amplifier C466a-2, circuit 31-MD19 (BK/BU), harness side and ground. Is the resistance less than 5 ohms? Yes : GO to F5. No : REPAIR the circuit. TEST the system for normal operation.
F5 CHECK CIRCUIT 1-MD19 (WH/RD) FOR AN OPEN OR A SHORT TO GROUND Disconnect: Audio Unit C290a. Measure the resistance between the subwoofer amplifier C466a-7, circuit 1-MD19 (WH/RD), harness side and the audio unit C290a -1, circuit 1-MD19 (WH/RD), harness side; and between the subwoofer amplifier C466-7, circuit 1-MD19 (WH/RD), harness side and ground. Is the resistance less than 5 ohms between the subwoofer amplifier and the audio unit, and greater than 10,000 ohms between the subwoofer amplifier and ground? Yes : GO to F6. No : REPAIR the circuit. TEST the system for normal operation.
F6 CHECK CIRCUIT 2-MD19 (GY/RD) FOR AN OPEN OR A SHORT TO GROUND Measure the resistance between the subwoofer amplifier C466a-8, circuit 2-MD19 (GY/RD), harness side and the audio unit C290a-2, circuit 2-MD19 (GY/RD), harness side; and between the subwoofer amplifier C466-8, circuit 2-MD19 (GY/RD), harness side and ground. Is the resistance less than 5 ohms between the subwoofer amplifier and the audio unit, and greater than 10,000 ohms between the subwoofer amplifier and ground? Yes : GO to F10 . No : REPAIR the circuit. TEST the system for normal operation.
F7 CHECK SUBWOOFER SPEAKER CIRCUITS Key in OFF position. Disconnect: Subwoofer Speakers. Disconnect: Subwoofer Amplifier C466b. Measure the resistance between the subwoofer amplifier output and return circuits; and between each subwoofer amplifier pin and ground as follows: SPEAKER OUTPUT Speaker Output + Output - Left Subwoofer C466b-3, circuit 8-MD22 (WH/GN) C466b-4, circuit 10-MD22 (GY/OG) Right Subwoofer C466b-1, circuit 8-MD21 (WH/BU) C466b-2, circuit 10-MD21 (GY/VT) Is the resistance approximately 5 ohms between the subwoofer amplifier and the speakers and greater than 10,000 ohms between the subwoofer amplifier and ground? Yes : GO to F8. No : REPAIR the circuit between the subwoofer amplifier and the inoperative subwoofer speaker. TEST the system for normal operation.
F8 CHECK SUBWOOFER SPEAKER Substitute the inoperative subwoofer speaker with a known good subwoofer speaker. Key in ON position. Check the operation of the subwoofer speakers. Does the known good subwoofer speaker operate correctly? Yes : INSTALL a new subwoofer speaker. REFER to «SUBWOOFER SPEAKER»(ref-207564-S23623385572005113000000) . TEST the system for normal operation. No : REMOVE the subwoofer amplifier and SEND it to an authorized audio system repair facility. REFER to «SUBWOOFER AMPLIFIER»(ref-207564-S18117287212005113000000) . TEST the system for normal operation.
F9 CHECK CIRCUIT 7-MD19 (YE/RD) FOR OPEN OR A SHORT TO GROUND Disconnect: Audio Unit C290a. Measure the resistance between the subwoofer amplifier C466b-1, circuit 7-MD19 (YE/RD), harness side and the audio unit C290a-4, circuit 7-MD19 (YE/RD), harness side. Measure the resistance between the subwoofer amplifier C466b-1, circuit 7-MD19 (YE/RD), harness side and ground. Is the resistance less than 5 ohms between the subwoofer amplifier and the audio unit and greater than 10,000 ohms between the audio unit and ground? Yes : REMOVE the audio unit and SEND it to an authorized audio system repair facility. REFER to «AUDIO UNIT»(ref-207564-S25479398902005113000000) . TEST the system for normal operation. No : REPAIR the circuit. TEST the system for normal operation.
F10 CHECK FOR SUBWOOFER SIGNAL AUDIO Connect: Audio Unit. Measure the AC voltage between the subwoofer amplifier C466a-7, circuit 2-MD19 (GY/RD), harness side and the audio unit C466a-8, circuit 1-MD19 (WH/RD), harness side. Is there a fluctuating AC voltage? Yes : REMOVE the subwoofer amplifier and SEND it to an authorized audio system repair facility. REFER to «SUBWOOFER AMPLIFIER»(ref-207564-S18117287212005113000000) . TEST the system for normal operation. No : REMOVE the audio unit and SEND it to an authorized audio system repair facility. REFER to «AUDIO UNIT»(ref-207564-S25479398902005113000000) . TEST the system for normal operation.

subwoofer amplifier
subwoofer speaker(s)
audio unit
circuit 1-MD19 (WH/RD) open or short to ground
circuit 2-MD19 (GY/RD) open or short to ground
circuit 7-MD19 (YE/RD) open or short to ground
circuit 7-MD27 (YE/VT) open or short to ground
circuit 8-MD21 (WH/BU) open or short to ground
circuit 8-MD22 (WH/GN) open or short to ground
circuit 10-MD21 (GY/VT) open or short to ground
circuit 10-MD22 (GY/OG) open or short to ground
circuit 30-MD19A (RD/BU) open or short to ground
circuit 31 -MD19A (BK/BU) open

Scheme 44

Scheme 44: PINPOINT TEST G: THE SUBWOOFER IS INOPERATIVE- NAVIGATION AUDIO UNIT ONLY

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

G1 CHECK THE SUBWOOFER OPERATION Key in ON position. Turn the audio unit on. Check the operation of the subwoofer speakers. Are both subwoofer speakers inoperative? Yes : GO to G2. No : GO to G9 .
G2 CHECK CIRCUIT 7-MD 19 (YE/RD) FOR POWER Key in OFF position. Disconnect: Subwoofer Amplifier C466a. Key in ON position. Turn the audio unit on. Measure the voltage between the subwoofer amplifier C466a-1, circuit 7-MD19 (YE/RD), harness side and ground. Is any voltage present? Yes : GO to G3. No : GO to G8 .
G3 CHECK CIRCUIT 30-MD19A (RD/BU) FOR VOLTAGE Measure the voltage between the subwoofer amplifier C466a-5, circuit 30-MD19A (RD/BU), harness side and ground. Is the voltage greater than 10 volts? Yes : GO to G4. No : REPAIR the circuit. TEST the system for normal operation.
G4 CHECK GROUND CIRCUIT 31-MD19A (BK/BU) FOR AN OPEN Key in OFF position. Measure the resistance between the subwoofer amplifier C466a-2, circuit 31-MD19A (BK/BU), harness side and ground. Is the resistance less than 5 ohms? Yes : GO to G5. No : REPAIR the circuit. TEST the system for normal operation.
G5 CHECK FOR AN AUDIO SIGNAL OUTPUT TO THE AMPLIFIER Measure the voltage between the subwoofer amplifier C466a-7, circuit 1-MD19 (WH/RD), harness side and the subwoofer amplifier C466a-8, circuit 2-MD19 (GY/RD), harness side. Is there a fluctuating AC voltage? Yes : REMOVE the subwoofer amplifier and SEND it to an authorized audio system repair facility. REFER to «SUBWOOFER AMPLIFIER»(ref-207564-S18117287212005113000000) . TEST the system for normal operation. No : GO to G6.
G6 CHECK CIRCUIT 1-MD19 (WH/RD) Disconnect: Audio Unit C2253d. Measure the resistance between the subwoofer amplifier C466a-7, circuit 1-MD19 (WH/RD), harness side and the audio unit C2253d-7, circuit 1-MD19 (WH/RD), harness side; and between the subwoofer amplifier C466a-7, circuit 1-MD19 (WH/RD), harness side and ground. Is the resistance less than 5 ohms between the subwoofer amplifier and the audio unit, and greater than 10,000 ohms between the subwoofer amplifier and ground? Yes : GO to G7. No : REPAIR the circuit. TEST the system for normal operation.
G7 CHECK CIRCUIT 2-MD19 (GY/RD) Measure the resistance between the subwoofer amplifier C466a-8, circuit 2-MD19 (GY/RD), harness side and the audio unit C2253d-16, circuit 2-MD19 (GY/RD), harness side; and between the subwoofer amplifier C466a-8, circuit 2-MD19 (GY/RD), harness side and ground. Is the resistance less than 5 ohms between the subwoofer amplifier and the audio unit, and greater than 10,000 ohms between the subwoofer amplifier and ground? Yes : REMOVE the audio unit and SEND it to an authorized audio system repair facility. REFER to «AUDIO UNIT»(ref-207564-S25479398902005113000000) . TEST the system for normal operation. No : REPAIR the circuit. TEST the system for normal operation.
G8 CHECK THE ENABLE CIRCUIT FOR AN OPEN Key in OFF position. Disconnect: Audio Unit C2253d. Disconnect: Audio Amplifier C4208a. Measure the resistance between the subwoofer amplifier C466a-1, circuit 7-MD19 (YE/RD), harness side and the navigation audio unit C2253d-9, circuit 7-MD27 (YE/VT), harness side. Measure the resistance between the subwoofer amplifier C466a-1, circuit 7-MD19 (YE/RD), harness side and ground. Is the resistance less than 5 ohms subwoofer amplifier and the audio unit and greater than 10,000 ohms between the subwoofer amplifier and ground? Yes : REMOVE the subwoofer amplifier REFER to «SUBWOOFER AMPLIFIER»(ref-207564-S18117287212005113000000) . SEND it to an authorized audio system repair facility. TEST the system for normal operation. No : REPAIR circuit 7-MD19 (YE/RD) or 7-MD27 (YE/VT). TEST the system for normal operation.
G9 CHECK FOR AN AUDIO SIGNAL OUTPUT TO THE INOPERATIVE SUBWOOFER SPEAKER Disconnect: Inoperative Subwoofer Speaker. Key in ON position. For the LH subwoofer speaker, measure the voltage between the subwoofer speaker C4068-1, circuit 8-MD22 (WH/GN), harness side and C4068-2, circuit 10-MD22 (GY/OG), harness side. For the RH subwoofer speaker, measure the voltage between the subwoofer speaker C4069-1, circuit 8-MD21 (WH/BU), component side and C4069-2, circuit 10-MD21 (GY/VT), component side. Is there a fluctuating AC voltage? Yes : INSTALL a new subwoofer speaker. TEST the system for normal operation. No : GO to G10.
G10 CHECK AUDIO SIGNAL CIRCUITS FOR OPENS AND SHORTS TO GROUND Disconnect: Subwoofer Amplifier C466b. Measure the resistance between the inoperative subwoofer speaker and the subwoofer amplifier, and between the subwoofer amplifier and ground as follows: SUBWOOFER SPEAKER PIN REFERENCE Speaker Subwoofer Speaker Pin Subwoofer Amplifier Pin Circuit LH C4068 1 3 8-MD22 (WH/GN) LH C4068 2 4 10-MD22 (GY/OG) RH C4069 1 1 8-MD21 (WH/BU) RH C4069 2 2 10-MD21 (GY/VT) Is the resistance between the inoperative subwoofer speaker and the subwoofer amplifier less than 5 ohms, and greater than 10,000 ohms between the subwoofer amplifier and ground? Yes : REMOVE the subwoofer amplifier and send it to an authorized audio repair facility. REFER to «SUBWOOFER AMPLIFIER»(ref-207564-S18117287212005113000000) . TEST the system for normal operation. No : REPAIR the circuit. TEST the system for normal operation.

steering wheel control switches
audio unit
clock spring
circuit 8-MD26 (WH/BK) open or shorted to ground
circuit 31S-MD26 (BK/RD) open
powertrain control module (PCM)

Scheme 53

Scheme 53: PINPOINT TEST H: THE AUXILIARY AUDIO CONTROL IS INOPERATIVE/DOES NOT OPERATE CORRECTLY-STEERING WHEE

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

H1 CHECK THE STEERING WHEEL AUDIO CONTROL SWITCH RESISTANCES Key in OFF position. Disconnect: Audio Unit C290b (DM1 00i) (CDX6). Disconnect: Audio Unit C2253a (navigation audio unit). Key in ON position. While pressing the steering wheel control switches, measure the resistance between the audio unit, C290b-18, circuit 8-MD26 (WH/BK) harness side and the audio unit C290b-19 circuit 31S -MD26 (BK/RD), harness side; or between the navigation audio unit C2253a-18, circuit 8-MD26 (WH/BK), harness side and the audio unit C290b-19, circuit 31S-MD26 (BK/RD), harness side. SWITCH POSITIONS CHART Switch (DM100i/CDX6) Switch (navigation audio unit) Resistance Range VOL Down MEDIA 53.1-57 ohms VOL Up NEXT 145.3-151 ohms SEEK Up VOL Up 297.7-307 ohms SEEK Down VOL Down 556.1 -570 ohms MEDIA REPEAT 1,026.4-1,050 ohms Phone/Mute VOICE 2,016.4-2,060 ohms none none greater than 5,000 ohms Are the resistances within specifications? Yes : REMOVE the audio unit. REFER to «AUDIO UNIT»(ref-207564-S25479398902005113000000) . SEND it to an authorized audio system repair facility. TEST the system for normal operation. No : GO to H2.
H2 CHECK CIRCUIT 8-MD26 (WH/BK) FOR AN OPEN OR A SHORT TO GROUND NOTE: Before disconnecting the clockspring, remove the driver side air bag module. Refer to «AIR BAG RESTRAINT SYSTEMS»(ref-170294) . Disconnect: Clockspring C218b. Measure the resistance between the clockspring C218b-2, circuit 8- MD26 (WH/BK), harness side and ground; and between the clockspring C218b-2, circuit 8-MD26 (WH/BK), harness side and the audio unit as follows. CONNECTOR-PIN REFERENCE Audio Unit Connector-Pin Circuit CDX6/DM100i C290b-18 8-MD26 navigation audio unit C2253a-18 8-MD26 Is the resistance less than 5 ohms between the audio unit and the clockspring, and greater than 10,000 ohms between the audio unit and ground? Yes : GO to H3. No : REPAIR the circuit. TEST the system for normal operation.
H3 CHECK CIRCUIT 31S-PG1 (BK/BU) FOR AN OPEN OR A SHORT TO GROUND Disconnect: PCM C175b. Measure the resistance between the clockspring C218b-3, circuit 31S-PG1 (BK/BU), harness side and the audio unit C290b-19, circuit 31S-PG1 (BK/BU), harness side; and between the clockspring C218b-3, circuit 31S-PG1 (BK/BU), harness side and ground (CDX6). Measure the resistance between the clockspring C218b-3 circuit 31S-PG1 (BK/BU), harness side and the navigation audio unit C2253a-19, circuit 31S-PG1 (BK/BU), harness side; and between the clockspring C218b-3, circuit 31S-PG1 (BK/BU), harness side and ground Is the resistance less than 5 ohms between the clockspring and the audio unit and greater than 10,000 ohms between the clockspring and ground? Yes : GO to H4. No : REPAIR the circuit. TEST the system for normal operation. INSTALL the airbag. REFER to «AIR BAG RESTRAINT SYSTEMS»(ref-170294) .
H4 CHECK THE CLOCKSPRING Disconnect: Horn Switch C217. Measure the resistance between the clockspring C218b-2, component side and the horn switch C217-6, component side; and between the clockspring C218b-3, component side and the horn switch C217-3, component side. Are the resistances less than 5 ohms? Yes : GO to H5. No : INSTALL a new clockspring; REFER to «AIR BAG RESTRAINT SYSTEMS»(ref-170294) . TEST the system for normal operation.
H5 CHECK THE HORN SWITCH HARNESS Check the horn switch harness for opens and shorts. Is the horn switch harness OK? Yes : GO to H6. No : INSTALL a new horn switch harness; REFER to «INFORMATION, GAUGES & WARNING DEVICES»(ref-207563) . TEST the system for normal operation. INSTALL the air bag. REFER to «AIR BAG RESTRAINT SYSTEMS»(ref-170294) .
H6 CHECK THE CIRCUITS BETWEEN THE AUDIO UNIT AND THE CLOCKSPRING FOR SHORTS TO POWER Key in ON position. Measure the voltage between the audio unit C290b-18, circuit 8-MD26 (WH/BK), harness side and ground; and between C290b-19 circuit 31S-MD26 (BK/RD), harness side and ground (CDX6). Measure the voltage between the navigation audio unit C2253a-18, circuit 8-MD26 (WH/BK), harness side and ground; and between navigation audio unit C2253a-19, circuit 31S-MD26 (BK/RD), harness side and ground Is any voltage present? Yes : REPAIR the circuit in question. TEST the system for normal operation. INSTALL the air bag. REFER to «AIR BAG RESTRAINT SYSTEMS»(ref-170294) . No : GO to H7.
H7 CHECK THE CLOCKSPRING FOR SHORTS TO POWER Key in OFF position. Connect: Clockspring C218b. Key in ON position. Measure the voltage between the audio unit C290b-18, circuit 8-MD26 (WH/BK), harness side and ground; and between C290b-19, circuit 31S-MD26 (BK/RD), harness side and ground (CDX6). Measure the voltage between the navigation audio unit C2253a-18, circuit 8-MD26 (WH/BK), harness side and ground; and between navigation audio unit C2253a-19, circuit 31S-MD26 (BK/RD), harness side and ground. Is any voltage present? Yes : INSTALL a new clockspring. REFER to «AIR BAG RESTRAINT SYSTEMS»(ref-170294) . TEST the system for normal operation. INSTALL the air bag. REFER to «AIR BAG RESTRAINT SYSTEMS»(ref-170294) . No : GO to H8.
H8 CHECK THE CIRCUITS BETWEEN THE PCM AND THE AUDIO UNIT FOR SHORTS TO POWER Key in OFF position. Connect: PCM C175b. Key in ON position. Measure the voltage between the audio unit C290b-18, circuit 8-MD26 (WH/BK), harness side and ground; and between C290b-19, circuit 31S-MD26 (BK/RD), harness side and ground (CDX6). Measure the voltage between the navigation audio unit C2253a-18, circuit 8-MD26 (WH/BK), harness side and ground; and between navigation audio unit C2253a-19, circuit 31S-MD26 (BK/RD), harness side and ground. Is any voltage present? Yes : The PCM is suspect. REFER to ENGINE SYSTEM-GENERAL INFORMATION to continue diagnostics. INSTALL the air bag. REFER to «AIR BAG RESTRAINT SYSTEMS»(ref-170294) . No : INSTALL new steering wheel control switches and TEST the system for normal operation. REFER to «STEERING WHEEL AUDIO CONTROLS»(ref-207564-S39518417122005113000000) . INSTALL the airbag. REFER to «AIR BAG RESTRAINT SYSTEMS»(ref-170294) .

audio unit
circuit 7-MD19 (YE/RD) open, short to power, short to ground
subwoofer amplifier

Scheme 60

Scheme 60: PINPOINT TEST I: LOUD POPPING SOUND WHEN CYCLING THE IGNITION

Scheme 61

Scheme 62

Scheme 63

Scheme 64

I1 CHECK CIRCUIT 7-MD19 (YE/RD) FOR POWER Key in OFF position. Disconnect: Subwoofer Amplifier C466a. Key in ON position. NOTE: There should be voltage present when the ignition is in the ACC and ON positions, but not when the ignition is in the OFF position. Measure the voltage between the subwoofer amplifier C466a-1, circuit 7-MD19 (YE/RD), harness side and ground, while cycling the ignition from OFF to ACC to ON to ACC to OFF. Pause in the ACC and ON positions to allow for the audio unit to power up and initialize. Is the voltage present as expected? Yes : GO to I2. No : GO to I3 .
I2 SUBSTITUTE A SUBWOOFER AMPLIFIER Key in OFF position. Substitute a known good subwoofer amplifier. Cycle the ignition from OFF to ACC to ON to ACC to OFF. Is the popping eliminated? Yes : REMOVE the subwoofer amplifier and SEND it to an authorized audio system repair facility. REFER to «SUBWOOFER AMPLIFIER»(ref-207564-S18117287212005113000000) . TEST the system for normal operation. No : GO to I3.
I3 CHECK CIRCUIT 7-MD19 (YE-RD) FOR POWER WITHOUT AUDIO UNIT ON AND IGNITION OFF Key in OFF position. Disconnect: Audio Unit C290a (CDX6). Disconnect: Audio Unit C2253d (navigation audio unit). Measure the voltage between the subwoofer amplifier C466a-1, circuit 7-MD19 (YE/RD), harness side and ground. Is any voltage present? Yes : REPAIR the circuit. TEST the system for normal operation. No : GO to I4.
I4 CHECK THE ENABLE CIRCUIT TO THE SUBWOOFER AMPLIFIER For CDX6, Measure the resistance between the subwoofer amplifier C466-1, circuit 7-MD19 (YE/RD), harness side and the audio unit C290a-4, circuit 7-MD19 (YE/RD), harness side: and between the subwoofer amplifier C466-1, circuit 7-MD19 (YE/RD), harness side and ground. For navigation audio unit, measure the resistance between the subwoofer amplifier C466a-1, circuit 7-MD27 (YE/RD), harness side and the audio unit C2253d-9, circuit 10-MD27 (GY/WH), harness side: and between the subwoofer amplifier C466a-1, circuit 7-MD19 (YE/RD) harness side and ground. Is the resistance less than 5 ohms between the subwoofer amplifier and the audio unit, and greater than 10,000 ohms between the subwoofer amplifier and ground? Yes : GO to I5. No : REPAIR the circuit. TEST the system for normal operation.
I5 CHECK VOLTAGE ON ENABLE CIRCUIT WITH IGNITION ON Key in ON position. Measure the voltage between the subwoofer amplifier C466a-1, circuit 7-MD19 (YE/RD), harness side and ground. Is any voltage present? Yes : REPAIR the circuit. TEST the system for normal operation. No : REMOVE the audio unit and SEND it to an authorized audio system repair facility. REFER to «AUDIO UNIT»(ref-207564-S25479398902005113000000) . TEST the system for normal operation.

Material

Item	Specification
Rear Window Defroster Repair D8AZ-19562-AA or equivalent	WSB-M4J58-B

ITEM SPECIFICATIONS

Scheme 65

Scheme 66

Scheme 67

Bring the vehicle up to room temperature of at least 16°C (60°F) or above.
Clean the entire grid line repair area with a non-alcohol based window cleaner and 0000 steel wool.
Mark the location of the grid break on the exterior of the rear window glass.
Using cellulose tape, mask the area directly above and below the grid break. The break area should be at the center of the mask.
Apply the repair coating to the grid break area in several smooth, continuous strokes. Apply three applications of the grid repair compound.
After five minutes, or after the repair area has dried completely, remove the mask.
Remove any excess repair compound above or below the grid line with a razor blade.
After optimum hardness is achieved, clean the repaired area with a non-alcohol based window cleaner.

Antenna

Note. The antenna is a conductive trace integral to the rear window glass and can be repaired, but not installed separately. For removal and installation of the back glass, refer to EXTERIOR TRIM . For repair procedures, refer to ANTENNA GRID WIRE REPAIR .

Note. Antenna cable is not serviceable, it comes with the interior harness.

Scheme 68

Scheme 68: Antenna

Disconnect the battery ground cable.
Remove the LH and RH rear quarter panel trim panels. For additional information, refer to «INTERIOR TRIM»(ref-207570) .
Lower the rear of the headliner.
Remove the parts in the order indicated in the following illustration and table.
To install, reverse the removal procedure.

Scheme 69

Scheme 69: Audio Unit

Scheme 70

Disconnect the battery ground cable.
Remove the console finish panel. For additional information, refer to «INTERIOR TRIM»(ref-207570) .
Remove the parts in the order indicated in the following illustration and table.
To install, reverse the removal procedure.

Door Speaker

Note. The removal and installation procedures apply to all original equipment door-mounted speakers.

Scheme 71

Scheme 71: Door Speaker

Remove the door trim panel. For additional information, refer to «INTERIOR TRIM»(ref-207570) .
Remove the parts in the order indicated in the following illustration and table.
To install, reverse the removal procedure.

Scheme 72

Scheme 72: Subwoofer Amplifier

Disconnect the battery ground cable.
Remove the parts in the order indicated in the following illustration and table.
To install, reverse the removal procedure.

Scheme 73

Scheme 73: Audio Unit Amplifier - Center Imaging

Remove the driver side kick panel.
Remove the parts in the order indicated in the following illustration and table.
To install, reverse the removal procedure.

Scheme 74

Scheme 74: Removal and Installation

Disconnect the battery ground cable.
Remove the LH trunk trim panel. For additional information, refer to «INTERIOR TRIM»(ref-207570) .
Remove the parts in the order indicated in the following illustration and table.
To install, reverse the removal procedure.

Scheme 75

Scheme 75: Subwoofer Speaker

Remove the parcel shelf trim panel. For additional information, refer to «INTERIOR TRIM»(ref-207570) .
Remove the parts in the order indicated in the following illustration and table.
To install, reverse the removal procedure.

Scheme 76

Scheme 76: Steering Wheel Audio Controls

Remove the driver air bag module. For additional information, refer to «AIR BAG RESTRAINT SYSTEMS»(ref-170294) .
Remove the parts in the order indicated in the following illustration and table.
To install, reverse the removal procedure.

Entertainment System: Other Lincoln LS I рестайлинг
